Daewoo DSP-4280GM Manuel utilisateur
PLASMA DISPLAY
USER’S MANUAL
DAEWOO ELECTRONICS, LTD.
DSP-4280GM
DSP-4282GM
Proper use guarantees
product life.
Before using the product, be advised
that you read this owner’s manual well
and try to operate it.
- Product Warranty is included -
2
This Owner’s Manual presents safety precautions and how to use the product.
After reading it thoroughly, use the product safely.
Keep this manual where the user can see it easily.
Failure to comply with warnings and cautions for the safe use of electric
appliances may cause fire or human injury.
• 42” super-wide, 8 cm Ultra Slim Wall-mounting TV
SUMMUS PLASMA opens new TV era with advanced plasma technology – 8 cm ultra slim TV.
Light weight of only 30 Kg allows installing in narrow space.
• DVD Direct Connection / Outstanding Picture Quality Digital
Broadcasts Receive (SD Grade)
DVD can be directly connected so that you can view clear digital images, and by connecting digital
broadcasts connecting terminal with which digital broadcasts can be viewed, you can enjoy high quality
images. (When using digital broadcasting set-top box)
•
PC Direct Connection
PC can be connected to the PDP without separate device, and can be used as clear monitor so that the
effect of presentation gets maximized, making it popular in various events and exhibitions.
•
PDP TV with Minimized Noise
Up to now, although PDP TV had outstanding picture quality, there was problem with the noise by cooling
fan. SUMMAS PLASMA does not need cooling fan any more since it adopts air circulation method with
excellent heat transfer, eliminating the fan noise.
•
160o wide-Angle Viewing Area
•
Flat Panel with No Distortion and Color Blurring
Since Plasma TV has no problems such as distortion, blurring, flickering unlike with existing brown tube
type, you can enjoy Home Theater with super speaker.
•
Various Video Control
- 11 languages OSD - 10 step screen zooming function - full-screen still function
- Various aspect ratio (16:9, Panorama, Normal, Zoom2, Zoom1)
•
3 Way 6 Speaker Stereo Sound System
•
Worldwide : NTSC, PAL, SECAM / Free Volt (100-240V 50/60Hz)
Features
Features
FCC RF INTERFERENCE ST
FCC RF INTERFERENCE STA
ATEMENT
TEMENT
NOTE :
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of
the following measures.
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
- Consult the dealer or an experienced radio, TV technical for help.
- Only shielded interface cable should be used.
Finally, any changes or modifications to the equipment by the user not
expressly approved by the grantee or manufacturer could void the users
authority to operate such equipment,
Always obey all
safety messages.
•All the safety and
operating
instructions should
be read before the
product is operated.
If anything strange
happens, unplug
this product from
the wall outlet.
•Do not disassemble
or replace any parts
of the monitor.
Refer servicing to
qualified service
personnel.
Safety Precautions
4
WARNING
You can be killed
or seriously
injured if you don’t
follow instructions.
During a lightning storm, or when it is left
unattended and unused for long periods
of time, unplug it from the wall outlet.
It can result in fire.
When unplugging your monitor, always
grip plug firmly and pull straight out from
the receptacle.
It can result in fire or electric shock due to
damaged power cord.
This product must be properly grounded.
• Improper grounding may cause malfunction or
electric shock.
• When proper grounding is not possible, install
circuit breaker.
• Do not ground to gas pipe, water pipe, lightning
rod, and telephone line.
During a lightning storm, unplug the
monitor from the wall outlet, and do not
touch antenna.
It can cause fire or electric shock.
Power
Installation
Do not use this product in the
neighborhood of a bath or shower.
It can result in electric shock or fire.
Do not place this monitor on an unstable
cart, stand, or table
It may cause the product and cart to overturn,
damaging equipment or causing possible injury.
5
While Using Monitor
Do not open cover (or back) because
high voltage is present within the
monitor’s enclosure.
It may cause electric shock.
Never push objects of any kind into
this product through opening at the
back of monitor.
It may cause fire or electric shock.
No objects filled with liquids, such as
vases, shall be placed on the monitor.
Spilled liquids may cause electric shock or
fire.
Do not allow children to play or hang
on the monitor.
These actions may tip it over, causing
personal injury.
Do not place candle or lighted
cigarette on the monitor.
If these fall into the inside of the monitor, it
may cause fire or explosion.
Do not disassemble batteries, and
do not allow children to swallow
them.
Heavy metal may contaminate environment,
and can be harmful or detrimental to human
health. (When children swallow the
batteries, go to hospital and consult with
him.)
Do not pray water to the monitor or
wipe with damp cloth.
It may cause electric shock or fire.
Unplug the monitor from the wall
outlet when smoke or strange smell
occur, then refer servicing to service
personnel.
In the case of continuous use, it may cause
fire or electric shock.
Always obey all
safety messages.
• All the safety and
operating instructions
should be read before
the product is
operated.
Safety Precautions
6
Power
Installation
CAUTION
You can be injured
or this product or
any other your
property can be
damaged if you
don’t follow
instructions.
When moving your monitor, remove the
power plug, antenna, and cables, and be
sure to move it by more than two
persons.
Failure to follow this instruction can result in
electric shock or personal injury.
Do not touch the power plug with wet
hands when plugging or unplugging.
It can result in a risk of electric shock.
Do not install the product where it will be exposed to
the direct sunlight, and the product should not be
placed near heat sources such as radiators, stoves.
It may cause malfunction.
Do not install where there are oil, smog,
moist, and dust
It may cause malfunction.
For proper ventilation, separate the product
from the wall, which may prevent ventilation,
and keep distance more than 10cm.
Due to the increase of temperature inside the
Monitor, it may cause fire.
Do not place the monitor at the place
where ventilation is not ensured.
Due to the increase of temperature inside the
Monitor, it may cause fire.
If you wish to install this product on the
wall or ceiling, refer to the professional.
Failure to do so may cause damage to product
and injury to human.
When using an outside antenna system, do not
install it in the vicinity of overhead power lines.
When antenna touches such power lines, it may
cause electric shock.
77
During Use
CAUTION
You can be injured or this
product or any other your
property can be damaged if
you don’t follow
instructions.
Do not wipe the monitor using a
cloth damped with chemicals
(benzene, thinner, etc.).
Monitor appearance may be marred.
(Unplug the power plug and wipe with soft
cloth.)
Do not place the monitor near
magnetic, speakers, or telephones.
It can cause the color tone of the screen.
Do not place any object or cover on
the monitor.
In an event of improper ventilation,
temperature inside the monitor will rise up,
causing fire.
Do not place heavy objects or heat
sources on the power cord.
It may damage the power cord, causing fire
or electric shock.
When watching the TV, the distance
between Monitor screen and your
eye should be as 5~7 times as the
diagonal distance of the Monitor.
Watching the TV for a long time may hurt
your eye sight.
When cleaning of the inside of the
monitor is required, consult the
qualified service personnel.
When the monitor is not cleaned for a long
period of time, dust in it may cause fire or
malfunction.
When the monitor is placed on a cart
or table, the front side of the Monitor
should not project outward.
Unbalance may cause the monitor to drop,
resulting in personal injury or equipment
malfunction.
Do not grip speakers when moving
the monitor attached with speakers.
When moving them while gripping
speakers, speakers may be separated from
the monitor due to the weight of the monitor,
causing personal injury.
8
INPUT
SELECTPOWER
DISPLAY
ZOOM
-
MODESCREEN
MODE
FREEZE
MUTE
SOUND
MODESLEEP
ZOOM+
MENU
VOL VOL
Remote Control Batteries (AAA)
AC Cable PC(15pin) Cable
A/V Cable Audio Cable
Check to be sure the following items are
packed with your Monitor.
Checking Accessories
Supplied Accessories
9
The following items are optional accessories.
Refer the purchasing of the optional accessories to
the DaeWoo Electronics Local Dealer or the dealer
from whom you purchased.
(45 page)
Supplied Accessories
DSP-SP20/SP21/SP22
-
Speaker Main Unit
Dimension : 100(W) x 628(H) x 83(D)mm
-
Including Speaker Stand
Dimension : 170(W) x 729(H) x 194(D)mm
-
Audio Amplifier : 8W + 8W
-
Impedance : 8Ω
-
Weight : 7.5kg
DSP-ST20/ST21/ST22
-
Dimension : 667(W) x 238(H) x 320(D)mm
-
Weight : 7kg
DSP-HG10
•
Variable Angles : 0º, 10º, 15º, 20º
Speaker Main Unit
•
Dimension : 601(W) x 592(H) x 35(D) mm
Including Stand
•
Weight : 4.5 Kg
Wall Mounting Unit
Table Top Stand
Speakers
10
