800W Microwave

Model No. SDA2477

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

800W Microwave

Model No. SDA2477

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

READING AND STORING THE USER MANUAL

Before using this product, please read through this manual

carefully paying particular attention to the safety instructions.

Failure to do so may result in personal injury or damage to the

product.

Carefully save this instruction manual for future reference. Ensure the

user manual is included when passing the product on to any third

parties.

IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE

When using electrical appliances, basic safety precautions should

always be followed.

Only use the product as described in this user manual. Any other use is

considered improper and may result in damage to property or persons.

The manufacturer or vendor cannot be held liable for damages or injury

incurred through improper or incorrect use.

•Read and familiarise yourself with all operating

instructions before using this Microwave Oven.

•Before plugging your unit into the mains, visually check

that the unit is intact and has not suffered any transit

damage.

•Check that the voltage indicated on the data plate

corresponds with that of the local network before

connecting the appliance to the mains power supply.

•Close supervision is required when using this appliance

near children.

•This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if

they have been given supervision or instruction

concerning use of the appliance in a safe way and

understand the hazards involved. Children shall not play

with the appliance. Cleaning and user maintenance shall

not be made by children unless they are older than 8 and

supervised.

•Keep the appliance and its cord out of reach of children

less than 8 years.

800W Microwave

Model No. SDA2477

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

•DO NOT touch hot surfaces. The outer surfaces are

liable to get hot during use. Always use the handles

and knobs.

•DO NOT immerse the appliance or its cord in water or any

other liquids.

•DO NOT leave the appliance unattended during use.

•DO NOT leave the appliance unattended whilst connected

to the mains supply.

•Always use this appliance on a solid, level, non-flammable

surface.

•DO NOT use this appliance outdoors.

•DO NOT use this Microwave Oven with a programmer,

timer, separate remote-control system or any other

device that switches the appliance on automatically.

•It is imperative to unplug the power cord after the

appliance has been used, before it is cleaned and whilst

being repaired.

•Repairs to electrical appliances should only be performed

by qualified personnel. Improper repairs may place user at

serious risk.

•DO NOT operate this appliance with a damaged plug or

cord, after a malfunction or after being dropped or

damaged in any way.

•Regular, periodic checks should be carried out on the

mains cable to ensure no damage is evident. Should there

be any signs of damage the appliance should not be used.

•If the power cable is damaged, it should only be replaced

by suitable qualified personnel in order to avoid a hazard.

•DO NOT allow the mains cable to hang over sharp edges

or come in contact with hot surfaces.

•DO NOT run the mains cable under carpets, rugs, etc.

•Allow the unit to cool before storage.

•Before cleaning, disconnect the appliance from the mains

supply and allow to cool.

•This appliance is intended for household use only and

800W Microwave

Model No. SDA2477

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

should not be used for industrial purposes.

•DO NOT use any accessories or attachments with this

appliance other than those supplied or recommended by

supplier.

•DO NOT use this appliance for anything other than its

intended use.

•DO NOT push objects into any openings as damage to the

appliance and/or electric shock may occur.

•Ensure appliance is situated in an open area, do not allow

it to come in contact with Cupboards, Curtains, wall

coverings, clothing or other flammable materials.

•Unplug after each use. Grasp the plug, not the cord.

•CAUTION Do not overcook food.

•Metallic containers for food and beverages are not

allowed during microwave cooking.

•When heating food in plastic containers or paper

containers, keep an eye on the oven due to the possibility

of ignition.

•The contents of feeding bottles and baby food jars shall be

stirred or shaken and the temperature checked before

consumption, in order to avoid burns.

•This appliance shall not be cleaned with a steam cleaner.

•The microwave oven is intended to be used free-standing.

•DO NOT place this microwave into a cabinet.

•CAUTION Remove wire twists from paper and plastic bags

before placing in the oven.

•DO NOT heat oil or fat for deep frying in the oven as the

temperature of the fat can’t be controlled.

•After use wipe the waveguide cover with a damp cloth,

followed by a dry cloth to remove any food splashes and

grease. Built up grease may overheat and smoke or ignite.

•If materials inside the oven smoke or ignite, keep the door

closed, turn oven off and disconnect the power supply in

order to stifle any flames.

• WARNING! Liquids and other foods must not be

800W Microwave

Model No. SDA2477

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

heated in sealed containers since they are liable to

explode; Baby bottles fitted with a screw cap or teat are

considered sealed containers.

•Liquids should be heated in a wide mouthed container and

left for a short period after the heating cycle to avoid

possible hazards such as delayed eruptive boiling of the

liquid. Therefore, care must be taken when handling the

container.

•Potatoes, sausage and other skinned foods should be

pierced before heating.

•Eggs in their shell and whole hard-boiled eggs should not

be heated in microwave ovens since they may explode,

even after microwave heating has ended.

•Only use utensils suitable for use in a microwave oven.

•DO NOT store food or other items in the oven.

•DO NOT operate the oven without any food or liquid

inside, this may damage the oven.

• WARNING! If the door or door seals are damaged or if

the oven has malfunctioned, the oven must not be

operated until it has been repaired by a competent

person. It is hazardous for anybody other than a suitably

qualified person to carry out any service or repair that

involves the removal of a cover which gives protection

against exposure to microwave energy.

•This microwave oven is intended for the heating of food

and beverages. The drying of clothes, heating of warming

pads slippers, sponges and cloths may lead to risk of

injury, ignition and fire.

•The oven should be cleaned regularly and any food

deposit removed.

•Failure to maintain the oven in a clean condition could

lead to deterioration of the surface that could adversely

affect the life of the appliance and possibly result in a

hazardous situation.

800W Microwave

Model No. SDA2477

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

Installation

•Select a level surface no less than 85cm (33 inches) from the floor,

that provides enough space for the outlet vents.

•A minimum clearance of 5cm (2 inches) is required between the oven

and any adjacent wall, with a minimum clearance of 10cm (4 inches)

between the rear of the microwave and the wall.

•Leave a minimum clearance of 20cm (8 inches) above the oven

800W Microwave

Model No. SDA2477

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

Explanation of Symbols

The following warning symbols or words are used in this instruction manual:

Products labelled with UK Conformity Assessment identifies

products conforming to UK statutory requirements.

Products labelled with this symbol conform to applicable

provisions of the European Economic Area.

You should now recycle your waste electrical goods and in doing

so help the environment. This symbol means waste electrical

products at the end of their useful life should not be disposed of

with normal household waste and not sent to landfill. Please

ensure it is taken to a suitable facility for disposal. Check with

your Local Authority or retailer for recycling advice or visit

www.recycle-more.co.uk enter your postcode to find out your

nearest recycling site.

This symbol provides useful additional information on the

use of this product.

This symbol indicates that the supply uses an alternating current

mains supply.

This symbol indicates that the surface gets hot and care must be

taken.

WARNING!

This designates a hazard with moderate risk, which may

result in severe injury if not adhered to.

800W Microwave

Model No. SDA2477

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

1. Door Viewing Mirror window 6. Waveguide Cover

2. Door catches 7. Timer

3. Turntable 8. Function/Power Level

4. Motor Spindle 9. Door Open Button

5. Turntable Support Ring

Description of Parts

The door must be fully closed in order for the Microwave to operate. The door

operates a safety interlock mechanism which prevents the unit from operating

whilst the door is open.

WARNING! The waveguide cover (6) should never be removed.

800W Microwave

Model No. SDA2477

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

Timer (7)

The timer can be set up to 30 minutes, each

division around the scale represents I minute.

Once the cooking time has elapsed, a bell will

sound and the microwave oven will automatically

switch off.

Description of Parts –Control panel

The door of the microwave oven must be fully closed in

order for it to operate, this is due to a safety interlock between the

locking mechanism and the control panel.

Place the turntable ring in first, fit the turntable onto the rotating

turntable support and make sure it is geared in properly

Never remove the waveguide cover

Make sure the turntable support is correctly located

Function/Power Level (8)

There are six power levels as below:

Power Setting

Power Output

Suggested Use

LOW

17%

Keep Warm

DEFROST

37%

Defrost Food

M.LOW

40%

Drinks or Soup

MED

66%

Slow Cooking

M.HIGH

85%

Normal Cooking

HIGH

100%

Fast Cooking

800W Microwave

Model No. SDA2477

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

Using Your Microwave Oven

1.Place the Microwave Oven on a solid level, heat resistant surface, ensure that

the ventilation outlets are not obstructed.

2.Before first use press the Door Open Button (9) and place the Turntable

Support Ring (5) in the base of the oven as shown in the diagram above.

3.Place the glass Turntable (3) onto the Motor Spindle (4).

Rotate the Turntable a little until the notches in the turntable drop onto the

Motor Spindle (4).

4.Place the food to be cooked (in a suitable non-metallic container) onto the

glass Turntable (3).

5.Push the Door closed.

6.Ensure the Timer (7) is set to zero and insert the mains plug into the nearest

socket.

7.Set the desired power level using the Function/Power Level control (8) and

cooking time using the Timer (7).

8.The food will begin to cook, to check the food, look through the Door Viewing

Window (1).

Cooking will stop if the door is opened, cooking will resume when the door is

closed again.

9.Once cooking is complete a bell will sound, the oven and internal lamp will turn

off.

If the food is removed before the cooking time is complete, set the Timer (7)

to zero to prevent the oven operating whilst empty.

Utensils guideline

It is recommended that only utensils and containers marked safe for microwave

use should be used in this microwave oven. As a general rule a container made

from heat resistant ceramic, glass or plastic are suitable for microwave cooking.

Never use metal containers for microwave cooking.

Material

Microwave?

Comments

Heat resistant ceramic

Yes

Do not use ceramics that have a gilt or metal rim

Heat resistant plastic

Yes

Should not be used for extended cooking times

Heat resistant glass

Yes

Plastic film

Yes

Should not be used cooking meats as the higher

temperatures may damage the film

Grill rack

Metal items must not be used in the microwave

oven.

Metal containers

Metal items must not be used in the microwave

oven.

Lacquer

Poor heat resistance

Bamboo, wood, paper

Poor heat resistance and risk of ignition

Table des matières

Autres manuels Daewoo Four à micro-ondes

Daewoo

Daewoo KOG-3000SL Instructions de montage

Daewoo

Daewoo KOR-63DBM Instructions de montage

Daewoo

Daewoo KOR-63B5 Manuel utilisateur

Daewoo

Daewoo KOR-63X5 Manuel utilisateur

Daewoo

Daewoo KOR-63B5 Manuel utilisateur

Daewoo

Daewoo KOR-1B5H Instructions de montage

Daewoo

Daewoo KOC-910K0S01 Manuel utilisateur

Daewoo

Daewoo KOR-8A6K5SA7 Manuel utilisateur

Daewoo

Daewoo KQG-868G7S Instructions de montage

Daewoo

Daewoo KOT-123Q0A Manuel utilisateur

Daewoo

Daewoo KOG-1A0A Manuel utilisateur

Daewoo

Daewoo KOR-1A0A0P Manuel utilisateur

Daewoo

Daewoo KOR-161G2 Manuel utilisateur

Daewoo

Daewoo KOT-1H0SW Manuel utilisateur

Daewoo

Daewoo KOR-63D70S Manuel utilisateur

Daewoo

Daewoo KOG-392G Manuel utilisateur

Daewoo

Daewoo Video recorder Manuel utilisateur

Daewoo

Daewoo KOR-6L253S Instructions de montage

Daewoo

Daewoo KOG-39BG Manuel utilisateur

Daewoo

Daewoo KOR-6Q1B3A Instructions de montage

Daewoo

Daewoo KOR-220SDF Manuel utilisateur

Daewoo

Daewoo KOC-624Q Manuel utilisateur

Daewoo

Daewoo KOR-6C275S15 Manuel utilisateur

Daewoo

Daewoo KOG-6CAB5S Manuel utilisateur

Manuels Four à micro-ondes populaires d'autres marques

LG MH7040SS Manuel utilisateur

Sharp

Sharp R-895(AL)M Manuel utilisateur

Dometic

Dometic DOTRM13W Manuel utilisateur

Sanyo

Sanyo EM-X680 Manuel utilisateur

Sharp

Sharp R-393M Manuel utilisateur

KitchenAid

KitchenAid KMCX4510 Instructions d'installation

Smeg

Smeg S45MCX1 Manuel utilisateur

Russell Hobbs

Russell Hobbs RHM2044 Manuel utilisateur

Sunbeam

Sunbeam SMW759 Manuel utilisateur

Gallet

Gallet FMOE230S Manuel utilisateur

Bosch

Bosch CEG732X.1B Manuel utilisateur

Dometic

Dometic Roadmate 230 Manuel utilisateur

Samsung

Samsung SJ0396W Manuel utilisateur

Sanyo

Sanyo EM-P494WS Manuel utilisateur

Sharp

Sharp R-240 Manuel utilisateur

Electrolux

Electrolux EMS2840 Manuel utilisateur

Impecca

Impecca CM07M2 Manuel utilisateur

Sanyo

Sanyo EM-G5596V UK2 Manuel utilisateur
