Daewoo SDA2519 Manuel utilisateur

14.5L 1700W Air Fryer Oven

Model No. SDA2519

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

14.5L Air Fryer Oven

Model No. SDA2519

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

Contents

Page No.

2 Contents

3 Reading and Storing the User Manual

3 Important Safety Instructions for Proper Use

6 Additional Safety Information

7 Explanation of Symbols

7 Introduction

8 Description of Parts –Overview

8 Description of Parts –Control Panel

8 Description of Parts –Accessories

9 Description of Controls

10 Pre-set Cooking Chart

11 Before the First Use of Your Air Fryer Oven

11 Cooking with Your Air Fryer Oven

11 Cooking Using the Mesh Trays

13 Using the Rotisserie Skewer

15 Cleaning and Maintenance

16 Cooking Timings, Temperatures and Quantity

17 Troubleshooting Guide

18 Technical Specification

18 Plug Wiring Information

18 Recycling Information

19 Recipes for You to Try

21 Customer Support

Back Page Warranty Information

14.5L 1700W Air Fryer Oven

Model No. SDA2519

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

READING AND STORING THE USER MANUAL

Before using this product, please read through this

manual carefully paying particular attention to the

safety instructions. Failure to do so may result in

personal injury or damage to the product.

Carefully save this instruction manual for future reference.

Ensure the user manual is included when passing the product on

to any third parties.

IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE

Whilst using electrical appliances, basic safety precautions

should always be followed.

Only use the product as described in this user manual. Any other

use is considered improper and may result in damage to

property or persons.

The manufacturer or vendor cannot be held liable for damages

or injury incurred through improper or incorrect use.

•Read and familiarise yourself with all operating

instructions before using this Air Fryer Oven.

•Before plugging your unit into the mains, visually check

that it is intact and has not suffered any transit damage.

•Check that the voltage indicated on the data plate

corresponds with that of the local network before

connecting the appliance to the mains power supply.

•DO NOT use this product with a programmer, timer,

separate remote-control system or any other such device.

•DO NOT immerse this appliance in water or any other

liquids.

•Cooking appliances should be positioned in a stable

situation with the handles (if any) positioned to avoid

spillage of liquids.

•DO NOT touch hot surfaces. Accessible surfaces

are liable to get hot during use. Always use the

handles provided.

•Oven gloves should be used whilst using this appliance.

•Close supervision is required when using this appliance

near children.

14.5L Air Fryer Oven

Model No. SDA2519

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

•Never leave this appliance within reach of children.

•This appliance shall not be used by children from 0 to 8

years.

•This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if

they have been given supervision or instruction

concerning use of the appliance in a safe way and

understand the hazards involved.

•Children shall not play with the appliance.

•Keep the appliance and its cord out of reach of children

less than 8 years.

•Cleaning and user maintenance shall not be made by

children.

•DO NOT leave the appliance unattended during use.

•DO NOT leave the appliance unattended whilst connected

to the mains supply.

•Always use this appliance on a solid, level, non-flammable

surface.

•DO NOT use this appliance outdoors.

•It is imperative to unplug the power cord after the

appliance has been used, before it is cleaned and whilst

being repaired.

•Regular, periodic checks should be carried out on the

supply cord to ensure no damage is evident. Should there

be any signs of damage the appliance should not be used.

•If the supply cord is damaged it is to be replaced by a

qualified person in order to avoid a hazard.

•DO NOT operate this appliance with a damaged plug or

cord, after a malfunction or after being dropped or

damaged in any way.

•DO NOT allow the mains cable to hang over sharp edges

or come in contact with hot surfaces.

•Allow the unit to cool before storage.

•Never place the appliance near to flammable material or

14.5L 1700W Air Fryer Oven

Model No. SDA2519

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

high-pressure containers.

•This appliance is intended for household use only and

should not be used for industrial purposes.

•DO NOT use any accessories or attachments with this

appliance other than those supplied or recommended by

the supplier.

•DO NOT use this appliance for anything other than its

intended use.

•DO NOT push objects into any openings as damage to the

appliance and/or electric shock may occur.

•Ensure appliance is situated in an open area, do not allow

it to come in contact with cupboards, curtains, wall

coverings, clothing or other flammable materials.

•Unplug after each use. Grasp the plug, not the cord.

•DO NOT cover this appliance.

•Never place this appliance on an electric, gas, or any other

type of hob.

WARNING! Do not attempt to move the air fryer whilst

it is hot or contains hot food or liquids. Turn the

appliance off and disconnect from the mains and let it

cool sufficiently before moving it.

WARNING! Hot steam may be released when opening

and closing the appliance during use. Risk of scalding!

WARNING! Always carry the appliance with both

hands. Always use ovengloves. Burn hazard!

THIS APPLIANCE MUST BE EARTHED

14.5L Air Fryer Oven

Model No. SDA2519

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

Additional Safety Information

•PLEASE NOTE: Before use, ensure that the Air Fryer is

used in an open, well ventilated area well away from

other appliances and other obstructions.

•Do not use the Air Fryer in front of, near or below

combustible materials such as plastics, curtains or

cupboards, etc.

•Do not place the appliance against a wall or against other

appliances. Leave at least 10cm minimum free space on

the back and sides and 10cm minimum free space above

the appliance.

•Do not place anything on top of the appliance.

The diagram left shows the rear of the air

fryer and the air vent outlets arrowed.

Keep these areas free and clear from

obstructions and any flammable materials

or materials that may be affected by high

temperatures as directed above.

The vent should be at least 230mm (9

inches) away from any obstruction that

may restrict the free flow of air.

Please note that during normal use, hot air

will be expelled from the air vent outlet.

Before use, ensure that the spacer is fitted to

the back of the unit as shown above using the

two screws supplied as right:

The Spacer (21) ensures that the unit cannot be

positioned too close to the wall in order to

allow sufficient ventilation.

14.5L 1700W Air Fryer Oven

Model No. SDA2519

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

Explanation of Symbols

The following warning symbols or words are used in this instruction manual:

Products labelled with UK Conformity Assessment identifies

products conforming to UK statutory requirements.

Products labelled with this symbol conform to applicable

provisions of the European Economic Area.

You should now recycle your waste electrical goods and in doing

so help the environment. This symbol means waste electrical

products at the end of their useful life should not be disposed of

with normal household waste. Please ensure it is taken to a

suitable facility for disposal. Check with your Local Authority or

retailer for recycling advice or visit www.recycle-more.co.uk to

find your nearest recycling point.

WARNING!

This symbol provides useful additional information on the

use of this product.

This symbol indicates that the supply uses an alternating current

mains supply.

This symbol indicates that the surface is gets hot and care must

be taken.

Introduction

This Air Fryer Oven cooks using very little or no cooking oil for healthier cooking.

If a little oil is required for extra browning for example, use a moderate amount of

spray type cooking oil.

WARNING! DO NOT fill your Air Fryer Oven with cooking oil as this will

cause a fire and scolding hazard.

WARNING! DO NOT fill your Air Fryer Oven with water as this will cause

a scolding hazard.

The Air Fryer Oven will quickly cook your food using a rapid cycling airflow of hot

air.

This designates a hazard with moderate risk, which may

result in severe injury if not adhered to.

14.5L Air Fryer Oven

Model No. SDA2519

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

Description of Parts - Overview

Description of Parts –Control Panel

Description of Parts –Accessories

1.Control Dial

2.Control Panel

3.Door Handle

4.Door

5.Viewing Window

6.Non-Slip Feet

7.Air Vent Outlet (Rear)

8.Timer Display

9.Rotisserie Function

10.Internal Light

11.Set Timer

12.Set Temperature

13.Grill Function

14.Oven Function

15.Temperature Display

16.Power Button

17.Drip Tray

18.Rotisserie Skewer Tongs

19.Rotisserie Skewer

20.Mesh Tray x3

21.Spacer

14.5L 1700W Air Fryer Oven

Model No. SDA2519

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

Description of Controls

Timer Display (8)

The display shows the current/set time and the remaining cooking time.

Temperature Display (15)

The display shows the current/set temperature.

Control Dial (1)

Rotate the Control Dial (1) to select one of the 12 cooking pre-sets.

Press the Control Dial (1) to start cooking.

Press the Control Dial (1) to pause during cooking, the fan will continue to run for

1 minute, press again to continue.

The Control Dial (1) will illuminate red whilst cooking.

The Control Dial (1) will illuminate blue when NOT cooking.

Set Timer (11)

•The timer is set in 1 minute increments up to 120 minutes.

•In Dehydrating mode, the Timer is set in 10 minutes increments up to 8 hours.

•Press the Set Timer button (11) and rotate the Control Dial (1) to increase or

decrease the cooking time.

Set Temperature (12)

•The temperature is set in 10°C increments from 40°C to 230°C.

•In Dehydrating mode, the temperature is set in 5°C increments from 50°C to

70°C.

•Press the Set Temperature button (12) and rotate the Control Dial (1) to

increase or decrease the cooking temperature.

Cooking Pre-sets

•Rotate the Control Dial (1) to select one of the 12 pre-set cooking programs

from the Pre-set Cooking Chart below.

•The time and cooking temperature will be automatically set.

•Once a pre-set has been selected, press either the Control Dial (1) or the Power

Button (16) to start cooking. The Internal Light (10) will stay on for 1 minute.

•Alternatively, the pre-set cooking programs can be overridden by pressing the

Set Time and Set Temperature buttons (11 & 12) and rotating the Control Dial

(1) accordingly. The Grill Function (13) and Oven Function (14) can also be

selected as desired.

14.5L Air Fryer Oven

Model No. SDA2519

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

Rotisserie Function (9)

Press the Rotisserie Function (9) button to start and stop the Rotisserie Skewer

(19) rotating.

Internal Light (10)

Press the Internal Light (10) button to operate the internal light to help check the

cooking progress through the Viewing Window (5).

The light indicator will keep flashing whilst the internal light is on.

Opening the Door (4) will pause cooking and the internal light will switch on.

Grill Function (13)

Press the Grill Function (13) button will override pre-set programs and power up

the top heating element only. This is the default setting for the Streaky Pork,

Chicken, Dehydrate and Kebab pre-set programs.

Oven Function (14)

Press the Oven Function (14) button will override pre-set programs and power up

both the top and bottom heating elements. This is the default setting for all the

pre-sets programs except Streaky Pork, Chicken, Dehydrate and Kebab.

Power Button (16)

Press the Power Button (16) to start cooking.

To stop cooking, press the Power Button (16) once, the Timer and Temperature

Displays (8 & 15) will show zero, the fan will continue to run for 1 minute to cool

the appliance down then the unit will switch off.

Pre-set Cooking Chart

Pre-set

Temperature

Cooking Time

Bake

160°C

40 minutes

Streaky Pork

180°C

20 minutes

Fries

220°C

20 minutes

Wings

200°C

15 minutes

Chicken

220°C

35 minutes

Shrimp

180°C

12 minutes

Grill

220°C

12 minutes

Dehydrate

70°C

8 hours

Kebab

200°C

20 minutes

Pizza

180°C

10 minutes

Toast

220°C

8 minutes

Defrost

80°C

10 minutes

Table des matières

Autres manuels Daewoo Friteuse

Daewoo

Daewoo DHFRYER Manuel utilisateur

Daewoo

Daewoo SDA2310 Manuel utilisateur

Daewoo

Daewoo HEA1032 Manuel utilisateur

Daewoo

Daewoo SDA1861 Manuel utilisateur

Daewoo

Daewoo SDA2616 Manuel utilisateur

Daewoo

Daewoo ACTUATE SDA2622 Manuel utilisateur

Daewoo

Daewoo SDA2488 Manuel utilisateur

Daewoo

Daewoo SDA2518 Manuel utilisateur

Daewoo

Daewoo SDA1551 Manuel utilisateur

Daewoo

Daewoo SDA2310 Manuel utilisateur

Daewoo

Daewoo SDA1804 Manuel utilisateur

Daewoo

Daewoo SDA1032 Manuel utilisateur

Daewoo

Daewoo SDA1032 Manuel utilisateur

Daewoo

Daewoo SDA1032 Manuel utilisateur

Daewoo

Daewoo DK2FRYER Manuel utilisateur

Daewoo

Daewoo SDA1551 Manuel utilisateur

Daewoo

Daewoo SDA2314 Manuel utilisateur

Daewoo

Daewoo SDA2310 Manuel utilisateur

Daewoo

Daewoo SDA2609 Manuel utilisateur

Daewoo

Daewoo SDA1601 Manuel utilisateur

Daewoo

Daewoo SDA2324 Manuel utilisateur

Daewoo

Daewoo SDA1553 Manuel utilisateur

Daewoo

Daewoo HEALTHY LIVING SDA1599 Manuel utilisateur

Manuels Friteuse populaires d'autres marques

Innsky

Innsky 55SA1US Manuel utilisateur

Falcon

Falcon G350/11 Guide de l'utilisateur

GoWISE USA

GoWISE USA GW22612 Manuel utilisateur

Wolf

Wolf IF15/S Manuel utilisateur

Electrolux

Electrolux Thermetic 9CHG583284 Guide rapide

Gourmia

Gourmia GAF799 Manuel utilisateur

DeLonghi

DeLonghi D677UX Manuel utilisateur

SEVERIN

SEVERIN DEEP FRYER - Guide de l'utilisateur

Toastmaster

Toastmaster TMFG18-NAT Manuel utilisateur

Domo

Domo DO465FR Manuel utilisateur

Henny Penny

Henny Penny PFG-691 Manuel utilisateur

Farberware

Farberware FBW FT 43721 B Manuel utilisateur

GERMANICA

GERMANICA GEAF5L3LD Manuel utilisateur

Roller Grill

Roller Grill MF 120 R Manuel d'utilisation

Philips

Philips HD9211 Manuel utilisateur

Linea 2000

Linea 2000 Domo DO536FR Manuel utilisateur

Lakeland

Lakeland 31796 Manuel utilisateur

Dash

Dash Tasti-Crisp DFAF755 Manuel utilisateur
