DAEWOO ELECTRONICS DWD-L1212 Manuel utilisateur

Service Manual

Drum Washing Machine

Model: DWD-L1212

Oct. 2009

✔ Caution

: In this Manual, some parts can be changed for improving, their

performance without notice in the parts list. So, if you need the

latest parts information, please refer to PPL(Parts Price List) in

Service Information Center (http://svc.dwe.co.kr).

S/M No. :

2. WASHER SpECIfICATIoN

1. Product Specification

■1st Model ■2st Model

MODEL DWC-LU1011/1211DWD-L1212

Dimension (mm) 600 X 645 X 850

Maximum mass of textile (kg) 9 Kg

Unit Weight (net/gross) 78/82 71/75

Standard Water Consumption 65 ℓ

Spin Speed (RPM) DWC(DWD)-LU10XX : MAX 1000

DWC(DWD)-LU12XX : MAX 1200

DWC(DWD)-LD14XX : MAX 1400

DWC(DWD)-LD16XX : MAX 1600

Operating Water Pressure 0.03MPa ~ 0.8MPa (0.3kgf/cm2~ 8kgf/cm2)

1. pANEl AS

3. pARTS LIST by ASS'y

A03

A02

A22

A21

A19

A20

A15

A14

A11

A09

A16

A18

A17

A01

A04

A05

A06

A07

A08

A10

A12

A13

■ 1st Model

No. PARTS NAME CODE SPECIFICATIONS Q’TY REMARK

A01 pANEl *f 36142T2000 AbS 1

A02 DECoRAToR WINDoW CoURSE 3611696000 AbS 1

A03 WINDoW CoURSE 3615509200 C-LU1011 1

A04 DECoRAToR WINDoW DISplAy 3611696100 AbS 1

A05 bUTToN fUNCTIoN 3616644000 AbS 1

A06 bUTToN pS 3616644100 AbS 1

A07 WINDoW DISplAy 3615509300 C-LU1011 1

A08 bUTToN lED 3616644200 C-LU1011 1

A09 pCb boARD 3614347000 l SERIES fRoNT pCb boARD 1

A10 CUSToM lED 3613058300 C-LU1011 1

A11 lED lAMp DS0302WP-- 9MM foRMING TypE , D=3MM 36

A12 SW TACT 5S50101402 2pIN, 6*6*5 9

A13 HolDER lED opTIoN 3613058000 HIpS 1

A14 HolDER lED fUNCTIoN 3613058100 HIpS 1

A15 HolDER lED CoURSE 3613058200 HIpS 1

A16 CASE pCb f 36111T1N00 HIpS 1

A17 bUTToN DIAl oUTER 3616643800 AbS 1

A18 bUTToN DIAl INNER 3616643900 AbS 1

A19 CASE DETERGENT 36111T1J00 pp 1

A20 CAp SofTENER 3610916600 pp 1

A21 CASE HANDlE 3611149200 AbS 1

A22 DECoRAToR CASE HANDlE 3611696200 AbS 1



PCB AS:



PRPSSWL001

PEDIR PCB AS

B01

B02

B03

B05

B04

B08

B07

B06

B10

B09

B11

B12

B13

B14

3. INlET boX AS

No. PARTS NAME CODE SPECIFICATIONS Q’TY REMARK

b01 NoZZlE *T 3618111100 pp 1

b02 NoZZlE *U 3618111000 pp 1

b03 boX INlET 3610526500 pp 1

b04 HoSE INlET 3613274600 EpDM 1

b05 ClAMp AS 3611203200 ID=60, WIRE+GUIDE+bolT+NUT 1

b06 VAlVE INlET 3615416820220-240V.VDE.BITRON. 1

b07 HoSE WATER SUpply 3613268900 EpDM ID9.5 oD14.5, WASHING 1

b08 HoSE WATER SUpply

3613268900

EpDM ID9.5 oD14.5, pRE.WASH 2

b09 ClAMp HoSE 3611205800 100H, ID=13.8 W=10.0 0.9T 10

b10 VAlVE INlET

3615414820

220-240V,1-WAY HOT PP 1

b11 HoSE WATER SUpply

3613268900

EpDM ID9.5 oD14.5, HoT 1

b12 HoSE WATER SUpply 3613270900 EpDM ID9.5 oD14.5, STEAM 1

b13 pIpE JoINT I 3614426000 pp 1

b14 Unit Steam AS 36189M2U00 L-SERIES STEAM UNIT 900W 1option

NO DISPONIBLE PARA ESTE MODELO

4. CAbINET f ASSy

C12

C01

C02

C03

C14

C15

C06

C07

C04

C05

C11

C08

C09

C10

C13

■ 1st Model

No. PARTS NAME CODE SPECIFICATIONS Q’TY REMARK

C01 CAbINET *f 3610814000 SECD 0.8T 1

C02 SWITCH DooR loCK 3619047200 DL-S1.250V16A.BITRON 1

C03 plATE HINGE SUppoRT 3614539800 SPG 0.8T, DWD-T110R 1

C04 fRAME DooR *o 36122UD800 AbS 1

C05 pRoTECToR GlASS 3618345500 AbS 1

C06 DECoRAToR DooR *o 3611695900 AbS 1

C07 HooK DooR 3613100900 ZNDC 1

C08 SpRING HooK 3615115400 SUS304, 1

C09 HooK SHAfT 3613101000 SUS, D=3.0 1

C10 fRAME DooR *I 36122UD600 pp 1

C11 HINGE DooR 3612903800 AL, DWD-T110R 1

C12 CAp HINGE DooR 3610916500 poM 4

C13 DooR GlASS 361A113300 GlASS 1

C14 CASE pUMp 36111T1K00 pp 1

C15 CoVER pUMp 3611431500 AbS 1

DOOR AS: 

36117ACE01



PUERTA 

COMPLETA

6. TUb ASSy(UNIVERSAl)

D26

D23

D22

D25

D24

D20

D18

D17

D19

D16

D15

D10

D21

D11

D04

D07

D05

D06

D08

D03

D01

D02 D43

D32

D46

D38

D45

D50

D47

D48

D49

D36

D35

D37

D40

D28

D30

D27

D29 D31

D34

D09

D13

D14

D12

D44

D42

D41

D33

D39

No. PARTS NAME CODE SPECIFICATIONS Q’TY REMARK

D01 bAlANCER WEIGHT l 3616110600 PP, D-LU1011, 6.6KG 1

D02 SpECIAl SCREW 3616029400 SWCH 8.5X30 8

D03 bAlANCER WEIGHT R 3616110500 PP, D-LU1011, 6.6KG 1

D04 ClAMp GASKET AS

3611207000

C-LU1011 1

D05 GASKET 3612325300 EPDM , WASH , D-LU1011 1

foR WASH

D06 GASKET 3612325400 EPDM , DRY , C-LU1011 1foR DRy

D07 NoZZlE SHoWER 3618111200 pp 1

D08 ClAMp GASKET bUSHING 3611206800

GI 1.2T

1foR DRy

D09 SpECIAl SCREW 3616029810 SWCH 6.5X45 4

D10 DUCT b AS 3610DUTl00 C-L E 1foR DRy

D11 HoSE DRAIN *I 3613275200 EPDM D-LU1011 1

D12 ClAMp AS 3611203200 ID=61, WIRE+GUIDE+bolT, GS 1

D13 ClAMp HoSE 3611204700 D26 1

D14 ClAMp HoSE 3611201400HSW3,yW,D2.6,ID36,W44.5 1

D15 AIR TRAp 361A500101 pp 1

D16 HoSE AIR(pRESSURE) 3613266930 ID=4,OD=8, L=680MM(L-SERIES) 1

D17 DAMpER fRICTIoN 361A700110

70N AKS ST=170-260 DL=197.5 LOW NOISE

D18 DAMpER pIN 361A700200 AKS D=14.5 2

D19 TUb fRoNT 3618830000 FRPP, C-LU1011 1

D20 SpRING SUSpENSIoN 3615116800 KGf 2

D21 SpECIAl SCREW 3616029800 SWCH 6.5X30 14

D22 SpECIAl SCREW 3616029500 SUS430 8*25 3

D23 lIfTER WASH 361A401300 pp,1pIECE,TWIST 3

D24 SCREW TAppING 7122401408 T2S TRS 4X14 SUS,STS 3

D25 DRUM AS 3617012600 D-LU1011 1

D26 SpIDER AS 361A301200 D-LU1011 1

D27 WATER SEAl 361A600100 NbR 1

D28 SEAlING TUb 3612321600EPDM L1600(-0~ +10) 1

D29 fIXTURE HEATER 3612006700 SUS 1

D30 bEARING INNER 3616303100 6206Z 1

D31 UNIT MoToR UNIVERSAl 36189l4H00DC220/50 G&J 2p pI340 45T(CCA) 1

D32 bAlANCER WEIGHT loWER 3616110300 PP, D-LU1011, 3.5KG 1

D33 SpECIAl SCREW 3616029400 SWCH 8.5X30 2

D34 SpECIAl SCREW 3616062800 SWRCH18A 7.4*25.5 2

D35 DAMpER fRICTIoN 361A700130

60N AKS ST=170-260 DL=197.5 LOW NOISE

D36 DAMpER pIN 361A700200 AKS D=14.5 2

D37 TUb REAR AS 36100T1400 D-LU1011 1

D38 bAlANCER WEIGHT T 3616110400 PP, C-LU1011, 2.48KG 1foR DRy

D39 bAlANCER WEIGHT T(WASH) 3616110700 PP, D-LU1011, 2.48KG 1

foR WASH

D40 SpECIAl SCREW 3616029400 SWCH 8.5X30 2

D41 ClAMp HoSE 3611204700 D26 1

D42 SpECIAl SCREW 3616007400 T2S TRS 4X10+24 2opTIoN

D43 UNIT bUbblE pUMp AS 36189l4120 220-240V DBK-240DB RP CHSHION 1opTIoN

D44 HoSE VENT 3613267100 EpDM 1

D45 bEARING oUTER 3616303200 6205Z 1

D46 HEATER WASH 3612803700 230V 2000W.1R5A721002.IRCA fUSE 2EA 1

D47 pIpE DUCT AS 3614414001 C-L PIPE DUCT+HOSE+CLAMP 1foR DRy

D48 pUllEy 3618434100 AlDC 1

D49 SpECIAl bolT AS 3616029600 SWCH 10*30,f/l bolT S.p/W SEAl loCK 1

D50 bElT V 3616591120 GATES 4pJ1175 bUTADIENE RUbbER 1

NO DISPONIBLE PARA ESTE MODELO

NO DISPONIBLE 

PARA ESTE

NO DISPONIBLE

NO DISPONIBLE 

PARA ESTRE

NO DISPON PARA ESTRE MODELO

NO DISPONIBLE

GASKET AS: 3612325301
