D-Link Wireless VPN Router DI-824VUP Manuel utilisateur

High-Speed Enhanced 2.4 GHz

Manual

Wireless VPN Router

Building Networks for People

10/11/04

DI-824VUP

AirPlus Xtreme G

D-Link

Contents

PackageContents ................................................................................3

Introduction............................................................................................4

Wireless Basics....................................................................................6

GettingStarted......................................................................................9

UsingtheConfigurationMenu..............................................................11

NetworkingBasics ..............................................................................69

ResettoFactory Default Settings ........................................................98

TechnicalSpecifications ......................................................................99

FrequentlyAskedQuestions..............................................................100

ContactingTechnicalSupport ............................................................153

Warranty............................................................................................154

Registration ......................................................................................157

InstallingthePrintServerSoftware ......................................................65

ConfiguringonWindows 98se/Me Platforms .......................................67

Contents of Package:

D-Link AirPlus Xtreme G DI-824VUP High-Speed Enhanced

2.4GHz Wireless VPN Router

PowerAdapter – 5V DC / 2.5A

ManualonCD

QuickInstallationGuide

Package Contents

Note:Usingapowersupplywithadifferentvoltageratingthantheoneincluded with the

DI-824VUPwillcausedamageandvoidthewarranty for this product.

If any of the above items are missing, please contact your reseller.

System Requirements For Configuration:



Computer with Windows, Macintosh, or Linux-based

operating system with an installed Ethernet adapter



Internet Explorer version 6.0 or Netscape Navigator

version 6.0 and above, with JavaScript enabled



Ethernet-Based Cable or DSL Modem



Introduction

The D-Link AirPlus Xtreme G DI-824VUP Wireless Broadband Router is an

802.11g high performance, wireless router with two printer ports, one parallel

and one USB. It is an ideal way to extend the reach and number of computers

connected to your wireless network.

Unlikemost802.11grouters, the DI-824VUPiscapable ofdata transferspeeds

up to 54 Mbps*(compared to the standard 11 Mbps) when used with other D-

Link AirPlus Xtreme G products such as the DWL-G650 and DWL-G520

Wireless Adapters.

After completing the steps outlined in the Quick Installation Guide (included in

your package) you will have the ability to share information and resources, as

well as share a printer wirelessly on your network.

The DI-824VUP is compatible with most popular operating systems, including

Macintosh, Linux and Windows, and can be integrated into a large network.

This Manual is designed to help you connect the Router and D-Link AirPlus

2.4GHz Wireless Adapters into a network in Infrastructure mode. Please take

a look at the Getting Started section in this manual to see an example of an

Infrastructure networkusing the DI-824VUP.

Connections

DHCPserversupportenablesallnetworkedcomputerstoautomatically

receiveIP addresses

Wireless connection of up to 54Mbps

Web-basedinterface forManagement

Access Control to manage users on the network

Maximumreliability, throughputand connectivity withautomatic data rate

switching

Strongernetworksecuritywith256-bitencryption

Printerportenablesconnectiontoa network printer

ConnectsmultiplecomputerstoanEthernetBroadband(CableorDSL)

modemtosharetheInternetconnection



SupportsVPNpass-through, providing addedsecurity



AdvancedFirewallfeatures foraddednetworksecurity



Features & Benefits



Note: Please refer to the Resetting the DI-824VUP to the Factory

Defualt Settings section in this manual for instructions on how to use

the Reset button.

WANandLANportsauto detect cable types (straight-through or cross-over)



UPnPsupported



LAN ports provide

connections to Ethernet-

enabled devices.

Pressing the

Reset Button

restores the

router to its

original factory

default settings.

All ports (both LAN and WAN)

auto-sense cable types to

accomodate straight-through or

cross-over cable.

Receptor

for the

Power

Adapter.

WAN port is the connection

for the Ethernet cable to the

Cable or DSL modem.

COM port provides serial

connection for a backup

analog dial-up modem.

The LPT port or USB port is

used to connect to your local

printer.

LEDS

LED stands for Light-Emitting Diode. The DI-824VUP has the following LEDs

as described below:

LED LED Activity

Power A steady light indicates

a connection to a power source

WAN A solid light indicates connection on the

WAN port. This LED blinks during data

transmission

WLAN A blinking light indicates that the wireless

segment is ready. This LED blinks during

wirelessdatatransmission.

D-Link AirPlus wireless products are based on industry standards to provide easy-to-

use and compatible high-speed wireless connectivity within your home, business, or

public access wireless networks. Strictly adhering to the IEEE standard, the D-Link

AirPlus wireless family of products will allow you to securely access the data you want,

whenandwhereyouwantit.Youwillbeabletoenjoythefreedomthatwirelessnetworking

delivers.

Awirelesslocal area network (WLAN) is acellular computer networkthat transmitsand

receives data with radio signals instead of wires. Wireless LANs are used increasingly

inboth home and office environments,and publicareas suchasairports,coffeeshops,

anduniversities.Innovativewaysto utilize WLAN technology are helping peopletowork

and communicate more efficiently. Increased mobility and the absence of cabling and

otherfixedinfrastructurehave proven to be beneficial for many users.

Wireless Basics

Flashes once per second to indicate the

unitisworkingproperly

LOCAL

NETWORK

(Ports1-4)

A solid light indicates a connection to an

Ethernet-enabledcomputeronports 1-4. This

LED blinks during data transmission.

Status

USB

COM

A steady light indicates a connection to a USB

printer.

A steady light indicates a connection to a back-

updial-upmodem.

LPT A steady light indicates a connection to a

parallelprinterport

Wireless Basics

Wireless users can use the same applications they use on a wired network.

Wireless adapter cards used on laptop and desktop systems support the same

protocols as Ethernet adapter cards.

Under many circumstances, it may be desirable for mobile network devices to

linktoaconventionalEthernetLAN inordertouseservers,printers,oranInternet

connectionsuppliedthrough the wiredLAN.AWireless Routerisa device used

to provide this link.

People use wireless LAN technology for many different purposes:

Mobility - Productivity increases when people have access to data in any

locationwithinthe operatingrangeof theWLAN.Management decisionsbased

on real-time information can significantly improve worker efficiency.

Low Implementation Costs – WLANs (Wireless LocalArea Networks) are

easyto setup, manage,change, andrelocate. Networksthatfrequentlychange,

both physically and logically, can benefit from WLANs ease of implementation.

WLANscanoperate inlocationswhere installationofwiring maybe impractical.

Installation Speed and Simplicity - Installing a wireless LAN system can

befast, easy,and caneliminate theneed topull cablethrough wallsand ceilings.

Network Expansion - Wireless technology allows the network to go where

wires cannot.

Scalability – Wireless LocalArea Networks (WLANs) can be configured in a

variety of topologies to meet the needs of specific applications or existing

infrastructure. Configurations are easily changed and range from peer-to-peer

networks suitable for a small number of users to larger infrastructure networks

to accommodate hundreds or thousands of users, depending on the number

of wireless devices deployed.

Wireless Basics

The DI-824VUP is compatible with other D-Link AirPlus Xtreme G 802.11g

products, which include:

♦Enhanced 2.4GHz Wireless Cardbus Adapters used with laptop

computers (DWL-G650)

♦Enhanced 2.4GHz Wireless PCI cards used with desktop computers

(DWL-G520)

Installation Considerations

TheD-LinkAirPlusXtremeG+ DI-824VUPletsyouaccess your network,using

a wireless connection, from virtually anywhere. Keep in mind, however, that

the number, thickness, and location of walls, ceilings, or other objects that the

wireless signals must pass through may limit the range. Typical ranges vary

dependingon thetypesofmaterialsandbackgroundRF(radiofrequency) noise

in your home or business. The key to maximizing wireless range is to follow

these basic guidelines:

1. Keep the number of walls and ceilings between the DI-824VUP and

your receiving device (e.g., the DWL-G650) to a minimum-each wall or

ceiling can reduce your D-Link AirPlus wireless product’s range from 3-90

feet (1-30 meters.) Position your receiving devices so that the number of

walls or ceilings is minimized.

2. Be aware of the direct line between routers and computers. A wall that is

1.5 feet thick (.5 meters), at a 45-degree angle appears to be almost 3 feet

(1 meter) thick.At a 2-degree angle it looks over 42 feet (14 meters) thick!

Try to make sure that devices are positioned so that the signal will travel

straight through a wall or ceiling for better reception.

3. Building Materials make a difference - a solid metal door or aluminum

studs may have a negative effect on range. Try to position wireless

devices and computers with wireless adapters so that the signal passes

through drywall or open doorways and not other materials.

4. Keep your product away (at least 3-6 feet or 1-2 meters) from electrical

devices or appliances that generate RF noise.

Based on the IEEE 802.11g standard, the DI-824VUP is interoperable with

existing compatible 2.4GHz wireless technology with data transfer speeds of

up to 54Mbps (with the D-Link AirPlus Xtreme G family of wireless devices,) as

wellasstandard802.11btechnology( theD-LinkAirfamilyof wirelessdevices),

with speeds of up to 11Mbps.

Standards-Based Technology

With a single IPAddress from your Broadband Internet Service provider you

can share the Internet with all the computers on your local network, without

sacrificing speed or security, using D-Link Air networking products.

Getting Started

An Infrastructure wireless network contains an Access Point. The

Infrastructure Network example, shown here, contains the following D-Link

network devices:

A wireless Broadband Router -

D-Link AirPlus Xtreme G DI-824VUP

A laptop computer with a wireless adapter -

D-Link AirPlus Xtreme G DWL-G650

A desktop computer with a wireless adapter -

D-Link AirPlus Xtreme G DWL-G520

A Cable modem -

D-Link DCM-201

Ifyouneed to assign IPAddresses tothecomputers on thenetwork,please

remember that the IP Address for each computer must be in the same

IP Address range as all the computers in the network, and the Subnet

Mask must be exactly the same for all the computers in the network.

For example: If the first computer is assigned an IPAddress of 192.168.0.2

with a Subnet Mask of 255.255.255.0, then the second computer can be

assignedanIPAddressof192.168.0.3withaSubnetMaskof255.255.255.0,

etc.

IMPORTANT: If computers or other devices are assigned the same IP

Address, one or more of the devices may not function properly on

the network.

IP ADDRESS

With its default settings, the DI-824VUP will connect with other

D-Link Air or AirPlus products, right out of the box.

Note: If you are using a DHCP-capable router in your network setup, such

as the DI-824VUP, you will not need to assign a static IPAddress.

Pleaseremember that D-Link AirPlus wirelessdevices are pre-configured toconnect

together, right out of the box, with their default settings.

Getting Started

Pleaserefertothefollowing

sections of this manual for

additionalinformationabout

setting up a network:

Networking Basics -learn

how to check and assign

yourIPAddress;share

printersandfiles.

Using the Configuration

Menu - learn the settings for

theDI-824VUP,usingthe

web-basedinterface.

Troubleshooting -learn

how to check for common

installation issues and other

tipsfortroubleshooting.

For a typical wireless setup at home (as shown above), please do the

following:

You will need broadband Internet access (a Cable or DSLsubscription line into

yourhomeoroffice).

ConsultwithyourCableorDSLprovider for proper installation of the modem.

ConnecttheCableorDSLmodem to theDI-824VUPwirelessbroadbandrouter

(Seethe Quick InstallationGuideincluded with the DI-824VUP.)

If you are connecting a desktop computer to your network, you can install the

D-LinkAirPlusXtremeGDWL-G520wirelessPCIadapterintoanavailablePCI

slot. (See the Quick Installation Guide included with the DWL-G520.)

Ifyou are connecting a laptop computerto yournetwork, installthe driversfor

the wireless cardbus adapter (e.g., D-Link AirPlusXtreme G DWL-G650)intoa

laptopcomputer.(SeetheQuickInstallationGuide included withthe DWL-

G650.)

Connectyourprintertothe printer port on the DI-824VUP. Please refer to

thequickinstallationguideforloadingtheprintserversoftware.

Autres manuels pour Wireless VPN Router DI-824VUP

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels D-Link Routeur sans fil

D-Link

D-Link DVG-N5412SP Manuel utilisateur

D-Link

D-Link DIR-625 - RangeBooster N Router Wireless Manuel utilisateur

D-Link

D-Link DSL-2740B Manuel utilisateur

D-Link

D-Link AirPlus DI-714P+ Manuel utilisateur

D-Link

D-Link DVG-G1402S - Wireless Broadband VoIP Router Manuel utilisateur

D-Link

D-Link DI-713P Manuel utilisateur

D-Link

D-Link DIR-868L Manuel d'installation et d'exploitation

D-Link

D-Link VoIP Wireless Router DVG-G5402SP Manuel utilisateur

D-Link

D-Link EXO DIR-1360 Manuel utilisateur

D-Link

D-Link DAP-1150 Manuel utilisateur

D-Link

D-Link AirPlus DI-714P+ Manuel utilisateur

D-Link

D-Link DI-713 Manuel utilisateur

D-Link

D-Link DSL-2870B Manuel utilisateur

D-Link

D-Link DIR-524 Manuel utilisateur

D-Link

D-Link DIR-820L Manuel utilisateur

D-Link

D-Link DIR-615 - Wireless N Router Manuel utilisateur

D-Link

D-Link DIR-2680 Manuel utilisateur

D-Link

D-Link DWR-530 Manuel utilisateur

D-Link

D-Link AirPlus G DWL-G650X Manuel utilisateur

D-Link

D-Link Ethernet Broadband Router DIR-100 Manuel utilisateur

D-Link

D-Link DWR-932 Manuel utilisateur

D-Link

D-Link DUB-1340 Manuel utilisateur

D-Link

D-Link VDSL2 Manuel utilisateur

D-Link

D-Link DWR-730 Manuel utilisateur

Manuels Routeur sans fil populaires d'autres marques

Milesight

Milesight UG67 Manuel utilisateur

Airlogic

Airlogic AirSync Class 1 Manuel du propriétaire

Samsung

Samsung WCH730B Manuel utilisateur

TELEFONICA

TELEFONICA USB Adapter Manuel utilisateur

NETGEAR

NETGEAR PowerLINE WiFi 1000 Series Manuel utilisateur

Askey

Askey RAC2V1K Manuel utilisateur

Alloy

Alloy WLF2454AP-S Manuel utilisateur

TP-Link

TP-Link TL-WR542G Manuel utilisateur

NETGEAR

NETGEAR WNR2000v4 Manuel utilisateur

Hama

Hama 53120 Manuel utilisateur

Intellinet

Intellinet 524582 Manuel utilisateur

Asus

Asus RT-N10P Manuel utilisateur

Sapido

Sapido GR297n Manuel utilisateur

Asus

Asus DSL-N55U Manuel utilisateur

AMTC

AMTC WR7502 Manuel utilisateur

Compaq

Compaq CP-2W - iPAQ Connection Point Manuel utilisateur

SMC Networks

SMC Networks WBR14-N2 FICHE Manuel utilisateur

Draytek

Draytek Vigor2120 Series Manuel utilisateur
