Additional documentation is also available on the D-Link website

DAP-3712

Quick Installation Guide

20 km Long Range 802.11ac Wireless Bridge

Contents

English 1

Quick Installation Guide 1

ENGLISH

Hardware Overview

LED Indicators

Figure 1: DAP-3712 LEDs

# LED Description

1Signal

Strength

Signal strength indicators. One light

indicates a weak signal. Two lights

indicate a medium signal.Three lights

indicate a strong signal.

Table 1: LED Descriptions

Interface Connectors

Figure 2: DAP-3712 Interface

# Feature Description

1 PoE Port

Uses a standard Ethernet cable to

connect the device to a PoE power

source such as a PoE switch or PoE

injector.

2Reset

Button

Resets the device to its factory

settings.

Table 2: Interface Descriptions

Before You Begin

This installation guide provides basic instructions

for installing the DAP-3712 on your network.

The device should be ensured that systems

employing high gain directional antennas

are used exclusively for ﬁxed, point-to-point

operations. For additional information about

how to use the access point, please see the

User Manual from the D-Link support website.

Package Contents

This DAP-3712 should include the following

items:

• 20 km Long Range 802.11ac Wireless Bridge

• PoE injector

• Power cord

• Mounting tie

• Quick Start Guide

If any of the above items are damaged or

missing, please contact your local D-Link reseller.

Note: Using a power supply with a diﬀerent

voltage than the one recommended for the

device will cause damage and void the warranty

for this product.

System Requirements

• Microsoft Windows®, or a Linux-based

operating system

• Ethernet port

• Microsoft Edge, Firefox 60.0, or Chrome

68.0.3440.106

2Quick Installation Guide

ENGLISH

3. Thread a standard RJ-45 Ethernet cable

through the cover for the PoE port on

the underside of the DAP-3712. Insert the

cable into the PoE port, then attach the

cover to the device.

Figure 5: Connecting the Ethernet Cable

4. Connect the adjustment kit to the base of

the DAP-3712 by pressing it in until it clicks

and locks in place. Use the adjustment

kit to position the antenna at the desired

angle

Figure 6: Attaching the Adjustment Kit

Powering the Access Point

To power the DAP-3712, use a standard Ethernet

cable to connect the PoE port on the DAP-3712

to a PoE power source device such as a PoE

switch or the included PoE injector.

Hardware Installation

Assembling the Access Point

1. Assemble the dish of the DAP-3712 by

sliding the two halves together until they

lock in place.

Figure 3: Assembling the Dish

2. Connect the antenna and base through

the hole in the center of the dish.

Figure 4: Attaching the Antenna

Quick Installation Guide 3

ENGLISH

Cable Requirements

Use a CAT 5 cable with an even sheath. The

Ethernet port on the DAP-3712 access point

cannot accept a CAT 5 cable that has an uneven

sheath; the RJ-45 connector on the cable will not

ﬁt properly into the receptacle on the access point.

Conguring the Access Point

To set up and manage the DAP-3712, use one

of the following methods.

Connecting Through a Computer

1. Use an Ethernet cable to connect the

DAP-3712 to the management computer.

2. Ensure the computer is in the same

subnet as the device. The default subnet is

192.168.0.2/255.

3. Launch awebbrowser. Enter192.168.0.50

in the address ﬁeld of your browser.

4. Log in to the administration user interface.

The default login information is:

Username: admin

Password: admin

Figure 7: Direct Connection

Connecting Through a Switch or Router:

1. Use an Ethernet cable to connect the

DAP-3712 to the switch or router the

management computer is connected to.

2. If the access point did not acquire an

IP address from a DHCP server on the

network, enter the default IP address of

the access point (192.168.0.50) in the

address ﬁeld of your browser. If the access

point is automatically assigned an IP

address by a DHCP server on your network,

enter the IP address assigned to the access

point into the web browser.

3. Log in to the administration user interface.

The default login information is:

Username: admin

Password: admin

DAP-3712

Switch or

router

Computer

Figure 8: Indirect Connection

Mounting the Device

Installation Recommendations

If you plan to install the DAP-3712 on a pole,

orient the front of the device (the dish and

antenna) toward the intended coverage area.

The antenna only transmits data in the direction

it is pointed.

DAP-3712

Computer

4Quick Installation Guide

ENGLISH

Be sure to install the device at a height that

ensures that the alignment between the devices

is visible and there are no obstructions in the

middle.

Note: The DAP-3712 is designed to receive PoE

power only from an 802.3at compliant source.

Connecting the DAP-3712 to a PoE device that

is not approved by D-Link can damage the

equipment.

Mounting on a Pole

1. Hold the DAP-3712 against the pole in the

desired position.

Figure 9: Mounting the Device

2. Thread the metal mounting tie through

the hole on the base of the DAP-3712 and

and wrap it around the pole. Fasten the

tie to secure the device against the pole.

Figure 10: Completed Installation

RF Frequency Requirements

This device is for outdoor use. High power

radars are allocated as primary users of the

5150 ~ 5250 MHz, 5725 ~ 5825 MHz bands.

These radar stations can cause interference

with and/or damage the PoE injector included

with this device.

TECHNICAL SUPPORT dlink.com/support

FCC Statement

This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference when the equipment is operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance

with the instruction manual, may cause harmful interference to radio communications. Operation of

this equipment in a residential area is likely to cause harmful interference in which case the user will be

required to correct the interference at his own expense.

FCC Radiation Exposure Statement

This device complies with FCC radiation exposure limits set forth for an uncontrolled environment and

it also complies with Part 15 of the FCC RF Rules. This equipment must be installed and operated in

accordance with provided instructions and the antenna(s) used for this transmitter must be installed to

provide a separation distance of at least 20 cm from all persons and must not be co-located or operating

in conjunction with any other antenna or transmitter. End-users and installers must be provided with

antenna installation instructions and consider removing the no-collocation statement.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

Caution!

Any changes or modications not expressly approved by the party responsible for compliance could

void the user's authority to operate the equipment.

Appendix - Statements

Ver. 1.00(WW)_130x183

2020/07/24
