D-Link DHP-W610AV Manuel utilisateur

Quick Installation Guide

DHP-W610AV

PowerLine AV2 1000 Wi-Fi

AC1200 Adapter

Version 1.00 | February 16, 2017

Краткое руководство по установке

Guía de Instalación Rápida

Guia de Instalação Rápida

快速安裝指南

Petunjuk Pemasangan Cepat

DHP-W610AV

ENGLISH

Package Contents

Wi-Fi Conguration Note Wi-Fi Conguration Card

Ethernet Cable

DHP-W610AV PowerLine AV2 1000 Wi-Fi AC1200 Adapter

Hardware Installation

1. Plug your existing Powerline device into a wall outlet near your router.

Connect one of the included Ethernet cables to a LAN port on your router,

and connect the other end of the cable to your Powerline device.

1ROOM A

RouterInternet

Powerline

Device

Quick Installation Guide

DHP-W610AV

ENGLISH

2. Fully extend the antennas and plug the DHP-W610AV into a wall outlet in a

place you want to extend your network. Slide the power switch on the side of

the device to the ON position.

3. Insert one end of the second included Ethernet cable into the DHP-W610AV,

and the other end into your computer. If you are using a wireless device

such as a mobile or tablet, connect to the DHP-W610AV over Wi-Fi with the

information on the Wi-Fi Conguration Card.

4. You have now nished the hardware setup of your PowerLine AV2 1000Wi-Fi

AC1200 Adapter. You must complete the First-time Conguration in the next

section before you can use your product.

3ROOM B

DHP-W610AV

Tablet

4ROOM A ROOM B

Powerline

Device

DHP-W610AV

RouterInternet

DHP-W610AV

ENGLISH

First-time Conguration

1. Open your web browser and type the following into the URL box:

Windows: http://dlinkapWXYZ or http://dlinkap

Mac OS: http://dlinkapWXYZ.local. or http://dlinkap.local.

Where WXYZ is the last 4 digits of the MAC address. The full address is

printed on the included Wi-Fi Conguration Card.

2. Select Admin for the User Name and leave the Password blank, then click

3. From the landing page, start the Setup Wizard to establish your Powerline

connection by clicking Launch Setup Wizard.

DHP-W610AV

ENGLISH

4. When prompted, press the Simple Connect Button for 2 seconds on your

existing Powerline device to connect it to the DHP-W610AV.

Note: If you don’t have an existing Powerline network, you will need

to set up security for all of your existing Powerline devices. Perform

the following steps for each device: press the Simple Connect Button

on the DHP-W610AV, then press the Simple Connect Button on your

existing Powerline device within 2 minutes.

5. Follow the on-screen instructions to set up your Powerline network. For

more detailed support, please refer to the User Manual.

DHP-W610AV

ENGLISH

Frequently Asked Questions

Q: Why can’t my DHP-W610AV nd my Powerline device?

• Be sure both devices are plugged directly into a wall outlet. Plugging into a

power strip or another device may disrupt the connection.

• The electrical wiring must be on the same electrical circuit. You may need

to consult a local electrician if you are not sure.

Q: My connection is erratic and sometimes cuts out or is slow, why?

• Try to keep nearby outlets free of other devices, such as chargers and hair

dryers, to minimize electrical interference.

Q: How do I nd my wireless network? Can I change the network name?

• You can nd the default Wi-Fi name (SSID) and password on the Wi-Fi

Conguration Card. You can also set your own password for security

purposes.

• You can change your wireless settings by opening your web browser and

going to http://dlinkapWXYZ.local. then Setup then Wireless Settings.

WXYZ is an example, the actual address is on your conguration card.

Q: Can I use only the DHP-W610AV to get online?

• Powerline devices work together to create a network. They communicate

over electrical wiring, but you still need an Internet connection from a

router and/or modem.

Q: Can I use more than one Powerline device at a time?

• Yes you can! D-Link oers a host of Powerline devices that include adapters,

extenders, and routers.

DHP-W610AV

ENGLISH

TECHNICAL SUPPORT

Australia:

Tel: 1300-700-100

24/7 Technical Support

Web: http://www.dlink.com.au

E-mail: [email protected]

India:

Tel: +91-832-2856000

Toll Free 1800-233-0000

Web: www.dlink.co.in

E-Mail: [email protected]

Singapore, Thailand, Indonesia,

Malaysia, Philippines, Vietnam:

Singapore - www.dlink.com.sg

Thailand - www.dlink.co.th

Indonesia - www.dlink.co.id

Malaysia - www.dlink.com.my

Philippines - www.dlink.com.ph

Vietnam - www.dlink.com.vn

Korea:

Tel : +82-2-2028-1810

Monday to Friday 9:00am to 6:00pm

Web : http://d-link.co.kr

E-mail : [email protected]

New Zealand:

Tel: 0800-900-900

24/7 Technical Support

Web: http://www.dlink.co.nz

E-mail: [email protected]

South Africa and Sub Sahara

Region:

Tel: +27 12 661 2025

08600 DLINK (for South Africa only)

Monday to Friday 8:30am to 9:00pm South

Africa Time

Web: http://www.d-link.co.za

E-mail: [email protected]

D-Link Middle East - Dubai, U.A.E.

Plot No. S31102,

Jebel Ali Free Zone South,

P.O.Box 18224, Dubai, U.A.E.

Tel: +971-4-8809022

Fax: +971-4-8809066 / 8809069

Technical Support: +971-4-8809033

General Inquiries: [email protected]

Tech Support: [email protected]

Egypt

1, Makram Ebeid Street -

City Light Building - oor 5

Nasrcity - Cairo, Egypt

Tel.: +2 02 23521593 - +2 02 23520852

Technical Support: +2 02 26738470

General Inquiries: [email protected]

Tech Support: [email protected]

Kingdom of Saudi Arabia

Ofce # 84 ,

Al Khaleej Building ( Mujamathu Al-Khaleej)

Opp. King Fahd Road, Olaya

Riyadh - Saudi Arabia

Tel: +966 1121 70008

Technical Support:

+966 1121 70009

General Inquiries: info.sa@ dlinkmea.com

Tech Support: support.sa@ dlinkmea.com

Pakistan

Islamabad Ofce:

61-A, Jinnah Avenue, Blue Area,

Suite # 11, EBC, Saudi Pak Tower,

Islamabad - Pakistan

Tel.: +92-51-2800397, 2800398

Fax: +92-51-2800399

Karachi Ofce:

D-147/1, KDA Scheme # 1,

Opposite Mudassir Park, Karsaz Road,

Karachi – Pakistan

Phone: +92-21-34548158, 34326649

Fax: +92-21-4375727

Technical Support: +92-21-34548310, 34305069

General Inquiries: [email protected]

Tech Support: [email protected]

You can nd software updates and user documentation on the D-Link website.

Tech Support for customers in

DHP-W610AV

ENGLISH

TECHNICAL SUPPORT

Iran

Unit 1, 1st Floor, Plot No 3, Pazhoheshgah (2)

Alley, Ahmad Ghasir (Bokharest) St. , Shahid

Beheshti (Abbas Abad) St. , Tehran, Iran.

Postal Code : 1514615911

Tel: +98-21-88880918,19

General Inquiries: [email protected]

Tech Support: [email protected]

Morocco

M.I.T.C

Route de Nouaceur angle RS et CT 1029

Bureau N° 312 ET 337

Casablanca , Maroc

Phone : +212 663 72 73 24

Email: [email protected]

Lebanon RMA center

Dbayeh/Lebanon

PO Box:901589

Tel: +961 4 54 49 71 Ext:14

Fax: +961 4 54 49 71 Ext:12

Email: [email protected]

Bahrain

Technical Support: +973 1 3332904

Kuwait:

Technical Support: + 965 22453939 / +965

22453949

DHP-W610AV

РУССКИЙ

Комплект поставки

   

    

2 Ethernet-

 PowerLine- AC1200  

HomePlug AV2 DHP-W610AV

Установка

1.  PowerLine-   , 

  .      

 Ethernet-  LAN-     PowerLine-

.

1КОМНАТА A

Маршрутизатор Интернет

DHP-P610AV

Wi-Fi Conguration Note
