CyberPower CPS140CHI Manuel utilisateur

User’s Manual for

AC Mobile Power

90/140/150 Watt Inverter

ADDITIONAL INSTALLATION TIPS CAN BE FOUND AT:

www.cyberpowersystems.com/FAQs.htm

Introduction

Thank you for purchasing the CyberPower 90/140/150 AC mobile power

inverter. Please complete and return the product Warranty Registration Card or

CyberPower 90/140/150 DC-to-AC inverter, ultra-compact and cup design

for mobile, provides safe, economical and convenient mobile power source,

transferring your vehicles 12V power to your laptop and accessories. Please

read this manual carefully for more information you need.

Features

“Plug-in” power

eliminates

the need for spare

batteries

Built-in surge protection

allows for safe usage

during car start-up and

shutdown.

Built-in splitter runs AC and

DC simultaneously. Use one

AC device and your cell

phone at the same time.

“Tangle free”

36 inch cord

Airplane adapter plug

Cigarette lighter plug

AC outlet dust

cover

Power / Surge

Indicator light

Standard 120VAC

outlet accommodates all

notebooks and mobile

accessories.

2 in 1 Connector

Safety

Before using CyberPower AC Mobile Power, read the following precautions :

zKeep the inverter from flammable materials, fumes or gases and avoid placing it in

direct sunlight or any heat-sensitive materials.

zDo not place any items on or around the inverter during operating.

zProper cooling is necessary while operating.

zKeep the inverter dry at all times.

WARNING: This product contains chemicals, including lead, known to the State of

California to cause cancer, and birth defects or other reproductive harm. Wash hands

after handling.

Installation and Operation

1.(a) In an automobile, attach 1to 2and insert the cigarette lighter plug into your car’s

cigarette receptacle.

(b) In an airplane, insert directly the airplane adapter plug into a plane’s in-seat power

receptacle.

2. Raise the dust cover on the inverter and plug the equipment (notebook, cell phone

recharger, DVD player, and other accessories) into the CyberPower AC Mobile Power

outlet.

Specification

Model CPS90UPA CPS140UPA

Capacity (Watt) 90W 140W

Input

Voltage 12Vdc

DC Input Voltage Range 10.5 - 15.8Vdc

Output

Voltage (Nominal) 120Vac ± 5%

DC Voltage 12Vdc ( Cigarette Jack )

Frequency 60 Hz ± 3%

Continuous Output Power 90W 140W

Peak Output Power 200W 270W

Output Waveform Simulated Sine Wave

Protection

Overload Protection Yes

Overheat Protection Automatic overheat shut-off at 150°F (65.5°C)

Low Battery Voltage Alarm Notifies user when DC voltage falls to 11.5V or less

Audible Alarm Power On: 3 Beeps

Overheat, Overload: Long Beep

Cooling Method Heat emitting from the housing surface Cooling Fan

Physical

Dimensions (inches) 5.9 x 2.3 x 2.8

Weight (lbs) 0.88

Troubleshooting

Problem Possible Cause Solution

Poor contact with lighter socket.

Make sure that the inverter is

securely plugged into the power

supply connector or socket.

In an automobile :

The ignition is required to be on.

Vehicle’s cigarette lighter socket

fuse blown.

Automatic shutdown when DC

voltage falls to 10.5v or less.

Turn the vehicle ignition key to the

“Accessory” position.

Check and, if necessary, replace

the damaged fuse.

Unplug the inverter and charge

the vehicle battery.

The indicator light is

not illuminated.

In an airplane :

The pilot has turned off the power

to the airplane seat.

Ask a flight attendant for

assistance.

Additional trouble shooting information can be found at :

www.cyberpowersystems.com/FAQs.htm

Limited Warranty

CyberPower warrants that the product will be free from defects in material and

workmanship under normal use for 2 years from the date of original purchase. If your

CyberPower AC Mobile Power is found to be defective within this period, we will promptly

repair or replace it. This warranty does not cover accidental damage, wear and tear or

consequential or incidental loss and applies only to the original purchaser. To obtain

service under warranty, please call CyberPower at (952) 403-9500 or (877) 297-6937 (toll

free), or e-mail CyberPower at : claims@cyberpowersystems.com.

Warranty Registration at : www.cyberpowersystems.com/registration_page.htm

Note : Registration is not required for Limited Warranty coverage, but if you do not

complete a registration you will be required to provide proof of purchase to have the

benefit of this Limited Warranty.

CyberPower Systems (USA), Inc.

Tel : (952) 403-9500

Fax : (952) 403-0009

E-mail : sales@cyberpowersystems.com

Web Site : www.cyberpowersystems.com

Address : 5555, 12th Avenue East, Suite 110, Shakopee, Minnesota 55379
