Curtis DVD2047 Manuel utilisateur
DVD HOME THEATRE SYSTEM
POWER
ON OFF
ENG
CONTENT
Front panel & back panel illustration............................1
Remote control..............................................2
System Subwoofer...........................................3
System Connection..........................................4
Video setup.................................................5
Remote control operation...................................6-8
Technical specification.......................................9
ENG
6
1
2 3 4 5 1.CD door
2.OPEN/CLOSE
3.PLAY/PAUSE
4.STOP
5.STANDBY
6.REMOTE SENSOR
7.POWER LIGHT
1
8
2 3 4
76 9
5
1.AC IN
2.Y
3.Pb/Cb
4.Pr/Cr
5.VIDEO
6.L
7.R
8.COAXIAL
9.S-Video
ENG
1
PREPARA TION OF THE REMOTE
CONTROL
At first , place the batteries into the
remote control, then you can use remote
control to operate the DVD video player.
1. Open the cover
2. Insert the batteries( No. AAA)
Make sure to match the +and on the
batteries to the marks inside the battery
Compartment.
3. Close the cover
Note on the batteries
Improper use of the batteries may cause
battery leakage and corrosion. To
operate the remote control correctly,
follow the instructions below.
7
REMOTE CONTROL
ENTER
When use, direct the remote control to the infra-red sensor (within 45 degrees).
Do not put remote control near to the place with high temperature or moisture.
Do not put water or any other object on remote control.
Do not usr new and old batteries or different type batteries togeter.
Please replace butteries when find remote control is out of work or weak sensitivity.
ENG
2
ENG
3
DISCRIPTION OF HOME THEATER SYSTEM
REAR PANEL OF THE SUBWOOFER
1.SUBWOOFER
2.SATELLITE (LEFT/RIGHT)
3.REMOTE CONTROL
4.POWER LED
5.POWER SWITCH
6.DVD PLAYER
7.AUDIO INPUT CABLE
8.INPUT JACK FOR CONNECTING TO THE DVD PLAYER
AUDIO R/L OUTPUT
9.OUTPUT JACK FOR CONNECTING THE SATELLITE SPEAKERS R/L
10.AC CABLE
1
22
3
6
4
5
7
8
9
10
SYSTEM SUBWOOFER
ENG
Home theater system connect instruction
Speaker-R
Speaker-L
4
SYSTEM CONNECTION
Speaker box
DVD Player
TV set
Yellow
Red
White
Menu
System setup
Language setup
Audio setup
Video setup
Speaker setup
Digital setup
TV System
Screen Saver
Video
TV TYPE
PASSWORD
RATING
DEFAULT
NTSC/PAL60/PAL/AUTO
ON/OFF
Interlace-YUV
P-SCAN YPBPR
S-VIDEO
4:3PS 4:3LB 16:9
0000
KID SAFE
G
PG
PG13
PG-R
R
NC-17
ADULT
RESTORE
OSD LANGUAGE
AUDIO LANGUAGE
SUBTITLE
MENU LANGUAGE
AUDIO OUT
SPDIF/OFF
SPDIF/RAW
SPDIF/PCM
BRIGHTNESS
CONTRAST
HUE
SATURATION
SHARPNESS
LT/RT
STEREO
VSS
LINE OUT
RF REMOD
STEREO
MONO L
MONO R
MIX MONO
OP MODE
DYNAMIC RANGE
DUAL MONO
English
German
Spanish
French
Portuguese
System setup Language setup Audio setup Video setup Digital setup
DOWNMIX
Speaker setup
This player allows you to customise the performance to your persomal preforences.
Displaying the setup menu screen
The setup preferences.
The selected category will provide you the setting details using the following screen.
1.Press SETUP key to access the setup menu.
2.Press direction keys to (highlight) a item,then press ENTER to confirm.
3.Press SETUP key to exit setup menu,factory defaults.
ENG
5
VIDEO SETUP
Using the remote control to proceed for the following setup:
6
ENG
Press clear to delete the numbers
you have enterded.
Each press of the repeat button
will change the repeat mode.
During VCD Playback,there are
three modes:Repeat single,repeat
all and off.
During DVD Playback,there are
three modes:Repeat charpter,
repeat title and off.
Note:During VCD Playback,the
PCB Mode must be set to off.
7
ENG
Press again to
resume after soundless.
(For VCD only)
