TLP

TROUBLESHOOTING GUIDE

G3 LOW PROFILE AIRPOT BREWER

Service & Sales

1-800-421-6150 www.wilburcurtis.com

Service & Sales

1-800-421-6150 www.wilburcurtis.com

Service & Sales

1-800-421-6150 www.wilburcurtis.com

PART # DESCRIPTION

BREWER PARTS IDENTIFICATION

1. WC-2962-101K KIT, FITTING SPRAYHEAD KYNAR

2. WC-717 CONTROL BOARD, SMART CARD SWITCH PANEL

3. WC-29030 SPRAYHEAD ASSY, ADVANCED FLOW ORANGE

4. WC-715 CONTROL MODULE, TLP 120V 16PIN

5. WC-102 SWITCH, TOGGLE SPST 25A 250VAC RESISTIVE

6. WC-1040 PUMP, WATER CENTRIFUGAL 120V 60 Hz

7. WC-1809

FAUCET, PS/HPS SERIES HOT WATER 1/2-20 UNF AP/ALP

8. WC-826L VALVE INLET 1GPM 120V 10W

PART # DESCRIPTION

9. WC-5310 TUBE, 5/16 ID x 1/8W SILICONE

10. WC-43062 GASKET, TANK

11. WC-5502-01

KIT, PROBE, ASSY WATER LEVEL W/HEX FITTING, O-RING & NUT

12. WC-917-04 ELEMENT, HEATING 1.45KW 120V W/JAM NUTS

& SILICONE WASHER

13. WC-523

THERMOSTAT, MANUAL RESET 120/220 VAC 25A 220 DEG F MAX

14. WC-1438-101 SENSOR, HEATING TANK

15. WC-1806 SEAT CUP, SILICONE

Service & Sales

1-800-421-6150 www.wilburcurtis.com

PARTS IMAGES

WC-2962-101K

KIT, FITTING SPRAYHEAD KYNAR

1

WC-717

CONTROL BOARD

2

WC-29030

SPRAYHEAD ASSY, ORANGE

3

4

WC-102

TOGGLE SWITCH

5

WC-1040

WATER PUMP

6

WC-715

CONTROL MODULE

WC-1809

FAUCET, HOT WATER

7

WC-826L

VALVE INLET

8

WC-5310

SILICONE TUBE

9

10

WC-5502-01

KIT, PROBE, O-RING & NUT

11

WC-917-04

ELEMENT, HEATING

12

WC-43062

GASKET, TANK

13

WC-1438-101

SENSOR, HEATING TANK

14

WC-1806

SEAT CUP, SILICONE

15

WC-523

THERMOSTAT, MANUAL

Service & Sales

1-800-421-6150 www.wilburcurtis.com

STEP 6. Verify the voltage at the toggle switch,

it should read: 120v between each terminal +

neutral.

STEP 7. Verify that there is 120v between pins

#15 & #16 on the Molex connector at UPM.

STEP 8. If all steps were taken and unit doesn’t

turn on, verify 5 VDC between pins #1 & #2 on 4

pin connector on SPS module:

Yes: Replace SPS module.

No: Replace UPM.

TROUBLESHOOTING INSTRUCTIONS

POWER ISSUES

STEP 1. Verify that the panel breaker is turned

on.

STEP 2. Verify voltage at the receptacle reads:

(L1-N = 120v, N-G = 0v).

STEP 3. Verify that the power cord is properly

connected to the receptacle.

STEP 4. Verify that the toggle switch is in the ON

position.

STEP 5. Verify the voltage at the reset thermostat,

it should read 120v between each terminal +

neutral.

The unit will not turn on:

“Ready to Brew” OFF

STEP 1. Verify that the resistance on the

temperature sensor is less than 10k ohm with a

hot tank (200+ degrees).

Yes: Bypass the sensor using a jumper with a 5k

ohm resistor.

No: Verify correct mounting and that the walls of

the tank are free of mineral deposits. If the unit

stops heating, replace the temperature sensor.

No: Replace the UPM.

“Ready to Brew” ON

Check for continuity between C & N O on UPM

(Heating Relay). If continuity is present, replace

UPM.

HEATING ISSUES

STEP 1. Verify 120 volts across the manual reset

thermostat.

Yes: Proceed to STEP 2.

No: Reset or replace the manual reset thermostat.

STEP 2. Verify 120 volts across the toggle switch.

Yes: Proceed to STEP 3.

No: Replace the toggle switch.

STEP 3. Verify 120 volts across the Heating

Element.

Yes: Replace the heating element.

No: Replace the UPM.

Not heating: Overheating/Steaming:

Service & Sales

1-800-421-6150 www.wilburcurtis.com

“Ready to Brew” light flashes 3+1 (Water Level

Error Code)

STEP 1. Verify the flow rate to be a minimum

of 1 GPM from outlet of the water filter. If not,

ensure that the inlet side of the water filter is

receiving a minimum of 1 GPM.

Yes: Replace the water filter. If not, consult a

plumber.

No: Remove the orange wire from the probe.

STEP 2. Does the tank start filling?

Yes: Replace the water level probe.

No: Verify 120 volts across the inlet valve coil.

STEP 3. Was 120 volts verified?

Yes: Replace inlet valve.

No: Replace UPM.

TROUBLESHOOTING INSTRUCTIONS - continued

BREWING ISSUES

Ready to Brew is Flashing But...

No response when Brew Button is pressed.

Replace the SPS Module.

No water ow from the sprayhead:

STEP 1. Does water ow from the hot water

faucet?

Yes: Verify 120 volts at the pump.

If voltage is present at the pump, replace

the pump.

No: If 120 volts is not present at the pump,

conrm continuity of wiring between

Molex connector and pump.

If OK, replace the UPM.

No: If water does not ow from the hot

water faucet, replace the water level

probe.

Short Pots:

TANK FILLING ISSUES

Overlling:Not lling:

Turn OFF toggle switch.

STEP 1. Does the tank continue to fill?

Yes: Replace water inlet valve.

No: Ground the probe wire to the chassis.

STEP 2. Does the tank continue to fill?

Yes: Replace the UPM

No: Replace the water level probe.

STEP 1. Verify that the hot water tank is lling

correctly. (See Tank Filling Issues)

BEFORE REPLACING ANY PARTS, VERIFY

THE FOLLOWING:

Ensure correct alignment of the sprayhead tting

and that the tubing is routed properly to allow for

maximum water ow.

Overowing:

STEP1. Ensure that the sprayhead (Orange

AFS ONLY) has not been removed. Replace as

needed.

STEP 2. Ensure that the Hot Water Tank is not

overowing (See Tank Filling Issues)

STEP 3. Ensure Cold Brew Lock is set to 5°F.

Service & Sales

1-800-421-6150 www.wilburcurtis.com

NOTES

__________________________________________________________________________________________

JUN/2017 M275_TS_WC_TLP_revNC

Wilbur Curs Co., Inc.

6913 Acco Street, Montebello CA 90640

Customer Service: 800.421.6150 | 323.837.2300

csrassistance@wilburcurs.com

Tech Support: 800.995.0417

www.wilburcurs.com
