CUE PDCUE Manuel utilisateur
User Manual
pdCUE
Version 03
User Manual pdCUE
UM025_03, 15.03.2005
Copyright © CUE, a.s., Praha, Czech Republic 1990 - 2005.
All rights reserved. Specifications are subject to change without prior notification.
User Manual pdCUE
www.cuesystem.com
Page 3 of 16
1. Table of Contents
1. Table of Contents........................................................................................................................... 3
2. Introduction .................................................................................................................................... 4
2.1. Overview................................................................................................................................................. 4
2.2. Models .................................................................................................................................................... 4
3. Connection ..................................................................................................................................... 5
3.1. CUEnet Connection................................................................................................................................ 5
3.2. eCUE Connection................................................................................................................................... 5
4. Software Installation...................................................................................................................... 6
4.1. Installation of pdCUE Manager............................................................................................................... 6
4.2. Installation and Registration of pdCUE ................................................................................................... 7
4.3. Software Registration Procedure............................................................................................................ 9
4.4. Downloading a Panel Layout File to pdCUE..........................................................................................11
4.5. Communication Setup ...........................................................................................................................12
5. Software and Firmware License................................................................................................. 13
6. Warranty Conditions ................................................................................................................... 14
7. Notes ............................................................................................................................................. 15
User Manual pdCUE
www.cuesystem.com
Page 4 of 16
2. Introduction
2.1. Overview
CUE brings a new solution to the market enabling the use of any Windows Mobile-based Mobile
Device i.e. PDA, or Tablet PC running Microsoft® Windows® Mobile™ 2003 software for the Pocket
PC, to run as a Cue System control panel. The wireless communication between the mobile device
and control system is based on Wi-Fi (IEEE 802.11b or 802.11g) data communication. The mobile
device is required to be equipped with a Wi-Fi module, and the control system uses a standard
wireless access point connected to the CUEnet. The application for the mobile device is designed with
Cue®Design Director software in mind, which is the standard programming tool for touch panel layout
creation. The mobile device is required to have the pdCUE runtime software installed (supplied in the
pdCUE software package). The pdCUE is suitable as the sole control panel in a system, or an
additional control panel to a system. The pdCUE has excellent applications in commercial,
educational, and residential systems. The advantage of the pdCUE is that it allows the user or users
(anyone within the access point range) to access their control system without using a panel, but
instead their PDA or Tablet PC.
2.2. Models
This manual refers to the following products.
Model Product code Description
pdCUE-S SW0001 Resolution 240 x 320 pixels
pdCUE-M SW0002 Resolution 640 x 480 pixels
pdCUE-L SW0003 Resolution 800 x 600 pixels
pdCUE-X SW0004 Resolution 1024 x 768 pixels
pdCUE-S /d SW0005 Resolution 240 x 320 pixels, Direct Link
pdCUE-M /d SW0006 Resolution 640 x 480 pixels, Direct Link
pdCUE-L /d SW0007 Resolution 800 x 600 pixels, Direct Link
pdCUE-X /d SW0008 Resolution 1024 x 768 pixels, Direct Link
User Manual pdCUE
www.cuesystem.com
Page 5 of 16
3. Connection
3.1. CUEnet Connection
3.2. eCUE Connection
User Manual pdCUE
www.cuesystem.com
Page 6 of 16
4. Software Installation
4.1. Installation of pdCUE Manager
1. Before installing pdCUE Manager, ensure that Microsoft ActiveSync 3.8 synchronization
software is already installed on your computer.
2. Run the installation file on your computer and confirm the default options.
3. After successful installation, the pdCUE Manager program will be displayed.
User Manual pdCUE
www.cuesystem.com
Page 7 of 16
4.2. Installation and Registration of pdCUE
1. Connect a Mobile Device to your computer using communication cable as described below.
2. Before running pdCUE Manager, ensure that Microsoft ActiveSync 3.8 is running and a
partnership with Mobile Device is already established.
3. Run the pdCUE Manager program on your computer (Start-All Programs-Cue Director-pdCUE
Manager).
4. Click the Installation tab.
5. Click on the button Install to Mobile Device, pdCUE will be installed on the connected device.
User Manual pdCUE
www.cuesystem.com
Page 8 of 16
6. Click on the Registration tab...
7. Proceed to online software registration at www.cuesystem.com located under Support - Software
registration.
User Manual pdCUE
www.cuesystem.com
Page 9 of 16
4.3. Software Registration Procedure
1. The online software registration is located at www.cuesystem.com under Support - Software
registration.
2. In the initial screen, select the type of the purchased software
SW0001 pdCUE-S
SW0002 pdCUE-M
SW0003 pdCUE-L
SW0004 pdCUE-X
SW0005 pdCUE-S /d
SW0006 pdCUE-M /d
SW0007 pdCUE-L /d
SW0008 pdCUE-X /d
3. Select the trailing part of the serial number of the purchased software
User Manual pdCUE
www.cuesystem.com
Page 10 of 16
4. Fill out all the compulsory information
Purchase ID - it is a number used for the license verification. It is stated on the printed version of
the license (the purchase ID has to be written exactly as it appears on the license - upper / lower
case letters matter).
Mobile device number - it is a string made of letters and digits generated by the pdCUE Manager
software for registration (the Mobile device number is not case sensitive i.e. has not to be written
exactly as it has been generated – upper / lower case letters do not matter).
E-mail - to this e-mail address the final copy of the registration will be forwarded to. Please type
the e-mail address correctly as the data sent to your e-mail is dedicated for your later reference.
5. Receiving the registration number
If all items are filled out correctly, the application will display your registration code. At the same
time the registration code will be forwarded to your e-mail address. If any of the items is entered
incorrectly, the application will announce which menu item has to be corrected.
