Cub Cadet Z-Force S 48 Manuel utilisateur

cubcadet.com

FEATURES

Z-FORCE® S 48

Z-FORCE® S 54

Z-FORCE® S 60

DESignED FOR HOmEOwnER

uSE witH CHallEnging

tERRain up tO 4 aCRES.

SmaRtER FEatuRES FOR a bEttER ExpERiEnCE. tHat’S tHE CUb CAdET AdvAnTAgE.

Z-FORCE®

SERIES

4-wHEEl StEER ZERO-tuRn RiDERS

ZERO-TURN

MANEUVERABILITY

WITH STEERING WHEEL

CONTROL

48", 54" OR 60"

HEAVY-DUTY

FABRICATED DECK

ADJUSTABLE

STEERING COLUMN

21.5-24 HP* CUB CADET®

PROFESSIONAL-GRADE

KAWASAKI® ENGINES

DUAL HYDROSTATIC

TRANSMISSION

PATENTED SMARTJET™

DECK WASH SYSTEM

OPTIONAL

ATTACHMENTS

AND ACCESSORIES

AVAILABLE

3-YEAR LIMITED

WARRANTY†

†See speciﬁcations for warranty information.

*as rated by engine manufacturer

A FORCE In ZERO-TURnS.

The Z-Force® S Series offers more power and performance than any other zero-turn on the market. With

features like a pivoting front axle and high-back seat with gel suspension for comfort, you’ll be able to relax

for the entire ride. Couple that with the unmatched stability of four-wheel steering and exclusive steering

wheel control and you’ll enjoy a better experience and better results every time.

UnSURPASSEd RESULTS OF

ThE CUb CAdET SIgnATURE CUT™

Aerospace engineers designed the heavy-duty, fabricated cutting deck

for optimal results and durability. Featuring a triple-blade cutting system

and ﬂoating deck, you’ll achieve a more precise cut even in challenging

or uneven terrain.

EFFORTLESS ZERO-TURnIng CAPAbILITIES

A dual hydrostatic rear-wheel transmission allows for effortless zero-turn

control that’s synchronized with the steering to virtually eliminate the risk

of turf damage. The results are a professional-quality cut that will leave

your neighbors envious.

InCREdIbLE MAnEUvERAbILITY, EASE OF USE

And COnFIdEnCE

The Z-Force® S Series is equipped with four-wheel steering and steering

wheel control to give you unprecedented command on hills, uneven terrain

and anywhere else. You’ll have the conﬁdence to handle any job.

lOCatE a DEalER at

CUbCAdET.COM

innOvatiOnS nO OnE ElSE Can DElivER. an ExpERiEnCE nO OnE

ElSE Can matCH. pROvE it tO yOuRSElF witH a tESt DRivE.

Z-FORCE® S SERIES

4-whEEL STEER ZERO-TURn RIdERS

EngInE Z-Force® S 48 Z-Force® S 54 Z-Force® S 60

Engine Type 21.5 HP* Cub Cadet® professional-grade

Kawasaki® V-Twin OHV

23 HP* Cub Cadet® professional-grade

Kawasaki® V-Twin OHV

24 HP* Cub Cadet® professional-grade

Kawasaki® V-Twin OHV

Engine Displacement/

Orientation 726cc/vertical

Cylinders/Materials 2/cast-iron sleeve

Engine Start Electric

Lubrication Fully pressurized automotive-style oil pump w/spin-on oil ﬁlter

Engine Oil Capacity 2 qt.

dRIvE SYSTEM

Transmission Dual EZT Dual Hydro-Gear™ ZT-2800™ w/oil reservoir

and ﬁlter

Dual Hydro-Gear™ ZT-2800™ w/oil reservoir

and ﬁlter

STEERIng

Steering Wheel Control Steering wheel with tilt column

ChASSIS

Frame 1.5" x 3.0" box, fully welded steel

Front Axle Cast-iron, greasable

Front Wheel Bearings Steel

Rear Tow Hitch Standard

ELECTRICAL SYSTEM

Alternator 15 amp. regulated

Battery 230 cold crank amp.

Safety Systems Operator presence

OPERATIOn

PTO Clutch Electronic ﬁngertip engagement

Deck Lift Foot pedal

Seat High-back w/arm rests and gel suspension

Parking Brake Mechanical

Hour Meter Standard electronic

AddITIOnAL SPECIFICATIOnS

Forward Speed 7 mph 8 mph 8 mph

Reverse Speed 4 mph

Front Tires 13" x 5.0" – 6"

Rear Tires 18" x 9.5" – 8" 20" x 10" – 8" 20" x 10" – 8"

Turning Radius Zero

Fuel Tank Capacity 4.25 gal.

Cup Holder w/Utility Bin Standard

Wheelbase 43"

Overall Length 70"

Approx. Weight 725 lbs. 775 lbs. 790 lbs.

MOwER dECK

Cutting Width/Blades 48" triple-blade (high-lift) 54" triple-blade (high-lift) 60" triple-blade (high-lift)

Greasable Spindles Standard

Deck Cutting Height 1" – 4"

Deck Style/Construction 11-gauge, ﬂoating, fabricated w/sloped nose

Deck Drive System Belt driven, Kevlar®

Anti-Scalping 4 greasable gauge wheels 4 greasable gauge wheels and front roller 4 greasable gauge wheels and front roller

Deck Wash Patented SmartJet™ high-pressure deck washing system

Deck Attach/Removal QuickAttach™ in seconds, no tools required

wARRAnTY†

3-year/180-hr limited warranty

This brochure is for advertisement purposes only. The product depictions are not meant to be used or relied upon as a substitute for the safety and use information that is published in the respective

operator’s

manual. Before operating the machine, read, understand and follow all instructions in the manual and on the machine. Speciﬁcations and programs are subject to change without notice.

Images may not reﬂect dealer inventory and/or unit speciﬁcations.

*as rated by engine manufacturer †See your local Cub Cadet Independent Dealer for warranty details.

ATTAChMEnTS makE a SmaRt CHOiCE EvEn SmaRtER.

Dial up the versatility of your rider by adding attachments that let you tackle more of your outdoor chores with conﬁdence and ease.

Twin and triple baggers, mulch kit, rear hitch, rear spreader, lawn sweeper, steel cart, poly cart, lawn dethatcher, lawn spike and plug

aerator, lawn roller, rear engine guard, work light kit and snow blade.
