INSTRUCTION MANUAL

BEVERAGE COOLER MODEL: RSSP-160001 A1

- Please read these instructions carefully before operating this appliance.

- Check if local voltage corresponds to the unit label.

SAFETY

- This appliance is designed to operate on alternative current (A.C.) Only

- DO NOT CONNECTTO DIRECT CURRENT (D.C.).

- Care should be taken when operating this appliance, as HOT SURFACES may cause

burns.

- DO NOT SHAKE OR TURN UPSIDE DOWN because it can damage the refrigeration

system.

- When not in use for long period unplug the appliance.

OPERATION

- Install the equipment on a counter 50” (1.2m) height (at least).

- Find a place well ventilated, protected from solar rays and away from heat sources.

- Plug the equipment without the product container and turn on. After some minutes you will

see a thin ice layer on the evaporator (drawing nº 5) that will melt a short time later and this

cycle will repeat.

- Replace the product container and the equipment is ready to use.

- We suggest fill in the product container with a already cooled product to get a best

performance.

- Obs.: The temperature is controlled by a thermostat that keeps the liquid around 41ºF

(5ºC).

CLEANING

- For your safety unplug the equipment before any maintenance service.

Body: Use only a damp cloth or sponge dipped in soapy water.

Product Container: Use only water and neutral soap. Avoid abrasive materials.

Product Dispenser: Use only water and neutral soap after disassemble (see drawing nº

35 and 36).

CROYDON

CROYDON CROYDONMAQ INDUSTRIAL LTDA.

Estrada São Lourenço, 891 - Capivari - Duque de Caxias.

RJ - Brasil - CEP 25243-150 Fax: 55 21 2676-2522

Phone: 55 21 2776-1928 / 55 21 2676-1512

e-mail: [email protected]

1.108-3

1.183-3

1.186-3

1.184-3

1.163-3

1.215-3

1.196-3

1.193-3

1.292-3

2.088-3

1.195-3

1.182-3

1.174-3

1.232-3

1.256-3

1.166-3

271

1.109-3

1.181-3

333

597

642

601

531

1.426-3

1.185-3

1.187-3

1.204-3

1.262-3

1.211-3

1.270-3

1.410-3

331

1.464-3

1.474-3

1.469-3

508

3.021-3

14.033-3

2.191-3

2.190-3

481

635

1.179-3

1.164-3

1.175-3

Product Container Cover

Product Container

Peel

Peel’s Rotor

Evaporator

Product Container Seat

Seat’s Base

Cabinet Cover

Condenser

Rubber Foot

Cabinet

Frontal Panel

Drip Pan

Drip Pan Support

Rotor’s Tube

Drip Pan Grate

On/Off Switch

Insulation Tube

Geared Motor Support

Screw (1/4”)

Lock Washer (1/4")

Washer (1/4”)

Nut (1/4")

Screw Hex Type

Fan Motor Assembly

Latex Ring

Plastic Tube w/ thread

Gas Filter R-134a

Nut (1/2")

Condenser Support

Thermostat

Thermostat Support

Screw

Compressor

Dispenser Tube

Dispenser

O’ring

Rubber Protection

Power Connection Cord

Wiring Conector Yel

Wiring Conector Or

Screw (3/16”)

Nut (M6)

Geared Motor Adapter

Geared Motor

Geared Motor Screw

12 11

36c

36a

36b

40 41

200

1.8 (110V60Hz)

15 / 4.0

17.2 /37.8

19/7.5x 65/25.6 x 52/20.5

Power (W)

Amperage (A)

Capacity (L/gl)

Weight (Kg/lbs)

Dimension WxHxD (cm/in)

RSSP-160001 A1

Technical Data

BEVERAGE COOLER (RSSP)BEVERAGE COOLER (RSSP)

Item Code Description

DISASSEMBLY SEQUENCE

TO WASH THE DISPENSER

- Push the lever (36c).

- Hold the Tube (35) by the loop and

pull it.

- Unscrew the plastic Nut(36a) (The

dispenser body (36c)will be free).

- Wash the components using water

and neutral detergent.

- Reassembly it in reverse sequence.
