1.5 2.0 2.5 4.0 5.5 7.0
Electronic equipment
THREAD
LOCK
CAUTION
1
GLUE
PAINT
(Not included)
TOOLS
(Not included)
ABS
CEMENT
To prevent serious personal injury and/or property damage,operate all rKITtely
controlled models in a responsible manner as outlined herein.
Safety Precautions
1.1 This radio-controlled model is not a toy, it is designed for persons 14 years of age or older.
1.2 Do not operate your vehicle on unsafe terrain; always pay attention to your surroundings.
1.3 Never operate your vehicle on public roadways, around moving people, animals, or operating machinery.
1.4 Keep clear of power lines and high-powered radio equipment to minimize radio frequency interference.
1.5 Since this vehicle contains small components, it may be a choking hazard for small children. Keep the vehicle and
any spare parts out of reach of small children.
Inspect your radio-controlled model before operation
2.1 Ensure that all screws are properly tightened. Use thread-lock to secure any metal to metal contacts- especially forcomponents designedto withstand
torque (servo mounts, motor mount, drive shaft grub screws etc.).
2.2 Always check the battery voltage for both the transmitter and vehicle prior to operating your vehicle. Keep the batteries fresh in thetransmitter and
always begin your vehicle runs with a fully charged battery pack.
2.3 Always check that the motor and servo are operating smoothly and in the right direction prior to operation. If binding between componentsis observed,
replace parts as necessary to reduce possibility of component or servodamage.
2.4 To turn on your vehicle, always power on your transmitter first, then power on yourreceiver.
After operating your radio-controlled model
3.1 To turn off the vehicle, always power off your receiver prior to powering off your transmitter.
3.2 Use caution when handling the vehicle- components, especially the ESC and motor which will be hot after operation.
3.3 Never use battery packs which are dented or otherwise damaged. Ensure that the wire insulation is intact and thatconnectors are properly soldered.
Lithium batteries can become fire hazards if mishandled.
Installation Reminder
1.Please read the manual carefullybeforeinstallation.
2.The Electronic equipment to be purchased separately:
(1) .4 channels or above transmissionand receiver* 1;
(2) .Steering servo * 1;
(3). 25g Micro servo *2;
(4). ESC *1;
(5). Battery (size in150 *50 * 40 mm).
3.Motor gear range: M0.6, 10t-18T.
4.Application range: Brush motor 30t - 35t; Brushlessmotor1400kV.
5.Screw sealant is only used between screw andmetalparts.
6.Please don't install tires or leave the model abovethe groundWhendebugging thetruck.
7.Please clean the surface first before paint to truck body. Keep it in a ventilatedand safeenvironment andawayfrom thefire source.
