CC Pilot™ XL

Introduction

In this user manual and reference handbook you, as a user, a reseller or system

integrator, will find important information about the CC Pilot™ XL. The handbook will

guide you and broaden your knowledge about this onboard computer’s technical

possibilities and advantages. Described herein are the possibilities which can be

obtained using CC Pilot™ XL in its standard configuration, but we also want to raise

your awareness of the possibility we have to offer specific customized solutions within

the framework of the platform on which CC Pilot™ XL is built.

Identification

There is a brand label on the back of the display and PC-unit of CC Pilot™ XL. On the

brand label there are numbers which identify your unique computer. During service and

other contact with the supplier it is important to be able to provide these numbers.

Brand Label

User Manual and Reference Handbook for the CC Pilot™ XL

Care All cables shall be disconnected from your CC Pilot™ XL during welding

or other service on the machine where it is installed.

The CC Pilot™ XL shall only be mounted and serviced by authorised

personnel. If the unit is opened by unauthorised personnel, the normal

guarantee will cease to be valid.

Scratches, or in the worst case damages, to the display occur easily if it

comes in contact with a sharp edge or hard material. In order to increase

the longevity of the screen, this is naturally something which should be

avoided.

The unit can be damaged if it becomes too hot. Therefore, do not cover

the unit by laying things on it, for example hanging a jacket or other

clothes on it.

Consider traffic safety when the CC Pilot™ XL is installed and whenever it

is used. CrossControl does not recommend that CC Pilot™ XL or its

accessories be used actively by the driver when a risk of injury to people,

or damage to property, is present.

Be advised that CC Pilot™ XL draws power from the vehicle battery. This

can result in the inability of the vehicle to start if the onboard computer

has been on for a period of time without the vehicle motor running.

Environment and Environmental Tolerance

The CC Pilot™ XL has been designed to cope with tough environmental demands.

Strict tests have been conducted on the unit in order to ensure that it fulfils the

expectations of a rugged unit. Much work has been performed to choose and design

internal components so that they, under all circumstances and in the best possible way,

provide you with a dependable and user-friendly working instrument. Whithin the

chapter Specifications, a list of standards can be found according to which the CC

Pilot™ XL has been tested and approved.

The CC Pilot™ XL shall preferably be placed under a roof in order to prevent exposure

to direct water contact. It is also important that it is mounted securely on a stand or the

like to inhibit the unit from moving and thereby becoming damaged, damaging the

vehicle and/or people during, for example, a traffic accident.

Cleaning

To ensure proper and reliable functionality over time, the unit shall be wiped cleaned of

dirt and dust. Use a suitable light damp rag to clean the unit.

Never use alkaline, alcoholic or other chemicals for cleaning which can damage the

unit.

User Manual and Reference Handbook for the CC Pilot™ XL

CC Pilot™ XL

Overview

The CC Pilot™ XL is a compact, robust and versatile onboard computer. It is equipped

with, among other things, a pressure-sensitive touch screen as well as a large number

of connection alternatives such as CAN, COM, Ethernet and USB.

The CC Pilot™ XL can be delivered in several configurations. This manual will cover the

basic configuration.

CC Pilot™ XL – Display unit

On the display unit of the CC Pilot™ XL there are buttons for adjusting the screens

brightness level and a status indicator. Depending on the configuration of the display it may

also be equipped with a touch screen.

Touch screen

Increase and decrease

the display’s brightness

level

Status Indicator

User Manual and Reference Handbook for the CC Pilot™ XL

CC Pilot™ XL – PC unit

CC Pilot™ also consists of a PC-unit which contains a hard disk and processor. It also

provides easily accessible external connectors.

Brand Label &

Connector legend

Mounting Holes

Connecting the Display to the PC unit

The display unit is connected to the PC unit with a (DMI) cable. The units can be

mounted separately or, if combined with a 12.1” display, as an integrated unit, as

shown in the illustration below. The PC unit can also be adjusted to work without the

display unit.

Connectors

The connectors on the CC Pilot™ XL are M12 connectors, except from the display and

power supply connectors. To be able to use connectors from standard peripherals,

adapter cables are available. For more information about see the chapter External

interface description. For more information on installing and setting up CC Pilot™ XL

see chapter Installation.

External connectors

User Manual and Reference Handbook for the CC Pilot™ XL

CC Pilot™ XL

Basic operations

This section covers basic operation of the CC Pilot™XL unit such as start-up

and shut down.

Function of the Display’s Push-buttons

In the top left of the CC Pilot™ XL there are two buttons to control the screen

brightness. Press and hold the button to gradually increase or decrease the display’s

brightness.

Starting Up

The unit is started by sending a short push signal to the ON/OFF pins in the power

connector on CC Pilot™ XL. For more information see the chapter Hook up of Power

Supply.

Starting in the cold

Rotating harddrives should not be in used in low temperature. To prevent damage, the

temperature of the harddrive is checked and if needed warmed before start up of CC

Pilot™ XL.

When sending the ON/OFF signal and the temperature is lower than +5°C (+41°F). Your

CC Pilot™ will not start immediately. Instead, an internal heater will warm up the harddrive.

During warm up the LED on the display’s will flash and the display will be activated.

Once the temperature for the hard disk is above +5°C, the CC Pilot™ will start

automatically. The heater continiues to warm the harddrive until it reaches +14°C.

To prepare for a fast start up in low temperatures preheating can be used. For more

information see chapter,

Heating via Preheating.

Values for the temperatures mentioned text are default values but can be changed

from the CCP Settings program.

Shutting-Down

To ensure that data does not get lost or the hard disk become corrupt, it is

recommended that all programs are closed before the unit is shut down.

CC Pilot™ XL can be shut down either from the operative system or from a short push

signal on the ON/OFF input in the power connector.

Forced Shut Down

Setting the ON/OFF signal high for 5 seconds will perform a forced shut down off the

onboard computer. The forced shut down is a direct shut down of the computer without

the control of the the operative system. This shut down should normally be avoided and

only be used when the computer is not responding to normal shut down.

Note that any information which was not saved will now be lost.

User Manual and Reference Handbook for the CC Pilot™ XL

Touch screen

The CC Pilot™ XL can as an option be fitted with a touch screen which gives the

opportunity to provide a very easy-to-use HMI (Human Machine Interface) for the user.

Double and right click on the touch screen

To perform the equivalent to a right click on the touch screen first tap the place where

the right click is supposed to be pressed and then tap the screen again slightly to the

side of the initial tap.

To perform a double click on the touch screen, tap the screen twice in the same place.

Calibration of touch screen

If needed the touch screen can be calibrated. Calibration is started manually via the

CCP Settings application. To keep the calibration data the administrator login must be

done in CCP Settings.

Be thorough with this calibration so that your touch screen will have the best possible

performance. You should use the same object (finger, stylus) during calibration which

you think you will use later.

Don’t use sharp or pointed objects on the touch screen since these can damage or

scratch it, which can seriously degrade its functionality.

User Manual and Reference Handbook for the CC Pilot™ XL

CC Pilot™ XL

External interface description

Accessible on the rear of CC Pilot™ XL, there are a number of ports to connect various

peripheral equipments. In order to give the CC Pilot™ XL its high environmental

classification, the unit is equipped with DIN M12 connectors. CrossControl provides

adapter cables which convert from DIN M12 to standard connectors.

Use caution and avoid plugging/unplugging of connectors when the computer is on. If

the pins become bent or damaged they may not function correctly, or in the worst case,

the onboard computer or other equipment may be damaged.

The connector legend describes where the connectors are located on your unit. The

connectors available is dependent on the unit’s configuration, therefore connections

can be addressed which may not be available to your unit

Notice that the following connector descriptions are those which are located on the unit,

not those that the attached cables shall have in order to mate with them.

Position Description

X1 Power Supply

X2 Audio

X3 USB 1

X4 USB 2

X5 USB 3

X6 USB 4

X7 Ethernet

X8 Video In

X9 CAN 2

X10 CAN 1

X11 COM

X12 VGA out

X13 DMI

Autres manuels pour CCpilot XL

Table des matières

Manuels PC industriel populaires d'autres marques

Chipsee

Chipsee PPC-A72-101 Manuel utilisateur

Advantech

Advantech UNO-2184G Manuel utilisateur

MSI

MSI MS-9A76 Manuel utilisateur

Stackrack

Stackrack THOR200 Manuel utilisateur

Moxa Technologies

Moxa Technologies DA-682C Series Manuel utilisateur

Nodka

Nodka eBOX-3000-ETC Manuel utilisateur

Siemens

Siemens SIMATIC IPC627E Manuel utilisateur

MSI

MSI MS-9A89 Manuel utilisateur

Artila

Artila Matrix-516 Manuel utilisateur

Siemens

Siemens SIMATIC Rack PC 840 V2 Manuel utilisateur

Advantech

Advantech IPPC-6152A Manuel utilisateur

Beckhoff

Beckhoff CX9020 Manuel utilisateur

Dell

Dell Embedded Box PC 5000 Manuel utilisateur

IBASE Technology

IBASE Technology ASB200-918 Series Manuel utilisateur

Lenovo

Lenovo ThinkCentre M90q Manuel du propriétaire

IXXAT

IXXAT Econ 100 Manuel utilisateur

Kontron

Kontron KBox A-151-TGL Manuel utilisateur

AXIOMTEK

AXIOMTEK ICO500-518 Series Manuel utilisateur

crosscontrol CCpilot XL Manuel utilisateur

Manuels PC industriel populaires d'autres marques
