For questions about features, operation/performance, parts or service,call:1-800-356-5268
USER’S OPERATION MANUAL
Before operating this unit, please read this manual
thoroughly, and retain for future reference.
English
CFDN2216AS
Contents
Brief Introduction ....................................................................................................................................................... 01
Important safety instructions .......................................................................................................................... 03
Installing your new appliance ......................................................................................................................... 07
Description of the appliance ........................................................................................................................... 20
Display controls .......................................................................................................................................................... 21
Using your appliance ............................................................................................................................................ 24
Cleaning and care .................................................................................................................................................. 29
Helpful hints and tips .............................................................................................................................................. 31
Troubleshooting ........................................................................................................................................................ 32
Disposal of the appliance .................................................................................................................................. 36
Thank you for choosing our appliance. We are sure you will find your new
refrigerator a pleasure to use. Before you use the appliance, we recommend
that you carefully read through these instructions, which provide details about
installing and using the product.
Brief introduction
Please ensure that everyone using this appliance is familiar with its
operation and safety features. It is important that you install the appliance
correctly and pay careful attention to the safety instructions.
We recommend that you keep this user's manual with the appliance for
future reference.
This appliance is intended to be used in households and similar
applications such as:
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have supervision or been given instruction
concerning use of the appliance. Children should be supervised to ensure
that they do not play with the appliance.
Do not store explosive substances such as aerosol cans with a flammable
propellant in this appliance.
1. Kitchen areas in shops, offices and other working environments;
2. Hotels, motels and other residential environments;
3. Bed and breakfast environments;
4. Catering and similar non-commercial applications.
Note
01
Connect to potable water supply only.
Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
Do not damage the refrigerant circuit.
Do not use electrical appliances inside the food storage compartments of
the appliance, unless they are of the type recommended by the
manufacturer.
When disposing of the appliance do so only at an authorized waste disposal
center. Do not expose to flame.
If the power cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
Keep ventilation openings, in the appliance enclosure or in the built-in
structure, clear of obstruction.
Warning
Brief introduction
02
It is important to use your appliance safely. We recommend that you
follow the guidelines below.
Store any food in accordance with the storage instructions from the
manufacturer.
Don't try to repair the appliance yourself. It is dangerous to alter the
specifications or modify this product in any way. Any damage to the power
cord may cause a short circuit, fire or electric shock.
Don't place too much food directly against the air outlet on the rear wall of
both the refrigerator and freezer compartment, as it may affect important
air circulation.
Don't place hot items near the plastic components of this appliance.
Frozen food must not be refrozen once it has been thawed out.
Don't store bottled or canned drinks (especially carbonated drinks) in the
freezer compartment. Bottles and cans may explode.
Use caution consuming popsicles or ice cubes straight from the freezer as
this can cause freezer burn to the mouth and lips.
General safety and daily use
Keep all packaging away from children to avoid risk of suffocation.
Protect children from being scalded by touching the compressor at the rear
bottom of appliance
Don't place items on top of the appliance as this could cause injury should
they fall off.
Never allow children to play with the appliance by hanging or standing over
or on the doors, racks, shelves and drawers etc.
Safety for children and other persons
Important safety instructions
03
To avoid the risks that are always present when using an electric
appliance, we recommend that you pay attention to the instructions
about electricity below.
Unpack and check through the appliance. Should any damage be evident,
don't plug in the appliance but contact the shop immediately from which
you purchased it. Keep all packing materials in this case.
We recommend that you wait for 4 hours before connecting the appliance
to allow the refrigerant to flow back into the compressor.
The appliance must be applied with single phase alternating current of
110~115V/60Hz If the voltage fluctuates exceeding the upper limit, A.C.
automatic voltage regulator of more than 350W should be applied to the
refrigerator for safety use.
The power plug must be accessible when the appliance is installed.
This appliance must be grounded.
This appliance is fitted with a plug, in accordance with local standard. The
plug should be suitable for use in all houses fitted with sockets in
accordance with current specifications.
If the fitted plug is not suitable for your socket outlets, it should be cut off
and carefully disposed of. To avoid a possible shock hazard, do not insert
the discarded plug into a socket. If in doubt contact a qualified, registered
electrician.
Do not use extension cords or multiple sockets which could cause
overloading of wiring circuits and could cause a fire. Always plug your
appliance into its own individual electrical socket which has a voltage
rating that matched the rating plate.
Electrical safety
Important safety instructions
04
Make sure that the plug is not squashed or damaged. Otherwise, it may
cause short circuit, electric shock or overheat and even cause a fire.
Do not insert the power plug if the socket is loose, there is a risk of electric
shock or fire.
Do not insert the power plug if the socket is loose, there is a risk of electric
shock or fire.
Switch off the appliance and disconnect it from the main power before you
clean or move it.
Never unplug the appliance by pulling on the electrical cord. Always grip
the plug firmly and pull straight out from the socket to prevent damaging
the power cord.
Do not operate the appliance without the cover of interior lighting.
Any electrical component must be replaced or repaired by a qualified
electrician or authorized service engineer. Only genuine replacement parts
should be used.
Do not use electrical appliances such as ice cream makers inside the food
storage compartments of the appliance unless they are approved by the
manufacturer.
To avoid eye injury, do not look directly into the LED light located in the
refrigerator compartment. If it is not functioning correctly, consult a
qualified, registered electrician or replace it in accordance with the
"Cleaning and Care" chapter.
Electrical safety
Important safety instructions
05
06
Refrigerant
The refrigerant isobutene (R600a) is contained within the refrigerant circuit
of the appliance. During transportation and installation of the appliance,
ensure that none of the components of the refrigerant circuit become
damaged.
The refrigerant (R600a) is flammable.
1.
2.
Don't store products which contain flammable propellants (e.g. spray cans)
or explosive substances in the appliances.
Should the refrigerant circuit be damaged:
Avoid open flames (candles, lamps etc.) and other sources of ignition.
Thoroughly ventilate the room in which the appliance is situated.
Caution: Risk of Fire
Important safety instructions
Installing your new appliance
Before using the appliance for the first
time, you should be aware of the
following tips.
07
For proper installation, this
refrigerator must be placed on a
level surface of hard material
that is the same height as the
rest of the flooring. This surface
should be strong enough to
support a fully loaded
refrigerator.
The rollers, which are not casters,
should be only used for forward
or backward movement. Moving
the refrigerator sideways may
damage your floor and the
rollers.
Warning
In order to improve efficiency of
the cooling system and save
energy, it is necessary to maintain
good ventilation around the
appliance for the dissipation of
heat. For this reason, sufficient
clear space should be available
around the refrigerator.
Suggest:
It is advisable for there to be at
least 2"(50mm) of clearance from
the back of the fridge to the wall,
at least 1/2"(12mm) of clearance
from its top, at least 1/2"(12mm)
from its side to the wall and a clear
space in front to allow the doors to
open 125°. As shown in the
following diagrams.
Ventilation of appliance
1/2"
2"
1/2" 1/2"
Installing your new appliance
Before using the appliance for the first
time, you should be aware of the
following tips.
Ambient temperature
+50°F to +90°F
+61°F to +90°F
+61°F to +100°F
+61°F to +109°F
Climate class
SN
N
ST
T
Stand your appliance in a dry place to
avoid high moisture damage. Keep
the appliance out of direct sunlight,
rain or frost. Stand the appliance away
from heat sources such as stoves, fires
or heaters.
This appliance performs well in
the climate class from SN to ST. It
may not work properly if being left
at a temperature above or below
the indicated range for a long
period.
Note
08
For sufficient leveling and air
circulating in the lower rear section of
the appliance, the bottom feet may
need to be adjusted. You can adjust
them manually by hand or by using a
suitable tool.
To allow the doors to self-close, tilt
the top backwards by 0.1" - 0.2".
(2.5-5mm)
Leveling of appliance
Adjustable
bottom feet
Front roller Rear roller
0.1"-0.2"
35.98“
28.74”
70.2“
35.75"
51.93"
43.9"
24.02"
125°
