The declared vibration total value has been measured in accordance with a standard test method and
may be used for comparing one tool with another. The declared vibration total value may also be used
in a preliminary assessment of exposure.
)$
The vibration emission during actual use of the power tool can differ from the declared total value
depending on the ways in which the tool is used. The need to identify safety measures and to protect
the operator are based on an estimation of exposure in the actual conditions of use (taking account of
all parts of the operating cycles such as the times the tool is switched off, when it is running idle, in
addition to trigger time).
!&: Before using this tool, read the instruction manual carefully.
!$'%
A Battery Pack must be inserted into the tool as detailed below. It is important that the Battery Pack
is of the designated type recommended for this machine. Newly purchased Battery Packs do not
come fully charged.
%& !$$!( &&&$*" Check that the battery pack is of
the designated type for this machine. We recommend that the slide switch should be
locked in the >position when removing or inserting the Battery Pack. Refer to section below.
a. Slide the Battery Pack into the base of the tool handle. The Battery can only fit one way.
b. Gently push the Battery Pack fully into the tool handle to engage the locking tabs.
The electrical connections inside the handle will be made automatically.
c. To remove the Battery Pack, simply press the two locking tabs with your finger and
thumb and withdraw the Battery Pack from the handle.
! !&$$ This tool is fitted with a variable speed trigger switch that delivers higher
speed and torque as the trigger pressure is increased. The trigger switch is also fitted with a
brake function which stops the chuck immediately when you quickly release the trigger.
&$$%)&! To lock the trigger switch in the OFF position, slide the
forward/reverse selection control to its central position.
!$)$$($%%&! For screwdriver use the forward rotation marked on the
selection lever. Push the lever fully to the right. For reverse rotation, necessary when removing
screws, push the selection lever to the left. Only operate the selection lever when the
screwdriver is at a complete stop.
!&!"$&! This screwdriver is equipped with a 1/4" Hex Tool- ess Collet Chuck.
a. To open the collet pull the collet sleeves forward.
b. Insert the required screwdriver bit onto the open collet chuck and push it fully home.
c. Release the collet sleeve. Check that the screwdriver bit is being held by the collet chuck.
&!$#''%& & Torque is the rotary force that the screwdriver can deliver. This
screwdriver has a 24 position torque adjustment ring. The higher the number the torque adjustment
ring is set at, the greater the torque delivered by the screwdriver. For guidance: 1-4 for driving small
screws, 5-9 for driving screws into soft material, 10-15 for driving screws into soft and hard materials,
16-24 for driving screws into hard materials and for maximum torque. We recommend that the
operator tests any torque application by starting with a low setting. Progressively increase the
torque setting until the desired outcome is achieved.
