Owners Manual
IMPORTANT: PLEASE READ THIS MANUAL
BEFORE USING YOUR CREWFIT LIFEJACKET
CREWFIT 165
SPORT
2
150N LIFEJACKETS
This level 150N lifejacket will give a reasonable assurance of safety from
drowning to a person who, for whatever reason, is no longer capable of
helping themselves fully. This level is intended for general application or
for use with foul weather clothing. It will turn an unconscious person into
a safe position and requires no subsequent action by the user to maintain
this position. This jacket is suitable for oshore use.
IMPORTANT INFORMATION
Train yourself in the use of this device
3
CREWFIT 165
SPORT
Introduction To Lifejackets
Crewt 165N Sport Lifejacket Features.................................Page 4
Crewt Lifejacket Donning
Donning the Crewt 165N Sport...........................................Page 5
Lifejacket Ination Methods
Know Your Ination Mechanism Type....................................Page 6
Re-Arming Automatic & Manual Operating Mechanisms .......Page 7
Lifejacket Features & Packing
Unpacking the Crewt 165N Sport . .....................................Page 8
Repacking the Crewt 165N Sport .......................................Page 9
Attaching & Using Spray Hoods............................................Page 11
Care & Maintenance
General Care & Maintenance ................................................Page 12
Cleaning, Storing & Other Important Information...................Page 13
Testing Your Lifejacket
Testing Your Lifejacket ..........................................................Page 14
Using the Ination Tube on Inatable Lifejackets....................Page 16
Other Information
Using Safety Lines with a Harness Lifejacket ........................Page 17
Correct Use of Lifting Beckets ..............................................Page 18
Warranty & Servicing.............................................................Page 19
CONTENTS
CREWFIT 165
SPORT
ISO12402-3 approved
High performance 165N Ination chamber
Exceptional turning speeds
Hard wearing outer cover
Single soft loop deck safety harness on harness version
ISO 12401:2009
Twin burst cover zip
Rapid adjusting buckle for perfect t
Single lifting becket
Single crotch strap*
Whistle
Optional SOLAS approved light
THE CREWFIT 165N SPORT LIFEJACKET
4*Not included on lifejackets sold into Australia
3
BUCKLE
THREADING
1
2
3
1
3
2
CREWFIT 165
SPORT
DONNING THE CREWFIT 165N SPORT LIFEJACKET
1 & 2 Don like a normal jacket
3Fasten front buckle
4Adjust waist belt by pulling side webbing backwards for a close secure t
5Fasten crotch strap* buckle and adjust straps by pulling webbing downwards for
a close secure t
1
4 5
2
DONNING YOUR LIFEJACKET
5
*Not included on lifejackets sold into Australia
KMOW YOUR INFLATION TYPE
KNOW YOUR INFLATION MECHANISM TYPE
MK5: AUTOMATIC OR MANUAL
1(AUTOMATIC ONLY) Check that the automatic ring capsule (C) is screwed fully onto the
operating mechanism (B). Ensure that the capsule (C) has not been red inadvertently by
checking that the bottom indicator shows green (D). Also check the expiry date on the
side of the capsule. Do not use a capsule that is out of date.
2Check the CO2 cylinder (A) is securely screwed into the operating mechanism. Check that
the top indicator (D) shows green.
3 Ensure toggle (E) is easily accessible.
MANUAL INFLATION (HALKEY ROBERTS)
1 Check that the green manual ring indicator is present (D); that the pull to inate lanyard
(C) is present.
2 Check the correct size 33g CO2 cylinder (A) is securely screwed into the inator body (B)
by 2 feeling through the fabric.
E
AUTOMATIC
On an automatic model, unscrew and remove the automatic capsule rst
A
B
D C
MANUAL
A B
D
C
6
7
RE-ARMING YOUR AUTOMATIC OPERATING MECHANISM
1 If red manually replace the ring arm into the main body and t the retaining clip. The clip
is tted by pressing it over the ring arm and into the recess either side in the center of the
operating mechanism.
2 Take the new Automatic ring capsule and screw onto the operating mechanism in
a clockwise direction. Screw right up ensuring there is no gap between the capsule and
the base of the operating mechanism. Do up hand tight.
3 Check that the cylinder sealing gaskets in the end of each operating mechanism has been
correctly tted. Check the new CO cylinders have not been used and screw into the main
body in a clockwise direction. Ensure the cylinders are screwed rmly (Hand tight) into the
operating mechanism.
4 The operating mechanism is now rearmed.
RE-ARMING YOUR MANUAL OPERATING MECHANISM
Always re-arm your lifejacket ready for use before you stow it away.
1 Unscrew the 33g cylinder from the manual ring head. Check to see if the cylinder has
been used.
2 Re-position ring arm into the ring head body. Secure green security saddle over ring arm.
3 Screw the replacement 33g cylinder into the manual operating head. Screw nger tight only
as over tightening can damage thread and lead to deation. Your manual operating head
is now ready to be used.
See www.halkeyroberts.com for more details on the manual operating mechanism.
1
1 2 3
2 3 4
WARNING: If you are unsure or have any doubt how to re-arm
and repack your lifejacket return the product to Crewsaver or
your nearest Crewsaver service agent.
RE-ARMING
UNPACKING YOUR LIFEJACKET
OPENING THE LIFEJACKET COVER
1Open the velcro tab.
2To avoid damaging your lifejacket zip, pull apart the zip, open the zip via the quick burst
elements, holding the cover either side.
3Once the zip has opened, insert your nger and slide it around the lifejacket. Undo the zip
all the way around the outside of the lifejacket. The lifejacket cover should now be open
and the ination chamber visible. Fully separate the zip. Both sides of the zip should be
apart, with the zip slider free to move back around the lifejacket to the start.
PREPARING ZIP FOR RE-PACKING
1Ensure that the zip slider is separated on one side.
2Slide the zip around to the right side of the jacket as worn.
3Feed the zip teeth into the slider ready to re-pack.
YKKYKK
YKK
YKK
YKK
YKK
YKK
YKK
YKK
YKK
To Open
To Close
21 3
8
9
REPACKING THE CREWFIT 165N SPORT LIFEJACKET
Ensure that your lifejacket is completely dry before packing.
(Refer to page 12 - Care and Maintenance for details on storing and cleaning your lifejacket)
1Start by folding the bottom left of chamber up over operating head.
2Then fold in half to make a concertina.
3Fold left side of chamber over the operating head. Then fold bottom right corner in.
4Fold rest of right side over.
5Fold the overlapping chamber back in on top so that the chamber sits inside the cover.
6Bring cover together and secure using velcro tabs before closing the zip.
DISPOSABLECYLINDER
USEONLY
33gm CO
2
XXXXXX
XXXXXXXXXXX
XXXXXX
XXXXXXXXXXX
XXXXXX
XXXXXXXXXXX
XXXXXX
XXXXXXXXXXX
XXXXXX
XXXXXXXXXXX
XXXXXX
XXXXXXXXXXX
XXXXXX
XXXXXXXXXXX
2
4
6
1
3
5
REPACKING YOUR LIFEJACKET
9
7Zip up the left side to enclose folded chamber, close velcro bursts tabs over zip . Now fold
the bottom right side of chamber up.
8Fold right side over and bottom left corner in.
9Fold the rest of left side over.
10 Fold chamber chin support down.
11 Fold the overlapping chin support and chamber back in on top so that the chamber sits
inside the cover.
12 Attach cover velcro tabs together to secure chamber folds. Concertina the chamber collar
with two folds, underneath the black fabric neck retainer.
13 Tuck in the black fabric neck retainer and fold in the last corners of the chamber. Bring the
zip round ensuring the velcro tabs are secure.
14 Finally tuck both ends of the zip into the cover and ensure ring capsule toggle is accessible.
XXXXXX
XXXXXXXXXXX
a
b
b
c
a
b
c
8
11
9
12
7
10
13 14
REPACKING YOUR LIFEJACKET
10
