Introduction
Features & Functions
The TPS-IMPC is an interface module designed for, and included with
the CrestronTPS-3000, TPS-5000, and TPS-6000 tilt touchpanels. The
sleek design of the touchpanel base left little room for all the connectors
that define the touchpanel's versatility. Furthermore, since the panel is not
a stationary user interface, it is impractical to have an excessive amount
of cable connections directly to the touchpanel. As a result, it was
necessary to connect the touchpanel to an interface module that could
offer additional space for interconnections.
Specifications
The following table provides a summary of specifications for the
TPS-IMPC.
Specifications of the TPS-IMPC
SPECIFICATION
DETAILS
Optional Power Pack PW-2420RU
(PWI-2420RU for international use)
Dimensions & Weight Height: 1.25 in (3.18 cm)
Width: 5.82 in (14.79 cm)
Depth: 3.50 in (8.89 cm)
Weight: 12.5 oz (0.36 kg)
Operations Guide - DOC. 6162 Interface Module: TPS-IMPC •1
Interface Module Crestron TPS-IMPC
Physical Description
The TPS-IMPC, shown in the following diagram, is supplied with the
TPS-3000, TPS-5000, and TPS-6000 tilt touchpanels. The module is
housed in a black enclosure with a silk-screened top panel. An AC
adapter port, network connector, and video input connectors are located
on one side of the unit. The opposite side provides a video input signal
selector switch, audio input connectors, microphone output connectors,
and audio/network/video connections to the touchpanel. The TPS-IMPC
also has mounting feet to secure the unit to a mounting surface.
Physical Views of the TPS-IMPC
FOR BOTH SIDES OF THE UNIT
THESE DIMENSIONS ARE THE SAME
Ø 0.16 in
(0.41 cm)
6 PLACES
0.27 in
(0.69 cm)
1.12 in
(2.84 cm)
1.14 in
(2.89 cm)
5.82 in
(14.78 cm)
5.32 in
(13.52 cm)
0.25 in
(0.64 cm)
3.50 in
(8.89 cm)
2.81 in
(7.12 cm)
1.25 in
(3.18 cm)
Ports
There are nine ports that serve various functions on the TPS-IMPC. Refer
to the following diagrams and descriptions of each port.
2 •Interface Module: TPS-IMPC Operations Guide - DOC. 6162
Crestron TPS-IMPC Interface Module
NTSC/PAL VIDEO
The NTSC/PAL video input consists of three connectors; two BNC
connectors for unbalanced video signals and one 6-pin mini-connector
for twisted pair wiring of balanced video signals. The video signal is
connected to these ports and requires a TPS-3000 or installation of the
TPS-VID-1 or TPS-VID-2 video card in a TPS-5000 or TPS-6000
touchpanel to display video. Consult the latest revision of the TPS-3000
Operations Guide (Doc. 6076) or TPS-VID-1/2 Operations & Installation
Guide (Doc. 6059) for details. Use either the two BNC connectors or the
six-pin connector for twisted pair wiring when connecting a video source.
NOTE: BNC connectors are physically located next to the twisted pair
connectors. Image is for illustration purposes only. Refer to the physical
view of the TPS-IMPC on page 2 for actual connector positions.
NOTE: The TPS-IMPC allows the use of either balanced or unbalanced
signals for video input. To select the signal type to be used, the DIP
switches located next to the MIC port must be set in the correct position.
Refer to “BAL/COAX” on page 6 for more information.
NET
This four-pin connector is used to connect to other Cresnetperipherals
in a system and provide network power to the touchpanel if an external
power pack is not used. If making network connections to a control
system or Cresnet peripherals, refer to “Network Wiring” on page 7.
24 VDC, 2.0A (Power Supply)
24VDC
2.0A
This female connector is used to supply 24 VDC power to the
TPS-IMPC and the touchpanel from an optional power pack (Crestron
model PW-2420RU). When power is supplied to the TPS-IMPC through
this connector, a Cresnet power connection is not required to display
video on the touchpanel.
CAUTION: Use only Crestron power supplies for Crestron equipment.
Failure to do so could cause equipment damage or void the Crestron
warranty.
Operations Guide - DOC. 6162 Interface Module: TPS-IMPC •3
Interface Module Crestron TPS-IMPC
CAUTION: If power is provided to the TPS-IMPC from the +24VDC on
a Cresnet connector or the PW-2420RU, power must not be applied to
the power input on the touchpanel base.
NOTE: When power is supplied through this connector, Crestron
recommends disconnecting the +24 VDC on the Cresnet connector (if it
is connected).
NOTE: Use care in wiring installations to avoid applying 24 VDC power
to Cresnet wiring from multiple sources.
NET/VIDEO (To Panel)
VIDEO
NET/
1
This 10-pin RJ-45 connection mates with the TPS-3000, TPS-5000, or
TPS-6000 touchpanel. Refer to the descriptions and pinout table that
follow this paragraph. The 10-pin net/video cable assembly to connect
the touchpanel to the TPS-IMPC is supplied. Even though the 8-pin audio
cable may fit into the port, do not use it.
This port provides the Cresnet connection to the touchpanel. This port
also provides composite or S-video input for the built-in video card (with
the purchase of a TPS-3000 or installation of the TPS-VID-1/2 in a
TPS-5000 or TPS-6000 touchpanel). Consult the latest revision of the
TPS-3000 Operations Guide (Doc. 6076) or TPS-VID-1/2 Operations &
Installation Guide (Doc. 6059) for details.
NET/VIDEO Pinouts
TYPE PIN DESIGNATION DESCRIPTION
1 +24V Power (Network)
2 GND Ground (Network)
3 C+ Chrominance (Positive) /Composite 2
4 C- Chrominance (Negative) /Composite 2
5 Y Data (Network)
6 Z Data (Network)
7 Y+ Luminance (Positive)/Composite 1
8 Y- Luminance (Negative)/Composite 1
9 GND Ground (Network)
10-pin RJ-45
Pin 1 Pin 1
10 +24V Power (Network)
To determine the location of pin 1, hold the cable so that the end of the
10-pin RJ-45 connector is facing away from you, with the clip side down
and the copper side up. The copper connector on the far left is pin 1.
4 •Interface Module: TPS-IMPC Operations Guide - DOC. 6162
Crestron TPS-IMPC Interface Module
CAUTION: The 10-pin RJ-45 net/video connector cable supplied by
Crestron is a custom cable and is the only one that should be used. The
end of the cable has a metal shield that is required to protect the
equipment. Using non-Crestron cables will result in damage to the
product.
AUDIO (To Panel)
AUDIO
1
This 8-pin RJ-45 mates with the TPS-3000, TPS-5000, or TPS-6000
touchpanel. The 8-pin audio cable assembly is supplied. Even though the
10-pin net/video cable may fit into the port, do not use it. This port
provides audio input to the touchpanel and microphone output from the
touchpanel. A description of the pinouts is shown in the following table.
AUDIO Pinouts
TYPE PIN DESIGNATION DESCRIPTION
1L+ Left Input (Positive)
2 L- Left Input (Negative)
3 GND/Shield Audio Input Ground/Shield
4 R+ Right Input (Positive)
5 R- Right Input (Negative)
6 GND/Shield Mic Output Ground/Shield
7 M+ Mic Output (Positive)
18
18
Front
Top
8 M- Mic Output (Negative)
To determine the location of pin 1, hold the cable so that the end of the
8-pin RJ-45 connector is facing away from you, with the clip side down
and the copper side up. The copper connector on the far left is pin 1.
AUDIO INPUT
The port mates with a six-pin connector (supplied) and provides balanced
and/or unbalanced audio input. Description of the pinouts is shown in the
following table.
Operations Guide - DOC. 6162 Interface Module: TPS-IMPC •5
Interface Module Crestron TPS-IMPC
AUDIO INPUT Pinouts
PIN DESCRIPTION
S Shield
R + Right Positive
R - Right Negative
L + Left Positive
L- Left Negative
S Shield
MIC OUT
The port mates with a three-pin connector (supplied) and produces line
level differential output. Description of the pinouts is shown in the
following table.
MIC OUT Pinouts
PIN DESCRIPTION
+ Positive
- Negative
S Shield
BAL/COAX
While not a port, these DIP switches are used to select which video
connections (balanced or unbalanced) to use when receiving video
signals. When used with a TPS-VID-2, each composite video signal can
come in on either the twisted pair (balanced) or coaxial (unbalanced)
connector. When used with a TPS-VID-1, the video signal (S-video or
composite) can be received over the twisted pair (balanced) or coaxial
(unbalanced) connectors. As long as a switch is in the appropriate
position, a signal can be connected to either the BNC or twisted-pair
connector.
To select the twisted pair connector for balanced video, the DIP switch
for the respective video source must be in the “UP” position. To use the
coaxial connector(s) for unbalanced video, the DIP switch must be in the
“DOWN” position.
6 •Interface Module: TPS-IMPC Operations Guide - DOC. 6162
Table des matières
Autres manuels Crestron Équipement d'enregistrement
Crestron
Crestron FT2-1200-ELEC Series Manuel utilisateur
Crestron
Crestron DIN-DALI-2 Mode d'emploi
Crestron
Crestron APAD Manuel utilisateur
Crestron
Crestron TPS-IMC Manuel utilisateur
Crestron
Crestron TST-600-IMCW Manuel utilisateur
Crestron
Crestron 1 Beyond Automate VX Series Manuel utilisateur
Crestron
Crestron TPMC-CH-IMW Manuel utilisateur
Crestron
Crestron C2N-UNI8IO Comment utiliser
Crestron
Crestron CNSNET Manuel utilisateur
Crestron
Crestron CEN-IDOC Manuel utilisateur
Crestron
Crestron CEN-IDOCV Manuel utilisateur
Crestron
Crestron TPS-IMC-BV Manuel utilisateur
Crestron
Crestron 3 Series Manuel utilisateur
Crestron
Crestron CNXBRMO Manuel utilisateur
Crestron
Crestron C2N-UNI8IO Instructions d'utilisation d'origine
Crestron
Crestron TPMC-L-IMC Manuel utilisateur
Crestron
Crestron DIN-DALI-2 Manuel utilisateur
Crestron
Crestron HD-XSP Comment utiliser
Crestron
Crestron PSPHD Manuel utilisateur
Crestron
Crestron C2N-DAP8RC Manuel utilisateur
Manuels Équipement d'enregistrement populaires d'autres marques
Strymon
Strymon NIGHTSKY Manuel utilisateur
Mitsubishi Electric
Mitsubishi Electric 16CH DIGITAL RECORDER DX-TL5000U Manuel utilisateur
Tews Technologies
Tews Technologies TPMC465 Manuel utilisateur
Honeywell
Honeywell Excel 50 Manuel utilisateur
SeaLevel
SeaLevel COMM+8.LPCI Manuel utilisateur
Arturia
Arturia AUDIOFUSE STUDIO Manuel utilisateur
