Overview

DM Lite® 4K60 4:4:4 extenders transport various signal types over CATx cable in point-to-point

applications. Consisting of a wide variety of DM Lite transmitters and DM Lite receivers, the

extenders offer the capability to transport HDMI®, USB-C® DisplayPort™ (DisplayPort Alt Mode),

analog audio, RS-232, and IR signals. The transmitters and receivers support video resolutions up

to 4K60 with 4:4:4 color sampling.

A CAT5e or higher cable is used to connect a DM Lite 4K60 4:4:4 transmitter to a DM Lite 4K60

4:4:4 receiver. For 1080p, WUXGA, and 2K signals, a cable length of up to 230 ft (70 m) is

supported. For UHD and 4K signals, a cable length of up to 130 ft (40 m) is supported.

In addition to interoperability between a DM Lite 4K60 4:4:4 transmitter and receiver, the

extenders are also interoperable with DMPS Lite™ switchers and with DM Lite 4K60 4:2:0

transmitters and receivers. A CAT5e or higher cable is used to connect a DM Lite 4K60 4:4:4

extender to a DMPS Lite switcher. Similarly, a CAT5e or higher cable is used to connect a DM

Lite 4K60 4:4:4 extender to a DM Lite 4K60 4:2:0 extender.

DM Lite 4K60 4:4:4 extenders are available as surface-mountable devices and as wall plate

devices. Surface-mountable devices are designed for mounting to a flat surface such as a wall.

Wall plate devices are designed for installation into an electrical box.

This section provides information about the following:

lModels

lFeatures

lPhysical description

2 • DM Lite® 4K60 4:4:4 Extenders Product Manual — Doc. 9259A

Models

The following table provides a list of DM Lite 4K60 4:4:4 transmitters and receivers.

Model Description

TRANSMITTERS

Transmitters, Surface-Mountable

HD-TX-4KZ-101 HDMI® Signal Extension over CATx Cable

HD-TXA-4KZ-101 HDMI and Analog Audio Signal Extension over CATx Cable

HD-TXC-4KZ-101 HDMI, RS-232, and IR Signal Extension over CATx Cable

HD-TXCA-4KZ-101 HDMI, RS-232, IR, and Analog Audio Signal Extension over CATx Cable

HD-TX-4KZ-111 USB-C® DisplayPort™ Signal Extension over CATx Cable

HD-TX-4KZ-201 2x1 Auto-Switcher, HDMI Signal Extension over CATx Cable

HD-TX-4KZ-211-CHGR 2x1 Auto-Switcher, HDMI and USB-C DisplayPort Signal Extension over

CATx Cable

HD-TX-4KZ-401 4x1 Auto-Switcher, HDMI Signal Extension over CATx Cable

HD-TX-4KZ-421-CHGR 4x1 Auto-Switcher, HDMI and USB-C DisplayPort Signal Extension over

CATx Cable

Transmitters, Wall Plate

HD-TX-4KZ-101-1G-B HDMI Signal Extension over CATx Cable, 1 Gang, Black

HD-TX-4KZ-101-1G-W HDMI Signal Extension over CATx Cable, 1 Gang, White

HD-TXA-4KZ-101-1G-B HDMI and Analog Audio Signal Extension over CATx Cable, 1 Gang, Black

HD-TXC-4KZ-101-1G-B HDMI, RS-232, and IR Signal Extension over CATx Cable, 1 Gang, Black

HD-TXC-4KZ-101-1G-W HDMI, RS-232, and IR Signal Extension over CATx Cable, 1 Gang, White

HD-TX-4KZ-111-1G-B USB-C DisplayPort Signal Extension over CATx Cable, 1 Gang, Black

HD-TX-4KZ-111-1G-W USB-C DisplayPort Signal Extension over CATx Cable, 1 Gang, White

HD-TX-4KZ-211-2G-B 2x1 Auto-Switcher, HDMI and USB-C DisplayPort Signal Extension over

CATx Cable, 2 Gang, Black

HD-TX-4KZ-211-2G-W 2x1 Auto-Switcher, HDMI and USB-C DisplayPort Signal Extension over

CATx Cable, 2 Gang, White

RECEIVERS

Receivers, Surface-Mountable

HD-RX-4KZ-101 HDMI Signal Extension over CATx Cable

HD-RXA-4KZ-101 HDMI and Analog Audio Signal Extension over CATx Cable

HD-RXC-4KZ-101 HDMI, RS-232, and IR Signal Extension over CATx Cable

Product Manual — Doc. 9259A DM Lite® 4K60 4:4:4 Extenders • 3

Model Description

HD-RXCA-4KZ-101 HDMI, RS-232, IR, and Analog Audio Signal Extension over CATx Cable

Receivers, Wall Plate

HD-RX-4KZ-101-1G-B HDMI Signal Extension over CATx Cable, 1 Gang, Black

HD-RXC-4KZ-101-1G-B HDMI, RS-232, and IR Signal Extension over CATx Cable, 1 Gang, Black

4 • DM Lite® 4K60 4:4:4 Extenders Product Manual — Doc. 9259A

Features

Key features of DM Lite 4K60 4:4:4 extenders include:

lDM Lite transmitter interoperability with a DM Lite receiver or DMPS Lite switcher

lDM Lite receiver interoperability with a DM Lite transmitter or DMPS Lite switcher

lPoint-to-point extension of various signal types over a CAT5e or higher cable:

oHDMI (all models excluding the HD-TX-4KZ-111 and HD-TX-4KZ-111-1G)

oUSB-C DisplayPort (DisplayPort Alt Mode) (HD-TX-4KZ-111, HD-TX-4KZ-111-1G,

HD-TX-4KZ-211-2G, HD-TX-4KZ-211-CHGR, and HD-TX-4KZ-421-CHGR only)

oAnalog audio (HD-TXA-4KZ-101, HD-TXA-4KZ-101-1G, HD-TXCA-4KZ-101, HD-RXA-

4KZ-101, and HD-RXCA-4KZ-101 only)

oBidirectional RS-232 and IR pass-through (HD-TXC-4KZ-101, HD-TXC-4KZ-101-1G,

HD-TXCA-4KZ-101, HD-RXC-4KZ-101, HD-RXC-4KZ-101-1G, and HD-RXCA-4KZ-101

only)

lDM Lite transmission distance up to 130 ft (40 m) for UHD and 4K signals or up to 230 ft

(70 m) for 1080p, WUXGA, and 2K signals

l4K60 video with 4:4:4 color sampling

lHDR10, HDR10+, and Dolby Vision® video formats

lCompliance with HDCP 2.3

lEDID pass-through capability

lCEC (Consumer Electronics Control) pass-through capability

lAutomatic switching of inputs on multi-input transmitters

lS/PDIF optical digital audio return (HD-TXCA-4KZ-101 and HD-RXCA-4KZ-101 only)

lUSB-C DisplayPort inputs with charging capability (HD-TX-4KZ-211-CHGR and HD-TX-

4KZ-421-CHGR only)

lSurface-mountable or wall plate design

lPower from one of the following:

oLocal 24VDC power pack

oRemote surface-mountable DM Lite transmitter or receiver

oRemote DMPS Lite switcher

lPower pack included with surface mountable DM Lite transmitters and receivers

DM Lite Interoperability

The DM Lite output port of a DM Lite 4K60 4:4:4 transmitter must be connected to a DM Lite

input port of a DM Lite receiver or DMPS Lite switcher. Similarly, the DM Lite input port of a DM

Lite 4K60 4:4:4 receiver must be connected to a DM Lite output port of a DM Lite transmitter or

DMPS Lite switcher. Supported DMPS Lite switchers are the HD-PS622, HD-PS621, HD-PS402,

and HD-PS401. A DM Lite 4K60 4:4:4 transmitter is also interoperable with the HD-RX-4K-210-

C-E and HD-RX-4K-210-C-E-POE DMPS Lite switchers.

Product Manual — Doc. 9259A DM Lite® 4K60 4:4:4 Extenders • 5

NOTE: DM Lite 4K60 4:4:4 extenders are also interoperable with DM Lite 4K60 4:2:0

extenders (for example, the HD-TX-101-C-E transmitter and the HD-RX-101-C-E receiver).

A DM Lite 4K60 4:4:4 transmitter and receiver can be configured and controlled only when the

devices are paired with a DMPS Lite switcher. The web interface of the switcher can be used to

configure the DM Lite devices. In addition, control system programming and .AV Framework™

software support of the DM Lite devices is hosted by the switcher.

4K60 4:4:4 and HDR Support

DM Lite 4K60 4:4:4 extenders support video resolutions up to 4K60 with 4:4:4 color sampling.

HDR10, HDR10+, and Dolby Vision® video formats are also supported.

Automatic Switching of Inputs

NOTE: Automatic switching of inputs is applicable to the following multi-input transmitters:

HD-TX-4KZ-201, HD-TX-4KZ-401, HD-TX-4KZ-211-CHGR, HD-TX-4KZ-421-CHGR, and HD-

TX-4KZ-211-2G.

When a multi-input transmitter is used with a DMPS Lite switcher, the web interface of the

switcher or control system programming hosted by the switcher can be used to configure the AV

switching behavior of the transmitter. Automatic switching of the inputs can occur based on the

last connected input or on the routing priority assigned to each input. In addition, one or more

input selection push buttons on the front of the transmitter enable the desired input to be

selected manually.

USB-C DisplayPort Input with Charging Capability

(Certain Models Only)

NOTE: Charging capability provided by a USB-C DisplayPort input is applicable to the HD-

TX-4KZ-211-CHGR and HD-TX-4KZ-421-CHGR transmitters only.

The HD-TX-4KZ-211-CHGR includes one USB-C DisplayPort input with charging capability. The

HD-TX-4KZ-421-CHGR includes two USB-C DisplayPort inputs with charging capability. When

the transmitters are powered by the included power pack, a USB-C DisplayPort input can charge

the connected AV source (for example, a laptop) with up to 60W of power. If the transmitters

are powered by a remote DM Lite receiver or DMPS Lite switcher, no charging capability is

provided by a USB-C DisplayPort input.

Analog Audio Embedding (Certain Models Only)

NOTE: Analog audio embedding is applicable to the HD-TXA-4KZ-101 and HD-TXCA-4KZ-101

transmitters only.

6 • DM Lite® 4K60 4:4:4 Extenders Product Manual — Doc. 9259A

The analog audio input port of the HD-TXA-4KZ-101 and HD-TXCA-4KZ-101 enables a

balanced/unbalanced stereo audio source to be embedded with the video signal from the HDMI

input. An audio selection push button is provided to switch between analog and HDMI audio

inputs as desired. The audio selection push button is functional only when the transmitter is used

with a DM Lite 4K60 4:4:4 receiver or a DMPS Lite HD-PS Series switcher.

Analog Audio De-Embedding (Certain Models Only)

NOTE: Analog audio de-embedding is applicable to the HD-RXA-4KZ-101 and HD-RXCA-

4KZ-101 receivers only.

The analog audio output port of the HD-RXA-4KZ-101 and HD-RXCA-4KZ-101 enables 2-channel

LPCM audio to be extracted from the AV signal.

S/PDIF Optical Digital Audio Return (Certain Models Only)

NOTE: S/PDIF optical digital audio return is applicable to the HD-TXCA-4KZ-101 transmitter

and HD-RXCA-4KZ-101 receiver only.

The HD-TXCA-4KZ-101 receives S/PDIF optical digital audio from a device (for example, a

display) connected to the S/PDIF optical digital audio input of the HD-RXCA-4KZ-101. The

S/PDIF optical digital audio output of the HD-TXCA-4KZ-101 then transmits the audio to an AV

receiver. Supported S/PDIF digital audio formats are Dolby Digital®, Dolby Digital EX, DTS®, DTS

ES, and LPCM up to 6 channels.

Surface-Mountable or Wall Plate Design

DM Lite transmitters and receivers are available as surface-mountable or wall plate devices.

Surface-mountable devices are designed to be mounted onto a flat surface such as a wall. Wall

plate devices (1 gang and 2 gang) are designed for installation into an electrical box.

Table des matières

Autres manuels Crestron Extenseur

Crestron

Crestron USB-EXT-2-LOCAL Manuel utilisateur

Crestron

Crestron DM-TXRX-100-STR Dessin dimensionnel

Crestron

Crestron HD-EXT3-C Manuel utilisateur

Crestron

Crestron USB-NX2-LOCAL-1G Manuel utilisateur

Crestron

Crestron USB-EXT Manuel utilisateur

Crestron

Crestron ST-CNB Manuel utilisateur

Crestron

Crestron USB-EXT-2-LOCAL-1G Manuel utilisateur

Crestron

Crestron ANT-EXT-5 Manuel utilisateur

Crestron

Crestron CEN-IO Series Manuel utilisateur

Crestron

Crestron ANT-EXT-10 Manuel utilisateur

Crestron

Crestron CEN-IO Series Manuel utilisateur

Crestron

Crestron AudioExpander Manuel utilisateur

Crestron

Crestron HD-EXT-USB-2000-C Dessin dimensionnel

Crestron

Crestron USB-EXT-DM Manuel utilisateur

Crestron

Crestron PYNG-CONNECT-COM Dessin dimensionnel

Crestron

Crestron LEPB-5 Manuel utilisateur

Crestron

Crestron USB-EXT-3-LOCAL Manuel utilisateur

Crestron

Crestron LEPB-4 Manuel utilisateur

Crestron

Crestron HD-TX-USB-2000-C Manuel utilisateur

Crestron

Crestron USB-EXT-3-LOCAL Manuel utilisateur

Crestron

Crestron HD-EXT3-C Dessin dimensionnel

Crestron

Crestron HD-EXT4-C Manuel utilisateur

Crestron

Crestron Sonnex SWE-8 Manuel utilisateur

Crestron

Crestron USB-EXT Manuel utilisateur

Manuels Extenseur populaires d'autres marques

SY HDBT-60T Manuel utilisateur

Appsys ProAudio

Appsys ProAudio ADX-16 Manuel utilisateur

Atlona

Atlona RS232 Manuel utilisateur

IDK

IDK OPF-TH1000-A Manuel utilisateur

Enable-IT

Enable-IT 824WP Manuel utilisateur

Worx

Worx Landroid RadioLink WA0864 Fiche technique

TP-Link

TP-Link TL-WA730RE Manuel utilisateur

Camplex

Camplex CMX-HDMI-SFPL Manuel utilisateur

SC&T

SC&T HE03-4K Manuel utilisateur

Marmitek

Marmitek MegaView70 Manuel utilisateur

Samsung

Samsung SCS-26UC4 Manuel utilisateur

Foxun

Foxun SX-GES24 Manuel utilisateur

MuxLab

MuxLab 500771 Manuel utilisateur

foxunhd

foxunhd SX-AEX01 Manuel utilisateur

TERK Technologies

TERK Technologies LFIRX2 Manuel utilisateur

Devolo

Devolo Audio Extender Manuel

Edimax

Edimax EW-7438RPn V2 Manuel utilisateur

Shinybow USA

Shinybow USA SB-6335T5 Manuel utilisateur
