HD-CTL-101

8K Smart Display Controller with

HDMI®connectivity

Product Manual

Crestron Electronics, Inc.

The original language version of this document is U.S. English.

All other languages are a translation of the original document.

Regulatory Model: M202116001

Crestron product development software is licensed to Crestron dealers and Crestron Service Providers (CSPs) under a

limited nonexclusive, nontransferable Software Development Tools License Agreement. Crestron product operating

system software is licensed to Crestron dealers, CSPs, and end-users under a separate End-User License Agreement.

Both of these Agreements can be found on the Crestron website at www.crestron.com/legal/software_license_

agreement.

The product warranty can be found at www.crestron.com/warranty.

The specific patents that cover Crestron products are listed online at www.crestron.com/legal/patents.

Certain Crestron products contain open source software. For specific information, please visit

www.crestron.com/opensource.

Crestron, the Crestron logo, Crestron Home, and XiO Cloud are either trademarks or registered trademarks of Crestron

Electronics, Inc. in the United States and/or other countries. Dolby, Dolby Atmos, and Dolby Digital are either trademarks

or registered trademarks of Dolby Laboratories in the United States and/or other countries. HDMI, the HDMI logo, and

High Definition Multimedia Interface are either trademarks or registered trademarks of HDMI Licensing LLC in the

United States and/or other countries. Active Directory is a trademark or registered trademark of Microsoft Corporation

in the United States and/or other countries. Other trademarks, registered trademarks, and trade names may be used in

this document to refer to either the entities claiming the marks and names or their products. Crestron disclaims any

proprietary interest in the marks and names of others. Crestron is not responsible for errors in typography or

photography.

Contents

Overview 6

Specifications 8

Dimension Drawing 10

Installation 11

In the Box 11

Install the Device 12

Mount on a Wall 12

Mount Under a Table 13

Install in a Rack 14

Connect the Device 15

Configuration 16

Accessing the Web Configuration Interface 17

Action 18

Save Changes 18

Revert 18

Reboot 19

Restore 19

Update Firmware 19

Download Logs 20

Manage Certificates 20

Manage EDIDs 21

Manage Device Drivers 23

Download Configuration 24

Upload Configuration 24

Manage Schedule 25

Status 27

Device 27

Occupancy Sensor 28

Input/Output 29

Network 30

Control System 30

Settings 32

System Setup 33

Occupancy Sensor 36

Inputs 37

Outputs 38

Security 47

Current User 47

Product Manual — Doc. 9366A Contents • iii

Users 48

Groups 49

802.1x Configuration 52

Resources 54

Crestron Support and Training 54

Programmer and Developer Resources 54

Product Certificates 54

iv • Contents Product Manual — Doc. 9366A

v • Contents Product Manual — Doc. 9366A

Product Manual — Doc. 9366A HD-CTL-101 • 6

Overview

The HD-CTL-101 is an 8K Smart Display Controller with HDMI® connectivity that provides a

variety of options for controlling displays without a control processor. Ideal for unified

communications, digital signage, and presentation spaces, the HD-CTL-101 can be configured to

automatically power displays on and off based on schedule, room occupancy, or video sync

detect. The HD-CTL-101 can also be utilized in residential systems to control a variety of devices

such as garage doors and TVlifts.

lDevice control options include CEC, RS-232, IR, Relay, and digital input ports

lAutomatic or scheduled display power on/off

l8K60 4:4:4 signal supported

lHDMI2.1 and HDCP 2.3 compliance

lHDR10, HDR10+, and Dolby Vision® video formats

lProvides RS-232 COM port with software handshaking

lEDIDmanagement

lXiOCloud® service support

lCrestron Home OS®support

lCrestron Driver support

lEnterprise-grade security

lBuilt-in web interface

lPoE(Power over Ethernet) network powered

lNo programming or control processor required

CECControl

CEC (Consumer Electronics Control) can control the source and display devices via the HDMI

connection, potentially eliminating the need for dedicated serial cables or IR emitters, as well as

eliminating the need for a control system. CEC over the HDMI output can also enable the display

devices to be turned on or off automatically.

7 • HD-CTL-101 Product Manual — Doc. 9366A

Device Control via RS-232, IR, Relay, and Digital Input Ports

The HD-CTL-101 includes built-in COM(RS-232), IR, relay, and digital input ports for control

source devices and accessories.

Built-In Web Interface

Full configuration of the HD-CTL-101 can be accomplished using the built-in web interface. To

simplify system installation, the configuration of a single unit can be downloaded to a computer

or mobile device and then uploaded to multiple HD-CTL-101 units.

EDID Management

The HD-CTL-101 provides comprehensive management of EDID (Extended Display Identification

Data) to ensure that every source is displayed at the optimal resolution and format. For

applications requiring a custom configuration, the HD-CTL-101 enables assessment of the

format and resolution capabilities of any device that is connected to the HDMI output. The HD-

CTL-101 provides the ability to configure signals appropriately for the most desirable and

predictable behavior.

8K60 4:4:4 and HDRSupport

The HD-CTL-101 supports video resolutions up to 8K60 with 4:4:4 color sampling. HDR10,

HDR10+, and Dolby Vision® are also supported.

Enterprise-Grade Security

The HD-CTL-101 includes advanced security features and protocols. Using 802.1X authentication,

Active Directory® credential management, PKI authentication, TLS, SSH, and HTTPS, the HD-

CTL-101 provides a true enterprise-grade AV switcher.

XiO Cloud® Service Support

The HD-CTL-101 is compatible with the XiO Cloud service, which is an IoT (Internet of Things)

platform for remotely provisioning, monitoring, and managing Crestron devices across an

enterprise or an entire client base. Built on the Microsoft® Azure® software platform and using

industry-leading Azure IoT Hub technology, the XiO Cloud service enables installers and IT

managers to easily deploy and manage thousands of devices. Unlike other virtual machine-based

cloud solutions, Azure services provide unlimited scalability to suit the ever-growing needs of an

enterprise. For more information, visit www.crestron.com/xiocloud.

Product Manual — Doc. 9366A HD-CTL-101 • 8

Specifications

Product specifications for the HD-CTL-101 are provided below.

Video

Input Signal Types HDMI with HDR10, HDR10+. Dolby Vision™, Deep Color, 8K60 4:4:4 support

(DVIand Dual-Mode DisplayPort™ interface compatible)

Output Signal Types HDMI with HDR10, HDR10+, Dolby Vision, Deep Color, and 8K60 4:4:4 support

(DVIcompatible)

Audio

Input Signal Types HDMI(Dual-Mode DisplayPort interface compatible)

Formats Dolby Digital®, Dolby Digital EX, Dolby Digital Plus, Dolby® TrueHD, Dolby

Atmos®, DTS®, DTS-ES, DTS 96/24, DTSHD® High Res, DTS-HDMaster Audio,

DTS:X®, LPCM up to 8 channels

Connectors

HDMIIN (1) 19-pin Type A connector, female;

HDMI2.1 compliant digital video/audio input (DVI and Dual-Mode DisplayPort

interface compatible)

HDMIOUT (1) 19-pin Type Aconnector, female;

HDMIdigital video/audio output (DVIcompatible)

IN (1) 2-pin 3.5 mm detachable terminal block;

Digital input;

Input Voltage Range: 0–24VDC;

Logic Threshold: ≥2.0VDC 0/low, ≤1.1VDC 1/high;

Input Impedance: 2.2k Ohms pulled up to 5V

COM (1) 3-pin 3.5 mm detachable terminal block;

Bidirectional RS-232 port;

Supports RS-232 up to 115.2k baud with software handshaking

IR (1) 2-pin 3.5 mm detachable terminal block;

IRoutput control port;

Supports IR up to 60 kHz;

IRP2 IR emitter probe sold separately

RELAY1-2 (2) 2-pin detachable terminal blocks;

Comprised of 2 normally open, isolated relays;

Rated 1A, 30VAC/VDC;

MOVarc suppression across contacts

Ethernet 1 (1) 8-pin RJ-45 connector, female;

100BASE-TX/1000BASE-TEthernet port;

Provides network connectivity to secondary device

9 • HD-CTL-101 Product Manual — Doc. 9366A

Ethernet 2 PoE (1) 8-pin RJ-45 connector, female;

100BASE-TX/1000BASE-TEthernet port;

PoE Class 3 powered device (PD) port, 8.2 WMaximum

Ground (1) 6-32 screw, chassis ground lug

Controls and Indicators

PWR (1) LED;

Amber indicates that the device is booting;

Green indicates that the device is operational.

HDMIIN (1) LED;

Green indicates an HDMI signal;

Amber indicates the device is ready for an HDMIsignal.

HDMIOUT (1) LED;

Green indicates an HDMI signal;

Amber indicates the device is ready for an HDMIsignal.

RESET (1) LED indicates the device is being reset.

ETHERNET 1 (2) LEDs on RJ-45 connector;

Green indicates that a 100BASE-TX link is established;

Flashing amber indicates Ethernet activity.

ETHERNET 2 PoE (2) LEDs on RJ-45 connector; Green indicates that a 100BASE-TX link is

established;

Flashing amber indicates Ethernet activity.

Environmental

Temperature 32° to 104°F (0° to 40°C)

Humidity 10% to 95% RH (noncondensing)

Construction

Chassis Metal, black finish, vented sides

Mounting Surface mountable or attachment to a single rack rail

Dimensions

Height 1.20 in. (31 mm)

Width 5.93 in. (151 mm)

Depth 4.09 in. (104 mm)

Weight

0.90 lb (.40 kg)

Compliance

Regulatory Model: M202116001

Product Manual — Doc. 9366A HD-CTL-101 • 10

Dimension Drawing
