INSTRUCTION MANUAL

Installation and Operating

These instructions should be read carefully and

retained for future use. Note also the information

presented on the appliance.

Creda TSRE Storage Heater

Models: TSRE050 / TSRE070 / TSRE100 / TSRE125 / TSRE150

08/80278/0 ISSUE 2 Series A

IMPORTANT SAFETY ADVICE

When using electrical heaters, basic precautions should always be followed to reduce the risk

of re, electrical shock, and injury to persons, including the following:

IMPORTANT – The wall bracket supplied with the heater must be used.

IMPORTANT – All packaging should be disposed of in an appropriate manner.

OVERHEATING WARNING

WARNING - In order to avoid overheating, do not cover or obstruct the heater. Do not place

material or garments on the heater, or obstruct the air circulation around the heater, for instance

by curtains or furniture, as this could cause overheating and a re risk. NEVER cover or obstruct in

any way the heat outlet slots at the top of the heater or the air outlet slots in the base of the heater.

WARNING - THE SURFACES ON THIS HEATER CAN BE HOT.

The heater carries a warning ‘DO NOT COVER’ to alert the user to the risk of re that exists if

the heater is accidentally covered.

CAUTION

- Some parts of this product can become very hot and cause burns.

Particular attention has to be given where children and vulnerable people are present

For your safety this heater is tted with a thermal cut-out. In the event that the product

overheats for some reason, the cut-out prevents excessive temperatures on the product by

cutting the power to the heater. Once the heater has cooled down, it will reset automatically,

it will continue to cycle on and o automatically until the reason for overheating is removed.

The display screen may ash red to indicate the product has overheated. To reset the display,

remove the obstruction and hold Enter for 10 seconds.

SUITABLE APPLICATIONS

WARNING - This heater is suitable for normal domestic household purposes and should not

be used in any other type of environment. This product should only be used in the country

where it was purchased from by a recognised commercial retailer. Do not use outdoors.

SERVICING AND REPAIRS

WARNING - Servicing and product repairs should only be undertaken by the manufacturers

approved service agent or a similarly trained or qualied person, using only exact manufacturer

approved spare parts.

PLEASE NOTE: Household dust, lit cigarettes, candles and oil burners, combined with the

convection eect of electric heaters can cause signicant soot deposits to build up on the

surface directly above and to the sides of the heater. This is not a fault of the heater. Extensive

burning of candles or smoking in the operating environment of this product can produce heavy

discolouration within a few months of use.

IMPORTANT

THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR

FUTURE REFERENCE. Note also the information presented on the appliance

CAUTION

FAILURE TO FOLLOW THESE INSTRUCTIONS MAY CAUSE INJURY AND/OR DAMAGE

AND MAY INVALIDATE YOUR GUARANTEE

OPERATING WARNINGS

IMPORTANT: Remember to observe all safety warnings and precautions when operating the

heater on the automatic or timer modes, either attended or unattended since a re risk exists

when the heater is accidentally covered or obstructed.

Mains cables are not provided with this heater.

CAUTION: Do not use if either of the heater’s mains power leads become damaged. If the supply

cord is damaged it must be replaced by the installer or an approved service partner.

Curtains must not come to within 250mm of the top of the heater.

Do not sit or stand on the heater

Do not place objects in contact with the heater.

To maintain stability, it is essential that the heater is placed on a level surface and care should

be taken to avoid irregular surfaces, such as may result from carpets or tiled surrounds

partially protruding under the heater.

ELECTRICAL INSTALLATION

The installation of the heater should be carried out by trained personnel.

WARNING - Minimum clearances and IP zone requirements must be adhered to in

accordance with the current wiring regulations.

WARNING - The electrical installation of this heater must be carried out by a suitably qualied or

trained electrician, and be in strict accordance with current wiring Regulations. The peak supply

must be connected via a switched fused spur with a fuse rated suitably for the appliances ex,

the o-peak supply , via a 20A double pole switch. Failure to follow these instructions will mean

that the manufacturer’s instructions have not been adhered to. THERE ARE NO EXCEPTIONS.

• This heater must be earthed

• Not suitable for connection via a plug top

• Do not locate the heater immediately above or below a xed electrical point i.e. socket outlet.

This appliance is intended for installation to a single phase supply only and is not suitable for

connection to 3 phase supplies.

The heater is not tted with a mains cable, this should be tted by the installer. Cable type

(minimum size) H05VV-F 1.5mm² three core for peak and 2.5mm² three core for o-peak for

connection to the xed wiring of the premises through suitable isolation devices positioned

adjacent to the heater. The supply circuits to the heater must incorporate a double pole isolating

switch having a contact separation of at least 3mm.

In installation the supply cord may be cut to the appropriate length for the electrical connection

point. Excess cable should not be inserted or stored behind the heater.

If, during reassembly of the heater, a part of the thermal insulation shows damage or deterioration,

it should be replaced by an identical part.

WARNING: All electrical connections to the terminal block must be secure to prevent risk of

ignition. Tighten to 0.5 Nm.

CHILD SAFETY

WARNING - Fixing kit screws are a potential choking hazard.

WARNING - This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have

been given supervision or instruction concerning use of appliance by a person responsible for

their safety.

This appliance can be used by children from 8 years and above and persons with reduced

physical, sensory or mental capabilities or lack of experience and knowledge if they have been

given supervision or instruction concerning use of the appliance. Children shall not play with the

appliance. Cleaning and user maintenance shall not be made by children without supervision.

Children of less than 3 years should be kept away unless continuously supervised. Children

aged from 3 years and less than 8 years shall only switch on/o the appliance provided that

it has been placed or installed in its intended normal operating position and they have been

given supervision or instruction concerning use of the appliance in a safe way and understand

the hazards involved. Children aged from 3 years and less than 8 years shall not regulate and

clean the appliance or perform user maintenance.

All Models

Controls Digitally controlled, Electronic Thermostat accurate to (±0.2oC). Setpoint range (7-26°C)

Timer modes: 7 Day Programmable User Timer, Out All Day, Holiday

Controller UI

•Graphical display with white backlight

•Capacitive buttons with audio feedback

•User replaceable battery (Coin-Type)

Controller Functions

•Open window detection

•Boost Mode and Settings

•Heat Demand % Adjustment

•History/Reporting

•Automatic Charge Control

•Bluetooth for software updates

•Child Lock

Safety Features Electronic overheat protection. Additional electromechanical overheat protection.

LVD and EMC compliance.

Storage Core High-density bonded magnetite energy cells

Colour/ Finish White (RAL 9016) ‘Trac White’. Grill RAL7035 anodised

Battery Backup 3.3V coin cell battery to backup real time clock. Battery life > 5 years.

Supply (each) 1/N/PE 230-240V / 50Hz (Peak / O Peak) Class II

IP Rating IPX4

Approvals CE & BEAB

Warranty 2 Years

Country of Origin United Kingdom

Technical Details

Models TSRE050 TSRE070 TSRE100 TSRE125 TSRE150

Input Rating +5% / -10% 1020W 1560W 2220W 2760W 3300W

Nominal Output (kW) 0.50 0.70 1.00 1.25 1.50

Storage Element Rating 230/240V~: 936/1020W 1435/1560W 2042/2220W 2540/2760W 3024/3300W

Rated Charge Period: 7.7 - 7 Hours 7.7 - 7 Hours 7.7 - 7 Hours 7.7 - 7 Hours 7.7 - 7 Hours

kWh: 7.14kWh 10.9kWh 15.5kWh 19.3kWh 23.1kWh

Fan Wattage 11W 11W 11W 11W 11W

UI Wattage 0.5W 0.5W 0.5W 0.5W 0.5W

Sound Level dB 27 29 32 30 31

Energy Cell Packs Required

(047243) 4 6 8 10 12

Installed Weight: 63kg 85kg 107kg 133kg 155kg

Height (mm) 749 749 749 749 749

Width (mm) 581 703 825 947 1069

Depth (mm) 182 182 182 182 182

Fig. 1b

Fig. 1a

Room Sensor

Housing

Models 050 070 100 125 150

Feet Position

1 ‘A/B’ 167/124 167/185 167/246 160/314 160/375

Feet Position

2 ‘A/B’ 93/198 93/259 93/320 100/374 100/435

Preparation

1. Place the heater within its packaging at

on the ground with arrows printed on the

base of the carton pointing upwards.

2. Feet are tted in the default position

(Xposition) and can be moved to the

outside position (Yposition) if necessary.

(Fig. 1a and Fig. 1b). NB: Repositioning

of feet may be required depending on

oor arrangement (e.g. replacing an

installation).

Stand the heater on its feet before removing

the packaging.

CAUTION SHOULD BE TAKEN NOT TO

REST THE HEATER UPON THE ROOM

TEMPERATURE SENSOR HOUSING. (Fig. 1b)

Dispose of packaging in an appropriate way.

Read these instructions carefully before

proceeding any further with the installation.

3. Ensure the heater is stable before removing

the screws which hold the bottom grille panel in position. (Fig. 2) Set the bottom grille to one

side, avoiding its sharp edges when handling.

4. Remove the two screws securing the front panel, located at the bottom of the heater (Fig. 3).

Once removed set carefully to one side to avoid damage.

NOTE - Retain these screws for reassembly. If misplaced, M4 x 10 Tritap screws must be used.

IMPORTANT - Do not use the outer top panel or the rear heat shield to lift or carry the heater.

749mm

150mm

(min)

150mm

(min)

Fig. 3

Do not place objects within 300mm of the front of the heater

and 150mm (min. 75mm) either side.

Ensure the back of the heater is ush against the wall. If the skirting board is taller than

120mm and deeper than 15mm it should be cut to accommodate safe installation of the

heater.

120 mm

15 mm

250 mm

300 mm

150 mm 150 mm

Fig. 2

The heater must be securely xed to a wall. Screws with suitable wall xings for solid walls

are provided. If other wall types are encountered it is the installer who must choose the most

suitable xing.

SUGGESTED FIXINGS

SOLID BRICK/BLOCK: No. 10 size high temperature resistant plastic inserts, 8mm drill bit. Drill

hole 15mm deeper than plastic insert length.

PLASTERBOARD - If possible locate studding and use No. 10 woodscrews directly into the

wood, otherwise M5 rawlplug intersets are suitable.

NOTE: FOR OTHER WALL TYPES (eg. timber frame and hollow concrete) SEEK SPECIALIST

ADVICE.

If the oor is carpeted then the carpet should be slit and underlay cut away to allow the feet

to rest rmly on the oor. Carpet gripper must be locally removed so that the feet may rest in

a level position.

This appliance is heavy. The oor must be checked to ensure that it is capable of bearing the

weight of the unit, up to 165kg.

This Heater is rated IPX4

DO NOT UNDER ANY CIRCUMSTANCES ATTEMPT TO MOVE OR REPOSITION

THIS HEATER WITHOUT SEEKING EXPERT ADVICE. THE HEATER SHOULD

NEVER BE FREED FROM THE WALL WITH ENERGY CELLS INSIDE.

USE CAUTION WHEN INSTALLING THIS PRODUCT, UNPAINTED METALWORK

CAN HAVE SHARP EDGES.

IMPORTANT Head of wall xing screw must be anged pan head type and have a diameter

no less than 11mm. No countersunk headed screws to be used for wall xing.

Fig. 5

Fig. 4

Installing the Heater

5. Place the heater in its nal position and mark the xing holes through the location holes

visible through the back of the heater.

6. Six xing positions must be selected for models TSRE100, TSRE125, TSRE150 and at least

4 xing positions for models TSRE050 and TSRE070. Fig. 6.

Common xing points for all heater sizes are shown in both Fig. 4 and Fig. 5.

Mark the positions for the xing holes towards the bottom of each slot. This allows the heater

to settle once the energy cells have been tted.

Move the heater away from the wall, drill the holes and t the wall xings best suited to the

application.

Secure the heater to the wall using correct quantity of screws required per model, using the

appropriate screw ttings.

NB: Do not fully tighten screws until energy cells are fully loaded to ensure full weight is

on feet and not on the wall xings.

NOTE: UNDER NO CIRCUMSTANCES SHOULD ANY SCREWS BE REMOVED WITHOUT

FIRST REMOVING ALL ENERGY CELLS FROM THE HEATER.

NEVER FREE THE HEATER FROM THE WALL WITH ENERGY CELLS REMAINING INSIDE

THE HEATER CAVITY.

NOTE: ANY FIXING DROPPED INTO HEATER MUST BE RETRIEVED AS THEY MAY

IMPACT PRODUCT SAFETY OPERATION.

Fig. 6

Warning: Before obtaining access to terminals, all supply circuits must be disconnected.

7. The heater leaves the factory congured to operate with two mains supplies, a 24 hour peak

supply and an o peak switched supply. (Fig. 7)

Not suitable for use on single supply.

Storage / Fan circuit

Fan Circuit = PEAK L

Storage Circuit = OFF-PEAK L

Fan Circuit = PEAK N

Storage Circuit = OFF-PEAK N

The earth wire should be connected into the earth terminal block marked E

WARNING - Terminal block maximum torque 0.5 Nm

Neutral

Live

(O-Peak)

Neutral

Live

(Peak)

Earth

(Both Supplies)

Switched

Supply

Terminal Block

Mains

Cable

Tighten Screws

Fig. 8

Fig. 7

Electrical Connections

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Creda Chauffage

Creda

Creda TPRIII050E Manuel utilisateur

Creda

Creda CSQ15 Manuel utilisateur

Creda

Creda TSF24K Manuel utilisateur

Creda

Creda COR15TS Manuel utilisateur

Creda

Creda CQH070 Manuel utilisateur

Creda

Creda CPH05T Manuel utilisateur

Creda

Creda CLR5C Manuel utilisateur

Creda

Creda Eco-Response ER300 Manuel utilisateur

Creda

Creda CDF2N Manuel utilisateur

Creda

Creda PH2TR Manuel

Creda

Creda Newera TSR12AW Manuel utilisateur

Creda

Creda CEP 500E Manuel utilisateur

Creda

Creda Newera 79348S Manuel utilisateur

Creda

Creda Newera TSR18CW Manuel utilisateur

Creda

Creda Duo300i Manuel utilisateur

Creda

Creda CLSTH050 Mode d’emploi

Creda

Creda TSF24K Manuel utilisateur

Creda

Creda CSS3 Manuel utilisateur

Creda

Creda NEWERA 85301 Manuel utilisateur

Creda

Creda CAR 033 Mode d’emploi

Creda

Creda CQH100 Manuel utilisateur

Creda

Creda 75773301 Manuel utilisateur

Creda

Creda Sunplus CSP2 Manuel de l'installateur

Creda

Creda 79341S Manuel utilisateur

Manuels Chauffage populaires d'autres marques

oventrop

oventrop Regucor Series Manuel utilisateur

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manuel utilisateur

ELMEKO

ELMEKO ML 150 Manuel utilisateur

BN Thermic

BN Thermic 830T Manuel utilisateur

KING

KING K Series Mode d’emploi

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guide de démarrage rapide

Well Straler

Well Straler RC-16B Manuel utilisateur

EUROM

EUROM 333299 Manuel utilisateur

Heylo

Heylo K 170 Manuel utilisateur

Eterna

Eterna TR70W Manuel utilisateur

Clarke

Clarke GRH15 Mode d’emploi

IRSAP

IRSAP The Radiator Company Ovali Manuel utilisateur

Empire Heating Systems

Empire Heating Systems WCC65 Manuel utilisateur

Wetekom

Wetekom 92 86 43 Manuel utilisateur

Desa

Desa SPC170-F Manuel utilisateur

Watlow

Watlow Watrod Electric Tubular Heaters Manuel utilisateur

Haverland

Haverland ECO-DRY GPS Series Manuel de la liste des pièces

Stelpro

Stelpro ASILVC2060 Series Manuel utilisateur
