Tumble Dryer

Instruction Book

Safety Advice 3-4

Electrical Requirements 4

Features - Get to know the main parts of your Dryer 5

Where to put and vent your Dryer 5

How to use your Dryer 6

Sorting your laundry 7

Wash Care Labels 8

Items requiring special attention 9

The Controls 10

Guide to Drying Times 11

How to Remove and Clean the Fluff Filter 12

Caring for your Dryer 12

If something goes wrong 13

If it still won’t work 14

Contents

Retention of this Instruction Book

This Instruction Book must be kept handy for reference as it contains important details on the safe

and proper use of the appliance.

If you sell or pass the appliance to someone else, or move house and leave it behind, make sure

this Book is also provided so the new owner can become familiar with the appliance and safety

warnings.

For your safety

NEVER ● Allow children to play with or otherwise interfere with the dryer.

NEVER ● Allow the air inlet at the back of the dryer,the air outlet or vent hose

to be obstructed.

NEVER ● Direct the vent hose outlet towards the air intake at the back of the

machine.

NEVER ● Allow the tumble dryer to recycle exhaust air.

NEVER ● Switch the machine off leaving a hot load in the drum.

NEVER ●Tumble dry without the filter in position.

NEVER ● Exceed the maximum load capacity recommended or place

dripping wet items in the drum.

NEVER ● Use the dryer on a carpeted floor where the pile height would

prevent air from entering the dryer from the base.

NEVER ● Allow lint to collect around the dryer.

NEVER ● Add liquid or sheet fabric conditioner to the dryer,use liquid

conditioner in the final rinse of your wash.

NEVER ●Use the dryer for commercial drying,the dryer is only suitable for

domestic use.

NEVER ●Dry Acrylics on the high heat setting.

NEVER ●Tumble dry articles that have NOT been well washed in water and

detergent then well rinsed and spun.

NEVER ●Tumble dry articles that have had chemicals used for cleaning.

NEVER ●Dry articles that are contaminated with flammable substances such

as: petrol, oil, paint, hair lacquer, creams, cooking fat or oil.

NEVER ●Tumble dry: rubber, foam rubber, plastic,plastic foam, nappy pants

or liners,polythene or paper.

Large, very bulky items including duvets and sleeping bags.

NEVER ●Never attempt to stand on top of your dryer,it is not designed for

such use and you could injure yourself or damage the dryer by such

abuse.

NEVER ●Switch electricity On or Off with wet hands.

IMPORTANT

Using your Tumble Dryer is easy.

Nevertheless, for your own safety and to get the best results it is important to know your Dryer

by reading right through this handbook before using your dryer for the first time.

A CHILD COULD CLIMB INTO OR TAMPER WITH AN UNATTENDED

TUMBLE DRYER.

WHEN THE MACHINE IS NOT IN USE SWITCH OFF,REMOVE THE PLUG AND CLOSE

THE DOOR.

IMPORTANT

For your safety

ALWAYS ●When the dryer is not in use, switch off, remove plug, and

close the door.

ALWAYS ●Comply with the specified electrical requirements.

ALWAYS ●Ensure that your dryer is installed correctly and has adequate

ventilation.(see“Where to put and vent your dryer”)

ALWAYS ●Use the vent hose for optimum drying performance.

ALWAYS ●Finish every programme with the cool tumble cycle provided on

the control.

ALWAYS ●Clean the filter,it is essential that the filter is kept clear of fluff

at all times.

ALWAYS ●Observe the rules for drying garments:

In particular woollen articles should not be dried in a

tumble dryer unless they are labelled‘Superwash’,

‘Machine washable’ or have the‘May be tumble dried’

symbol:

If in any doubt do not dry wool in the machine.

Unlike other materials,the mechanism of wool

shrinkage is irreversible,i.e.it will not stretch back to

the original size and shape.

ALWAYS ●Buy genuine accessories and spares.

Electrical Requirements

REFER TO THE RATING PLATE FOR VOLTAGE AND CURRENT

REQUIREMENTS.(See diagram for location.)

The dryer should be connected to the mains supply via a suitable socket

which is accessible after installing your dryer.

The wires in the mains lead are coloured in accordance with the

following:

GREEN/YELLOW - EARTH

BLUE - NEUTRAL

BROWN - LIVE

If a replacement plug is to be fitted, the appropriate wire must be

connected to the correct terminal,the cut-off plug must be disposed of

safely. DO NOT leave where it can be inserted into a socket and create a

shock hazard.

Should the mains lead ever require replacing at any time please

contact your nearest Service Centre. A charge will be made for the

replacement of the mains lead or if you require a longer lead.

The mains lead must only be replaced by a specially prepared cable

obtainable from your Spares Stockist and fitted by a qualified

electrician.

WARNING: This appliance must be earthed!

Changing the

mains cable

NOTE: IF IN DOUBT ABOUT ANY OF THE ABOVE CONSULT A

QUALIFIED ELECTRICIAN.

CAUTION:

When the dryer is in use avoid touching the rear of

the dryer as it may be hot!

Features - Get to know the main parts of your dryer

Where to put and vent your dryer

Your tumble dryer should NOT be located adjacent to a gas hob,cook-

er, heater, or eye level grill as flames from the burners could cause

damage to your machine.

The dryer should be placed where air can freely circulate around it,

preferably near a window that can be opened to reduce the possibili-

ty of condensation occuring while the dryer is in use.

When operating the dryer, there has to be adequate ventilation to

avoid the back flow of gases into the room from appliances burning

other fuels,including open fires.

A vent hose is recommended for optimum performance.

DO NOT operate the dryer in an enclosed environment, ensure

the dryer is adequately ventilated.

DO NOT allow clothes, towels etc., to hang down the front of the

dryer into the airstream. This obstructs the airflow and may dam-

age the dryer.

Ensure that the end of the hose is not directed towards the air

intake grille at the rear of the dryer.

NOTE: The vent hose should not exceed 2.4 metres in length, and

should be kept free of any possible accumulation of fluff lint (and

water) by frequently shaking it out. Always ensure that the hose

is not squashed.

●

Filter Assembly

(on inside of the door)

Mains On/Off

Indicator Light

(if fitted)

Heat Selector Switch

Exhaust Air Grille

Door Release

Timer Knob

Window Vent Kit

Wall Hanging Kit

A venting kit is available as an optional extra, which will take the moist air

directly from the dryer and out through an open window.

The venting kit is fitted to the front of the door.

This allows the dryer to be mounted on a wall of suitable strength to take

the weight. Alternatively it should be used when the dryer is mounted on

top of a work surface to secure the dryer to the wall.

WARNING:

DO NOT DISCHARGE THE EXHAUST AIR INTO A FLUE WHICH IS

USED FOR EXHAUSTING FUMES FROM OTHER APPLIANCES

BURNING GAS OR OTHER FUELS.

How to use your dryer

1. Plug in, switch on

electricity. 2. Sort your laundry

(see section “Sorting

Your Laundry”)

3. Open the door.

Check that the fluff

filter is clean

(see section How to

remove and clean

the fluff filter).

4. Load the dryer

placing the clothes

carefully in the

drum, pushing

them well towards

the back and away

from the door seal.

Close the door.

5. Select the

relevant heat setting

(see section “Sorting

your Laundry”).

Push IN for full heat, for cottons, linens and syn-

thetics.

Low setting - button OUT for acrylics and

acrylic mixtures.

6. Turn the Timer clock-

wise to select the required

drying time. (See Section

“The Controls”.)

The dryer will start

7. When finished

open the door and

take out the laundry.

Clean and replace the

fluff filter.

WARNING: WHEN

SWITCHING ON OR

OFF, PLEASE

ENSURE THAT YOUR

HANDS ARE DRY

WARNING: WHEN

SWITCHING ON OR

OFF, PLEASE

ENSURE THAT YOUR

HANDS ARE DRY

Button IN

HIGH HEAT

Button OUT

LOW HEAT

Never switch the dryer off with a hot load in the drum.

You must terminate every programme with the Cool Tumble Phase.

8. Switch off electricity

and remove plug from

socket.

Sorting your laundry

1. Always separate laundry into the correct fabric groups before

washing and drying.

2. See that all zips are closed, hooks and eyes are fastened and belt,

strings etc.are tied loosely in bows, you will normally have done this

for each item before the washing stage.

3. It is important to extract as much water as possible from each

item before drying.This saves you time and money.

4. Make sure that the items to be dried are suitable for tumble

drying, or are not of a type requiring ‘special attention’(see“Wash

Care Labels”section).

Your dryer will hold a load of 3kg (6.6lb) dry weight of natural fabrics. if

you are drying items of man-made fibres (synthetic or acrylics), the

maximum load should not exceed 2kg (4.4lb) dry weight.

This difference is that man-made fibres require more space to tumble-dry

without creasing.

To help you estimate how many items it takes to make up a drying load,

the charts below show the approximate weights of some everyday

washing items.

If you group small cotton or terry-towelling items with a synthetic fabric

load they could be damp at the end of the drying cycle. If this happens

simply give them an additional short period of drying to finish them off.

Maximum

load size

Typical load

WARNING: CLOTHES SHOULD NEVER BE LOADED DRIPPING WET

WARNING: DO NOT OVERLOAD AS THIS COULD RESULT IN

REDUCED DRYING PERFORMANCE AND A POSSIBLE FIRE

HAZARD.

Clothes

Blouse Cotton 150g 5oz

Other 100g 31/2oz

Dress Cotton 500g 1lb 2oz

Other 350g 12oz

Jeans 700g 1lb 6oz

10 Nappies 1000g 2lb 3oz

Shirt Cotton 300g 101/2oz

Other 200g 7oz

T-Shirt 125g 41/2oz

Household Items

Duvet cover Cotton 1500g 3lb 5oz

(Double) Other 1000g 2lb 3oz

Large Tablecloth 700g 1lb 6oz

Small Tablecloth 250g 9oz

Tea Towel 100g 31/2oz

Bath Towel 700g 1lb 8oz

Hand Towel 350g 12oz

Double Sheet 500g 1lb 2oz

Single Sheet 350g 12oz

Wash Care Labels

Most of today’s fabrics can be tumble dried in your Dryer with no

trouble at all, but there are certain fabric finishes which should be dried

away from direct heat.

The majority of garments now have wash-care labels on them, giving full

washing and drying instructions. These should always be followed

carefully especially when you are drying something for the first time.

Typical symbols are:

May be tumble dried

Do not tumble dry

Or:

Tumble dry at high heat setting

Tumble dry at low heat setting

• Those containing foam rubber or rubber-like materials or plastic

film (e.g. pillows,cushions, PVC rainwear), or any other articles which

are inflammable or contain inflammable substances (e.g.towels

contaminated with hair lacquer

• Fibreglass (e.g.some types of curtains)

• Items which have been dry cleaned

• Woollens.Woollen items need as much care in drying as they do

in washing.The movement of the tumble-drying action causes the

woollen fibre to shrink and distort.

• Garments with the ITCL Code (see ‘Items Requiring Special

Attention’).

Do not tumble dry.

• Large bulky items e.g. continental quilts, sleeping bags, pillows,

cushions,double blankets and large bedspreads.These expand

when drying and would prevent airflow through the Dryer.

WARNING: THE DRYER IS INTENDED FOR USE ONLY WHERE

WATER SOLUTION IS USED FOR THE CLEANING PROCESS. MISUSE

OF A TUMBLE DRYER MAY CREATE A FIRE HAZARD.

Items not suitable for tumble drying

Items requiring special attention

The drying requirements of blankets and bedspreads will, of course, vary

tremendously according to size and weight. Some, however are simply

too big. if you have difficulty getting them into the Dryer, the machine will

have difficulty drying them properly. Blankets (and Garments) made from

Acrylic fibres (e.g. Acilan, Courtelle, Orion and Dralon) must be dried with

special care on Low heat setting. Overdrying should be avoided to ensure

heat creasing does not occur.

Your dryer will cope with such clothes very well, but you should always

read the manufacturer’s drying instructions attached to the garment

before you begin.

Starched articles should be dried together in the same load to avoid the

distribution of starch to non-starched items. You should use a slightly

heavier starch solution than you would when drying the items on the

washing line. Make sure that as much of the solution is removed from the

load as possible before placing it in the Dryer.

Remove the items from the dryer as soon as they reach ironing

dampness. If they are overdried the starch will powder, leaving the fabric

limp - which rather defeats the purpose of the exercise!

To make sure all your tumble dried clothes come out really fresh and soft

we recommend you use a liquid fabric conditioner in the final rinse of

your wash. A liquid fabric conditioner restores bounce and softness and

helps eliminate static cling.

Garments with the ITCL Code may be cleaned using one of the Home

Dry Cleaning Kits available.

The instructions supplied with the Home Dry Cleaning Kit must be strictly

followed.

Blankets and

Bedspreads

Permanently

pleated or creased

garments

Starched articles

Fabric conditioner

Home Dry Cleaning

WARNING: ON NO ACCOUNT SHOULD LIQUID FABRIC

CONDITIONER BE ADDED TO THE DRYER ITSELF.

The Controls

Turn the Timer clockwise to select the required drying time.

The drying time for both heat settings is controlled by the timer. All you

have to do is turn the Timer Control clockwise slightly past the required

time and then back to the required time.

Do not rotate the knob beyond 120 (maximum drying time) or past the

zero stop. If you have selected more time than you require turn the knob

anti-clockwise to select the correct time required.

This operation also starts the dryer, provided the door is closed and the

machine is plugged in.The “Guide to Drying Times” section will tell you

how much time you’ll need for various loads.

Setting the timer

Door Release

Heat Selection

Mains Light

(if fitted)

To open door, grip the handle and pull towards you.

If the door is opened while the Dryer is in use, the drying programme cuts

out automatically and the machine stops. When the door is closed the

Dryer will restart but you will not need to reset the Timer Control.

You can however reset the Timer Control at any stage, should you wish.

Select the appropriate button for low heat or for high heat.

With the switch IN High Heat is selected

With the switch OUT Low Heat is selected

The choice of FULL HEAT or LOW HEAT depends upon the fabric you wish

to dry (see section “Sorting your Laundry”)

This light indicates that there is power being supplied to the dryer when

plugged into a suitable socket.

WARNING: CHILDREN HAVE BEEN KNOWN TO CLIMB INTO

TUMBLE DRYERS AND INJURE THEMSELVES. ALWAYS ENSURE

THAT THE MACHINE IS SWITCHED OFF AT THE MAINS WHEN THE

DRYER IS NOT BEING USED.

Table des matières

Autres manuels Creda Séchoir

Creda

Creda HB37549 Guide produit

Creda

Creda HB37567E Manuel utilisateur

Creda

Creda S102GW, S202PW Manuel utilisateur

Creda

Creda HB37513 Manuel utilisateur

Creda

Creda HB37447 Manuel utilisateur

Creda

Creda HB37436 Guide produit

Creda

Creda HB37550 Manuel utilisateur

Creda

Creda HB37551 Manuel utilisateur

Creda

Creda HB37647 Manuel utilisateur

Creda

Creda HB37519 Manuel utilisateur

Creda

Creda HB37679 Manuel utilisateur

Creda

Creda HBT512VW Manuel utilisateur

Creda

Creda T522VW Manuel utilisateur

Creda

Creda HBTCR13 Manuel utilisateur

Creda

Creda TCS3 Manuel utilisateur

Creda

Creda HB37427 Guide produit

Creda

Creda HBT620CW Manuel utilisateur

Creda

Creda HB37496 Manuel utilisateur

Creda

Creda TVS3 Manuel utilisateur

Creda

Creda CT61C Mode d’emploi

Creda

Creda HB37281 Manuel utilisateur

Creda

Creda Tumble Dryer Manuel utilisateur

Creda

Creda HB373 Manuel utilisateur

Creda

Creda 5kg Manuel utilisateur

Manuels Séchoir populaires d'autres marques

Bosch

Bosch WTA79200GB Manuel utilisateur

Amana

Amana W10233410A Manuel utilisateur

Miele

Miele TWH 780 WP Manuel utilisateur

Asko

Asko T760 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manuel utilisateur

Bosch

Bosch Logixx 10 WTB76556GB Fiche technique

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Mode d’emploi

Electrolux

Electrolux EW2H328R2 Manuel utilisateur

Beko

Beko DS8433RX1M Manuel utilisateur

Dawlance

Dawlance Spinner DS 6000 C Manuel utilisateur

Electrolux

Electrolux TP5080TW Manuel utilisateur

AEG

AEG TR838P4OB Manuel utilisateur

Indesit

Indesit IDV 75 Manuel utilisateur

Infiniton

Infiniton SD-DG85C Manuel utilisateur

BOMANN

BOMANN WT 5019 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manuel utilisateur

Asko

Asko T793C Manuel utilisateur

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manuel utilisateur
