Creative MuVo S200 Manuel utilisateur

P/N : 03PF187000000 Rev.A

. . . .

. . .

. . . .

. . .

. .

32. . . .

. . . .

. . .

. .

43. . . .

. . . .

. . .

. .

54.

. . .

. .

. . .

. .

. e

çk

rü

mf.

aL MP

93:5

600

mf.

aL M

P 9

Congratulations ____________________

MuVo®S200 is the new digital player from Creative. Read on to learn how to get started with

your new player!

MIC

REC

4123

678

( )

1. Play/Pause button

Press and hold to turn the player on

and off.

Press once to start playing tracks, and

press again to pause playback.

When your player is locked, press to

turn on the PLED display

2. Record button

Press to make a voice recording in any

screen except FM screen.

Press to make an FM recording in FM

screen.

3. Headphone jack

4. Battery compartment

5. Menu button

For information on using the Menu

button, see “Using the Menu Button”

on page 2.

6. Microphone

7. PLED display

8. USB port

rosemary d qsb.fm Page 1 Wednesday, February 22, 2006 1:35 PM

Using the Menu Button ______________

We use the term “Select” to mean the following action:

1. Move the Menu button left or right to highlight the option that you want.

2. Press the Menu button to select the option.

Getting Started _____________________

Step 1: Set up software

1. Turn on your computer.

If you have Microsoft®Windows®XP or Windows 2000, you must log in as an

administrator in Windows before you can set up the software. For more information, refer

to your operating system’s online Help.

• Push the Menu button left or right to move between tracks, or push and hold the Menu

button to move within a track.

• Push the Menu button up or down to adjust the volume during playback.

DO NOT connect your player to your computer before setting up the software.

rosemary d qsb.fm Page 2 Wednesday, February 22, 2006 1:35 PM

2. Insert the Installation CD into your CD-ROM/DVD-ROM drive. Your CD should start

automatically. If it does not, follow the steps below:

i. Double-click the My Computer icon.

Alternatively, click Start →My Computer.

ii. Right-click the CD-ROM/DVD-ROM drive icon, and then click AutoPlay.

3. Follow the instructions on the screen and when prompted, restart your computer.

4. When your computer restarts, follow the product registration instructions on the screen.

5. When prompted, connect your player to your computer’s USB port using the supplied USB

cable. Do not press the buttons on your player while connecting it to your computer.

You will require an Internet connection to register your product.

RESET

POWER

MIC

rosemary d qsb.fm Page 3 Wednesday, February 22, 2006 1:35 PM

Step 2: Turn on player

Your player comes preloaded with some music to get you started immediately.

1. Insert a AAA alkaline battery into your player.

2. Press and hold the Play/Pause button until your player turns on.

3. Connect your earphones and move the Menu button up and down to adjust the

volume.

4. When you turn on your player for the first time, the menu will be in English. To change the

language:

i. Press the Menu button. The main menu appears.

ii. Select the Settings option.

iii. Select the Language option, and then Select the language that you want.

5. After you have finished using your player, press and hold the Play/Pause button until

the Power off message disappears.

For more information on using the Menu button, see “Using the Menu Button” on page 2.

AAA battery

rosemary d qsb.fm Page 4 Wednesday, February 22, 2006 1:35 PM

Step 3: Rip and copy music

Rip music from your CD collection to your player, or copy audio files (such as music you have

purchased online) from your computer.

To rip music from your CD collection

1. Double-click the My Computer icon on your desktop.

Alternatively, click Start →My Computer.

2. Double-click the Creative Media Explorer icon.

3. Click the Rip Audio CDs icon.

4. Follow the instructions on the screen.

Album information is automatically retrieved if you are connected to the Internet, and have

registered with a music information provider like CDDB®.

To copy audio or data files from your computer

1. Make sure your player is connected to your computer as shown on page 3.

2. Double-click the My Computer icon on your desktop. You will notice that your player is

recognized as a Removable Disk.

3. Double-click the Creative Media Explorer icon.

4. Click the Browse Data icon.

5. Copy files using the drag-and-drop or copy-and-paste method.

Step 4: Disconnect player

When disconnecting your player from your computer, always use the Windows Eject or

Safely Remove Hardware icon on the Taskbar. If not, your player may not function normally.

Follow these steps below to safely disconnect your player.

To safely disconnect your player in Windows XP, Windows 2000 or Windows Me

1. Click the Safely Remove Hardware icon on the Taskbar.

rosemary d qsb.fm Page 5 Wednesday, February 22, 2006 1:35 PM

2. Select Safely remove USB Mass Storage Device, and disconnect your player when you

are prompted to do so.

To safely disconnect your player in Windows 98 SE

1. On your desktop, right-click the My Computer icon and select Explore.

2. Right-click the Removable Disk icon and select the Eject option.

3. Make sure that this status diagram appears on the display for at least five seconds before

disconnecting your player.

rosemary d qsb.fm Page 6 Wednesday, February 22, 2006 1:35 PM

Playing a track______________________

1. Press and hold the Play/Pause button until your player turns on.

2. Press the Menu button. The Options menu appears.

3. When you turn on your player for the first time, the display will be in English. To change

language:

i. Select the Settings option.

ii. Select the Language option, and then Select the language that you want.

4. Select the Music option.

5. Select a track. The track plays back automatically.

Locking your player _________________

Locking your player disables the functions of all buttons and the Menu button on your player.

Locking your player is useful when you do not want to accidentally activate functions on your

player.

1. Press the Menu button. The main menu appears.

2. Select the Lock option.

The lock icon appears at the top right corner of the display.

3. To unlock your player, press any button and Select the Unlock option.

rosemary d qsb.fm Page 7 Wednesday, February 22, 2006 1:35 PM
