Craig CHT923 Manuel utilisateur

Bluetooth

Sound Bar with

Built-In subwoofer

WARNING:Changes or modifications to this unit

not expressly approved by the party responsible

for compliance could void the user’s authority to

operate the equipment.

NOTE: This equipment has been tested and

found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide

reasonable protection against harmful interference

in a residential installation. This equipment

generates, uses, and can radiate radio frequency

energy and, if not installed and used in

accordance with the instructions, may cause

harmful interference to radio communications.

However, there is no guarantee that interference

will not occur in a particular installation. If this

equipment does cause harmful interference to

radio or television reception, which can be

determined by turning the equipment off and on,

the user is encouraged to try to correct the

interference by one or more of the following

measures:

•Reorient or relocate the receiving antenna.

Increase the separation between the

equipment and receiver.

Connect the equipment into an outlet on a

circuit different from that to which the receiver

is connected.

Consult the dealer or an experienced radio/TV

technician for help.

•

FCC Warnings

This equipment complies with FCC radiation exposure

limits set forth for an uncontrolled environment.

This equipment should be installed and operated with

minimum 20 cm between the radiator and your body.

This transmitter must not be collocated or operating

in conjunction with any other antenna or transmitter

unless authorized to do so by the FCC.

WARNING˖To reduce the risk of fire or electric shock,

do not expose this apparatus to rain or moisture. The

apparatus shall not be exposed to dripping or splashing

and that objects filled with liquids, such as vases, shall

not be placed on apparatus.

25.CAUTION: Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type.

26.WARNING: The mains plug is used as disconnect device, the

disconnect device shall remain readily operable.

27 This equipment is a Class II or double insulated electrical appliance.

It has been designed in such a way that it does not require a safety

connection to electrical earth.

28.Use of the apparatus in moderate climates.



Insert the AC plug (with the 2 blades) into a conveniently located

AC outlet having AC 100-240V~, 50/60 Hz.

2. Mounting the Speaker Bar onto a wall

We recommend having this speaker professionally mounted. By using the included

wall mounting accessories, the sound bar can be mounted onto a wall.

Distance Between Two Brackets

1. Placing on the table

Ventilation

When placing the Sound Bar on an entertainment center, bookshelf, or any type of

enclosed space, be sure to allow at least 2-3 inches of space around the Sound Bar

for ventilation. If the Sound Bar is enclosed in a tight space, without ventilation, heat

generated from the Sound Bar could produce a potential heat hazard.

16 inches

AC Plug

AC~

Note: The AC plug supplied with the unit is

polarized to help minimize the possibitity

of electric shock. if the AC plug does not

fit into a nonpolarized AC dutlet,do not

file or cut the wide blade ,it is the user’s

responsibility to have an electrician

replace the obsolete outlet.

2.1. Mounting on the wooden wall

You should use

1. Mark the position of the mounting screws on the wall using a pencil.

2. Put the sound bar onto the mounting brackets. Make sure they are firm and stable.

You may use

2.2. Mounting on the wall

2 pieces of plastic tubes

(Included)

2 pieces of short screws

(Included)

2 pieces of short screws

(Included)

1. Mark the position of the mounting screws on the wall using a pencil.

2. Drill 2 x 0.315” holes by a powerful electric drill.

3. Insert the supplied 2 plastic tubs into the holes by hamme

4. Put the SOUND Bar onto the mounting brackets. Make sure they are firm and stable.

(1) (2)

VOLUME +

STANDBY SOURCE MUTE

AC~

AUX R AUX L LINE IN

1. VOLUME -: Press to decrease volume.

2. VOLUME +: Press to increase volume.

3. STANDBY button: Press to turn the sound bar off or on.

4. SOURCE: Press repeatedly to select the input sound to

BT (Bluetooth receiver),AUX, LINE in or FM.

5. MUTE: Press to mute the sound, press again to resume.

6. AUX L/R IN jacks.

7. 3.5mm LINE IN jack.

8: Power cord.

9. Mounting bracket.

1. SLEEP: Press to turn the unit to sleep mode.

2. SOURCE: Press repeatedly to select the input sound to

BT (Bluetooth receiver),AUX, LINE in or FM.

3. CLOCK: Press to set the clock.

4. TIMER: press to set the time.

5. MUTE: Press to mute the sound, press again to resume.

6. STANDBY button: Press to turn the unit on or off.

7. :Previous the Fm channel.

8. :Next the Fm channel.

9. Number buttons: press 0-9 to select the radio channel.

10. MEM: press to save the favorable Fm channel.

11. PAIR/ :Press to match your blue tooth device to this sound bar under BT

mode. When play music, press it to pause, Press again to resume.

12. VOICE button: Press to switch to the EQ optimized for dialogue.

13. EQ:

14. MUSIC button: Press to switch to the EQ optimized for music.

15. MOVIE button: Press to switch to the EQ optimized for movie sound.

16. TREBLE buttons: Press to adjust the treble up or down.

17. BASS buttons: Press to adjust the bass up or down.

18. CH + button: Press to skip to next stored channel.

CH - button: Press to skip to previous stored channel.

19. VOLUME + buttons: Press to adjust the volume up.

VOLUME - buttons: Press to adjust the volume down.

1. Push the tab, then slide out the battery tray as the

figure on the right.

2. Replace the old button cell by a new CR 2025

button cell as the polarity markings on the remote

control.

3. Close the battery tray.

To replace the button cell:

7. Do not mix different types of batteries together (e.g. Alkaline and Carbon-zinc) or old

batteries with fresh ones.

PUSH

OPEN

[The remote control supplied with] This product contains a coin/button cell battery. If the

coin/button cell battery is swallowed, it can cause severe internal burn in just 2 hours and

can lead to death.

Keep new and used batteries away from children. If the battery compartment does not

closesecurely, stop using the product and keep it away from children.

If you think batteries might have been swallowed or placed inside any part of the body,

seek immediate medical attention.

If an apparatus contains a user-replaceable COIN/BUTTON CELL BATTERYm either of

the following symbols shall be placed on the apparatus close to the battery compartment:

In addition, there shall be a warning in the accompanying documentation. The warning shall

contain the symbol placed on the apparatus and the following text or equivalent.

WARNING

DO NOT INGEST BATTERY, CHEMICAL BURN HAZARD

Lithium Cell

CR2025

SC UL

45° 45°

Listening from AUX IN jacks:

1. Connect the Aux out jacks from the external audio player (such like DVD player, TV,

VCR …etc.) to the AUX IN jacks on the rear of Sound Bar by the supplied RCA

connection cable as the figure below:

2. Connect the Sound Bar to the power as previous procedures. The Standby indicator

will turn on.

Note: Left=white,

Right=red.

3. Press the Standby ( ) button on the Sound Bar or Remote Control to power on

the Sound Bar.

4. Press the SOURCE button on the unit or Remote Control repeatedly to turn to AUX

mode.

The display will show AUX.

5. Power on the connected external player and start playback as usual.

6. Press the volume buttons to adjust volume level.

7. Press the TREBLE buttons on the Remote Control to adjust treble as desired.

8. Press the BASS buttons on the Remote Control to adjust bass as desired.

9. Press the EQ preset mode buttons MUSIC; MOVIE or VOICE to turn on the preset

EQ effect as desired.

10. Press the MUTE button to turn off the sound, press again to resume.

11. When finished listening, press Standby ( ) button on the Speaker or Remote

Control to power Off (Standby mode) the Speaker.

1. Connect the Headphone/Earphone; Line out jacks from the external audio player

(such like MP3 player; Discman … etc) to the LINE IN jacks on the rear of Sound Bar

by the supplied Line In connection cable as the figure below:

LISTENING FROM LINE IN JACKS:

OPERATION:

AUX R AUX L LINE IN

mp3

red white
