Model: CKR1307

PLEASE READ BEFORE OPERATING THIS EQUIPMENT.

Owner's Manual

UNDERCABINET CD PLAYER

with AM/FM Alarm Clock Radio and

Bluetooth® Wireless Technology

UNDERCABINET CD PLAYER

with AM/FM Alarm Clock Radio and

Bluetooth® Wireless Technology

This equipment must be installed and operated in accordance with provided instructions and

the antenna(s) used for this transmitter must be installed to provide a separation distance of at

least 20 cm from all persons and must not be co-located or operating in conjunction with any

other antenna or transmitter. End-users and installers must be provided with antenna

installation instructions and transmitter operating conditions for satisfying RF exposure

compliance.

PREPARATION FOR USE

Power Sources

Main Unit:

Unwind the AC power cord and extend it to its full length. Insert

the AC plug of the cord into any convenient

AC 120V~ 60Hz household

outlet as the illustrated on right:

NOTES:

This unit is equipped with a polarized AC plug which has one blade wider

than the other. This is a safety feature to reduce the likelihood of electric

shock. This polarized AC plug will only fit in a polarized AC outlet. If you find

that you cannot insert this plug you’re your outlet, you may have an obsolete

non-polarized outlet. Please do not try to defeat this safety feature by using

a non-polarized adaptor or by filling the wider blade to make it fit into your

outlet. If this plug does not fit into your outlet, you should contact a qualified

licensed electrician to replace your obsolete outlet

If the AC power failure, this electronic clock is designed to continue operat-

ing internally (without showing the time on the Clock Display) with three (3)

AAA size batteries (not included). Install the batteries as follows:

Open the battery door on the left side of the

unit by sliding it out and then lifting it as the

illustrated on right:

Insert three (3) AAA size batteries (not

included) according to the polarity diagram

inside the battery compartment. (Alkaline

batteries are recommended.)

Replace the battery door.

PULL

CR2025

OPEN

PUSH

To replace the button cell if it is consume:

BATTERY PRECAUTIONS:

1. Push and slide out the battery tray as the illustrated below.

2. Replace the button cell by a new CR2025 button cell with the polarity “+” face up as

the illustrated below and the marking on the rear of Remote Control.

3. Close the battery tray.

Follow these precautions when using a battery in this device:

1. Use only the size and type of battery specified.

2. Be sure to follow the correct polarity when installing the battery as indicated

in the battery compartment. A reversed battery may cause damage to the

device.

3. Do not mix different types of batteries together (e.g. Alkaline and

Carbon-zinc) or old batteries with fresh ones.

4. If the batteries in the device are consumed or the device is not to be used for

a long period of time, remove the batteries to prevent damage or injury from

possible battery leakage.

5. Do not try to recharge the battery not intended to be recharged; it can

overheat and rupture. (Follow battery manufacturer’s instructions.)

6. Do not dispose of battery in fire. Battery may explodes or leak.

7. Clean the battery contacts and also those of the device prior to battery

installation.

8. This product contains a coin/button cell battery. If the coin/button cell battery

is swallowed, it can cause severe internal burn in just 2 hours and can lead to

death. Keep new and used batteries away from children. If the battery

compartment does not close securely, stop using the product and keep it

away from children. If you think batteries might have been swallowed or

placed inside any part of the body, seek immediate medical attention.

Remote Control:

In first time use, remove and discard the insulation film on the battery compartment

as the illustrated follows:

PULL

PAIRPAIR

PULL

Main Unit:

Remote Controls:

LOCATION OF CONTROLS

STANDB

STANDBY Indicator

Y Button

P-MODE/CLK SET

(Program-Mode/Clock set) Button

DISPLAY Button

LCD Display

FUNCTION Button

AUX IN Jack

TUNING Knob

ALARM Button

10 11 13 17

14 16

PAIR

CD Door Open/Close Button

CD Door

Forward Button

Fast Search Forward/Skip

/PAIR (Play-Pause/BT Pair) Button

Fast Search Backward/Skip Backward

Stop Button

(Remote) SENSOR

VOL - (Volume down) Button

VOL + (Volume up) Button

Battery Compartment

AC Cord

FM Antenna

1. (CD Door) OPEN/CLOSE Button

2. STANDBY Button

3. FUNCTION Button

4. ALARM Button

5. DISPLAY Button

6. CLK SET/P-MODE (Clock set/Program-Mode) Button

7. /PAIR (Play-Pause/BT Pair) Button

8. Fast Search Forward/Skip Forward Button

9. Stop Button

10. Fast Search Backward/Skip Backward Button

11. VOL DN (Volume down) Button

12. VOL UP (Volume up) Button

13. Battery Tray

INSTALLATION

1. Detach the Plastic Assemble

Install the unit to the bottom of cabinet (if need) as follows:

Plate from the top of unit by slide

it to rear of unit as the illustrated:

2. Mount the Plastic Assemble

Plate on the desired location as

follows illustrated:

3. Replace the unit to the

mounted Plastic Assemble

Plate as follows illustrated:

CAUTION:

To reduce the risk of fire, never mount the unit near any heat elements such like

stoves; oven … etc.

OPERATION

GENERAL OPERATION:

ACTUAL TIME SETTINGS:

1. Connected the unit to AC power as instructed earlier. The Red

Indicator will illuminate.

2. Press the Button on the unit or Remote Control to power on the

unit from standby mode. The Red Indicator will not light and the LCD

Display will illuminate.

3. Press the FUNCTION Button on the unit or Remote Control

repeatedly to select the playback source.

4. Press the VOL +/- Buttons on the unit or the VOL DN/UP Buttons on the

Remote Control to adjust volume level as desire.

5. When finished listening, press the Button on the unit or Remote

Control to turn off (standby) the unit. The Red Indicator will illuminate.

To set or reset the actual time:

1. In power off (Standby) mode. Press and hold the P-MODE/CLK SET

Button on the unit or Remote Control approximate 2 seconds until the

digit of Hour on the LCD Display is blinking.

2. Press the or Button on the unit or Remote Control repeatedly to

set hour. (Make sure the PM Indicator appear on the display if the

time is PM and the AM Indicator is appear on the display if the time is

AM).

3. Press the P-MODE/CLK SET Button again, the digit of Minute will

blink.

4. Press the or Button repeatedly to set minute.

5. When finished, press the P-MODE/CLK SET Button to save the

settings and exit. The display will stop blinking.

BT (BLUE TOOTH)

In first time use or re-pairing to a new BT Device, pairing it as below:

1. In standby mode, press the Button to power on the unit.

2. Press the FUNCTION Button repeatedly until the indicator

display and blink.

3. Power on the external BT Device and enter to BT searching mode. Start

pairing as the on screen instructions on the external BT Device. After

paired, the indicator will stop blinking. (For details pairing

procedures, please refer to the user’s manual of your BT Device.).

4. Plays the music in the paired BT Device as usual.

appear on the

When the external BT Device searched the unit, our model number

“CKR1307” will appear on the display of external BT Device.

Pairing code “0000” or “1234” may need to enter.

Notes:

Note:

Normal operation after paired:

CD:

1. Turn on the BT function of the external BT Device.

2. Power on the unit and enter to BT mode as the instructed earlier. The

indicator will appear on the display and blink.

3. Wait a few seconds until the unit auto paired to the external BT Device.

(The indicator will stop blinking).

4. Plays the music in the paired BT Device as usual.

5. During playback:

1. In standby mode, press the  Button to power on the unit.

2. Press the FUNCTION Button repeatedly until “---” or “no” (No Disc)

appear on the display.

3. Press the Button to open the CD door then place a CD disc on the

tray, with the printed label side up.

If the unit already paired to an external BT Device and you wants to pair

the unit to another new external BT Device in BT paired mode.

Press and hold the PAIR/ Button on the unit or Remote Control

approximate 2 seconds until the indicator on the display start

And then pair the new BT Device to the unit as the instructed earlier.

Press the PAIR/ Button to pause; press again to resume normal

playback.

Press the /HR or /MIN Button to skip tracks.



blinking to unpaired it.
