Cradlepoint CBA750B Manuel utilisateur
CRADLEPOINT CBA750B | USER MANUAL Firmware version 5.0
`
Preface
CradlePoint reserves the right to revise this publication and to make changes in the content thereof without obligation to
notify any person or organization of any revisions or changes.
Manual Revisions
Revision
Date
Description
Author
1.0
Mar. 14, 2013
Initial release for Firmware version 4.2
Jeremy Cramer
1.1
Sept. 2, 2013
Updates for Firmware version 4.4
Jeremy Cramer
2.0
Nov. 21, 2013
Updates for Firmware version 5.0
Jeremy Cramer
Trademarks
CradlePoint and the CradlePoint logo are registered trademarks of CradlePoint, Inc. in the United States and other
countries. All other company or product names mentioned herein are trademarks or registered trademarks of their
respective companies.
Copyright © 2013 by CradlePoint, Inc. All rights reserved. This publication may not be reproduced, in whole or in part,
without prior expressed written consent by CradlePoint, Inc.
CRADLEPOINT CBA750B | USER MANUAL Firmware version 5.0
`
Table of Contents
1!INTRODUCTION*.................................................................*3!
1.1! PACKAGE!CONTENTS!.............................................................!3!
1.2! SYSTEM!REQUIREMENTS!........................................................!3!
1.3!CBA750B!OVERVIEW!..........................................................!4!
1.4! CRADLEPOINT!ARC!CBA750B!SERIES!.....................................!6!
2!HARDWARE*OVERVIEW*...................................................*12!
2.1! PORTS,!BUTTONS,!AND!SWITCHES!.........................................!13!
2.2!LEDS!...............................................................................!15!
3!QUICK*START*...................................................................*16!
3.1! BASIC!SETUP!.....................................................................!16!
3.2! ACCESSING!THE!ADMINISTRATION!PAGES!................................!17!
3.3! COMMON!PROBLEMS!.........................................................!18!
4!WEB*INTERFACE*::*ESSENTIALS*........................................*21!
4.1! ADMINISTRATOR!LOGIN!.......................................................!22!
4.2! GETTING!STARTED!–!FIRST!TIME!SETUP!..................................!24!
4.3! QUICK!LINKS!.....................................................................!29!
4.4! CONFIGURATION!PAGES!......................................................!30!
4.5! ENTERPRISE!CLOUD!MANAGER!REGISTRATION!.........................!32!
4.6! IP!PASSTHROUGH!SETUP!.....................................................!33!
5!STATUS*............................................................................*35!
5.1! CLIENT!LIST!.......................................................................!36!
5.2! DASHBOARD!.....................................................................!37!
5.3!GPS!................................................................................!40!
5.4! INTERNET!CONNECTIONS!.....................................................!41!
5.5! ROUTING!..........................................................................!51!
5.6! STATISTICS!........................................................................!52!
5.7! SYSTEM!LOGS!....................................................................!55!
6!NETWORK*SETTINGS*........................................................*56!
6.1! CONTENT!FILTERING!...........................................................!57!
6.2! DHCP!SERVER!..................................................................!61!
6.3!DNS!...............................................................................!62!
6.4! FIREWALL!.........................................................................!65!
6.5! LOCAL!NETWORKS!..............................................................!73!
6.6! MAC!FILTER!/!LOGGING!.....................................................!87!
6.7! ROUTING!..........................................................................!89!
7!INTERNET*........................................................................*90!
7.1! CONNECTION!MANAGER!.....................................................!91!
7.2! DATA!USAGE!..................................................................!115!
7.3!WAN!AFFINITY!AND!LOAD!BALANCING!................................!119!
8!SYSTEM*SETTINGS*..........................................................*123!
8.1! ADMINISTRATION!.............................................................!124!
8.2! DEVICE!ALERTS!................................................................!141!
8.3! ENTERPRISE!CLOUD!MANAGER!...........................................!143!
8.4! SERIAL!REDIRECTOR!..........................................................!145!
8.5! SNMP!CONFIGURATION!...................................................!147!
8.6! SYSTEM!CONTROL!............................................................!150!
CRADLEPOINT CBA750B | USER MANUAL Firmware version 5.0
© 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 2
8.7! SYSTEM!SOFTWARE!..........................................................!151!
9!GLOSSARY*.....................................................................*153!
10!APPENDIX*......................................................................*167!
10.1! REGULATORY!AND!SAFETY!INFORMATION!............................!167!
10.2! WARRANTY,!LIABILITY,!PRIVACY,!ETC.!................................!168!
10.3! SPECIFICATIONS!.............................................................!169!
CRADLEPOINT CBA750B | USER MANUAL Firmware version 5.0
© 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 3
1 INTRODUCTION
1.1 Package Contents
•CradlePoint Cellular Broadband Adapter (CBA750B)
•AC power adapter (12V, 1.5A) WARNING: using a power adapter other than the one provided may damage the
CBA750B and will void the warranty
•Mounting hardware
•CAT5 Ethernet cable
•Setup guide
•Optional: ARC Series includes integrated 3G/4G business-grade modem with modem antennas
oARC CBA750B-LE – 4G LTE / EVDO for Verizon
oARC CBA750B-LP-AT – 4G LTE / HSPA+ for AT&T
oARC CBA750B-LP2-EU – 4G LTE / HSPA+ for Europe
oARC CBA750B-LP – 4G LTE / HSPA+ for Canada
oARC CBA750B-W – 4G WiMAX for Sprint or CLEAR
1.2 System Requirements
•An Internet source: a CradlePoint 3G/4G business-grade modem or broadband data modem (USB,
ExpressCard) with active subscription.
•Windows 2000/XP/7, Mac OS X, or Linux computer.
•Internet Explorer v6.0 or higher, Firefox v2.0 or higher, Safari v1.0 or higher.
CRADLEPOINT CBA750B | USER MANUAL Firmware version 5.0
© 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 4
1.3 CBA750B Overview
WIRELESS WAN CONNECTIVITY
The CradlePoint CBA750B mobile broadband series adapters enable easy-to-install wireless WAN connectivity in fixed-
business locations. For distributed enterprises like branch offices, retail stores, restaurants, and small businesses, the
CBA750B provides 3G/4G wireless network connectivity to keep your business up and running.
FAILOVER MADE SIMPLE
The CradlePoint CBA750B 3G/4G cellular broadband adapter provides IP passthrough capabilities for any device that
requires wireless broadband access. For most applications, simply connect the CBA750B to an existing CPE router
configured for WAN failover, and it’s ready to go. The CBA750B handles the wireless WAN connection through a 3G/4G
modem (included with ARC models) when failover occurs.
PRIMARY CONNECT IS EASY TOO
For temporary networks – or when wired connections are impractical – the CBA750B can serve as a primary-connect
device, converting mobile broadband to Ethernet for point-of-sale tools, digital signs, and kiosks.
KEY FEATURES
• 3G/4G mobile broadband connectivity
• Drop into existing network for a turnkey failover solution
• Remote management capabilities
• Power-over-Ethernet
1.3.1 CradlePoint Enterprise Cloud Manager
Rapidly deploy and dynamically manage networks at geographically distributed stores and branch locations with
Enterprise Cloud Manager, CradlePoint’s next generation management and application platform. Enterprise Cloud
Manager integrates cloud management with your CradlePoint devices to improve productivity, increase reliability, reduce
costs, and enhance the intelligence of your network and business operations. Learn more at http://cradlepoint.com/ecm.
CRADLEPOINT CBA750B | USER MANUAL Firmware version 5.0
© 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 5
1.3.2 CradleCare – Access the Experts 24/7
CradlePoint understands how important and critical network uptime is to your business. We have a knowledgeable
enterprise technical support staff that is available anytime via phone, chat, or email to protect your investment. Our
experts will expedite issue resolution and provide flexible device-by-device solutions to help maximize operational
efficiency. This allows you to dedicate more time to what’s important: your business.
Support
•CradleCare Support Agreement: 24/7 technical support, software upgrades, and advanced hardware exchange –
1, 3, and 5 year options
•CradleCare Extended Warranty: extends the standard warranty to 3 or 5 years
On-Site Services
•CradleCare Standard 3G/4G Site Survey: Comprehensive carrier analysis for optimal performance
•CradleCare Standard Installation: Deploy the experts to ensure a successful installation
Learn more at http://www.cradlepoint.com/products/cradlecare.
CRADLEPOINT CBA750B | USER MANUAL Firmware version 5.0
© 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 6
1.4 CradlePoint ARC CBA750B Series
ARC Series includes a CradlePoint 3G/4G business-grade modem with the CBA750B and creates an
effortless instant network from high-speed wireless broadband.
CradlePoint integrated business-grade modems are specifically designed to provide the highest level of
performance, reliability, and security for 24x7 business-critical applications. Modems can be located and
oriented to receive the highest signal strength.
Choose from the following ARC CBA750B Products:
•ARC CBA750B-LE-VZ – 4G LTE/EVDO for Verizon
•ARC CBA750B-LP-AT – 4G LTE/HSPA+ for AT&T
•ARC CBA750B-LP2-EU – 4G LTE/HSPA+ for Europe
•ARC CBA750B-LP – 4G LTE/HSPA+ for AT&T
•ARC CBA750B-W – 4G WiMAX for Sprint or CLEAR
CRADLEPOINT CBA750B | USER MANUAL Firmware version 5.0
© 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 7
CBA750B-LE-VZ 4G LTE/EVDO for Verizon
Technology: LTE, EVDO Rev A
Downlink Rates: LTE 100 Mbps, EVDO 3.1 Mbps (theoretical)
Uplink Rates: LTE 50 Mbps, EVDO 1.8 Mbps (theoretical)
Frequency Band:
•LTE Band 13 (700 MHz)
•CDMA EVDO Rev A/1xRTT (800/1,900 MHz)
Power: LTE 23 +/−1 dBm, EVDO 24 +/−1 dBm (typical
conducted)
Module: Sierra Wireless MC7750
Antennas: two SMA male (plug), 1 dBi (LTE), 2 dBi
(Cellular/PCS) gain; finger tighten only; maximum torque spec is 7
kgf-cm
GPS: standalone GPS support
Industry Standards & Certs: FCC, Verizon
Modem Model Number: MC200LE
CRADLEPOINT CBA750B | USER MANUAL Firmware version 5.0
© 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 8
CBA750B-LP-AT 4G LTE/HSPA+ for AT&T
Technology: LTE, HSPA+
Downlink Rates: LTE 100 Mbps, HSPA+ 21.1 Mbps (theoretical)
Uplink Rates: LTE 50 Mbps, HSPA+ 5.76 Mbps (theoretical)
Frequency Band:
•LTE Band 17 (700MHz), Band 4 (AWS)
•HSPA+/ UMTS (850/1900/2100 MHz)
•GSM/GPRS/EDGE (850/900/1800/1900 MHz)
Module Power: LTE 23 +/−1 dBm, UMTS 23 +/−1 dBm (typical
conducted)
Module: Sierra Wireless MC7700
Antennas: two SMA male (plug), 1 dBi (LTE), 2 dBi
(Cellular/PCS) gain; support for GPS on aux connection; finger
tighten only
GPS: standalone GPS support
Industry Standards & Certs: PTCRB, FCC, IC, AT&T
Modem Model Number: MC200LP
