CPS BlackMax Series Manuel utilisateur

OWNER’S MANUAL (English)
(Software Version 1.1 or Higher with CPS®Link™App)
2 Valve Series: MD50W, MD50WHE, MD50WVHE
4 Valve Series: MD100W, MD100WHE, MD100WVHE
WIRELESS SERIES
For use with free BLACKMAX® app featuring CPS®Link™
US Patent No. 9,043,161. For Android or iOS mobile devices.
www.calcert.com sales@calcert.com1.888.610.7664 0
5
10
15
20
25
30

2
Overview ...................................................................................................................................2
General Safety Instructions.......................................................................................................3
Controls and Features ........................................................................................................... 4-5
Manifold Accessories................................................................................................................6
Quick Start Instructions (For Use With BLACKMAX Mobile APP).............................................7
BLACKMAX App Home Screen............................................................................................ 8-10
Testing: Pressure or Vaccum Hold ..........................................................................................11
Data Logging...........................................................................................................................12
Help Screen.............................................................................................................................13
Quick Start Instructions (Wireless Manifold without APP) .....................................................14
Initial Operation.......................................................................................................................15
Setting To Zero Pressure.........................................................................................................16
Testing: Pressure or Vaccum Hold .................................................................................... 16-19
Programming/Setting Units ............................................................................................. 19-22
Setting APO On or Off .............................................................................................................22
Connecting to an A/C system..................................................................................................23
Recovering Refrigerant ...........................................................................................................23
Evacuating Procedure .............................................................................................................24
Charging Procedure - Low Side ..............................................................................................24
Charging Procedure - High Side..............................................................................................25
Appendix A (Specifications: Manifold) ....................................................................................25
Appendix B (Specifications: MDXVG Vacuum Gauge Accessory) ...........................................25
Appendix C (Specifications: MDXBK Charger Accessory) .......................................................26
Appendix D (Battery Selection and Replacement)...................................................................26
Appendix E (Cleaning Sensor in MDXVG Vacuum Gauge) ......................................................26
Appendix F (Limited Warranty) ...............................................................................................27
Appendix G (Refrigerants Stored in MD50W and MD100W series) ........................................27
Appendix H (Error Indicator Screens) .....................................................................................28
CONTENTS
OVERVIEW
New Wireless BLACKMAX digital manifolds can be used as conventional, stand-alone
manifolds or can also be used with a free APP allowing a mobile device (running on
iOS or Android platforms) to communicate directly with and control select functions
on these models remotely. The resulting APP provides the HVAC/R technician with the
convenience of running and monitoring a BLACKMAX digital manifold (from up to 300
feet away), while also providing additional capabilities not found in non-wireless versions
(such as comprehensive views of system measurements, graphical depictions of test
functions, data logging, and more). If your mobile device is NOT available, your wireless
manifold may be operated as a stand alone device using the yellow keypad.
www.calcert.com sales@calcert.com1.888.610.7664 0
5
10
15
20
25
30

3
Please read, follow and understand the contents of this entire manual, with special attention given
to Danger, Warning and Caution statements.
FOR USE BY PROFESSIONALLY TRAINED AND CERTIFIED OPERATORS ONLY.
MOST STATES, COUNTRIES, ETC., MAY REQUIRE THE USER TO BE LICENSED.
PLEASE CHECK WITH YOUR LOCAL GOVERNMENT AGENCY.
DANGER: EXPLOSION/RUPTURE RISK!!! Use extreme caution when working with
flammable refrigerants. DO NOT use manifold with unregulated nitrogen,
carbon dioxide or other very high pressure gasses. NEVER USE MANIFOLD
WITH OXYGEN. Unregulated gasses can cause components in a refrigeration
system to rupture. Severe Injury or Death can occur.
DANGER: ELECTRICAL SHOCK HAZARD: Always disconnect power source when servicing
equipment.
WARNING: DO NOT APPLY MORE THAN 900 PSI TO ANY PORT ON MANIFOLD.
FOLLOW ALL EQUIPMENT MANUFACTURER’S TEST PROCEDURES WHEN
SERVICING THOSE SPECIFIC TYPES OF EQUIPMENT.
WARNING: Remove all hoses with care as they may contain liquid refrigerant under pressure.
Contact with refrigerant may cause frostbite or other related injuries. Wear proper
personal protective equipment such as safety goggles and gloves. When disconnecting
any hose, please use extreme caution.
WARNING: Avoid breathing refrigerant vapors and lubricant vapor or mist. Breathing high
concentration levels may cause heart arrhythmia, loss of consciousness, or even cause
suffocation. Exposure may irritate eyes, nose, throat and skin. Please read manufacturer’s
Material Safety Data Sheet for further safety information on refrigerants and lubricants.
NOTE: It may be unlawful to discharge or exhaust refrigerants into the
atmosphere. CPS strongly recommends the practice of recovery or
recycling. Check your local government agencies for refrigerant handling
regulations.
GENERAL SAFETY INSTRUCTIONS
www.calcert.com sales@calcert.com1.888.610.7664 0
5
10
15
20
25
30

4
CONTROLS AND FEATURES - BLACKMAX WIRELESS DIGITAL MANIFOLD
1. [ON/OFF] - Press and hold to turn On or Off
2. [SET] - For entering programed values
3. [REF] (Refrigerant) - Scrolls through 5 pre-selected “favorite” or commonly used
refrigerants
4. [MODE] - Programming (change English vs. Metric units; Turn Auto-Power OFF)
5. [SH/SC] (Superheat, Subcool)- Controls display of Superheat/ Subcool, Saturation
temperatures, and Delta T.
6. [TEST] - Press to obtain either “Pressure Hold” or “Vacuum Hold” tests.
7. [CLR] (Clear)- Sets pressure to zero point . Also ends any test in process.
8. [BACKLIGHT] - Press once to turn light On or Off
9. HIGH SIDE VALVE- Controls flow to right side ¼” SAE male port
10. REFRIGERANT VALVE (MD100 Series Only)- Controls flow through RIGHT MIDDLE
¼” SAE Male Port.
11. SIGHTGLASS- Monitor refrigerant flow
12. VACUUM VALVE (MD100 Series Only)- Controls flow through LEFT MIDDLE 3/8”
SAE PORT.
13. LOW SIDE VALVE- Controls flow to LEFT SIDE ¼” SAE Port.
14. CENTER PORT (MD50W Series Only)- A ¼” SAE Male “T” port used as common
connection to vacuum pump, recovery unit or refrigerant supply tank. The addition
of a ¼” SAE Male “T” fitting with valve core allows for a dual hook up between
vacuum pump and refrigerant supply tank.
15. 9V DC Charger Port - Connection for Accessory MDXBK
16. Vacuum Gauge Accessory Port - Connection for accessory MDXVG
17. Thermistor Sensors - Ideal for taking Superheat and Subcool true temperatures on
round pipes, at any angle
18. Swivel Hook - Heavy Duty 360°
19. Battery Compartment - Uses 4 AA batteries
20. Hose Hangers - For securing ends of unused hoses
21. Connection Points- For (2) thermistor sensors
22. Storage Posts - For thermistor sensors
23. SAE Connection Ports - For SAE Hoses
www.calcert.com sales@calcert.com1.888.610.7664 0
5
10
15
20
25
30

5
CONTROLS AND FEATURES - BLACKMAX WIRELESS DIGITAL MANIFOLD
4 Valve Manifold
(Front)
6.) Test
7.) Clear
8.) Backlight
9.) High Side Valve
10.) Refrigerant
Valve
11.) Sightglass12.) Vacuum
Valve
13.) Low
Side
Valve
1.) On/Off
2.) Set
3.) Refrigerant
4.) Mode
5.) Superheat/ Subcool
21.) Connection Points For
Thermistor Sensors
18.) Swivel Hook
19.) Battery Compartment
20.) Hose Hangers
15.) 9V DC
Charger Port
16.) Vacuum Gauge
Accessory Port
22.) SAE Hose Connection Ports
22.) Storage Posts
4 Valve Manifold
(Back)
www.calcert.com sales@calcert.com1.888.610.7664 0
5
10
15
20
25
30

6
ACCESSORIES
Optional MDXSC Soft Case
• Padded sides
• Rear storage pocket with zipper
• Protective skirt with drawstring
• Holds 7” tablet, instruction
manual, thermistor sensors, etc.
Vacuum Gauge
Accessory
(only available
with MDXVG Kit)
AVT45 Brass
Tee Connector
(Included with
MDXVG Kit)
MDXCP Thermistor Sensor with 6 Ft.
lead for taking Superheat and Subcool
true temperatures on pipes
Vacuum Gauge Accessory Kit MDXVG
U.S. Plug 5 Ft. CordUK/Ireland/
Singapore/
Hong Kong
Plug
Euro Plug
Australia/New
Zealand/China Plug
Universal Charger MDXBK
4 (AA)
Rechargeable
NiMH Batteries
Thermistor Sensor MDXCP Soft Case MDXSC
Included (2)
www.calcert.com sales@calcert.com1.888.610.7664 0
5
10
15
20
25
30

7
Press “>” to go to Home
Screen
1. Download and install the FREE APP for your wireless BLACKMAX Digital Manifold;
• For iOS mobile devices - Navigate to the iTunes APP Store and
download the free BLACKMAX Wireless Digital Manifold APP.
• For Android mobile devices - Navigate to Google Play and
download the BLACKMAX Wireless Digital Manifold APP.
2. Install 4 AA Alkaline (included) or rechargeable batteries in back of manifold.
3. Press and hold [ON/OFF](green button) to turn manifold ON.
4. Open the “BLACKMAX CPS Link” icon from your mobile device.
5. The application will appear on your mobile device screen in landscape mode.
6. Select one BLACKMAX Wireless Digital Manifold to operate.
7. Review and adhere to all safety instructions.
8. Connect the BLACKMAX manifold to an AC system. (see pages 24-26)
9. You are now ready to work.
Indicates
wireless
manifold
has been
detected
If you plan to use the wireless manifold without the free app, go to page 14 for quick start
instructions - manifold only.
QUICK START INSTRUCTIONS (For Use With BLACKMAX Mobile APP)
Scroll Up/
Down to
refresh the
scanning
process
Or Swipe LEFT
here to open
Side Screen
(Help Or Exit)
www.calcert.com sales@calcert.com1.888.610.7664 0
5
10
15
20
25
30

8
Touch
Settings Icon
Left Swipe
From Right
Side Of Screen
And Touch
Settings
Side Menu
BLACKMAX APP HOME SCREEN
Analog Scale
Digital Scale
Current Refrigerant
Home
Screen SettingsData
Logging
Vacuum
Hold
Presure
Hold
Working
Temperature(s)
CHANGE OR CONFIRM SETTINGS
High SideLow Side
Touch arrows
to toggle between
Home Screens
(View 1
Or View 2)
View 1
View 2
OR
Touch icons here to
select any of these
functions
www.calcert.com sales@calcert.com1.888.610.7664 0
5
10
15
20
25
30

9
Open manifold to atmosphere
before each use especially if
manifold has been dropped
or pressurized beyond 800
psig (55 Bar).
!
BLACKMAX APP SETTINGS SCREEN
Select One
Change Language
Zero Offset
Target Superheat
Change Units
Settings
www.calcert.com sales@calcert.com1.888.610.7664 0
5
10
15
20
25
30

10
CHANGE OR CONFIRM REFRIGERANTS
Move screen Up/Down then select a new
active refrigerant.
Note: Refrigerant selected will
become the default (but not affect FAVORITE FIVE.
Changing FAVORITE FIVE refrigerants permanently
must be done using the manifold. See page 21 for
more information)
