IST-3402.PT13.02/A AC999/ User instruction Pag.6/16
CPF Industriale S.p.a Via Enrico Fermi 98 Gussago ( BS ) Tel: 030/31 04 61 Fax: 030/310465
2.2.1. SETTINGS
Press “
ENTER
” to select the instrument’s settings:
•AUTO OFF
•BEEP
•DATA & TIME
•PRINTER
AUTO OFF
:press “
ENTER
” and then
▲
to select
YES.
Press
“
ENTER
” again to confirm. The instrument will turn off
automatically after 5 minutes of inactivity.
To disable the function, select NO and press “
ENTER
” to
confirm.
BEEP (Buzzer)
:press “
ENTER
” and then select “YES” or
“NO” with the
▲
or
▼
arrows. Press “
ENTER
” to confirm.
To disable the buzzer, select NO and press “
ENTER
” to
confirm.
DATE AND TIME
:Press “
ENTER
” to display the date and
time. Use the
▲ ▼
arrows to increase or decrease the value
displayed, starting with the first digit in the top left corner.
Press “
ENTER
” to move the cursor to the right, “
ESC
” to
move the cursor back to the start and “
ENTER
” to confirm.
PRINTER
: press “
ENTER
” and then use the
▲
arrow to
select the current printer.
2.2.2. PRESSURE AND TEMPERATURE
Press “
ENTER
” to display the instrument’s pressure and
temperature readings.
2.2.3. UNIT OF MEASUREMENT
Press “ENTER” to display > “PRESSURE”
Press “ENTER” again to display the configured unit of
measurement. Press ▲ ▼ if you need to select another unit of
measurement: bar, MPas, PSI
Press “ESC” to return to the previous page. Scroll with the ▼
arrow to “>TEMPERATURE”, and press “ENTER” to display the configured unit of
measurement. Press ▲ ▼ to select any other unit of measurement: °C, °F o K
Press “ESC” to return to the previous pages.
