cozze 808779 Manuel utilisateur
1
HEATED BACK & SHOULDER WARMER
Model No: 808779
220-240V, 50Hz
100W
PLEASE READ AND RETAIN THESE INSTRUCTIONS FOR
FUTURE REFERENCE
HEATED BACK & SHOULDER WARMER
2
INSTRUCTION MANUAL
Product Overview
Congratulations on the purchase of this excellent product. This useful
appliance is great to help ease tense muscles around the base of your neck,
the top of your back and the shoulder areas! Using it could not be easier, with a
range of convenient heat settings to choose from.
Key features are:
Easy to use Controller with clear Digital Display of your Temperature Setting.
6 Heat Settings for simple adjustment to your desired temperature.
90 Minute timer with safety shut off.
Overcurrent and Overtemperature Protection with continuous temperature
monitoring.
Comfortable Plush Fleece covering and Cosy Neck band.
Two fastening positions to ensure a snug fit.
Used and cared for in line with the guidance provided within this Instruction
Manual it should provide you with many years of trouble free service.
3
General Description
KEY PARTS
1. Heated Pad
2. Collar Area
3. Collar Fasteners
4. Controller Cord
5. Mains Supply Cord
6. Pad Plug Connector
7. Controller Socket Connector
8. Controller Socket Connector
(Showing Keyways)
9. Controller (KS6-45/90)
2
1
5
9
6
4
7
8
4
3
4
Health and Safety
The use of any electrical appliance requires the application of the following
common-sense safety rules.
Failure to observe these safety rules exposes the user to the risk of personal
injury or the product itself to the risk of damage. These two categories are
denoted by the following conventions:
WARNING: Danger to the person!
IMPORTANT: Damage to the appliance!
Please therefore note the following safety advice.
WARNING: Fire Risk – Most people are aware of the risks of Electrical Fires. Probably
we all know someone who has experienced an issue of this kind, be it major or minor. The
most common causes of these issues are Tumble Dryers, Washing Machines and to a
lesser degree Refrigerators. However, as a responsible Supplier we want to provide you
with the best advice to try and avoid a problem of this kind with any product you buy from
us, no matter how small the risk. Therefore, please take particular note of any warnings in
these Operating Instructions that are followed by “Risk of Fire”.
Location
This appliance is intended for domestic use only. It should NOT be used
for commercial purposes. Such use may damage the product and will
invalidate your warranty.
Do not use the appliance outdoors, or near water.
Mains Cable
The mains cable should reach from the socket to the product without
straining the connections.
When routing the cable, take care to not create a trip hazard. Keep it
away from areas where people will be walking.
5
If the supply cable or controller cable is damaged, DO NOT USE THE
APPLIANCE. The cable must be replaced by a suitably qualified person
with a special cable assembly available from the manufacturer or its
service agent.
Personal Safety
WARNING: To protect against fire, electric shock and personal injury, do
not immerse the cord, plug and / or the controller in water or any other
liquid.
WARNING. This appliance contains no user-serviceable parts. All
repairs must only be carried out by a qualified engineer. Improper
repairs may place the user at risk of harm.
WARNING. Do not use the appliance after a malfunction or if it has
been dropped or damaged in any way.
WARNING. Do not use the appliance for any purpose other than its
intended use.
WARNING. Do not use the product with wet or moist hands.
Only clean your Product after it has been disconnected from the Mains
Supply and allowed to fully cool down.
This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or
instruction concerning the use of the appliance by a person responsible
for their safety.
Children shall not carry out maintenance or cleaning of this appliance.
Children
Never allow a child to operate this appliance.
Children are less able to regulate their body heat than adults. Therefore,
do not allow young children to use this appliance.
Safety Considerations Specifically for this Product
WARNING. DO NOT attempt under any circumstances to remove the
Rating Plate from this product. It contains important information and
6
additionally, removing it may damage the Heated Back & Shoulder
Warmer and expose the user to a risk of electric shock.
WARNING- ANIMALS & PETS. DO NOT under any circumstances allow
your animals or pets to lie on or play with this Heated Product. Cats in particular
can pierce the outer covering and the insulation on the element wire with
potentially fatal results for them and irreparable damage to the Appliance.
WARNING. DO NOT us this Heated Product if it is damp or wet.
WARNING. This appliance is not intended for medical use in hospitals.
WARNING. This Product is intended to be used ONLY as a Personal
Heating Product. Do not attempt to lie on it or use it for any purpose
other than that described in this manual.
WARNING. DO NOT tightly fold the Heated Back & Shoulder Warmer
or place heavy items on it which may cause the heating wire to become
sharply bent. This can result in permanent damage to your appliance.
Risk of fire.
WARNING. DO NOT use in conjunction with any other personal heating
device.
To disconnect, turn off at the wall socket before removing the plug from
the mains outlet.
Unplug from the outlet when not in use and before cleaning. Always
hold and pull the plug, never pull the cord.
WARNING. DO NOT attempt to disconnect the Cord from the Heated
Pad when it is operating.
Allow the appliance to cool before cleaning.
WARNING. DO NOT Dry Clean this appliance.
Never leave the appliance unattended when operating.
WARNING. Do not use this appliance in conjunction with an external
timer or remote control.
IMPORTANT. Examine the Heated Back and Shoulder Warmer
regularly to check for any signs of wear or damage. Should anything be
found, DO NOT use the appliance, contact your Service Centre for
advice.
7
WARNING. This appliance must not be used by persons insensitive to
heat or other vulnerable persons who cannot react appropriately to
overheating.
WARNING: DO NOT insert sharp objects such as pins into the Heated
Pad. Risk of electrocution.
WARNING. DO NOT allow the Controller to come close to any hot
objects such as Electric Fires, Gas Heaters, Radiators etc. There is a
risk of damage to the product.
WARNING. DO NOT place the Controller on the Heated Pad when
operating. This may cause overheating and malfunction.
IMPORTANT. This is a CLASS II Product and as such does not need
to be EARTHED.
HEALTH ADVISORY
Temperature Sensitivity – Persons with poor awareness of
temperature should avoid using an Electric Blanket or other personal
Heated Products for extended periods. This includes but is not
limited to persons suffering from Diabetes where some sufferers can
develop Diabetic Neuropathy leading to numbness and an inability to
sense when something is hot.
Pregnancy – Pregnant women should also exercise caution as there
is some evidence that higher body temperatures associated with the
use of Personal Heated Products for extended periods or at high
temperature settings can be harmful to the foetus.
8
Explanation of Symbols
Read the instructions for use Do not bleach Do not tumble dry
Do not iron Do not dry clean Do not inset pins
Do not use folded or rucked Maximum washing temperature 40°C, mild process
Not to be used by very young children (0-3) years
Electrical Requirements
When using electrical appliances basic safety precautions should always
be followed.
Check that the voltage indicated on the rating plate corresponds with that of
your local network before connecting the appliance to the mains power
supply.
9
How to use your Heated Back & Shoulder Warmer
To begin using your Heated Back and Shoulder Warmer, first, carefully
unpack it and check that it has not sustained any damage during transportation.
Also, check that all the items shown in the PRODUCT OVERVIEW are present.
We recommend that you retain your packaging so that, in the unlikely event of
a fault developing, you are able to return the product in the correct packaging
to ensure best protection.
Before first use
1. Remove all packaging material.
2. Remove any stickers or labels from the appliance. DO NOT remove the
Product Rating Plate.
Preparing for use
1. This appliance is intended to be used a personal heating product and
therefore should always be placed on an individual. It is NOT intended
nor should be used for ANY OTHER PURPOSE.
2. Connect the Controller Socket Connector (7) on the end on the
Controller Cord (4) to the Heated Pad (1), Pad Plug Connector (6),
see the diagram below:
PAD PLUG CONNECTOR CONTROLLER CORD SOCKET CONNECTOR
NOTE: The Keyways (8) of the Socket Connector face downwards.
3. Ensure that the Connectors are pushed fully together.
NOTE: If the Display indicates “P” then you have not correctly inserted
the connector.
10
User Controls
Fig 1: Default Setting Fig 2: Low Setting Fig 3: High Setting
User Controls and Indicators Description
A. 7 Segment Display: This indicates your Heat Setting and can be
adjusted from 1 – 6. (The Default Setting is 3).
B. ON/OFF Switch: Press and hold for approximately three seconds to
turn ON or turn OFF the Heated Pad.
C. Temperature Switch: Press sequentially to adjust the Heat Setting
between 1, 2, 3, 4, 5 and 6.
User Control Markings
A. 7 Segment Display
B. ON/OFF Switch
C. Temperature Switch
A
B
C
