COX MINI BOX BIG BUTTON REMOTE CONTROL Manuel utilisateur
Control your TV and your
mini box™/ Digital Adapter
(DTA) with one remote!
MINI BOX
BIG BUTTON
REMOTE
CONTROL
Part Number 4220-RF Rev 3/16
SETUP GUIDE
UNDERSTANDING
YOUR REMOTE
Pages 4–5
BATTERIES
Page 6
REMOTE CONTROL
MODES
Page 7
PAIRING YOUR REMOTE
Pages 8–9
PROGRAMMING
YOUR REMOTE
Pages 10–11
ADVANCED SETUP
Pages 12–13
FCC NOTICE
Pages 14–15
POPULAR REMOTE
BRAND CODES
Pages 16–21
HAVING TROUBLE?
Visit cox.com/support
TABLE OF
CONTENTS
4
UNDERSTANDING
YOUR REMOTE
CONTROL BUTTONS
1
4
5
6
2
3
8
11
13
9
10
12
14
7
5
1. POWER: Will turn the TV
on and o once you have
programmed the remote
to control your TV
2. SETUP: Press and hold
SETUP for 3 seconds until
the red indicator light
turns on to enter the setup
mode for your remote
3. GUIDE: Will display
program guide
4. COX MENU: Provides
access to main functions
such as Guide, Settings
and Customer Support
5. INFO: Will display
information for currently
selected program
6. DIRECTIONAL PAD: Up,
Down, Right, Left and
SELECT buttons
7. CC: Shortcut to turn
closed captioning on
and o
8. ZOOM: Zoom or stretch
the standard definition
video to fill up the TV
screen size
9. EXIT: Exit current menu
and return to previously
tuned program
10. LAST: Quick access to
the most recently tuned
channel
11. VOL: Controls the
volume once you have
programmed the remote
to control your TV
12. PG/CH: Use to tune
channel up or down and
for navigation in the guide
13. MUTE: Will turn o volume
14. NUMBER KEYS: Use to
enter channel numbers
and Parental Control PIN
6
BATTERIES
Use two AA alkaline batteries.
Check the diagram inside the
battery compartment to ensure
the batteries are inserted facing
the correct direction.
CAUTION: This remote
should be kept out of the
reach of children under the
age of 6 as the batteries are
a choking hazard.
Insert 2 AA
Batteries
Remove
Battery Cover
Back of Remote
7
REMOTE CONTROL
MODES
This remote operates in one
of two modes to control your
mini box (DTA).
IR MODE:
In infrared (IR) mode, the
remote relies on a direct line
of sight to control the mini
box (DTA) via infrared signals.
This remote is already set in IR
mode when you take it out of
the box.
RF MODE:
In radio frequency (RF) mode,
the remote does not require
a direct line of sight. This
allows you to hide the mini box
(DTA) behind your TV or in an
entertainment center. To set
the remote in RF mode, you
must pair the remote with the
mini box (DTA).
After the pairing is complete,
the remote will only control
the mini box (DTA) with which
it is paired. Please note that
using the remote in RF mode
requires you to have an RF
DTA or a mini box with an RF
adapter. If you do not have an
RF DTA or a mini box with an
RF adapter, then your remote
must be used in IR mode.
Note: When the remote is set
in RF mode, it will only control
your RF DTA (or mini box with
an RF adapter) without a line
of sight. To control the TV’s
volume and power functions,
you must always point your
remote at your TV.
8
PAIR YOUR REMOTE
WITH THE RF DTA
1. Turn on the TV using your
TV’s existing remote or the
TV’s power button.
2. Hold the remote in
front of the mini box
(DTA) and press the
COX MENU button on
the remote.
3. Navigate to Customer
Support and press
the SELECT button
on the remote.
4. Navigate to Remote
Control Pairing and
press the SELECT
button on the remote.
5. Press and hold the
SETUP button for 3
seconds until the red
indicator light turns
on, then release.
6. Press the COX MENU
button. The red
indicator light on
the remote will blink
periodically.
7. Enter the 3-digit code
displayed on the TV. If the
code entered is correct, a
confirmation message will
be displayed on your TV.
8. Using your new remote,
try changing channels. If
this works, your remote is
now paired!
9
Note: To pair this remote with
the RF adapter connected
to a mini box, please follow
the instructions provided in
the user’s manual of the RF
adapter (Universal RF4CE
Serial Adapter).
10
AUTOMATIC CODE SEARCH
METHOD A:
1. Turn on the TV using your
TV’s existing remote or the
TV’s power button.
2. Press and hold the
SETUP button for 3
seconds until the red
indicator light turns
on, then release.
3. Press and release the
POWER button. The
red indicator light on
the remote will blink
once and stay lit.
4. Aim the remote at
your TV. Press and
hold the UP arrow to
start the automatic
code search. The red
indicator light will blink
periodically as it searches
for the code for your TV.
When the correct code is
found for your TV, the TV
will turn o automatically.
5. Using your new
remote, press and
release the POWER
button to turn on
your TV. Try changing
the volume and channels.
If this works, your remote
is set up!
PROGRAM YOUR REMOTE
TO CONTROL THE TV
You can program your remote
to conveniently control your TV’s
volume and power functions.
You can do this by using any
one of the following methods.
