Covert NBF22 Manuel utilisateur
Page1
NBF22
Instruction Manual
Page2
Table of Contents
Quick Setup:.............................................................3
Camera button info diagram:...................................4
Installing the batteries ............................................. 6
Installing the SD card ............................................... 7
Customizing the camera settings............................. 9
Setting the camera mode:...................................... 10
Video mode settings:. ............................................ 11
PIR tab:................................................................... 12
SYS tab.................................................................... 16
Viewing photos on the color display:..................... 20
Manually taking photos or video: .......................... 22
Tricks and Tips/Trouble Shooting .......................... 23
Covert Scouting Cameras Warranty:...................... 25
Covert Warranty Policy and Procedure: ................ 25
Covert International Warranty:..............................27
Page3
What You Will Need To Setup
the Camera:
-Minimum of 4 AA Batteries
-(1) 4GB SD Card (Up to 32GB)
Quick Setup:
1. Install batteries and SD card.
2. Turn camera onto setup.
3. Under the SYS tab, set the time and date.
4. Turn the camera on. (The screen will go
black for “power saver” mode.)
Page4
Congratulations on your purchase of the NBF22
Covert Scouting Camera! We truly value your
business and will strive to provide you top quality
customer service should you ever need help with
any of our products. Check out our other products
on our website at www.covertscoutingcameras.com
Covert Scouting Cameras
4338 Greenridge Spa Road
Lewisburg, KY 42256
Page5
Camera button info diagram:
Figure 2
Figure 1
Page6
Installing the batteries
The NBF22 can function short term on 4AA
batteries. We suggest you use 8AA batteries to
maximize camera performance and battery life.
Install the batteries by sliding the top battery in to
the sleeve first, then depressing the spring with the
other battery and snapping down in place. Pay
attention to the (+) or (-) molded into each sleeve to
determine if you insert the positive or negative end
into the sleeve first. Negative battery terminal
always contacts the spring.
Page7
Installing the SD card
To be able to power up the camera you will need to
install a Covert SD card in the slot in the bottom of
the camera. Push into the card slot until it clicks
and release. To remove, repeat that process, the
card will pop out enough to remove. You can use
any SD card size up to 32GB. You must have the SD
card in the camera to be able to turn the camera on
and set it up.
.
Page8
Understanding main screen info:
Camera/Video
icon
Megapixels
chosen
Battery life
indicator
# of photos
taken
# of Megabytes
remaining on
card
Figure 3
Date
Time
Page9
Customizing the camera settings
Your camera is set to function with the default
settings without any further customization.
However, you will likely want to at least set the
clock and date. The following information will help
you customize your camera settings so you can get
the most out of the trail camera experience.
To start, Press the MENU button once to open the
customization menus. We will start with the CAM
system tab. You will see CAM, PIR, and SYS tabs
across the top of the screen. CAM should be
highlighted in white. (Figure 4).
Figure 4
Page10
Setting the camera mode:
Press the ▼button to enter the Camera Mode
option. Either Photo or Video will show up in a
white box. Press the ►button to toggle between
Photo or Video until the option you want shows in
the white box. Press OK to save this setting. The
white box will turn red to indicate it’s saved.
NOTE: If you do not press OK, your setting will
return back to the previous setting.
Camera mode settings:
PHOTO SIZE: Press the ▼or ▲button to enter the
Photo Size option.
Press the ►arrow repeatedly to toggle between
3mp, 5mp, 8mp, 12mp, 16mp and 20mp. Press OK
once the desired option shows in the white box.
Again, the box will turn red.
PHOTO BURST: Your camera can take a 1-10 shot
burst every time the PIR is triggered to take a
photo.
