Countbox STD-1 Manuel utilisateur

User guide

Countbox STD-1

info@countbox.us USA +1 (312) 940-4641 CST UK +44 (203) 769-6450 GMT

User Guide

Version 3.2

CountBOX smart device

Visitors counting video system

This guide familiarizes the user with the technical characteristics and functionality of the CountBOX smart

device visitors counting video system, Version 3.2 (hereinafter CountBOX STD-1).

The documentation includes connection, authentication, setup and operating manuals CountBOX STD-1, a

web interface description of the device, and a chapter dedicated to creating queries with the use of WEB API

for programmers and system administrators.

User guide

Countbox STD-1

info@countbox.us USA +1 (312) 940-4641 CST UK +44 (203) 769-6450 GMT

Contents

Getting started …………………………………………………………………………………………………………………………………..............3

1. Fundamental Principles .................................................................................................................................. 4

2. Technical Requirements and Characteristics .................................................................................................. 5

3. Device Connection and Assembly ................................................................................................................... 6

4. CountBOX STD-1 Startup and Shutdown Process ............................................................................................7

5. CountBOX STD-1 Installation .......................................................................................................................... 9

5.1 Device setup ............................................................................................................................................. 9

5.1.1 "System" tab ................................................................................................................................ 10

5.1.2 "Network" tab .............................................................................................................................. 11

5.1.3 "Miscellaneous" tab ..................................................................................................................... 14

5.2 IP address identification for CountBOX STD-1 ....................................................................................... 17

5.3 Editing CountBOX STD-1 User Accounts ................................................................................................. 18

5.4 Algorithm Setup ..................................................................................................................................... 19

5.4.1 Intersection line setup ................................................................................................................. 19

5.4.2 Object Size Setup ......................................................................................................................... 23

5.4.3 Algorithm checkup ....................................................................................................................... 25

5.5 Generating Reports ................................................................................................................................ 26

5.5.1 Diagram Report ............................................................................................................................ 26

6. Description of LED Indicator Functions ......................................................................................................... 27

7. Factory Reset ................................................................................................................................................ 29

8. CountBOX STD-1 software interface reference ............................................................................................ 31

8.1 Web API ………........................................................................................................................................ 31

8.1.1 API access address....................................................................................................................... 31

8.1.2 Authentication….......................................................................................................................... 31

8.2 API requests ……..……………………………………………….................................................................................. 31

8.2.1 Locations………………………………………….......................................................................................... 32

8.2.2 Finances ……………........................................................................................................................ 33

8.2.3 Visitors ………………………………………………….................................................................................... 39

8.2.4 Profile ……………………………………………………................................................................................... 46

8.2.5 Errors…………………………………………................................................................................................ 48

Appendix A. Interface description .................................................................................................................. 50

Appendix B. Possible error codes in error_id field …….................................................................................... 53

User guide

Countbox STD-1

info@countbox.us USA +1 (312) 940-4641 CST UK +44 (203) 769-6450 GMT

Getting started

The CountBOX STD-1 is designed for counting visitors in various public places, such as banks, offices

or shops — any place where attendance analysis is required.

This device captures and processes video data and records results in an embedded database

(hereinafter DB). It is also possible to see CountBOX STD-1 results in the form of a diagram and

report.

User guide

Countbox STD-1

info@countbox.us USA +1 (312) 940-4641 CST UK +44 (203) 769-6450 GMT

1. Fundamental Principles

The CountBOX STD-1 operating principle consists of counting visitors passing through the coverage

zone of a video camera. The calculation is carried out in two directions: incoming and outgoing. The

general number of incoming and outgoing visitors is recorded in a DB. The statistics can then be

used in any number of ways according to the user’s demands.

CountBOX STD-1 performs the following functions:

1. Collects statistics

2. Saves statistics in DB

3. Displays statistics in CountBOX STD-1 web interface in the form of a diagram

4. Exports statistics to reports in XML/CSV format.

CountBOX STD-1 combines the following functions:

1. Receiving video images (fig. 1.1)

2. Accessing web interface (fig. 1.2)

3. Video analysis (fig. 1.3)

4. Device status indication (fig. 1.4)

5. DB storage (fig. 1.5)

6. Automatic restart in case of failure/hang-up (fig. 1.6)

7. Factory reset (fig. 1.7).

Figure 1: CountBOX STD-1 functions

User guide

Countbox STD-1

info@countbox.us USA +1 (312) 940-4641 CST UK +44 (203) 769-6450 GMT

2. Technical Requirements and Characteristics

In order to provide the CountBOX STD-1 with good working capacity, there are certain requirements

for throughput, device voltage and the user’s computer software. See table 1 for the description of

technical requirements.

Table 1: Technical requirements

Requirement type

Characteristic type

Property value

Hardware requirements

Throughput At least 2 Mbit/s

Connection method UTP–based Ethernet network

Voltage

PoE 802.3af, class 0

Minimum screen resolution

1024x768

Software requirements

Compatible browsers

Mozilla Firefox

—

28.0

Google Chrome —

33.0.1750.154m

Safari — 6.0.5 (8536.30.1)

Internet Explorer —

8.0.7600.16385;

9.0.8112.16421;

10.0.9200.16844

Browser plugins JavaScript, Cookies

Device ports available to the

browser

for http protocol — 80; 1024

— 32668

for https protocol — 443

Time synchronization with NTP server

User guide

Countbox STD-1

info@countbox.us USA +1 (312) 940-4641 CST UK +44 (203) 769-6450 GMT

3. Device Connection and Assembly

Assembly of the CountBOX STD-1 should be carried out in accordance with the following

requirements:

1. The device must be installed over a doorway with a height of 2.7-5 meters (with lenses

adjustment up to 15 meters).

2. The device’s optical axis must be oriented perpendicular to the floor.

3. Device coverage zone must not be narrower than a hallway (corridor), where counting of visitors

will take place.

Device connection to the local network is carried out with the help of a PoE–injector1. All the device

power and local network requirements are listed in chapter 2, "Technical Requirements and

Characteristics". The connection scheme of CountBOX STD-1 to the local network is shown in fig. 2.

Figure 2: Connection scheme of CountBOX STD-1 to the local network

After assembly and connection, in accordance with the scheme, are finished (see fig. 2), the

CountBOX STD-1 is ready for setup.

1 Power over Ethernet (PoE) — a technology to power the end device through regular Ethernet twisted pair

wires combined with network information.

User guide

Countbox STD-1

info@countbox.us USA +1 (312) 940-4641 CST UK +44 (203) 769-6450 GMT

4. CountBOX STD-1 Startup and Shutdown Process

Authorization in CountBOX smart device web interface is required for CountBOX STD-1 startup.

Follow the steps below to authorize:

1. Enter the IP address in browser’s address bar 1 (http://192.168.10.10 by default). If the IP address

is unknown or has been lost, you can define it by searching CountBOX STD-1 in the network2.

2. Enter user name/password3 in the authorization window (fig. 3) of CountBOX STD-1 web interface

(fig. 3.1):

a) admin/admin for the administrator

b) user/user for the user

The " " button is displayed during entering the password. This button is used to view the

password. It is necessary to press and hold the button the required time to view the password.

3. Click "Login" (fig. 3.2).

Figure 3: Authorization window of CountBOX STD-1 web interface

As a result, the CountBOX STD-1 web interface is displayed (fig. 4).

1Information about compatibility of CountBOX STD-1 software with browsers is provided in chapter 2,

"Technical Requirements and Characteristics".

2 Information about CountBOX STD-1 IP address definition is provided in chapter 5.2, "IP address

identification for CountBOX STD-1 ".

3Information about account settings is provided in chapter 5.3, "Editing CountBOX STD-1 User Accounts".

User guide

Countbox STD-1

info@countbox.us USA +1 (312) 940-4641 CST UK +44 (203) 769-6450 GMT

Figure 4: CountBOX STD-1 web interface

For CountBOX STD-1 shutdown, click "Logout" in the upper right corner

User guide

Countbox STD-1

info@countbox.us USA +1 (312) 940-4641 CST UK +44 (203) 769-6450 GMT

5. CountBOX STD-1 Installation

CountBOX STD-1 installation is performed by device and algorithm setup. Device setup includes the

following steps:

1. System settings setup

2. Network settings setup

3. Users’ accounts editing.

Algorithm setup includes the following steps:

1. Intersection line setup

2. Object size setup

3. Algorithm checkup.

5.1 Device setup

CountBOX STD-1 setup is carried in the "Device" tab (fig. 5.1). This tab also contains information

about the device model (fig. 5.2) and firmware version (fig. 5.2).

Figure 5: "Device" tab

Description of the "Device" tab is given in table 2.

User guide

Countbox STD-1

info@countbox.us USA +1 (312) 940-4641 CST UK +44 (203) 769-6450 GMT

Table 2: Description of the "Device» tab

Number in

fig. 5 Tab name Description

3 System Used for setting the date, time and CountBOX STD-1 name

4 Network Used for network connection setup and obtaining

CountBOX STD-1 domain name

5 Update Used for CountBOX STD-1 firmware update

6 Miscellaneous Used for getting log-files, DB cleanup and CountBOX STD-1

reload

5.1.1 "System" tab

The "System" tab (fig. 6.1) is used for setting the date, time and device name. It also contains

information about the CountBOX STD-1 serial number.

Figure 6: "System" tab

Description of the "System" tab is given in table 3.
