Air Cooler
CAC-PD63ECO
1
In order to avoid dangers caused by misoperation and use the
machine more conveniently, please pay attention to the following
precautions which are indicated by icons. Please get familiar with the
icons below, and read the Operating Instructions.
WARNING:
1. This appliance in not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning the use of appliance by a
person responsible for their safety.
2. Cleaning and user maintenance shall not be
made by children without supervision.
3. If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualified persons in order
to avoid a hazard.
4. Unplug the appliance during filling and
cleaning.
5. The appliance is only for household and
indoor use.
Safety Warnings and Precautions
2
Symbol Meaning Description
Warning
Indicate that could result in death or
serious injury, or property damage
General
prohibition
Indicate the behaviors that must be
absolutely prohibited
Must
Obey
Indicate the content that must be
enforced
If the product has problem,
please send it to the repair
station or notify the service
center. Do not disassemble
or replace parts without
permission.
Disassembly and alteration
without permission will affect
the safety of the product.
Do not touch the power cord
with wet hands.
Risk of electric shock.
Disassembly
prohibited
Electric
shock
Do not
touch
3
Never insert wood sticks,
metal sticks and other
objects into the air inlet and
outlet.
It may lead to current
leakage, short circuit and
product damage.
Do not spray insecticides or
flammable sprays around the
product.
It may cause damage to the
product.
Avoid direct blowing to
children for long time.
It may lead to child sickness
or affect the health.
Do not pull the cord when
unplug the power plug.
It may damage the power
cord and cause current
leakage and other hazards.
Electric
shock
General
prohibition
General
prohibition
General
prohibition
Electric
shock
General
prohibition
4
Make sure that no foreign
matter is adhered to the
power plug and insert the
plug completely.
It may cause current
leakage.
Exception handling
If there is any peculiar smell
or abnormal sound when
using the product, stop it
immediately and disconnect
the power.
Do not use the product if the
power cord is exposed or
damaged.
It may cause current
leakage, short circuit and fire
hazard.
If the power cord is
damaged, it must be
replaced by qualified
personnel of the
manufacturer, repair or
similar departments in order
to avoid hazards.
Do not bend the power cord
or place heavy objects on it.
It may cause current
leakage.
Electric
shock
Must
Obey
Must
Obey
Electric
shock
Must
Obey
Electric
shock
Must
Obey
5
The water level of the tank
mustn’t exceed the maximum
level. When the cooling or
humidification function is
turned on, the water level
shouldn’t be lower than the
minimum level.
Do not tilt or impact the
device when placing or
moving it after filling water, in
order to prevent water
spilling.
If the product has ever
inclined and there is water
inside, immediately pull out
the plug, and dry 24 hours
before starting again.
If you go out or the device
won’t be used for a long time,
turn it off and unplug the
power cord from the outlet.
Do not use the device if
children, animals or persons
lack of self-control are
unattended.
Only use the power outlet
that meets the requirements
and the load capacity of the
outlet shouldn’t be lower than
10A/250V.
Make sure that the supply
voltage and the voltage
designated on the nameplate
are consistent.
Confirm the voltage when the
device is moved.
Electric
shock
Must
Obey
Electric
shock
Must
Obey
Must
Obey
Must
Obey
6
When the tank is filled with
water, do not lift the product
by holding the handle, or else
the water in the tank will
overflow. Please push the
handle. If there is no water or
little water in the tank, you
can hold the handle to lift the
device.
During humidification, do not
remove the air filter and wet
curtain bracket.
It may cause water droplets
ejection from air outlet.
Do not turn the blades with
hands, or else it will damage
the synchronous motor
Must
Obey
General
prohibition
7
1. Wind mode: normal, natural, sleep, and smart
2. Third levels: high, medium, and low
3. Humidifying / cooling
4. Timing shutdown: schedule time increases by 0.5h; maximum
schedule time 8H
5. Wind direction: 360° rotation of the blades
6. Electronic key control, digital tube displays timing and
temperature
7. Infrared remote control
8. Full pumping water tank, easy to clean
9. Ultra large high quality wet curtain with high evaporation and
good cooling effect
10.Spray water circulation cooling technology, large recycling
capacity, faster cooling
11.Power failure protection; tank water shortage protection
12.Double air filtration
13.Universal front caster wheel design
Functions and Features
8
Product structure
1. Button 2. Blade
3. Function display window 4. CD grain decorative sheet
5. Front shell 6. Water level display window
7. Universal casters 8. Handle
9. Remote repository 10. Back shell
11. Air filter 12. Reel
13. Power cord 14. Water tank
15. Casters 16. Tank lock
Accessory
Remote control
Names and Functions of Parts
9
Operation pane
Display panel diagram
The operation panel of the remote control is subject to the
importing country.
