Cord Tech CEVM2T2 Manuel utilisateur
MODEL: CEVM2T2
Mode 2, Type 2
Portable EV Charger - Instruction Manual
1
Before Use
•Read all instructions & warnings carefully.
•Check the specifications of your electric vehicle to ensure compatibility.
•Fully uncoil lead prior to charging.
•Check for damage, if damaged in any way DO NOT USE.
2
Intended Use
This product is intended for TEMPORARY charging of portable electric vehicles. It is
not intended to be used as a permanent charging solution.
3
Warnings
•Your Mode 2 CordTech charging lead plugs directly into a 10Amp power socket:
•We recommend consulting a registered electrician to assess that your socket
outlet/power circuit can support this. Older wiring or heavily “loaded” power
circuits can present issues as this is a high-power device.
•Do not modify this product in any way.
•Do not wire directly into a mains supply.
•Do not submerge the control box or charging connector in water.
•Do not step on, pull, fold or knot the cable.
•Keep away from high temperature objects during charging.
•Ensure the charging cable is not a tripping hazard during use.
•The 10Amp Plug (which connects to the wall outlet) is not waterproof and must
always be used indoors or suitably waterproofed.
•If this product is damaged in any way cease use immediately, either discard or
consult a registered electrician.
•Caution must be taken when using this product to prevent risk of electric shock.
4
Vehicle Compatibility
•COMPATIBLE WITH TYPE 2 CONNECTIONS found on
multiple EV makes and models including Tesla, Audi, BMW,
Toyota, Hyundai, Jaguar, Porsche, Nissan, Volkswagen,
Volvo, Citroen, Land Rover, Mercedez, Mini Cooper,
Renault, Kia and more*
*Not all makes and models will be available in your region.
Scan this QR Code on this page for our most up to date model
list.
5
Start Charging
1) Uncoil the charging lead, insert the 3 pin plug into a wall outlet. Ensure it is
securely connected and not loose.
2) Gently remove the socket cap off the Type 2 (Mennekes) plug, connect to your
vehicle inlet. Ensure the plug is securely connected and not loose.
3) The device will start charging automatically while the READY/CHARGE, POWER
indicators are all green.
NOTE: The default current setting is 8A, press the "CURRENT SETTING" to adjust to
your required current. The current will increase by 1A each time you press, the
maximum output is 10Amps.
1) Disconnect the Type 2 Plug from the vehicle inlet.
2) Close the protective cap of vehicle inlet.
3) Place the protective cap onto the Type 2 (Mennekes) plug.
4) Disconnect the plug from the wall outlet.
5) Store your Charging cable.
6
Stop Charging
CEVB –Storage Bag (Sold Separately)
7
Indicator Lights
LIGHT INDICATOR STATUS
FAULT
Off Normal
On Short Circuit Protection
Flash Once Leakage Current Protection
Flash Twice Input Wiring Defect
Flash Thrice Plug Overheating
Flash Quartet Over Current Protection
Flash Quintet CP Signal Defect
Flash Sextet Control Box Overheating
Flash Septet Relay Adhesion
READY/CHARGE
On Charging
Flash Connected but Not Charging
Off Not Connected
POWER
On Input Normal
Flash Input Over Voltage
Off Input Under Voltage
6A On Output Current:6A
Flash Output Current:7A
8A On Output Current:8A
Flash Output Current:9A
10A On Output Current:10A
8
Specifications
CordTech 5M EV Cable Mode 2 Type 2 (6A, 8A, 10A)
Model
CEVM2T2 (PEC
-002)
Output Current
6A min.
–10A max.
Rated Power
2.4Kw Max
Input Voltage
166
-288V 50/60Hz
IP Rating
Control box: IP67
Type 2 Connector: IP55
10A Plug: Not IP Rated
Protection
Short circuit protection
Leakage current protection
Over voltage and under voltage protection
Over and under frequency protection
Over current protection
Over and under temperature protection
Ground protection
Surge protection
Operating Temp
-
30℃~+50℃
Storage Temp
-
40℃~+80℃
Operating Humidity
20%
-85%
9
Maintenance
•Wipe clean regularly, do not use abrasive chemicals or detergents.
•Ensure the product is stored in a dry location.
