Cooper Scantronic 750r Manuel utilisateur

750r

Radio Siren Installation Guide

Zo installeert u draadloze sirene

Sirène radio manuel d’installation

Funksirene Installationsanleitung

Sirena Radio Manuale di Installazione

Radio Siren Guía de instalación

Sirene via Rádio Guia de Instalação

Radiostyret sirene Monterings-

vejledning

Radio Siren Installationshandbok

Radiostyrt alarm Installasjons-

veiledning

Radiosireeni Asennusohje

497291 Issue 2

For further detail and Declaration of Conformity please go to www.coopersecurity.co.uk.

This product complies with the requirements of European Directive: 1995/5/EC (Radio &Telecom-

munications Terminal Equipment Directive).

Ce produit est conforme aux exigences de la directive européenne : 1995/5/EC (Equipements

terminaux de radio et de télécommunication).

Dit product is conform de normen van de Europese Richtlijn 1995/5/EC (R&TTE Richtlijn)

Questo prodotto è conforme ai requisiti della Direttiva Europea: 1995/5/EC (Radio&Telecommunic

ations Terminal Equipment Directive).

Dette produkt er i overensstemmelse med kravene i EU-direktivet: 1995/5/EF (Direktiv om radio-

og teleterminaludstyr).

Dette produktet overholder kravene i EU-direktivet: 1995/5/EC (Radio &Telecommunications Ter-

minal Equipment Directive, R&TTE).

Den här produkten uppfyller kraven i EU-direktivet: 1995/5/EG (direktivet för radioutrustning och

teleterminalutrustning).

Dieses Produkt erfüllt die Anforderungen der europäischen Richtlinie 1995/5/EG (Richtlinie für

Funkanlagen und Telekommunikationsendeinrichtungen).

Este producto cumple con los requisitos de la Directiva Europea 1995/5/CE (Directiva de equipo

de terminal de radio y telecomunicaciones).

Este produto está conforme os requisitos da Directiva Europeia: 1995/5/CE (Directiva sobre Equi-

pamento de Radiocomunicações e Terminal de Telecomunicações).

Tämä tuote täyttää EU:n direktiivin 1995/5/EY (Radio- ja telepäätelaitedirektiivi) asettamat vaa-

timukset

750r

Radio Siren

Installation Guide

750r

Page ii 497291

Contents

Introduction............................................................................... 3

Overview ..................................................................................3

Technical Specification............................................................... 4

General.................................................................................................... 4

Security ................................................................................................... 4

Radio....................................................................................................... 4

Power Supply............................................................................................ 4

Electromagnetic Compatibility ..................................................................... 5

Electrical Safety ........................................................................................ 5

Compatible Equipment................................................................ 5

Installation ................................................................................ 6

Location ...................................................................................6

Teaching the Siren to the Control Unit ..........................................7

At the Siren:............................................................................................. 7

At the control unit: .................................................................................... 8

Physical Installation ...................................................................9

Safety Warning ....................................................................................... 10

At the Control Unit................................................................................... 10

750r

497291 Page 3

Introduction

Overview

The 750r is an external siren and strobe unit designed to

work with the Homelink 75 security system

Fitted within a Polycarbonate plastic enclosure are a 90dB

siren, radio transceiver operating on 868MHz, battery pack

and strobe light. The unit can be mounted on any vertical

surface up to 100m from a Homelink 75 control unit. (Note

that the range may vary depending on the site conditions.)

This Guide shows the procedure required to install the radio

siren and program the control unit to operate the siren in an

alarm.

To gain access to the battery compartment pull off the lower

cover.

1. Sound aperture 5. Battery trim cover

2. Fixing screw for transparent battery cover. 6. Fixing bracket

3. Battery compartment and transparent cover 7. Siren

4. Fixing holes (front and back view) 8. Tamper arm

Figure 1. Main Features

750r

Page 4 497291

Technical Specification

General

Product name 750r

Manufacturer Cooper Security Ltd

Environmental This product is compliant with EN

50130-5 environmental class I

Operating temperature Tested -10 to +55°C

Humidity 93% RH

Dimensions 272mm W, 207mm H, 80mm D

Weight 1.71 kg (without batteries)

Case material Polycarbonate

Security

Security Grade This product is suitable for use in

systems designed to comply with

EN 50131-1 at grade 2

Radio Supervision Programmable at control unit.

Radio

Radio Section Operating frequency

868.6625MHz Narrowband.

I-ETS 300 220.

CE tested to I-ETS 300 339 (draft

standard).

Transmitter range The range of the control unit

compatible with this siren

depends on the environment in

which they are both installed. As

a guideline, most units will work

up 100m range in free space

conditions.

Power Supply

Batteries 4 x 1.5V LR20 Alkaline (not

supplied).

Monitoring includes Battery low voltage.

750r Technical Specification

497291 Page 5

Electromagnetic Compatibility

Immunity Conforms to EN50130-4.

Emissions Conforms to EN61000-6-3:2002

Electrical Safety

Conforms to EN60950-1:2002.

Compatible Equipment

7500rEUR-00 Homelink 75 control unit.

750r

Page 6 497291

Installation

Before installing the siren carry out a radio site survey. Use

the 790r signal strength meter and test transmitter to make

sure that radio reception is adequate at the proposed sites for

the control unit and siren.

Location

DO site the siren:

a) So that that there is a clear space around the case to allow

it to receive a good quality radio signal.

b) As high as possible to make sure an intruder cannot

interfere with it. Make sure the unit can be seen and heard

easily. Do not place the unit facing heavy traffic or a

railway line, which will drown the sound of the sounder.

Do NOT site the siren:

a) Outside the area covered by the alarm system.

b) Near ground level.

c) Close to or on large metal structures, for example: metal

doors or frames, water tanks, cars, fridges and freezers.

d) Closer than one metre to mains wiring and metal water or

gas pipes.

e) Inside steel enclosures.

f) Next to high voltage electrical equipment, or electronic

equipment, particularly computers, photocopiers or other

radios.

Exposure to Radio Frequency Radiation

The radiated output power of this device is below those levels

considered safe by European exposure limits. Nevertheless,

when fitting the product place it in such a manner as to

minimise the potential for human contact during normal

operation. To minimise exposure, users should be more than

200 mm from the device during normal operation.

750r Installation

497291 Page 7

Teaching the Siren to the Control Unit

You will need to “teach” the identity of the radio siren to the

Homelink 75 control unit. It is better to do this before

physically installing the siren in its final position.

At the Siren:

Remove battery trim

cover.

Remove transparent

battery cover.

Insert batteries.

Note: The siren emits a

loud tone (“beep beep”) as

you apply power.

Replace transparent

battery cover.

Installation 750r

Page 8 497291

At the control unit:

1. Enter installer mode.

2. Select “Other Devices”.

3. Select “External Siren Menu”.

4. Select “Add/Del Ext Siren”.

The display shows a list of the positions available for

learning external sirens. If a “ ” icon appears at the end

of a line then that position is already assigned to an

external siren.

5. Use the scroll key to select the position you want to use,

and then press “Select”.

The display shows “Activate Ext Siren Tamper”.

Activate the tamper arm on

the siren.

The control unit display shows “Siren Added Signal

Strength” and a number.

The number represents the signal strength of the radio

transmission from the siren, measured by the control

unit. For successful operation the number should be

higher than 3 when the siren is mounted in its final

position (see page 10).

7. Press “Back”.

The display shows the list of external sirens. The siren

you have just made the control panel learn should now

show the “ ” icon.

Note: Do not leave installer mode until you have fitted the

siren in its final position.
