Cooper Lighting VRM Manuel utilisateur

FAIL-SAFE®

ARCHITECTURAL VANDAL RESISTANT

COOPER LIGHTING

DIMENSIONS DESCRIPTION

The Fail-Safe VRMC, VRM and

2VRM Series ﬂuorescent

luminaires combine a low

proﬁle, surface modular design

with the latest in energy-

efﬁcient technology. Their

Energy Saving Ballast

complies with Federal Energy

Efﬁciency Standards while a

dihedral recessed top allows

for cooler operation. Other

features include a die-formed

housing, surface or stem

mounting (single or

continuous row), full seam-

welded corners and a broad

selection of attractive door

frames. U.L. listed and C.S.A.

certiﬁed.

VRMC

VRM

2VRM

1' x 4', 2' x 2', 2' x 4'

2, 3, OR 4 LAMPS

VANDAL RESISTANT

LUMINAIRE

• Housing is die-formed code

gauge prime CRS. Smooth

sides permit ﬂush joints

when continuous row

mounting. Die-formed

captive lampholder

brackets

• Ballasts are CBM/ETL Class

“P” and positively secured

by mounting by mounting

bolts. Pressure lock

lampholders

• Electrostatically applied

baked white polyester

powder enamel ﬁnish

• Positive cam action steel

latches with baked white

enamel ﬁnish

• Die formed, heavy gauge,

ﬂat steel door with

reinforced mitered corners

and baked white enamel

ﬁnish. Positive light seals.

Frame and lens are secured

to housing with 4 or 6

stainless steel TORX®

screws

For additional options, consult your Cooper Lighting Representative.

Specifications and Dimensions subject to change without notice.

MOUNTING

ABC

VRMC 3 15/16" 12" 48"

1' x 4' (100mm) (305mm) (1219mm)

(2 lamp)

VRM 3 15/16" 12" 48"

1' x 4' (100mm) (305mm) (1219mm)

(3 lamp)

2VRM 3 15/16" 24" 24"

2' x 2' (100mm) (610mm) (610mm)

2VRM 3 15/16”" 24" 48"

2' x 4' (100mm) (610mm) (1219mm)

Ballast Type

LE3= Energy Saving

Ballast

LEOC8= Energy Saving

Ballast

(T-8 Lamp Only)

EB_ _= Generic Electronic

Ballast

No. of Ballasts

1or 2

Lamp Size

2=T12

8=T8

5=T5 Biax

(For speciﬁc electronic

ballast specify brand and

catalog number)

ORDERING INFORMATION

SAMPLE NUMBER: 2VRM-232A-120V-EB81-U

Width

Blank=1'

2=2'

Series

VRMC=1' Width (2 Lamp)

VRM=1' Width (3 Lamp)

2VRM=2' Width

Number of

Lamps

2, 3, or 4lamps

(Not Included)

LTS=Low

Trigger Start

(20 Watt)

HTS=High

Trigger Start

(20 Watt)

Voltage

120=120V

277=277V

347=347V

UNV=Universal

Voltage 120-277

Wattage (Length)

U6=40W (24")

U6T8=32W (24")

20=20W (24")

17=17W T8 (24")

U1-5/8=31W

T8 (24")

BX40=40W

Biax (24")

40=40W (48")

32=32W T8 (48")

Lens Type

ACTF140 = .140 Thick

ACTF187 = .187 Thick

PA375 = .250 polycarbonate with

.125 prismatic overlay

(standard with 6S

option)

Door Type

Standard=Flat White Steel

Door (Leave Blank)

Options

(add as sufﬁx)

GL=Internal Single

Element Fusing

GM=Dual Element

Fusing

EL4=Emergency Lighting

self-contained

SMB=Side Mounted

Ballast For Stem

Applications .

(Recommended For 4

Point Suspension)

RIF1=Radio Interference

Suppressor

EKO=End Plate with 7/8"

KO (Required for

Continuous Row

Mounting)

RLS=Rotor-Lock Socket

(T8 Lamps Only)

6S=Six TORX-head

Screws(3 per side)

SC=Safety Chain

1431
