Product Instruction Manual
Performance Combo
…………………………………………………….
……………………………………………………..
Power connection
• Connect the power IEC lead into the back of the unit.
• Plug into to the mains supply.
• Switch on power to the unit.
• Press the on / o button on the front panel.
• The unit will then be lit up.
Note: there is a fuse under IEC socket
…………………………………………………….
• FEED a CD printed side up into the slot, the CD can be
CDA format or MP3.
• EJECT - If pressed this will send the disc out.
• SPEED - Turning left enables a slower play speed,
turning right allows a faster play speed. Normal speed is
achieved by turning the control until the centre dent/
notch is felt.
• SOURCE - When the Source key is pressed you can
toggle between the CD, USB and SD CARD READER.
• FOLDER-When in “stop “mode, select the folder to be
played by scrolling through <<back or >> next folder.
When in the “play” mode, you can skip the track being
played to the next or previous track that is in the folders
list by pressing << or >>.
CAUTION If no sound is heard;
• Check the mute button on the CD, if playing from a CD/
USB/SD Card.
• Turn up the master volume & input volume to the
desired level.
Playing a CD/USB/SD Card
Input Mix Levels
• Each audio input has its own volume level, as a starting
point set all to half volume (12 o’clock) then tweak each
one to your desired level (note at 12 o’clock this is already
pre-set).
• E.g. CD volume slightly lower than Microphone so that
your voice can be heard over the music.
• Then use the master volume to adjust the overall volume
Wired Microphones
• Plug in a Coomber 1918 microphone to any of the 4 free
microphone ports (if required the wireless microphone ports
can be used).
• Turn up the control.
Bluetooth
• Turn the unit on.
• Enable Bluetooth on your device– iPod/iPhone etc.
• When discovered Audio Device will be displayed on your
device.
• Select pair or connect on your device.
• An audio notication will be heard and also connected or
paired will be shown on your device.
• You will be able to play music on your device and amplify
it with the Performance Combo.
• Bluetooth range is generally low power Class2 10mtrs
without drop out.
NOTE: If another device is already paired/connected you
will not be able to pair at the same time. You will need to
switch the unit o and on then try again or turn o the
Bluetooth on the other device.
Speakers
Using twist & lock speakon connectors simply locate and
push in to the relevant speaker outlet L & R ideally to a 430
or 429 Coomber speaker.
40W 8Ω per outlet.
…………………………………………………….
