Contour CHD1080p Manuel utilisateur
1
Product Guide
2
Quick Start
About the Camera
aPower Button
bBattery Status
cRecord Button
dRotating Lens
eRecord Status
fMemory Status
gResolution Switch
hUSB
iCharge Indicator
jBattery Latch
kBattery Slot
lMicroSD card
ContourHD1080p
3
Getting Ready
• Open the back door.
• Insert battery with (+) aligned
and close latch.
• Align back door slightly above
camera and slide down until
it locks in.
Power Up
• Push power button.
• Camera beeps and lights turn off.
• You are ready to record.
Note: Power up with record switch
forward to enable silent mode.
4
Record
• Start: slide switch forward.
• Stop: slide switch back.
• Congrats, your first video!
Share
• Install Easy Edit Software directly from MicroSD card provided or
download at: www.VholdR.com/support/software.
• Connect camera to computer with USB cable.
• Set date and time on your camera using the Easy Edit Software
• Then import, clip and share your videos…
Note: HD is beautiful but some computers cannot play smooth HD video. Visit
www.vholdr.com/support for the latest information on computer requirements.
ContourHD1080p
5
Power
Recharge
• Connect to computer with
USB cable.
• Red light indicates charging.
• Charge complete when camera
beeps and red light turns off.
(about 4 hrs)
Power Off
• Press and hold power button
for 3 seconds.
• Double beep & lights turn off.
Note: Camera automatically turns
off after 15 minutes of inactivity.
Video
Use switch under back door to select video resolution.
Default Resolutions:
HI: 1920 x 1080 @ 30 fps
LO: 1280 x 960 @ 30 fps
Alternate Resolutions:
1280 x 720 @ 30 fps
1280 x 720 or 848 x 480 @ 60 fps
Use Easy Edit Software to select alternate resolutions, adjust video
and mic settings, and set camera time.
6
Status
Press power button to check status.
• Record Status
Green = ready
Red = recording
Flashing = memory full or corrupt
• Memory / Battery Available
Green > 80%
Yellow 20-80%
Red < 20%
Error Conditions
• Time invalid: Memory/battery flash red at power on.
• Memory full: (3) beeps, recording stops.
• Memory corrupt: (3) beeps, shuts off.
• No card or memory corrupt: (3) beeps, shuts off.
• Low battery: lights flash, beeps, shut off.
• Battery dead: lights flash, beeps, shut off.
• No beeps: camera in silent mode.
2GB microSD card included. Accepts up to 16GB microSD.
(SDHC compatible)
Note:
Always turn
camera
off before
removing
SD card.
ContourHD1080p
7
Flat Surface Mount
• Unhook leash on base and loop
through camera.
• Slide camera onto rails until
completely forward.
• Adhere mount to flat surface
(top or side of helmet
recommended).
• Hold base, pull camera away,
rotate to align, and press into
mount to reattach.
8
Goggle Mount
• Slide camera on rails until completely forward.
• Press thumb on large tab
(top of mount) and pull camera away.
• Slide goggle strap into base.
• Align vertical angle of camera.
• Snap rails back into
mount over strap.
ContourHD1080p
Thumb tab
9
Align
• Press power button to activate lasers.
• Aim at your hand, a wall, or other object.
• Rotate lens to align lasers horizontally.
• Remove and reorient mount rails to
adjust mount angle. Aim a little high for
the best shot.
10
Cautions and Warranty
This Important Product Information Guide contains regulatory, safety,
handling, disposal and recycling information, as well as the 180-day
limited warranty for your ContourHD1080p Camera.
Read all safety information below and operating instructions before using
ContourHD1080p Camera to avoid injury. For detailed operating instructions and
the latest Important Product Information Guide, go to: www.vholdr.com/support.
WARNING: Failure to follow these safety instructions could result in fire,
electric shock, or other injury or damage.
Battery and Handling
The lithium-ion battery may present a hazard if mistreated. Do not
disassemble, crush, or puncture the lithium-ion battery. Do not immerse
battery in water and store in a cool dry place when not in use. Do not
use or leave battery near a heat source or in direct sunlight.
ContourHD1080p
