Thank you for selecting the DR-1 data reader as the compact disc

transportforyouraudiosystem.Itisideallysuitedforuseincombination

with any of conrad-johnson’s digital/analog converters, to form a com-

pact disc playback system capable of extracting all the detail and

dynamics of the best digital recordings.

At conrad-johnson, we expect our products to be a source of satisfaction

and of pride to their owners for many years to come. Accordingly, circuit

designs, parts and materials for all conrad-johnson products are se-

lected with a view to maintaining optimal performance over the years.

Our reputation for producing among the industry’s most reliable compo-

nents is a natural consequence of this engineering approach.

Although the DR-1 has been designed so that its basic operation is

intuitively apparent, it has a number of sophisticated features which are

fully explained in this manual. Please take a few minutes to read the

manual to better understand the features and capabilities of your DR-1.

In closing, we’d like to welcome you to the family of conrad-johnson

owners. We want you to enjoy your conrad-johnson product to the

fullest. To this end, our staff stands ready to answer any questions you

may have about the function and application of your DR-1, and to

provide any needed service both during, and after the warranty period.

Our goal is to heighten your enjoyment of recorded music.

DR-1 Owner’s Manual 1

Limited Warranty For Conrad-Johnson Components

conrad-johnson design, inc. will provide service under warranty to the

original owner on products sold new in the United States for the lesser

periodofthreeyearsfrom thedateof purchasebythe originalpurchaser,

or five years from the date of shipment to the authorized conrad-johnson

dealer. During the warranty period, conrad-johnson will repair defective

units without charge for labor or parts (with the exception of vacuum

tubes and batteries).

Exclusions. The following are not covered under this warranty:

a) Units which have been damaged by misuse, abuse, or accident.

b) Units which have been modified, altered, or improperly repaired by

anyone not specifically authorized by conrad-johnson design, inc.

c) Units not purchased from an authorized conrad-johnson dealer in the

United States for use in the United States.

d) Normal wear.

e) Incidental or consequential damages are not covered under this

warranty. Some states do not allow the exclusion of incidental or

consequential damages, so this exclusion may not apply to you.

Obtaining Warranty Service:To obtain warranty service, the unit must

be shipped, along with evidence of purchase, in factory packing to

conrad-johnson design (or designated service center) with freight and

insuranceprepaidbytheowner.Afterrepair,theunitwillbereturnedwith

freight and insurance prepaid by conrad-johnson design to any destina-

tion in the United States.

Allimplied warranties,includingmerchantability andfitnessfor aparticu-

lar purpose are limited in duration to the duration of this express

warranty. Some states do not allow limitations on the duration of implied

warranties so the above limitations may not apply to you.

This warranty gives you specific legal rights and you may also have

other rights which vary from state to state.

Conrad-Johnson products purchased outside the United States are

covered by warranty terms of the importing distributor in the country in

which the product was originally purchased, which may differ from the

terms set out herein. Importing distributors are not obligated to provide

warranty service for products originally purchased outside their country.

Conrad-Johnson will provide warranty service for products outside the

DR-1 Owner’s Manual 2

United States, but the customer must pay all shipping, handling and

customs costs both to and from our Service Department.

Questions about this warranty should be addressed to:

Service Department

conrad-johnson design, inc.

2733 Merrilee Drive

Fairfax, VA 22031

The Service Department can also be reached by phone at 703-698-

8581, or by fax at 703-560-5360

Service

If your conrad-johnson audio component requires service, repack it

using the original box and packing material and ship to the Service

Department address above. Boxes and packing materials can be ob-

tainedfrom ourservicedepartment foranominal charge,ifyou nolonger

have yours. Include with the unit a note describing the problem you are

having in as much detail as possible. It is especially important for our

technician to know if the problem is intermittent. If you want an estimate

of cost for out of warranty service, be sure to request it in this note. Be

aware that requesting an estimate will delay service to your unit as we

will have to contact you for your approval before commencing service.

Registering The Warranty

Please return the enclosed card to the factory within 30 days of pur-

chase to register the warranty.

DR-1 Owner’s Manual 3

Installation

Because the DR-1 dissipates very little heat, ventilation is not an impor-

tantconsideration, allowinggreaterflexibility forcustomor built-ininstal-

lations. Of course, reasonable judgement must be exercised to see that

the DR-1 does not obstruct ventilation required by amplifiers or other

equipment in the system. The unit must be mounted horizontally.

All DR-1s sold in the United States are configured for operation on a

60Hz ac power line producing between 108 and 126 volts. Export

versions of the DR-1 will have the correct operating voltage and fre-

quency clearly marked on the back panel of the unit, near the ac power

cord. In all cases, the actual line voltage should be within + 5/- 10% of

the nominal rated voltage.

Electromagnetic Interference (EMI)

Considerable care has been taken in the design of the DR-1 to minimize

it’s susceptibility to radio frequency interference and other forms of EMI.

Choice of materials, physical layout, grounding practice, and power

supply design have all been specified with a view to reducing the impact

of electromagnetic fields on the performance of this unit, and to assure

that it does not radiate fields that might interfere with the operation of

other units.

Careininstallationcan oftenavoidEMIinducedproblems. Thefollowing

practices should generally be observed in any application, and will be

especially important where EMI may be a problem.

Audiointerconnectcables should be kept as short as possible (3meters

or less), and shielded cable should be used (cable which has two center

conductors, and a separate external shield connected at only one end).

Physical location and cable "dress" can be an important factor in mini-

mizing hum pickup. The installation should situate the DR-1 away from

the preamplifier and other sources. Power (ac mains) cords should be

dressed to remain at least 4" (100mm) away from audio signal cables,

and from coaxial digital cables.

DR-1 Owner’s Manual 4

CONNECTION

The outputs from the DR-1 are digital signals only. You must have a D/A

(digitaltoanalog) converter inordertoprovidean analog signalthatyour

stereo system can use. The DR-1 comes standard with a coaxial (RCA)

outputconnector.Useacoaxialdigitalcabletoconnectthisoutputtothe

digital input of your D/A converter. If your DR-1 is equipped with the

Professional Output option, it also has available connectors for AT&T

glass fiber optic cable or balanced (XLR) transmission lines. The choice

will depend on the available inputs on your D/A converter as well as

personal preference.

DR-1 Owner’s Manual 5

CONTROLS

power: This is the main power switch for the CD transport.

o/c (OPEN/CLOSE): Pressing this button will open the CD tray. Press

again to close.

> (PLAY): Pressing this button starts playback of the chosen track. If

a track is already playing, pressing it will restart playback from the

beginning of the track being played. If the CD tray is open, pressing >

will close the tray, and initiate playback.

(STOP): Pressing this button during play will stop playback. Press-

ing it while programming will clear (erase) the program.

|| (PAUSE):Pressing this button interrupts play. PAUSE will light up on

the display. To resume play, press a second time.

<< AND >> : These buttons can be used to select another track during

playor to select the track tostart play with. Briefly pressing the >>button

will move to the next track, while pressing << will move to the previous

track. Pressing and holding these buttons during play will enable fast

search (forward >> or backward <<). These buttons are also used to set

edit parameters (see instructions for tape dubbing, below).

time: This button is used to select between the program time display

options. During playback, the display initially reads the elapsed time of

the track being played (TRACK TIME will be lit above the time display).

Press time once to switch the display to read the time remaining for the

current track (REM TRACK TIME). Press time again to display time

remaining for the entire CD (TOTAL REM TIME). Pressing once again

will return to the initial display of elapsed track time.

prgm (Program): This button is used to initiate and then to close

programming of playback.

clr (Clear): Used to erase a program in its entirety or track selections

from within a program.

review: Displays the program in memory, allowing user to check the

program prior to execution.

DR-1 Owner’s Manual 6

edit:allows user to set up a recording session that will fit within the time

constraints of a particular cassette.

peak: pressing this will cause player to scan the entire CD for the

loudest passage, and when found, will play that passage repeatedly,

allowing recording levels to be set. Press STOP to end.

THE REMOTE CONTROL

PLAY, STOP, PAUSE, <<, and >> are duplicated on the remote control.

These keys on the remote function in exactly the same way as the front

panelcontrols.Thefollowingadditionalcontrolsareavailableonlyonthe

remote control:

NUMBER KEYS 0-9: These keys can be used for direct selection of a

different track during play, a track to begin play with, and tracks for a

program.The second digit in two digit numbers (eg: 12) must beentered

within 2 seconds.

SCAN: Press to automatically play the first ten seconds of each track.

To play a full track, press again, or press PLAY.

REPEAT: Press once before or during play to cause the displayed track

to play continuously. REPEAT 1 will light on the display. Pressing a

secondtime beforeorduring playwillrepeat theentireCD, andREPEAT

will light on the display. Pressing a third time will end the repetition.

VOLUME (+ and -):Digitally adjusts the playback level. Important Note:

when playing HDCD encoded discs with an HDCD D/A converter,

volumelevelmust be set to maximum for the HDCD decoder to operate.

The volume control is a convenience feature which we believe you will

find useful. Be aware, however, that volume should be set to the

maximum level for best sonic performance.

SHUFFLE: Press before or during play to play tracks in random order.

SHUFFLE will light on the display. Press again to return to normal play.

If you elect to repeat the entire cd in SHUFFLE mode, the tracks will be

played randomly each time, except that playback will always begin with

the same track.

DR-1 Owner’s Manual 7

The handheld remote is a battery operated device, using two 1.5 volt

AAA(or RO3, UM4)batteries.Expectedbattery life isapproximatelyone

year.

DISPLAY MESSAGES

The DR-1 is equipped with a six character alpha-numeric display. This

displayshows track and time information during normal playback. Italso

isusedtoprovideotherinformationandinstructionsregardingthestatus

and operation of the machine. Some of the messages you may see are

described in this section.

close: cd tray is being closed.

read: the CD’s contents are being scanned.

nodISC: there is no CD in the player.

noAUdIOdISC: disc in player is a non-audio CD (CD-ROM, CD-I, or

CDV).

notPOSSIbLE: a non-existent track number has been selected.

FULL: you have attempted to program more than 30 tracks.

GO tO PLAY: youhave attempted afunctionwhichrequires that youfirst

start play.

GO tO STOP: you have attempted a function which requires that you

first stop play.

DR-1 Owner’s Manual 8

Standard CD Playback

To play a cd:

-- press power, if unit is not already turned on;

-- press o/c to open the cd tray;

-- place a 3" or 5" audio cd in the tray, printed side up;

-- press o/c to close the cd tray. After initializing, the display will

show the number of tracks and total time of the cd;

-- press > to begin play from the beginning of the cd, or

-- select a track to begin play by pressing >> as many times as

needed to get to the desired track number, and then press

play, or simply select a track number directly by using the 0-9

keys on the remote control (the second digit of a two digit

number must be entered within two seconds of the first digit).

-- play will stop after the final track is completed.

Programming

The DR-1 can be programmed to play up to thirty tracks on a CD in any

desired sequence. To enter a program:

-- if needed cd is playing, press STOP ;

-- press prgm (PROGRAM lights up and flashes);

-- key in desired track numbers using number keys on remote

control. Each time you key in a track number, the number of

tracks and the playing time of your option will be shown under

TRACK and TOTAL TIME on the alpha-numeric display;

-- press PRG to conclude the program;

-- press PLAY to play the program.

You can check the program you have entered by pressing review. The

track/time display will show in sequence the track numbers and track

times for your program. If you press review without having first entered

a program, the display will show NO PROG.

Youcan erase the program while playing by pressingo/c, or by pressing

STOP twice. You can erase a program that is not playing by pressing

o/c, clr (clear), or STOP.

DR-1 Owner’s Manual 9

You can remove a track from the program by stopping play, then

pressing review. When the track number you want to remove is dis-

played, pressclr (clear).

Taping CDs

The DR-1 has special features to assist you in making tape recordings

of your favorite cds. These features are provided solely to assist you in

making legal copies of cds for your own private use. They are not

intended to facilitate illegal copying of copyrighted material.

One particularly useful feature is peak search, which will locate the

loudestpassageonacdandplayitcontinuously(from2secondsbefore

the peak to 2 seconds after), allowing you to set the recording levels on

your tape recorder. To initiate this process, press the button labeled

peak. The process can be concluded by pressing STOP, oro/c.

The DR-1 will also determine for you how many tracks will fit on each

side of a tape, and set up a program to play only those tracks. To use

this feature:

-- press STOP if the cd is playing;

-- press edit to activate edit mode (display shows "EDIT") - this

selects the "normal" edit mode.

-- two modes are available: EDIT (normal) and OPT(imal). EDIT

- will determine which tracks fit on each side of the tape and

will stop on the last track. Tracks will be recorded in the order

in which they appear on the CD. OPT - will calculate the

number and order in which the tracks should be recorded to

best utilize available recording time.

-- if desired, use the << and >> buttons to display OPT(imal), or

CANCEL, or EDIT (normal). With the desired mode displayed,

press EDIT to select. Selecting CANCEL will exit edit mode.

-- the display will now show "C90" which is the default setting.

With the << & >> buttons, other tape lengths may be selected

(options are: C100, C105, C120, C30, C45, C60, C75, or

C90). Press Edit to store the desired recording time.

-- the track number indicator will now show which tracks fit onto

side A of the tape, and the alpha-numeric display will show the

number of tracks and total playing time. Begin recording, and

press >(PLAY) on the DR-1. The transport will play the tracks

DR-1 Owner’s Manual 10

Table des matières

Autres manuels Conrad-Johnson Lecteur CD

Conrad-Johnson

Conrad-Johnson DF2 Manuel utilisateur

Manuels Lecteur CD populaires d'autres marques

RCA

RCA RP-7923 Manuel utilisateur

Pioneer

Pioneer DEH-P3550MP XM Manuel utilisateur

Philips

Philips AZ1207 Manuel utilisateur

Philips

Philips CD582 Manuel utilisateur

Philips

Philips AZ 6821 Manuel utilisateur

Lasonic

Lasonic MSU-2020 Manuel utilisateur

THOMSON

THOMSON RCD150 Manuel utilisateur

Denon

Denon DCD-1420 Manuel utilisateur

Panasonic

Panasonic SJ-MR100 Manuel utilisateur

Onkyo

Onkyo DX-7210 Manuel utilisateur

Sony

Sony MZ-R3 Manuel utilisateur

Denon

Denon DVM-4800 Manuel utilisateur

JBL

JBL MR-32 Manuel utilisateur

RCA

RCA RCD152 Manuel utilisateur

Technics

Technics SL-PS770A Manuel utilisateur

Clarion

Clarion compact disc Manuel utilisateur

Sony

Sony MZ-M10 Manuel utilisateur

Philips

Philips Expanium AZ 1538 Manuel utilisateur
