Concept2 Sentinel S70 Guide de démarrage rapide
1
Thank you for purchasing a Concept Smoke Screen Titanium system. Your
choice to protect your property and premises with this equipment has given
you the use of one of the most effective security systems currently available.
Concept Smoke Screen systems have been in service for over 35 years and
have protected many millions of pounds worth of property, defeating criminals
and securing premises on an almost daily basis.
The Titanium line in particular is home to some incredibly sophisticated and
flexible security fog generators, borne from years of development and
refinement.
Please take the time to read and understand this guide to ensure you achieve
the maximum performance from your Smoke Screen. If you have any
questions that remain unanswered, please call our experts at Concept Smoke
Screen and we will help. Once again, thank you for your decision; we hope
that it’s one that never needs to be tested.
Matt Gilmartin, Managing Director
2
CONTENTS
1
General
5
1.1
1.2
1.3
1.4
1.5
Safety instructions………………………………………………………………………………………………………...…..
How does your Smoke Screen work?……………………………………………………………………………..
Introduction………………………………………………………………………………………………………………………..
Overview…………………………………………………………………………………………………………………………….
Typical installations…………………………………………………………………………………………………............
5
5
6
6
7
4
2
Location
8
2.1
2.2
2.3
2.4
2.5
Positioning………………………………………………………………………………………………………………………….
Installation process…………………………………………………………………………………………………………...
Access………………………………………………………………………………………..……………………………………..
Mounting………………………………………………………………………………………………………………..…………..
Nozzle changing……………………………………………………………………………………………………….……….
8
9
9
10
12
3
Function
13
3.1
3.2
Controlling the smoke……………………………………………………………………....………………………………
Outputs……………………………………………………………………………………….……………………………………..
13
14
4
Connections
15
4.1
4.2
Circuit board layout…………………………………………………………………………………………………………..
Generic connection diagram……………………………………………………………….……………………………
15
16
5
Settings
17
5.1
5.2
5.3
5.4
5.5
5.6
5.7
5.8
Screen
sensor……………….……………………………………………………………………………………………...……
Energy saving mode…………………………………………………………………………………………….……………
Service mode……...………………………………………………………………………….…………………………………
Turbo smoke
mode...……………………………………………………………………….………………………………..
Tamper……………………………………………………………..…………………………………………...…………………..
.
Fluid management………..…………………………………………………………………………………………………..
Battery management………..……………………………………………………………………………………………….
Programming………..…………………………………………………………………………………………………………...
17
17
17
17
18
18
20
21
6
Commissioning
23
6.1
6.2
Operation…………………………………………………………………………………………………………………………..
Testing………………………………………………………………………………………………………………………………..
23
23
3
7
Servicing
24
7.1
7.2
7.3
7.4
7.5
LCD live status indications……………………….…………………………………………………………….………...
LDC, LED and sound indications…………….…………………………………………………………….………….
Thermal cut-out (TCO) reset…………………………………………………………………..…………………………
Action after every activation………………..……………………………………………………………………………
Servicing and fluid replenishment……………………………………………………………………………………
24
26
27
28
28
8
Miscellaneous
29
8.1
8.2
FAQ…………………………………………………………………………………………………………………………………...
Installer notes……………………………………………………………..……………………………………………………
29
30
4
General
1
1.1 SAFETY INSTRUCTIONS
Before installing and using the Smoke Screen read, follow and retain this manual and safety instructions for future
reference.
To reduce the risk of severe injury or death to persons, or damage to the Smoke Screen:
●Do not work on the Smoke Screen unless qualified by the manufacturer to do so.
●Disconnect the mains power supply before working in the heater block compartment or anywhere that mains
voltage is indicated by the warning labels shown below.
●Install in accordance with the instructions in this manual.
●Operate the Smoke Screen only from the type of power source indicated on the label.
●Do not modify the Smoke Screen.
●Adjust only the controls specified in this manual.
●Use only consumables and replacement parts specified by the manufacturer.
●Do not spill liquid of any type on, or inside, the Smoke Screen.
The following signs, or a variation, may be used for safety notices in this manual or on the Smoke Screen:
This type of warning note is
used to indicate possible
electrical shock hazards that
may cause serious injuries or
death.
This type of warning note is
used to indicate the possibility
of injury caused by hazards
other than electrical shock.
1.2 HOW DOES YOUR SMOKE SCREEN WORK?
Your Smoke Screen passes a non-toxic fluid through an efficient heat exchanger to create smoke, or more accurately
a thermally generated fog, that obscures visibility, discouraging intruders from entering your premises.
This fog is very persistent and will stay suspended in the room for a significant length of time until it is vented by
opening the doors and windows.
The Smoke Screen uses a sophisticated electronic control system to ensure it heats up to, and maintains, its ideal
operating temperature using a minimal amount of electricity.
The control system similarly provides a flexible interface with intruder detectors, alarm systems and remote
monitoring centres to ensure that you are always protected and free of inadvertent activations.
5
1.3 INTRODUCTION
This manual covers the Sentinel S70 and S100.
Before commencing installation of the Smoke Screen ensure that you have all of the following equipment supplied in
the box:
●1 x Smoke Screen.
●1 x Mounting bracket.
●1 x Swift-Fit fluid reservoir.
●2 x 12v batteries.
●1 x literature pack and warning sign.
You will also need:
●Mains power supply; an un-switched 13 amp fused spur connected to a dedicated breaker.
●Connections into the alarm panel or other triggering system.
●PIR (or equivalent) to provide the hold-off where required.
1.4 OVERVIEW
The Smoke Screen is designed to form part of an existing intruder alarm system but may also be configured as a
‘stand-alone’ system or as part of a centrally monitored, command and control system. A typical installation is shown
in the following schematic:
6
1.5 TYPICAL INSTALLATIONS
A typical installation can be configured in the following way:
●The Smoke Screen is wall or ceiling mounted in the appropriate location.
●A Hold-off PIR (or similar device) located within the same area as the Smoke Screen providing a confirmation
signal to the Smoke Screen to start, or re-start, ‘smoke’ production.
●A Set command supplied by an alarm control panel, or equivalent, in the form of an N/C (normally closed) or
an N/O (normally open) relay changing state when the alarm system is set for operation.
●A Trigger command supplied by the alarm control panel, or equivalent, in the form of an N/C (normally
closed) or an N/O (normally open) relay changing state when the alarm system confirms an intruder alert.
7
Location
2
2.1 POSITIONING
The Smoke Screen should ideally be sited in a covert position away from prying eyes and thereby reducing the
possibility of tamper or an attack. The ideal place for the Smoke Screen is above a ceiling from where the smoke
plume is used to its best effect, bursting on the ground and spreading outwards and upwards through 360°. If no
suitable ceiling location is available then the next best location is a wall mounting as close to ceiling height as
possible.
Wall-mounting
The optimum wall mounting position for the Smoke Screen is 2.5 metres above the floor facing the area to be
protected and using an appropriate angle nozzle. The maximum recommended mounting-height above floor level is
3 metres, the minimum is 1 metre and there should be no obstacle within 1 metre of the smoke output nozzle.
Ceiling-mounting
The optimum wall mounting position for the Smoke Screen is 2.5 metres above the floor facing the area to be
protected and using an appropriate angle nozzle. The maximum recommended mounting-height above floor level is
3 metres, the minimum is 1 metre and there should be no obstacle within 1 metre of the smoke output nozzle.
8
2.2 INSTALLATION PROCESS
1. Site the Smoke Screen, fix to the wall or ceiling as appropriate.
2. Select the “Service Mode”dip switch to “On”.
3. Make connections as required to the alarm panel and hold-off PIR.
4. Make connection to the Smoke Screen Interface (if used) and set the key switch to isolate.
5. Connect and turn on the mains power.
6. Turn on the internal battery back-up.
7. The Smoke Screen will heat up to operating temperature in approximately 20 minutes.
8. Set correct time/date and smoke timing for the specified room size.
9. Ensure the “Service Mode” dip switch is selected to “Off”.
10. Insert a Swift-Fit fluid reservoir.
11. Make sure all tamper switches are closed.
12. If fitted set the Smoke Screen Interface key switch to ‘Ready’ and you are ready for test.
2.3 ACCESS
To access the PCB connections, programming panel, mounting holes, batteries and fluid, remove the front cover by
unscrewing the set screws on either side and unhooking it from the back plate; refitting is the reverse process.
Installation cable entry is through the serrated grommet on the left back of the back plate.
9
2.4 MOUNTING
The Smoke Screen can be mounted on a ceiling or a wall using the simple standard bracket supplied with the unit.
This flush-fitting bracket maximizes security by concealing all the mounting fastenings such that they can only be
accessed, or the Smoke Screen dismounted, by dismantling the unit. Moreover, the Smoke Screen has a tamper
protection switch to provide an alert in the unlikely event that it is disturbed. In all cases, the installer must attach the
Smoke Screen to the building structure using appropriate fasteners.
NB: When mounting the Smoke Screen ensure that the airflow through the vent holes in the rear of the unit is not
obstructed.
Wall and ceiling mounting
Ceiling or wall mounting is the same process except that rather than fixing the Smoke Screen direct to a ceiling an
intermediate unistrut section may be used or it can be suspended as described in the next section. Attach the
bracket to the wall or ceiling using appropriate fixings.
Carefully hook the slots on the back
of the Smoke Screen onto the
bracket.
Slide along to align the screw fixing
holes. The unit will now hang on the
bracket. Fit, and ensure tight, 4 x M6
set screws with washers in the holes
in the back of the Smoke Screen
alongside each mounting slot.
Access to the fixing holes is through
the fluid and heater block
compartments.
10
