Unpacking & Inspection
Open the shipping carton and check that all equipment necessary to operate the system has arrived intact.
If transit damage is evident, contact your Concept dealer immediately. In addition to this user manual, you
should receive the following items:
-Air Trace MK2 smoke system
-Rechargeable Battery
-Battery charger and cable
-500ml Smoke Fluid
-Extension Spout
-Professional Carry Case (with keys)
Important Notes & Warnings
-Remove the battery / unplug power adaptor before filling the liquid tank.
-Keep the unit upright. Keep this device dry.
-Remove the battery or unplug the power adaptor when not in use.
-This machine is not water proof or splash proof. If moisture, water, or fog liquid gets inside the
housing, immediately remove power and contact Concept before using again.
-No user serviceable parts inside. Refer to your Concept dealer or other qualified service personnel.
-Never leave the unit running unattended.
-Keep nozzle at least 50cm away from contact with anything while in operation.
-The fog vapour at point of release is under pressure and is hot.
-Never aim the output nozzle directly at people.
-Use in a well-ventilated area. Never cover the vents on the front of the smoke machine. Never aim
the output nozzle at open flames.
-The output nozzle becomes hot during operation. Keep flammable materials at least 50cm away
from the nozzle.
-Always allow the smoke machine to cool down before attempting to clean or service it.
-Do not expose the battery to excessive heat, keep away from open flames.
-Only use the supplied Air Trace Smoke Fluid.
-Always make sure there is sufficient liquid in the liquid tank to avoid unnecessary damage.
-If your Air Trace MK2 fails to work properly, discontinue use immediately. Drain all Smoke Fluid
from the tank, pack the unit securely and return it to your Concept dealer for service.
-Always drain Smoke Fluid from tank before shipping or transporting this unit.
-Never drink Smoke Fluid. If it is ingested, call a doctor immediately. If Smoke Fluid comes in contact
with skin or eyes, rinse thoroughly with water.
