COMPX RegulatoR Manuel utilisateur

RegulatoR, Keyless Locking 16

SlamCAM spacer discs (if so equipped) can be inserted between the lock barrel

and SlamCAM mechanism to adjust the backset. See image below:

FlexaCam adaptors (if so equipped) can be attached to the cam to provide up to

12 different dimensional variations. See image below:

Rev. B 1/14

333153000000

RegulatoR, Keyless Locking 1

Instruction Manual

RegulatoR, Keyless Locking 2

Thank you for purchasing the CompX RegulatoR. The RegulatoR is an

innovative solution for locking cabinet doors and drawers. It can mount to

cabinet doors or drawers with a material thickness of 1/32” to 1-7/16”.

code. Operation is simple: type a valid code and press ENTER. Then just turn

the lever to the locked or unlocked position.

RegulatoR is easy to install, and offers:

Programmable user and supervisor codes

Programmable modes of operation

Programmable reset features

RegulatoR is intended for interior use only.

Operating Temperature: 50°F – 120°F (10°C – 48°C)

Note: It is strongly recommended that batteries be replaced on an annual basis.

In the event the batteries should die, they can be replaced via the external battery

compartment.

RegulatoR, Keyless Locking 15

RegulatoR, Keyless Locking 14

Reset User Code to Factory Default 1234

(Does not apply to Single Use Mode)

To reset the User Code to the factory default 1234 follow the steps on page 8to

enter programming mode.

There is a 10 second programming time limit between each step. If RegulatoR

times out or error is made, programming will end and you will need to enter

programming mode again.

1. Place RegulatoR into programming mode (see page 8).

2. Type 8888 and then press the ENTER button.

3. If successful, the green indicator light will illuminate for 1 second.

Continue programming or press 9and then ENTER to exit programming.

RegulatoR, Keyless Locking 3

Packaged Components

CompX RegulatoR is offered in two versions: Manual Lock and Self Lock.

Contents will vary depending on the version.

Contents – Manual Lock Version:

Manual RegulatoR Lock Assembly

2 AAA alkaline batteries

1 Offset locking cam / 1 Straight locking cam

FlexaCam adapters

Mounting hardware

Contents – Self Lock Version:

Self Locking RegulatoR Lock assembly featuring SlamCAM

2 AAA alkaline batteries

SlamCAM spacer discs

Mounting hardware

Each lock contains 2 green stickers that are needed for resetting RegulatoR. In

the event RegulatoR needs reset, one green sticker is placed on the back of the

device. The remaining green sticker should be saved in a safe and secure

location for future reference.

Care and Cleaning

To clean the RegulatoR surface, apply non-acid based cleaner to a clean cotton

cloth; do not spray cleaner directly on the RegulatoR. Wipe down keypad and its

respective housing surfaces of excess cleaner.

RegulatoR, Keyless Locking 4

Powering Up and Battery Installation

CompX RegulatoR is shipped with two AAA batteries. While RegulatoR

features a low battery indicator, annual battery replacement is recommended.

Mixing batteries of different chemistries could damage the RegulatoR resulting

in lock failure.

To power up RegulatoR, remove the red tag. Lock is now ready for use.

A T-15 pin in head Torx

(6-lobe) will be required to remove the battery cover.

(Not Included)

To change batteries:

1. Loosen the retaining

screw.

2. Remove battery cover.

3. Press CLEAR 5 times.

4. Insert new batteries as

shown in the illustration.

5. Reinstall battery cover,

tighten retaining screw.

RegulatoR, Keyless Locking 13

Programming Security Timeout ON / Security Timeout OFF

Warning: Security Timeout ON will disable the RegulatoR from use for 5

minutes when 5 invalid attempts to unlock RegulatoR occur. During this time,

RegulatoR will not unlock with either the valid user or supervisor code.

To change the RegulatoR to Security Timeout ON or OFF, follow the steps on

page 8 to enter programming mode.

There is a 10 second programming time limit between each step. If RegulatoR

times out or error is made, programming will end and you will need to enter

programming mode again.

1. Place RegulatoR into programming mode see page 8).

a. To turn Security Timeout ON, type 11 and then press

ENTER.

b. To turn Security Timeout OFF, type 10 and then press

ENTER.

2. If successful, the green indicator light will illuminate for 1 second.

Continue programming or press 9and then ENTER to exit programming.

RegulatoR, Keyless Locking 12

Programming Single Use Timeout ON / Single Use Timeout OFF

Warning: Manual Lock - Single Use Timeout ON is a feature to prevent users

from occupying a shared use locker or cabinet for a prolonged period of time.

Turning this feature on will disable the user code after a programmable amount

of time. After this time elapses, RegulatoR and can only be opened with the

supervisor code.

To change the RegulatoR to Single Use Timeout ON or OFF, follow the steps

on page 8 to enter programming mode.

There is a 10 second programming time limit between each step. If RegulatoR

times out or an error is made, programming will end and you will need to enter

programming mode again.

1. Place RegulatoR into programming mode (see page 8).

a. To set Timeout ON, type 2XX and then press ENTER.

(XX represents a time period from 04 - 12 in whole hours.)

b. To turn Timeout OFF, type 20 and then press ENTER.

3. If successful, the green indicator light will illuminate for 1 second.

Continue programming or press 9and then ENTER to exit programming.

RegulatoR, Keyless Locking 5

Programming – Introduction

CompX RegulatoR is easy to program and operate. Type the user code (factory

default 1234) and press ENTER to lock or unlock the cabinet.

The supervisor can change operating codes, modes and restore lock settings.

While RegulatoR is easy to program, we highly recommend reading the

complete programming instructions prior to making any changes. Remember to

keep track of any programming changes.

Button locations, indicator lights and knob referenced in the programming

instructions are shown below.

CLEAR button erases any key input made in error

Indicator Lights

Green – Indicates button

input and valid code

Yellow - Indicates low

battery or program mode.

Red – Indicates incorrect

entry

Knob is always rotated

clockwise to unlock ENTER button is used to complete code

and counter clockwise to lock and begin programming

RegulatoR, Keyless Locking 6

CompX RegulatoR is offered with Self Lock featuring SlamCAM. If your lock

is the Self Lock version, follow the directions below to unlock and lock the

RegulatoR:

To operate the Self Lock version of RegulatoR:

Type a valid code, press ENTER and rotate knob

clockwise 90°, hold knob until door or drawer is

open. Release knob, RegulatoR knob will return

to the locked position. Door or drawer can be

closed at any time.

RegulatoR, Keyless Locking 11

CompX RegulatoR features several modes of operation. These functions can be

changed using the following instructions with a valid supervisor code.

Programming Single Use Mode / Standard Mode

Single Use Mode allows for a revolving user code so multiple people may use

the lock without having to reprogram the RegulatoR each time.

Note: This mode cannot be used with Self Lock with SlamCAM.

Standard Mode RegulatoR operates with a fixed code. To change the code,

follow the Changing the User Code steps on page 9.

To change the RegulatoR to Single Use or Standard Mode, follow the steps on

page 8 to enter programming mode.

There is a 10 second programming time limit between each step. If RegulatoR

times out or an error is made, programming will end and you will need to enter

programming mode again.

1. Place RegulatoR into programming mode (see page 8).

a. To turn Single Use Mode “ON”: type 51 and then press

ENTER.

b. To return to Standard Mode: type 50 and then press ENTER.

2. If successful, the green indicator light will illuminate for 1 second.

Note: Returning to Standard Mode will reset the factory user default code

(1234).

Continue programming or press 9and then ENTER to exit programming.

RegulatoR, Keyless Locking 10

Changing the Supervisor Code

To change the supervisor code, follow the steps on page 8to enter programming

mode.

The factory default supervisor code is 12345 (supervisor codes must be 4 to 8

digits in length.)

There is a 10 second programming time limit between each step. If RegulatoR

times out or an error is made, programming will end and you will need to enter

programming mode again.

1. Place RegulatoR into programming mode (see page 8).

2. Press 2and then press ENTER.

3. Type the current supervisor code and press ENTER.

4. Type the new supervisor code and press ENTER.

5. Retype the new supervisor code and press ENTER.

6. If successful, the green indicator light will illuminate for 1 second.

Continue programming or press 9and then ENTER to exit programming.

RegulatoR features a reset code which will restore the default supervisor code

and user code. RegulatoR was shipped with reset stickers; one attached to the

back of the RegulatoR and an extra sticker that should be saved in a safe and

secure location for future reference.

To restore the factory default supervisor and user code, type the Reset Code

assigned to the RegulatoR and press ENTER.

RegulatoR, Keyless Locking 7

CompX RegulatoR is offered in a Manual Lock version. If your lock is the

Manual Lock version follow the directions below to unlock and lock the

RegulatoR.

To operate Manual Lock version of

RegulatoR:

To unlock, type a valid code, press

ENTER and rotate knob clockwise 90°.

To lock, rotate knob 90° counter

clockwise.

RegulatoR, Keyless Locking 8

RegulatoR Programming Mode

To enter programming mode you must know the supervisor code. The default

supervisor code is 12345. Once in programming mode, multiple changes can be

made prior to exiting programming.

There is a 10 second programming time limit between each step. If RegulatoR

times out or an error is made, programming will end and you will need to enter

programming mode again.

1. Lock must be in the locked position prior to entering programming

mode.

2. Type supervisor code and press ENTER.

3. Turn knob clockwise 90° to the unlocked position and press and hold

ENTER for 3seconds (yellow indicator light will illuminate).

•If product is Self Lock with the SlamCAM feature you can

now let go of the knob.

4. With the yellow indicator light illuminated, programming can begin.

RegulatoR, Keyless Locking 9

Changing the User Code

To change the user code, follow the steps on page 8to enter programming mode.

The factory default user code is 1234 (User codes must be 4 to 8 digits in

length.)

There is a 10 second programming time limit between each step. If RegulatoR

times out or an error is made, programming will end and you will need to enter

programming mode again.

1. Place RegulatoR into programming mode (see page 8).

2. Press 1and then press ENTER.

3. Type the current user code and press ENTER.

4. Type the new user code and press ENTER.

5. Retype the new user code and press ENTER.

6. If successful, the green indicator light will illuminate for 1 second.

Continue programming or press 9and then ENTER to exit programming.

Autres manuels pour RegulatoR

Autres manuels COMPX Verrouillage

COMPX

COMPX Stock Locks C425519RL Mode d’emploi

COMPX

COMPX CA-CAM Manuel utilisateur

COMPX

COMPX SW20-3118MC Mode d’emploi

COMPX

COMPX Timberline CB-242 Manuel utilisateur

COMPX

COMPX C8150 Mode d’emploi

COMPX

COMPX TYPE300 Mode d’emploi

COMPX

COMPX Stock Locks C1801 Mode d’emploi

COMPX

COMPX Timberline CB-265 Manuel utilisateur

COMPX

COMPX Timberline CB-265 Manuel utilisateur

COMPX

COMPX Timberlane LR-100 Manuel utilisateur

COMPX

COMPX Timberline D270CB Manuel utilisateur

COMPX

COMPX Timberline CB-D150 Manuel utilisateur

COMPX

COMPX 230SERIES Manuel utilisateur

COMPX

COMPX TuBAR Retrofit for Dresser WayneVista 2 & 3 CAT... Manuel utilisateur

COMPX

COMPX Stock Locks C1802 Mode d’emploi

COMPX

COMPX Timberline CB-245 Manuel utilisateur

COMPX

COMPX TYPE360 Mode d’emploi

COMPX

COMPX Stock Locks C8054 Mode d’emploi

COMPX

COMPX MFW 23118 Mode d’emploi

COMPX

COMPX Timberline CB-280 Manuel utilisateur

COMPX

COMPX MFWPLTT078 Mode d’emploi

COMPX

COMPX Stock Locks C4153 Mode d’emploi

COMPX

COMPX MFW-1118 Mode d’emploi

COMPX

COMPX Timberline CB-284 Manuel utilisateur

Manuels Verrouillage populaires d'autres marques

Magic

Magic 105 Manuel utilisateur

Gantner

Gantner GAT NET.Lock 7020 System Guide rapide

Wittkopp

Wittkopp Insys 7202 Manuel utilisateur

Dorma

Dorma Studio Classic Manuel utilisateur

Securam

Securam ECSL-601 Manuel utilisateur

Sudhaus

Sudhaus 3003 Manuel utilisateur

Safety 1st

Safety 1st 48517 Manuel utilisateur

Pado

Pado FDS-10 Manuel utilisateur

Esco

Esco systeQ Series Manuel utilisateur

secureo

secureo Key Box Manuel utilisateur

Stock Loks

Stock Loks C8713 Manuel utilisateur

Auslock

Auslock T11 Manuel utilisateur

ELCOM

ELCOM 7205 Manuel utilisateur

Stealth SAFES

Stealth SAFES ShadowVault Manuel utilisateur

Knox

Knox KeySecure 5 Manuel utilisateur

Kwikset

Kwikset 48334/01 Manuel utilisateur

Metra Electronics

Metra Electronics Door Access Terminal Combo Manuel utilisateur

Kilitronik

Kilitronik miniK10m Manuel utilisateur
