Compaq ProLiant DL380 G2 Guide de référence rapide

White Paper

Compaq Confidential - Need to Know Required

March 2002

14UH-0701A-WWEN

Prepared by Industry Standard

Server Group

Compaq Computer Corporation

Contents

Executive Summary.....................1

Symbols in Text ...........................3

Symbols on Equipment...............3

Server Warnings ..........................4

Rack Warnings.............................4

Where to Find Information ..........5

Introduction..................................5

Power, Thermal, and Weight

Information.................................10

Power Distribution Units and

Power Cords ..............................11

Console Management

Systems......................................16

Planning Rack

Configurations ...........................19

Installation Procedures .............26

Appendix A −

−−

−Related

Documents .................................34

Appendix B −

−−

−Parts

Reference ...................................35

Appendix C – Power and

Thermal Budgeting....................38

Appendix D −

−−

−Connecting

Multiple Racks ...........................43

Compaq ProLiant DL380

Generation 2 Server

High-Density Deployment in

Compaq Racks

Abstract: This white paper is intended for use as a planning guide

to expedite concentrated deployments of several

Compaq ProLiant



DL380 Generation 2 servers in a Compaq rack.

Use this white paper in conjunction with documents for the

ProLiant DL380 Generation 2 server and Compaq rack deployment

products. This paper is intended for Field Systems Engineers (FSEs)

and customers (IT managers, system managers, account managers,

and installers).

Executive Summary

Many business enterprises and service providers use network

infrastructure and web applications that work best on dedicated

servers. This creates the need to fit a large number of smaller servers

into existing server rooms and data centers. Compaq meets this need

with the density-optimized line of ProLiant servers such as the

ProLiant DL380 Generation 2 server. At a height of 2U each, up to

21 ProLiant DL380 Generation 2 servers can fit in a single Compaq

42U rack. While the ProLiant DL380 Generation 2 server has clear

space saving benefits, its compressed size presents new challenges

for rapid server deployment, as well as cable management and

environmental considerations.

Compaq engineers have developed innovations in rapid high-volume

deployment and improved cable management for large installations

of ProLiant DL380 Generation 2 servers. This white paper

introduces planning, power and thermal considerations, server and

rack requirements, and installation configurations. It also outlines the

products associated with high-volume deployment in Compaq rack

configurations.

IMPORTANT: This document discusses only the ProLiant DL380

Generation 2 server, the Compaq 7000- and 9000-series racks, and

related Compaq rack options. This document does not discuss other

Compaq servers or products or racks not manufactured by Compaq.

Compaq ProLiant DL380 Generation 2 Server High-Density Deployment in Compaq Racks 2

Compaq Confidential - Need to Know Required

14UH-0701A-WWEN

Notice

Compaq, the Compaq logo, and ProLiant Registered in U.S. Patent and Trademark Office. All other

product names mentioned herein may be trademarks of their respective companies.

Compaq shall not be liable for technical or editorial errors or omissions contained herein. The information

in this document is provided “as is” without warranty of any kind and is subject to change without notice.

The warranties for Compaq products are set forth in the express limited warranty statements accompanying

such products. Nothing herein should be construed as constituting an additional warranty.

Compaq ProLiant DL380 Generation 2 Server High-Density Deployment in Compaq Racks 3

Compaq Confidential - Need to Know Required

14UH-0701A-WWEN

Symbols in Text

The following symbols may be found in the text of this guide.

WARNING: Text set off in this manner indicates that failure to follow directions in the

warning could result in bodily harm or loss of life.

CAUTION: Text set off in this manner indicates that failure to follow directions could

result in damage to equipment or loss of information.

IMPORTANT: Text set off in this manner presents clarifying information or specific

instructions.

Note: Text set off in this manner presents commentary, sidelights, or interesting points of

information.

Symbols on Equipment

The following symbols are located on equipment in areas where hazardous conditions may exist.

This symbol in conjunction with any of the following symbols indicates the

presence of a potential hazard. The potential for injury exists if warnings are not

observed. Consult the documentation included with the server for specific details.

This symbol indicates the presence of hazardous energy circuits or electrical

shock hazards. Refer all service to qualified personnel.

WARNING: To reduce the risk of injury from electrical shock hazards, do not

open this enclosure. Refer all maintenance, upgrades, and service to qualified

personnel.

This symbol indicates the presence of electrical shock hazards. The area contains

no user or field serviceable parts. Do not open for any reason.

WARNING: To reduce the risk of injury from electrical shock hazards, do not

open this enclosure.

This symbol on a RJ-45 receptacle indicates a Network Interface Connection.

WARNING: To reduce the risk of electrical shock, fire, or damage to the

equipment, do not plug telephone or telecommunications connectors into this

receptacle.

Compaq ProLiant DL380 Generation 2 Server High-Density Deployment in Compaq Racks 4

Compaq Confidential - Need to Know Required

14UH-0701A-WWEN

This symbol indicates the presence of a hot surface or hot component. If this

surface is contacted, the potential for injury exists.

WARNING: To reduce the risk of injury from a hot component, allow the

surface to cool before touching.

Server Warnings

Adhere to the following guidelines when servicing or installing a Compaq server:

WARNING: To reduce the risk of electrical shock or damage to the equipment:

• Unplug the power cord from the system.

• Do not disable the power-cord grounding plug. The grounding plug is an important

safety feature.

• Plug the power cord into a grounded (earthed) electrical outlet that is easily accessible

at all times.

CAUTION: To properly ventilate the system, provide at least 7.6 cm (3 inches) of

clearance at the front and back of the computer.

CAUTION: The system is designed to be electrically grounded. To ensure proper

operation, plug the AC power cord only into a properly grounded (earthed) AC outlet.

Rack Warnings

WARNING: To reduce the risk of personal injury or damage to the equipment:

• Do not attempt to move or relocate an equipment rack populated with servers. A fully

populated rack can weigh as much as 771 kg (1,700 lb). The rack may become

unstable and cause serious personal injury or equipment damage.

• Before installing the servers, extend the leveling jacks to the floor and rest the full

weight of the rack on the leveling jacks. Either install the stabilizer kit or couple

multiple racks together for stability.

• Always load the heaviest item first, and load the rack from the bottom to the top.

Loading in this manner makes the rack “bottom-heavy” and helps prevent the rack

from becoming unstable.

• Extend only one ProLiant DL380 Generation 2 server at a time. A rack may become

unstable if more than one ProLiant DL380 Generation 2 server is fully extended for

any reason.

CAUTION: Do not overload the AC supply branch circuit that provides power to the

rack.

Compaq ProLiant DL380 Generation 2 Server High-Density Deployment in Compaq Racks 5

Compaq Confidential - Need to Know Required

14UH-0701A-WWEN

Note: Slide rails, power distribution units (PDUs), power cords, and cables can be preinstalled

into the rack in a build room or on the data center floor before moving the rack to its final

location.

Where to Find Information

Table 1. Where to Find Information

Section Description Where to Find

Introduction Explains the purpose and scope of this white paper and

provides a glossary of terms

Page 5

Power, Thermal, and Weight

Information

Lists important information about the

ProLiant DL380 Generation 2 server, Compaq racks,

PDUs, and related options to help choose a rack

configuration

Page 10

Power Distribution Units and

Power Cords

Discusses specific PDU and power cord choices Page 11

Console Management Systems Discusses server management options Page 16

Planning Rack Configurations Discusses rack configuration issues Page 19

Installation Procedures Describes installation procedures Page 26

Related Documents, Appendix A Lists documents and websites that provide additional

information about Compaq racks, rack options, and rack

deployment of ProLiant DL380 Generation 2 servers

Page 34

Parts Reference, Appendix B Lists part numbers for all the components referred to in

this white paper

Page 35

Power and Thermal Budgeting,

Appendix C

Explains calculating power deratings Page 38

Connecting Multiple Racks,

Appendix D

Discusses connecting multiple racks and lists rack

deployment options for 7000- and 9000-series racks.

Page 43

Table 2. Steps for High-Volume Server Deployment

Step Description

Step 1 Choose PDUs from Table 6.

Step 2 Determine the PDUs and related options from Table 12.

Step 3 Determine rack configuration. See examples on pages 22-24.

Step 4 Determine rail, console, and cable configurations. See the "Rack Management

Systems" section on page 25.

Step 5 Install the ProLiant DL380 Generation 2 server. See the "Installation Procedures"

section on page 26.

Introduction

Compaq designed the dense ProLiant DL380 Generation 2 server to meet the challenges

associated with deploying a high concentration of servers in a single rack. Compaq suggests that

customers evaluate their environments, power distribution, console, cable, and thermal

management choices well in advance to ensure the efficient deployment of multiple

Compaq ProLiant DL380 Generation 2 Server High-Density Deployment in Compaq Racks 6

Compaq Confidential - Need to Know Required

14UH-0701A-WWEN

ProLiant DL380 Generation 2 servers in a rack. Use this document, in conjunction with the

documents listed in Appendix A, as a guideline for planning rack configurations for high-volume

deployments of ProLiant DL380 Generation 2 servers.

The “Power Distribution Units” section outlines Compaq PDU choices best suited for building

rack configurations. This section provides technical specifications for high- and low-voltage

PDUs. It also describes how to allocate the correct number and type of PDUs for specific rack

deployments.

The “Planning Rack Configurations” section provides weight information for individual rack

components to help address floor support requirements. It also describes cable systems.

The “Console Management Systems” section provides information on server management

options.

All discussions of power requirements for ProLiant DL380 Generation 2 servers are based on the

input power of the server. This document uses the maximum rated power supply input of 575 W

for calculation purposes. However, derating the input power may be effective to:

• Minimize the number of PDUs required for each rack.

• Match the rack current requirements with the existing circuit breaker capacity.

• Match the rack cooling requirements with the existing facility cooling capability.

For more information about input power derating, see Appendix C.

IMPORTANT: In this document, derating the input power budget means using less than the

maximum rated input power values for the power supply. To derate the input power, see

Appendix C. Compaq strongly recommends that the derated power budget satisfies all the

installation requirements, including future upgrade plans.

Refer to the Compaq ProLiant DL380 Generation 2 Server QuickSpecs for detailed specifications

and options for the ProLiant DL380 Generation 2 server.

Compaq ProLiant DL380 Generation 2 Server High-Density Deployment in Compaq Racks 7

Compaq Confidential - Need to Know Required

14UH-0701A-WWEN

References

Sources referenced in this paper are listed in Table 3.

Table 3. Sources of Information

Topic Where to Find

Information focal point for the Compaq

ProLiant DL380 Generation 2 server

www.compaq.com/proliant

Specifications, options, and a list of other Compaq

products and options compatible with the

ProLiant DL380 Generation 2 server

Compaq ProLiant DL380 Generation 2 QuickSpecs

Installation and service guidelines for the

ProLiant DL380 Generation 2 server

Compaq ProLiant DL380 Generation 2 Setup and Installation

Guide, P/N 203844-001

Compaq ProLiant DL380 Generation 2 Maintenance and

Service Guide, P/N 203840-002

Installation of vertical-mount PDU brackets and

Y-cables

Vertical-Mount PDU Brackets kit, P/N 191265-B21

Vertical-Mount PDU Brackets with High-Voltage Cables kit, P/N

166097-B21

Installation guidelines for the

ProLiant DL360 Generation 2 server in third-party

racks. (Contains information that applies to the

ProLiant DL380 G2 server.)

Compaq Ultra-Dense Server Deployment in Third-Party Cabinet

Racks, Document Number 12CU-0400A-WWEN

Third-Party Rack Cabinet kit, P/N 228894-B21

Installation guidelines for the

ProLiant DL360 Generation 2 server in

telecommunications (Telco) racks. (Contains

information that applies to the ProLiant DL380 G2

server.)

Compaq Ultra-Dense Server Deployment in

Telecommunications (Telco) Racks, Document number 12CZ-

0400A-WWEN

Telco Rack kit, P/N 228892-B21

Compaq ProLiant DL380 Generation 2 Server High-Density Deployment in Compaq Racks 8

Compaq Confidential - Need to Know Required

14UH-0701A-WWEN

Table 4. Notations for Optional Components

Notation Description

1x, 2x, 4x Number of components, for example, 1 x 128 MB means one 128-MB DIMM

1.13 GHz Intel Pentium III 1.13-GHz processor

1.266 GHz Intel Pentium III 1.266-GHz processor (when available)

128 MB 128-MB DIMM

256 MB 256-MB DIMM

512 MB 512-MB DIMM

HDD Hard disk drive

36-GB HDD

72-GB HDD (when available)

Hot-plug fan

Hot-plug power supply

Tape drive

SA5300 Smart Array 5300 Controller option (64-bit PCI card)

Remote Insight Lights-Out

Edition

Remote Insight Lights-Out Edition option (32-bit PCI card)

Glossary

1U – A rack unit (1U) is 4.45 cm or 1.75 inches in vertical dimension. The height of a device,

(also known as form factor), can be expressed in rack units (Us). The ProLiant DL380

Generation 2 server is a 2U server.

1U Integrated Keyboard/Mouse/TFT −

−−

−The TFT5600 RKM (rack-mount keyboard and

monitor) is a 1U integrated keyboard and monitor. Its full 15-inch TFT active matrix display

provides flicker-free, quality display at viewing angles up to 120 degrees horizontally and

105 degrees vertically.

Flat Panel Display (FPD) – A Compaq TFT5010R (15-inch) flat panel monitor provides a large

image size and exceptional screen performance in a space-saving 2U size that enables the

monitor to be neatly tucked away when not in use.

High-voltage – AC line voltage of 200 V to 240 V. With higher voltage levels, a server can use a

lower current and still meet its power requirements. Compaq recommends using a high-

voltage source to support high-volume deployments of ProLiant DL380 Generation 2 servers

in a rack.

In-Rack Keyboard – The 1U Rack Keyboard Drawer and the Internal Keyboard with Trackball

are designed to work together to save room in space-constrained, rack-mount environments.

The 1U Keyboard Drawer requires only half the Compaq rack depth and provides enough

space behind it to mount a Compaq Server Console Switch.

Keyboard/Video/Mouse (KVM) – KVM refers to a keyboard cable, a video cable, a mouse

cable, or a switch. Some Compaq parts lists may refer to KVM switches as Server Console

Switches.

Local Console –A local console system interacts with a server using a set of KVM devices and

can be in-rack or off-rack. In this paper, in-rack local console refers to a flat panel display

Compaq ProLiant DL380 Generation 2 Server High-Density Deployment in Compaq Racks 9

Compaq Confidential - Need to Know Required

14UH-0701A-WWEN

and a keyboard/trackball in the same rack as the servers. Off-rack local console refers to any

combination of a display, a keyboard, and a pointing device located outside of the rack. A

local console system does not use a network connection to interact with the server.

Low-Voltage – AC line voltage of 100 V to 120 V.

N.A. – North America, including U.S., Canada, and Mexico.

Network Interface Controllers (NICs) – Controllers that are embedded on the system board of

the ProLiant DL380 Generation 2 server.

Power Distribution Unit (PDU) – A PDU is a high-voltage or low-voltage device that is

equipped with circuit breakers that help prevent electrical surges and external equipment

malfunction by providing over current and surge protection for connected devices. See the

“Power Distribution Units” section of this paper.

Remote Console – A remote console is a server console system that uses a network connection to

interact with the server. This system enables any computer with appropriate software and

network access to control a server from anywhere across the globe. Compaq recommends

using the remote-console system for managing a large number of servers because it

eliminates the congestion of KVM cabling.

Remote Insight Lights-Out Edition – The Compaq Remote Insight Lights-Out Edition is

designed to provide remote access and control of Compaq ProLiant server products from

anywhere on the network with a standard web browser. Consequently, customers can deploy

a ProLiant DL380 Generation 2 server in a true “headless” fashion with a minimum of only

three cables per server: one power cord for the server, one network cable for the LAN

connection, and one network cable for the Remote Insight Lights-Out Edition management

LAN connection. Using the Remote Insight Lights-Out Edition, customers can deploy 21

ProLiant DL380 Generation 2 servers in a 42U Compaq rack with significantly fewer cables

than in a local console.

Server Console Switch – A device that enables multiple servers in a rack to be accessed and

managed by a single keyboard, mouse, and monitor. These switches are also known as KVM

switches.

Sliding Rail – A toolless rack management system designed for Compaq 7000- and 9000-series

racks that supports in-rack serviceability for ProLiant DL380 Generation 2 servers.

UID LED and Switch – The blue Unit Identification LED identifies the ProLiant DL380

Generation 2 server requiring service. A UID switch toggles both the front and rear UID

LEDs simultaneously.

Wake on LAN (WOL) – An option that enables a remote restart of the server.

For detailed information about the products in this glossary visit the Compaq website:

www.compaq.com

Compaq ProLiant DL380 Generation 2 Server High-Density Deployment in Compaq Racks 10

Compaq Confidential - Need to Know Required

14UH-0701A-WWEN

Power, Thermal, and Weight Information

Power, thermal, and weight considerations are the most important parameters in high-volume

server deployment. Table 5 provides server parameters necessary to calculate the power needs,

thermal requirements, and total weight of a full rack of ProLiant DL380 Generation 2 servers.

Table 5. ProLiant DL380 Generation 2 Server Parameters

Dimensions H x W x D

8.64 x 65.45 x 44.45 cm (3.38 x 25.75 x 17.50 inches)

Server Weights

Minimum configuration: 1 x processor, 2 x 128-MB DIMM, 0 x CD-ROM drive, 1 x diskette

assembly, 0 x HDD, 5 x fans, 1 x power supply

16.7 kg (37 lb)

Average configuration: 1 x processor, 4 x 256-MB DIMM, 4 x HDD, 1 x CD-ROM drive,

1 x diskette assembly, 5 x fans, 1 x power supply, 1 x Remote Insight Lights-Out Edition

21.2 kg (47 lb)

Maximum configuration: 2 x processor, 6x DIMMs, 6 x HDDs, 2 x SA5300, 1 x CD-ROM drive,

1 x diskette assembly, 8 x fans, 2x power supplies, 1 x Remote Insight Lights-Out Edition

27 kg (60 lb)

Component Weights

CD/diskette drive assembly 0.34 kg (0.75 lb)

DIMM 0.04 kg (00.1 lb)

HDD 0.86 kg (1.9 lb)

Remote Insight Lights-Out Edition 0.86 kg (1.2 lb)

SA5300 0.45 kg (1.0 lb)

Rack Rails and Hardware Weights

Cable arm 0.81 kg (1.8 lb)

Slide (2) 2.07 kg (4.6 lb)

Rail (2) 1.8 kg (4.0 lb)

Total Weight: 4.7 kg (10.4 lb)

Power Ratings

Maximum power supply rated input AC power

115 V 575 W

240 V 545 W

Maximum system measured input AC power (per power calculator)

115 V 457 W

240 V 400 W

Maximum power supply rated input current

115 V 6.4 A

240 V 3.2 A

Maximum system measured input current (per power calculator)

115 V 3.8 A

240 V 1.7 A

continued

Autres manuels pour ProLiant DL380 G2

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Compaq Serveur

Compaq

Compaq 1850R - ProLiant - 128 MB RAM Manuel utilisateur

Compaq

Compaq AlphaServer GS60E Manuel utilisateur

Compaq

Compaq BL10e - HP ProLiant - 512 MB RAM Document technique

Compaq

Compaq DL590 - HP ProLiant - 1 GB RAM Manuel utilisateur

Compaq

Compaq DL320 - ProLiant - G3 Manuel technique

Compaq

Compaq ProLiant 8500 Manuel

Compaq

Compaq 6400R - ProLiant - 1 GB RAM Instructions d'utilisation et de sécurité

Compaq

Compaq 195294-001 - ProLiant - ML370R Instructions d'utilisation et de sécurité

Compaq

Compaq 2500 - ProLiant - 64 MB RAM Manuel utilisateur

Compaq

Compaq ML570 - ProLiant - G2 Manuel

Compaq

Compaq Evo Thin Client t20 Manuel utilisateur

Compaq

Compaq BL10e - HP ProLiant - 512 MB RAM Instructions de montage

Compaq

Compaq AlphaServer GS60E Manuel utilisateur

Compaq

Compaq BL10e - HP ProLiant - 512 MB RAM Manuel utilisateur

Compaq

Compaq 222863-001 - TaskSmart W2200 Model 10 Manuel utilisateur

Compaq

Compaq Evo Thin Client t20 Manuel de service

Compaq

Compaq 1850R - ProLiant - 128 MB RAM Instructions d'utilisation et de sécurité

Compaq

Compaq DS20E - AlphaStation - 1 GB RAM Manuel utilisateur

Compaq

Compaq ProLiant DL380 G2 Manuel technique

Compaq

Compaq ProLiant DL380 Generation 2 Manuel

Compaq

Compaq AlphaServer 4100 s Mode d’emploi

Compaq

Compaq AlphaServer ES45 Manuel utilisateur

Compaq

Compaq 6400R - ProLiant - 1 GB RAM Manuel

Compaq

Compaq TruCluster Server AA-RHGWB-TE Manuel utilisateur

Manuels Serveur populaires d'autres marques

HP AlphaServer ES47 Manuel utilisateur

Dell

Dell PowerEdge R410 Manuel utilisateur

PowerNAS

PowerNAS CMA Manuel utilisateur

Supero

Supero FatTwin F617R3-FT Manuel utilisateur

MSI

MSI P1-109N-L70 Manuel utilisateur

Dell

Dell PowerEdge XE9640 Manuel

Dell

Dell PS4100 Instructions de montage

EtroVISION

EtroVISION EV3151 Manuel utilisateur

NEC

NEC Express5800/T110j Manuel utilisateur

HP ProLiant Gen9 Manuel utilisateur

Dell

Dell PowerEdge 3YPMN Manuel utilisateur

iRobo

iRobo IPC2U Manuel utilisateur

Nortel

Nortel 1000 Con?guration guide Manuel utilisateur

Asus

Asus AP7500 Manuel d'utilisation et d'entretien

Avid Technology

Avid Technology AirSpeed 5000 Manuel utilisateur

HP Integrity rx2600 Guide d'installation

Milestone

Milestone Husky IVO 350T Manuel utilisateur

Planet

Planet NAS-7410 Manuel utilisateur
