QuickSpecs

Compaq Evo Notebook N200

DA-10921 World Wide — Version 5 — March 4,2002

Overview

What's New

• 2.5 lb/1.13 kg Ultraportable

• Ultra Low VoltageMobile Intel



Pentium



III processor

• Intel 440MX chipset with 100-

MHz bus

• Optional Mobile Expansion Unit

(MEU)

• Microsoft



Windows



Professional

• Support for two batteries in the

system

• Easy Access Internet Buttons

• Enhanced Industrial and

ergonomic design

At A Glance

• Ultra Low Voltage Mobile Intel

Pentium III 700 MHz-M

• 10.4-inch XGAdisplay

• 2.5 lb/1.13 kg weight with one

battery

• 0.83 in/2.11 cm thin

• 192 MB SDRAM standard

(100 MHz)

• 20 GB user removable SMART

hard drives

• Integrated Mini PCI modem/NIC

combo

• 90% keyboard

• Microsoft Windows XP

Professional Edition or, Microsoft

Windows 2000

• Includesa One-year,Worldwide

Warranty—Certain restrictions

and exclusions apply. Consult

the Compaq Customer Support

Center for details.

What’s Special

• Ultra Thin and lightweight design

• Ultra Low Voltage Processor

• Magnesium system enclosure

• Common MultiBay with optional

MEU

• Dual batterysupport

• Exceptionalbatterylife

• Ease of connectivity

QuickSpecs

Compaq Evo Notebook N200

DA-10921 World Wide — Version 5 — March 4,2002

Standard Features

Processor and Panel 700 MHz-M on Ultra low voltage Mobile Intel Pentium III processor with 512 KB L2 cache

10.4-inch color TFT XGA with 1024 x 768 resolution (up to 16.7M colors internal)

NOTE: Mobile Intel Pentium III processors support enhanced Intel SpeedStep™ technology.

Memory Standard/Maximum 192 MB 100-MHz SDRAM (128-MB SODIMM in slot 1 and 64 MB on board)

NOTE:Due to the non-industry standard nature of some third-party memory modules, we recommend Compaq

branded memory to ensure compatibility.

Communications Type III Mini PCI 56K (V.90) modem plus 10/100 NIC Combo

Optional Compaq 56 K (V.90) Modem plus Intel PRO/100+ NIC with IPSec (Internet Protocol Security)

NOTE: Designed only to allow faster downloads from V.90 compliant sources. Maximum achievable download

transmission rates currently do not reach 56 KB/s, and will vary with line conditions.

NOTE: Modem availability is subject to country regulatory approval.

Keyboard 90% 102-key compatible keyboard with isolated, inverted-T cursor control keys, and right-control key, special

feature hotkeys for instant access to power conservation, QuickLock/QuickBlank (ex: FN+F6), toggle between

internal and external, or simultaneous displays, battery gauge, speaker volume control and brightness.

NOTE: Key pitch is 16 mm vertical and 17 mm horizontal, and key stroke is 2 mm.

Easy Access Internet

Buttons The Evo™ Notebook N200 comes with four Easy Access Buttons designed to increase customer productivity by

providing one-touch access to helpful Compaq information, favorite Internet destinations, files, or applications.

Pointing Device Touchpad

PC Card Slots One Type II PC Card Slot which support both 32-bit CardBus and 16-bit PC Cards

Storage Diskette Drives*Optional Floppy Drive

Optical Drives*DVD/CD-RW combo Drive

CD-RW Drive

DVD-ROM Drive

CD-ROM Drive

Hard Drives 20-GB SMART Hard Drive

NOTE: * = Requires optional Mobile Expansion Unit (MEU).

QuickSpecs

Compaq Evo Notebook N200

DA-10921 World Wide — Version 5 — March 4,2002

Standard Features

Multimedia Integrated 16-bit Stereo Sound

Integrated mono speaker and microphone

Headphone-out

Microphone in

Software MPEG1 support, MPEG2 and DVD

CD-RW Drive (optional, with MEU only)

8X DVD-ROM Drive with movie playback software (optional, with MEU only)

24X CD-ROM Drive (optional, with MEU only)

PCI Graphics support

4MB SGRAM

Interfaces

PC Card

USB 1 (Type II)

DC Power 1

RJ-45 (NIC) 1

RJ-11 (modem)

Headphone/Line-out

Microphone in

MEU Connector

LED status indicators

VGA/External Monitor

Infrared Port

1 (4 Mb/s support)

(IrDA 4 MB compliant. IR performance will vary depending on performance of IR

peripherals and application used.)

Graphics ATI Mobility L with 4 MB SGRAM

Display (External) Supports 1280 x 1024 @ 100 Hz refresh for single display mode operation.

Display (Internal) 10.4-inch color TFT XGA with 1024 x 768 resolution (up to 16.7M colors internal)

Operating System Microsoft Windows XP Professional Edition*or Microsoft Windows 2000 preinstalled

NOTE: * = Available December ’01 on select models.

Software Fax Central for Microsoft Windows 2000

Diagnostics for Microsoft Windows 2000

DVD Playback Software (with optional MEU)

Safety and Comfort Guide

Reference Guide

System Recovery Each unit is shipped with a CD kit for quick recovery (erases hard disk and restores manufacturer installed image)

and software recovery (installs only selected standard software)

Security Configuration Control Hardware

Set-up Password

Power-On Password

DriveLock

Support for PC Card SmartCard and Biometric options

Power Supply External AC adapter, 6-foot/1.8-meter power cord included. Total length including External AC adapter is 12-

feet/3.66-meter

QuickSpecs

Compaq Evo Notebook N200

DA-10921 World Wide — Version 5 — March 4,2002

Standard Features

Battery The Evo Notebook N200 provides 2.5 hours of battery life using the standard 6-cell Lithium-Ion polymer battery.

With the additional 4-cell external battery installed, battery life may be increased to 6.5 hours.

NOTE: Actual results may vary with product model, configuration, and individual usage. Compaq results of 2:30

(hr:min) were achieved running the eTesting Labs Inc.'s BatteryMarkTest version 4.0.1 on a N200 with

an Ultra Low Voltage Intel Pentium III 700 MHz-M CPU, 10.4-inch XGA panel, 192 MB RAM, 20-GB

HDD, 6-cell Li-polymer battery, and combination NIC/modem. System parameters were set according to

eTesting Labs’ recommendations: panel brightness 50%, hard drive standby and video idle time three

minutes, Intel SpeedStep battery optimized mode.

NOTE: This test was performed without independent verification by eTesting Labs Inc. eTesting Labs Inc. makes

no representations or warranties as to the result of the test. BatteryMark is a trademark of Ziff Davis

Publishing Holdings Inc., and affiliate of eTesting Labs Inc., in the U.S. and other countries.

Power Conservation Support enhanced Intel SpeedStep Technology (Allows a Battery Optimized Mode, Maximum Performance Mode,

or Automatic mode)

Hibernation

Instant-on via Standby

One custom level of power conservation

ACPI compliant

MultiBay Devices MultiBay devices may be swapped in the system docked to the MEU powered on (hot) or in suspend mode

(warm) under Microsoft Windows 2000 (except MultiBay Zip drive or MultiBay secondary hard drive). MultiBay

devices can be swapped with system power off under any supported operating system.

Service and Support Compaq Services includes a One-year, Worldwide Limited Warranty, pick-up or carry-in, upgrade to on-site

warranty or additional Two-year warranty available, and toll-free 7 x 24 hardware technical phone support.

NOTE: Certain restrictions and exclusions apply. Consult the Compaq Customer Support Center for details.

QuickSpecs

Compaq Evo Notebook N200

DA-10921 World Wide — Version 5 — March 4,2002

Standard Features

Naming Convention The Etymology of a Model name:

QuickSpecs

Compaq Evo Notebook N200

DA-10921 World Wide — Version 5 — March 4,2002

Standard Features

Models

Display 10.4-inch color TFT XGA with 1024 x 768 resolution (up to 16.7M colors internal)

Processor 700 MHz-M on Intel Ultra Low Voltage Mobile Pentium III processor

Cache Memory 512 KB, L2 Cache

N2P700X020C19T2P

P/N

Memory Standard/Maximum 192 MB SDRAM

Optical Drive N/A

Hard Drive 20-GB SMART

Communications Type III Mini PCI 56K (V.90) modem plus 10/100 NIC Combo

Graphics ATI Mobility L, with 4 MB SGRAM

Audio 16-bit SoundBlaster Pro compatible

Operating System Microsoft Windows 2000

Pointing Device Touchpad

Display 10.4-inch color TFT XGA with 1024 x 768 resolution (up to 16.7M colors internal)

Processor 700 MHz-M on Intel Ultra Low Voltage Mobile Pentium III processor

Cache Memory 512 KB, L2 Cache

N2P700X020C19ToP

P/N

Memory Standard/Maximum 192 MB SDRAM

Optical Drive N/A

Hard Drive 20-GB SMART

Communications Type III Mini PCI 56K (V.90) modem plus 10/100 NIC Combo

Graphics ATI Mobility L, with 4 MB SGRAM

Audio 16-bit SoundBlaster Pro compatible

Operating System Microsoft Windows XP Pro/Microsoft Windows 2000

Pointing Device Touchpad

QuickSpecs

Compaq Evo Notebook N200

DA-10921 World Wide — Version 5 — March 4,2002

Standard Features

Pentium III-700 MHz-M ULV

10.4-inch TFT

192 MB

20-GB

Combo

Microsoft Windows 2000

Pentium III-700 MHz-M ULV

10.4-inch TFT

192 MB

20-GB

Combo

Microsoft Windows XP Pro/Microsoft

Windows 2000

NORTH AMERICA

US N2P700X020C19T2P 470019-385

N2P700X020C19ToP 470026-715

Fr Canada N2P700X020C19T2P 470019-386

N2P700X020C19ToP 470026-718

EUROPE/MIDDLE EAST/AFRICA

Belgium-FR/NL/US N2P700X020C19T2P 470019-387

Czech Republic N2P700X020C19T2P 470019-388

Denmark N2P700X020C19T2P 470019-389

Euro N2P700X020C19T2P 470019-390

N2P700X020C19ToP 470026-719

France N2P700X020C19T2P 470019-391

N2P700X020C19ToP 470026-720

Germany N2P700X020C19T2P 470019-393

N2P700X020C19ToP 470026-721

Greece/Poland N2P700X020C19T2P 470019-514

Hungary N2P700X020C19T2P 470019-394

Israel N2P700X020C19T2P 470019-395

Italy N2P700X020C19T2P 470019-396

N2P700X020C19ToP 470026-722

Middle East N2P700X020C19T2P 470019-397

Netherlands N2P700X020C19T2P 470019-398

Norway N2P700X020C19T2P 470019-399

Portugal N2P700X020C19T2P 470019-400

Russian N2P700X020C19T2P 470019-402

Slovak, Slovenian N2P700X020C19T2P 470019-404

Spain N2P700X020C19T2P 470019-401

N2P700X020C19ToP 470026-723

Sweden/Finland N2P700X020C19T2P 470019-403

Swiss 1-FR/GR/US N2P700X020C19T2P 470019-405

N2P700X020C19ToP 470026-752

Swiss 2-FR/GR/IT N2P700X020C19T2P 470019-406

N2P700X020C19ToP 470026-753

Turkey N2P700X020C19T2P 470019-409

UK N2P700X020C19T2P 470019-410

N2P700X020C19ToP 470026-724

CKK

Japan-Jpn N2P700X020C19T2P 470019-412

N2P700X020C19ToP 470026-725

Japan-Eng N2P700X020C19T2P 470019-413

N2P700X020C19ToP 470026-726

QuickSpecs

Compaq Evo Notebook N200

DA-10921 World Wide — Version 5 — March 4,2002

Standard Features

Pentium III-700 MHz-M ULV

10.4-inch TFT

192 MB

20-GB

Combo

Microsoft Windows 2000

Pentium III-700 MHz-M ULV

10.4-inch TFT

192 MB

20-GB

Combo

Microsoft Windows XP Pro

LATIN AMERICA

LTNA N2P700X020C19T2P 470019-415

N2P700X020C19ToP 470026-727

BRAZIL N2P700X020C19T2P 470019-417

ASIA PACIFIC

APD N2P700X020C19T2P 470019-418

N2P700X020C19ToP 470026-728

APD - THAI N2P700X020C19T2P

Australia N2P700X020C19T2P 470019-420

N2P700X020C19ToP 470026-729

GREATER CHINA

PRC N2P700X020C19T2P 470019-531

Taiwan N2P700X020C19T2P 470019-422

Hong Kong N2P700X020C19T2P 470019-424

Korea N2P700X020C19T2P 470019-429

QuickSpecs

Compaq Evo Notebook N200

DA-10921 World Wide — Version 5 — March 4,2002

Options

Expansion Mobile Expansion Unit – CD 231492-B21

Mobile Expansion Unit – DVD 231493-B21

Mobile Expansion Unit – CD-RW 231494-B21

Monitors TFT8030 Flat Panel Color 18-inch (carbon/silver) 243362-xxx

TFT7020 Flat Panel Color 17-inch with integrated speakers (carbon/silver) 253217-xxx

TFT5015 Flat Panel Color 15-inch (carbon/silver) 234044-xxx

TFT5030 Flat Panel Color 15-inch (carbon/silver) 228134-xxx

V720 17-inch CRT (carbon/silver) 232944-001

S720 17-inch CRT (carbon/silver) 239287-001

V570 15-inch CRT (carbon/silver) 228113-001

MultiBay Hard Drives 30-GB SMART Hard Drive 212791-B25

20-GB SMART Hard Drive 212790-B25

MultiBay Storage Devices DVD/CD-RW Combo Drive 237184-B25

(Optional MEU Required) CD-RW Drive 136186-B25

8X DVD-ROM Drive 138320-B25

24X

CD-ROM Drive 298452-B25

Floppy Drive 226935-B25

Iomega Zip 250 Drive 217387-B25

Other Storage Devices IBM 1GB Microdrive (PC card Device) 217390-B25

USB Disk-on-Key 249552-B25

USB Floppy drive 230330-B25

Connectivity Compaq M420 56K Global Modem 317900-001

10/100 TX PC Card UTP Controller 335506-B21

56K V.90 modem and 10/100 NIC IPSEC 225638-001

Wireless Connectivity Compaq WL100 11 Mbps Wireless LAN PC Card 233814-xx1

Compaq WL400 11 Mbps Wireless LAN Hardware Access Point 146927-001

Compaq WL Software Access Point 11Mbps 158603-001

NOTE: For more information on Compaq WLAN Wireless LAN solutions visit:

http://www.compaq.com/products/wlan/wl100-specifications.html

NOTE: This website is available in English only.

Power Primary Battery 258940-B25

External Battery (4-cells) 244389-B25

Common Power Solutions ArmadaE500, Armada M300 and Evo Notebook N200, Evo Notebook N400c, and

Evo Notebook N600c

AC Adapter 50W 120765-xx1

Auto Power Adapter/Charger 401043-B25

Aircraft Power Adapter 386504-B21

AC Line Cord (10 ft/3.1 m) 217932-xx2

QuickSpecs

Compaq Evo Notebook N200

DA-10921 World Wide — Version 5 — March 4,2002

Options

Input Devices External Enhanced III Keyboard (carbon – PS/2)*118003-008

Compaq 2 Button Mouse (carbon – PS/2)*103180-B21

USB 2 Button Scroll Mouse (carbon) 195255-B25

External 10-Key Numeric Keypad (carbon – PS/2)*294317-B21

USB EZ Access Keyboard 222726-xx8

NOTE: * = Item requires optional MEU.

Security Security Cable Lock 294316-B21

Compaq Smart Card PC Card Reader 135646-B25

Biometrics PC Card 146805-B25

Useful Accessories MP1400 Microportable Projector 174626-xx1

MP1800 Microportable Projector 180226-xx1

MP2800 Microportable Projector 180228-xx1

MP1600 Video Adapter 116298-001

MP1600 Lamp replacement kit 118052-001

MP1800/1400 Lamp replacement kit 189789-001

MP2800 Lamp replacement kit 215464-001

Carrying Cases Evo Notebook N200 specific

Compaq Evo Notebook N200 Portfolio Case 259396-B25

Compaq Value Case 294266-B21

Compaq Workstation Case 294267-B21

Compaq Global Case 294268-B21

Compaq Professional Case (nylon) 401366-B21

Compaq Professional Case (leather) 401367-B21

Armada M300, Evo Notebook N600c and Evo Notebook N400c specific

Compaq M Series Portfolio Case 167337-B21

Compaq Ultralight Case 167336-B21

NOTE: For additional Compaq Brand cases, visit http://www.compaq.com/products/notebooks/.

Autres manuels pour Evo Notebook N200 Series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Compaq Ordinateur portable

Compaq

Compaq 800 Series Instructions d'installation et d'utilisation

Compaq

Compaq Armada E500 Series Manuel utilisateur

Compaq

Compaq Evo N160 Series Manuel utilisateur

Compaq

Compaq Evo n1005v - Notebook PC Manuel utilisateur

Compaq

Compaq Armada E500 Series Manuel utilisateur

Compaq

Compaq TC1000 - Tablet PC - Crusoe TM5800 1 GHz Manuel

Compaq

Compaq Presario V2000 - Notebook PC Manuel utilisateur

Compaq

Compaq EVO NOTEBOOK N410C Guide de démarrage rapide

Compaq

Compaq TC1000 - Tablet PC - Crusoe TM5800 1 GHz Instructions d'installation

Compaq

Compaq 510 - Notebook PC Manuel utilisateur

Compaq

Compaq 3000 Series Manuel d'exploitation et d'entretien

Compaq

Compaq Presario,Presario 1234 Manuel utilisateur

Compaq

Compaq 1200US - Presario - Celeron 800 MHz Manuel

Compaq

Compaq Armada M300 Series Manuel

Compaq

Compaq Compaq Presario,Presario 1255 Manuel

Compaq

Compaq 1600XL Manuel utilisateur

Compaq

Compaq Presario 2700 - Notebook PC Manuel utilisateur

Compaq

Compaq Presario X1000 - Notebook PC Manuel de la liste des pièces

Compaq

Compaq Presario 1900 - Notebook PC Manuel

Compaq

Compaq 7400 - Armada - PII 366 MHz Manuel utilisateur

Compaq

Compaq Armada 100S Series Manuel utilisateur

Compaq

Compaq Presario V5000 Series Manuel

Compaq

Compaq Presario X1000 - Notebook PC Mode d’emploi

Compaq

Compaq Presario R3000 - Notebook PC Guide de démarrage rapide

Manuels Ordinateur portable populaires d'autres marques

HP ze2401xt - Pavilion Notebook PC Manuel utilisateur

Velocity

Velocity NoteMagix M10 Manuel utilisateur

Dell

Dell Alienware 17 R2 Manuel utilisateur

Toshiba

Toshiba A105-S2236 Manuel utilisateur

HP ENVY 17 Manuel

Winbook

Winbook LM Manuel utilisateur

Dell

Dell Inspiron 1464 Manuel utilisateur

Dell

Dell Inspiron 15R 5537 Manuel utilisateur

HP PROBOOK 4520S Manuel

Dell

Dell Latitude ATG D620 Manuel utilisateur

Sony

Sony VAIO PCG-FX270 Manuel utilisateur

Dell

Dell Latitude 7310 Manuel utilisateur

Dell

Dell Precision GU806 Manuel utilisateur

Sony

Sony VAIO PCG-R505JLK Manuel utilisateur

Lenovo

Lenovo THINKPAD X32 Manuel utilisateur

HP Compaq tc4200 Guide de démarrage rapide

Toshiba

Toshiba mini NB300 Manuel utilisateur

Lenovo

Lenovo ThinkPad X201 Tablet Manuel
