QUICKSPECS

Overview

1DA-10013-00A-003 — 11.23.1999

Compaq Armada 3500

1. Display

2. Full-Sized Keyboard with Four User-programmable

Keys

3. LEDs

4. Suspend/Resume Button

5. Power Switch

6. PC Card Slots

7. Speakers

8. Speakers, Subwoofer

9. Fixed 24X Max4CD-ROM Drive or DVD-ROM Drive

10. MultiBay (supports second Hard Drive [with

adapter], SuperDisk LS-120 Drive, Zip Drive or

floppy diskette drive)

11. Expansion connector

12. AC Adapter

13. Li-Ion Battery

14. Volume Controls

15. External Diskette Drive port

16. USB Port

17. External Diskette Drive adapter (supports floppy

diskette drive)

18. Headphone/Microphone Connector

AT A

LANCE

•Lightweight Pentium®II notebook

as lightas 4.4 lbs/2 kg

•Intel Mobile Pentium II 333 to 366

with integrated256-KB cache or

Intel Mobile Pentium II processors

from 266 to 300 MHzwith 512-KB

level two cache

•12.1-inch CTFTdisplay(SVGA)o

13.3-inch CTFTdisplay(XGA)

•Magnesiumalloydisplay

enclosure

•High flexibility with Mobile 3500

Expansion Unit,which supports

SuperDisk LS-120 Drive, Iomega

Zip drive,diskette drive, ora

second Hard Drive

•Wide palm rest and multi-

functional EasyPoint IV™ Pointing

Stick

•64-bit PCI localbus graphics

•32 MB and 64 MB SDRAM of

standard memory, expandable up

to 192 MB

•4.1-or6.4-GB1SMART Hard

Drives

•Full-sized 101-key compatible

keyboard

•Intelligent Manageability for lower

total cost of ownership

•CompaqServices, including a

three-year, Worldwide Limited

Warranty2with second business

day3expedited pick-up and repair

in North America

QUICKSPECS

Standard Features

2 DA-10013-00A-003 — 11.23.1999

Compaq Armada 3500

Lightweight and Flexible Design

Ideal for the highly mobile professional, the Armada 3500 offers portability and flexibility. The Armada 3500

weighs as little as 4.4 pounds is only 1.3-inches thick, and features Pentium II performance, full-size displays

and a full-size keyboard. For flexibility and changing needs, the Armada 3500 may be connected to the Mobile

3500 Expansion Unit (MEU) for CD-ROM or DVD-ROM and MultiBay capabilities. The MultiBay supports a

diskette drive, a second hard drive (with adapter), a SuperDisk LS-120 Drive or an Iomega Zip Drive.

Processor

Intel Mobile Pentium II processor 366 MHz

6366/T/6400/0/0/3

6366/T/6400/0/0/2

6366/T/6400/0/0/1

Intel Mobile Pentium II processor 333 MHz

6333/T/4100/0/0/3

6333/T/4100/0/0/2

6333/T/4100/0/0/1

Intel Mobile Pentium II processor 300 MHz

6300/T/6400/0/0/3

6300/T/6400/0/0/1

Intel Mobile Pentium II processor 266 MHz

6266/T/4100/0/0/3

6266/T/4100/0/0/2

6266/T/4100/0/0/1

Cache Memory

512-KB L2

6300/T/6400/0/0/2

6300/T/6400/0/0/1

6266/T/4100/0/0/3

6266/T/4100/0/0/1

Integrated 256-KB L2

6366/T/6400/0/0/3

6366/T/6400/0/0/2

6366/T/6400/0/0/1

6333/T/4100/0/0/3

6333/T/4100/0/0/2

6333/T/4100/0/0/1

MODELS

Windows 95

6266/T/4100/0/0/1

310200-xx1

6266/T/4100/0/0/1

(GEM/NAFTA)

310200-xx3

6300/T/6400/0/0/1

310300-xx1

6300/T/6400/0/0/1

(GEM/NAFTA)

310300-xx3

6333/T/4100/0/0/1

310350-xx1

6333/T/6400/0/0/1

(GEM/NAFTA)

310350-xx3

6366/T/6400/0/0/1

310400-xx1

6366/T/6400/0/0/1

(GEM/NAFTA)

310400-xx3

Windows 98

6266/T/4100/0/0/2

310200-xx4

6333/T/4100/0/0/2

310350-xx4

6366/T/6400/0/0/2

310400-xx4

Windows NT

6266/T/4100/0/0/3

310200-xx6

6300/T/6400/0/0/3

310300-xx6

6333/T/4100/0/0/3

310350-xx6

6366/T/6400/0/0/3

310400-xx6

MODELS

Windows NT

6366/T/6400/0/0/3

310400-xx6

6333/T/4100/0/0/3

310350-xx6

6300/T/6400/0/0/3

310300-xx6

6266/T/4100/0/0/3

310200-xx6

Windows 98

6366/T/6400/0/0/2

310400-xx4

6333/T/4100/0/0/2

310350-xx4

6266/T/4100/0/0/2

310200-xx4

Windows 95

6366/T/6400/0/0/1

310400-xx1

6333/T/4100/0/0/1

310350-xx1

6300/T/6400/0/0/1

310300-xx1

6266/T/4100/0/0/1

310200-xx1

QUICKSPECS

Standard Features

3 DA-10013-00A-003 — 11.23.1999

Compaq Armada 3500

Memory

Standard 32 MB

Maximum 160 MB

6333/T/4100/0/0/3

6333/T/4100/0/0/2

6333/T/4100/0/0/1

6266/T/4100/0/0/3

6266/T/4100/0/0/2

6266/T/4100/0/0/1

Standard 64 MB

Maximum 192 MB

6366/T/6400/0/0/3

6366/T/6400/0/0/2

6366/T/6400/0/0/1

6300/T/6400/0/0/3

6300/T/6400/0/0/1

Keyboard

101-key compatible keyboard with isolated, inverted-T cursor control keys, right-control key, four user-

programmable keys, special feature hotkeys for instant access to power conservation, QuickLock/ QuickBlank,

toggle between internal and external, or simultaneous displays, speaker volume control, brightness

Pointing Device

Keyboard-integrated, textured, multi-functional EasyPoint IV Pointing Stick with press-to-select features with

Function (Fn + F2) settings

PC Card Slots

Two Type II/One Type III PC Card Slot(s) with CardBus5

Storage

Diskette Drives 1.44 MB

Hard Drives

6.4-GB1SMART

6366/T/6400/0/0/3

6366/T/6400/0/0/2

6366/T/6400/0/0/1

6300/T/6400/0/0/3

6300/T/6400/0/0/1

4.1-GB1 SMART

6333/T/4100/0/0/3

6333/T/4100/0/0/2

6333/T/4100/0/0/1

6266/T/4100/0/0/3

6266/T/4100/0/0/2

6266/T/4100/0/0/1

QUICKSPECS

Standard Features

4 DA-10013-00A-003 — 11.23.1999

Compaq Armada 3500

Multimedia

Integrated 16-bit Sound Blaster Pro-compatible audio

Integrated speaker

Hardware/software volume control

Headphone out jack

Microphone in jack

Software MPEG

Interfaces

PC Card Two Type II/One Type III Slot(s)

Enhanced Parallel 1

Serial 1

External Monitor 1

External Keyboard/

Pointing Device 1

Convenience Base 1

Headphone/Line-out 1

Microphone 1

AC Power 1

RJ-11 1

Infrared 1 (4 Mb/s6supported)

USB 1

Graphics

Magnesium alloy display enclosure protects against the rigors of travel. The Armada 3500 also has 64-bit video

graphics on a PCI local bus and 2-MB VRAM for increased color depth and graphics performance.

Display

13.3-inch color XGA TFT with 1024 x 768 resolution and 24-bit true color (16.8M colors internal)

6366/T/6400/0/0/3

6366/T/6400/0/0/2

6366/T/6400/0/0/1

6300/T/6400/0/0/3

6300/T/6400/0/0/1

12.1-inch color SVGA TFT with up to 800 x 600 resolution and 24-bit true color (16.8M colors internal)

6333/T/4100/0/0/3

6333/T/4100/0/0/2

6333/T/4100/0/0/1

6266/T/4100/0/0/3

6266/T/4100//0/02

6266/T/4100/0/0/1

QUICKSPECS

Standard Features

5 DA-10013-00A-003 — 11.23.1999

Compaq Armada 3500

Software

Windows NT Workstation 4.0

Insight Management Agents

Intelligent Manageability

Security 32

Diagnostics for Windows NT

Compaq Power Management

Online Safety and Comfort Guide

Reference Guide

Carbon Copy

6366/T/6400/0/0/3

6333/T/4100/0/0/3

6300/T/6400/0/0/3

6266/T/4100/0/0/3

Windows 98

Insight Management Agents

Intelligent Manageability

Security 32

Diagnostics for Windows 98

Compaq Power Management

Online Safety and Comfort Guide

Reference Guide

Carbon Copy

6366/T/6400/0/0/2

6333/T/4100/0/0/2

6266/T/4100/0/0/2

Windows 95

Insight Management Agents

Intelligent Manageability

Security 32

Diagnostics for Windows 95

Compaq Power Management

Online Safety and Comfort Guide

Reference Guide

Carbon Copy

6366/T/6400/0/0/1

6333/T/4100/0/0/1

6300/T/6400/0/0/1

6266/T/4100/0/0/1

OS Support

Windows NT Workstation 4.0

Windows 98

Windows 95

Intelligent Manageability

The Armada 3500 lowers total cost of ownership by providing enhanced security, asset management and fault

prediction with SMART drives.

Security

Cable lock support

Power-on and setup passwords

Ability to disable serial port, parallel port, diskette drive, diskette drive boot sequence

Drive Lock for advanced data protection

QuickLock

QuickBlank

To experience full Compaq PremierSound™ add the MEU containing stereo speakers and subwoofer.

QUICKSPECS

Standard Features

6 DA-10013-00A-003 — 11.23.1999

Compaq Armada 3500

Power Supply

The external AC Adapter weighs approximately 0.6 lbs/0.27 kg and allows system operation and battery charge

from up to 10 feet away from a power source.

Battery

The Li-Ion Battery provides over 2 hours of battery life7. An optional Extended Life Li-Ion Battery provides over 3

hours of battery life7.

Power Conservation

The Power Conservation provides Hibernation, Instant-On via Standby; pop-ups with three presets and one

custom level of power conservation, as well as ACPI hardware-ready support.

Service and Support

Compaq Services provides a range of services for the Armada 3500, including a three-year, Worldwide Limited

Warranty2, with 7 x 24 service line at 1-800-OK-Compaq (1-800-652-6672) and a free one-year, second

business day3pick-up and delivery service from Compaq. All shipping and handling materials are supplied by

Compaq.

QUICKSPECS

Options

7 DA-10013-00A-003 — 11.23.1999

Compaq Armada 3500

Memory

128-MB SDRAM Memory Modules 315177-B21

64-MB SDRAM Memory Modules 314891-B21

32-MB SDRAM Memory Modules 314890-B21

Monitors8

TFT8000 Flat Panel 307906-001

TFT5000 Flat Panel 325700-001

P1610 Color9305708-001

P1100 Color9325606-001

P900 Color 386326-001

P700 Color 380207-001

P110 Color9325600-001

P75 Color 307806-001

V1100 Color 386472-001

V1000 Color 351757-001

V900 Color 303500-001

V500 Color 325900-001

V700 Color 325800-001

S910 Color 138485-001

S900 Color 152991-001

S710 Color 360512-001

S700 Color 360512-001

Hard Drives

6.4-GB1SMART Hard Drive (MEU) 310380-B21

6.4-GB1SMART Hard Drive (CPU) 310313-B21

4.1-GB1SMART Hard Drive (CPU) 310312-B21

Expansion/Convenience Bases

24X Max4CD Mobile 3500

Expansion Unit 310250-001

DVD Mobile 3500 Expansion Unit 310330-001

Convenience Base II (Ethernet)10 316239-001

Convenience Base II

(Pass-Through)10 316238-001

Convenience Base Monitor Stand 316246-B21

MultiBay Devices for the Mobile 3500

Expansion Bases

SuperDisk LS-120 Drive 310314-B21

Iomega Zip Drive 310315-B21

6.4-GB1SMART Hard Drive 310380-B21

PC Card/Communications

USB CardBus Card

Compaq Microcom 420 56K11 Global

Fax Modem PC Card 296501-B21

Compaq Microcom 550 Combo PC

Card 317900-001

Compaq Ethernet LAN PC Card 321550-001

10/100 TX PC Card UTP Controller 224750-001

10 T PC Card UTP Controller 335506-B21

10 2 PC Card Coax Controller 292806-B21

10/100 TX PC Card UTP Controller

Upgrade 292807-B21

16/4 TR PC Card IBM UTP/STP

Controller 292813-B21

For additional compatible PC Cards, view the Compaq

PC Card Solution List on the Compaq website at

http://www.compaq.com/support/techpubs/

pcmcia/pccardlist.html.

Power

3-Wire Power Cord, 10-foot 217932-002

Extended Life Battery, 9 cell Li-Ion 217932-002

Auto/Aircraft Adapter 310316-B21

Input Devices

External Enhanced III Keyboard

(beach gray) 110562-001

External Enhanced III Keyboard (opal) 110562-001

External Enhanced III Keyboard

(carbon) 294343-001

Compaq Mouse (beach gray) 118003-xx8

Compaq Mouse (opal) 143315-001

Compaq Mouse (carbon) 143315-B21

Other

Security Lock 294316-B21

Portable Video Conferencing Kit 294316-B21

Armada Headset with Microphone 296954-001

Universal Monitor Stand 220460-001

Carrying Cases

CPQ Value Case 294260-B21

CPQ Workstation Case 294260-B21

CPQ Global Case 294267-B21

CPQ Professional Case (Nylon) 294268-B21

CPQ Professional Case (Leather) 401366-B21

For additional Compaq Brand cases, call

1-800-888-5903.

QUICKSPECS

Memory

8 DA-10013-00A-003 — 11.23.1999

Compaq Armada 3500

Compaq Armada 3500 6266/T/4100/0/0/1, 6266/T4100/0/0/2, 6266/T/4100/0/0/3, 6333/T/4100/0/0/1,

6333/T/4100/0/0/2, 6333/T/4100/0/0/3

STANDARD MEMORY

32 MB Standard on System Board

Standard Slot

32 MB Empty

STANDARD MEMORY PLUS

OPTIONAL MEMORY

Support for up to 160 MB of memory is available with the installation of optional SDRAM

Memory Kits.

Up To Slot

64 MB

96 MB

160 MB

Following are memory options available from Compaq:

•128-MB SDRAM Memory Kit 315177-B21

•64-MB SDRAM Memory Kit 314891-B21

•32-MB SDRAM Memory Kit 314890-B21

QUICKSPECS

Memory

9 DA-10013-00A-003 — 11.23.1999

Compaq Armada 3500

Compaq Armada 3500 6300/T/6400/0/0/1, 6300/T/6400/0/0/3, 6366/T/6400/0/0/1, 6366/T/6400/0/0/2,

6366/T/6400/0/0/3

STANDARD MEMORY

64 MB Standard on System Board

Standard Slot

64 MB Empty

STANDARD MEMORY PLUS

OPTIONAL MEMORY

Support for up to 192 MB of memory is available with the installation of optional SDRAM

Memory Kits.

Up To Slot

96 MB

128 MB

192 MB

Following are memory options available from Compaq:

•128-MB SDRAM Memory Kit 315177-B21

•64-MB SDRAM Memory Kit 314891-B21

•32-MB SDRAM Memory Kit 314890-B21

QUICKSPECS

Storage

10 DA-10013-00A-003 — 11.23.1999

Compaq Armada 3500

DRIVE SUPPORT Quantity

Supported Drive Bay Supported

MEU Drive Support

1.44-MB Diskette Drive Up to 1 Mobile 3500 Expansion Unit MultiBay

SuperDiskLS-120Drive Up to 1 Mobile 3500 Expansion Unit MultiBay

Iomega ZIP Drive Up to 1 Mobile 3500 Expansion Unit MultiBay

6.4-GB1SMART Hard Drive Up to 1 Mobile 3500 Expansion Unit MultiBay

24X Max4CD MEU Up to 1 Integrated in Mobile 3500 Expansion UnitOptical Bay

DVD MEU Up to 1 Integrated in Mobile 3500 ExpansionUnit Optical Bay

CPU Hard Drive Support

6.4-GB1 SMART HardDrive Up to 1 System Upgrade

4.1-GB1SMART Hard Drive Up to 1 System Upgrade

1 Integrated in Mobile 3500

Expansion Unit Optical Bay

2 Mobile 3500 Expansion Unit

MultiBay

Autres manuels pour Armada 3500

Table des matières

Autres manuels Compaq Ordinateur portable

Compaq

Compaq Armada E700 Series Manuel

Compaq

Compaq 1750 - Armada - PII 333 MHz Instructions d'utilisation

Compaq

Compaq Armada 6500 - Notebook PC Manuel utilisateur

Compaq

Compaq 1200US - Presario - Celeron 800 MHz Manuel

Compaq

Compaq 12XL125 - Presario - K6-2 533 MHz Manuel utilisateur

Compaq

Compaq Armada 1500C series Guide de référence rapide

Compaq

Compaq Presario V2605TN Instructions de montage

Compaq

Compaq Armada 7300 - Notebook PC Instructions d'installation

Compaq

Compaq Evo N600c Manuel

Compaq

Compaq Essential 615 Manuel utilisateur

Compaq

Compaq Presario,Presario 1234 Manuel utilisateur

Compaq

Compaq nx6315 - Notebook PC Manuel utilisateur

Compaq

Compaq Evo D500 - Convertible Minitower Guide de démarrage rapide

Compaq

Compaq 800 Series Instructions d'installation et d'utilisation

Compaq

Compaq PRESARIO Presario 1255 Manuel

Compaq

Compaq Presario R3000 - Notebook PC Manuel utilisateur

Compaq

Compaq Prosignia 170 Instructions d'utilisation

Compaq

Compaq Compaq nx6115 Manuel utilisateur

Compaq

Compaq Evo Notebook N800v Instructions d'installation

Compaq

Compaq Compaq Notebook Series Guide de l'utilisateur

Compaq

Compaq Armada E500 Series Manuel

Compaq

Compaq EVO NOTEBOOK N410C Manuel utilisateur

Compaq

Compaq Deskpro 286 - Desktop PC Manuel

Compaq

Compaq Compaq Presario Manuel utilisateur

Manuels Ordinateur portable populaires d'autres marques

HP ze2401xt - Pavilion Notebook PC Manuel utilisateur

Velocity

Velocity NoteMagix M10 Manuel utilisateur

Dell

Dell Alienware 17 R2 Manuel utilisateur

Toshiba

Toshiba A105-S2236 Manuel utilisateur

HP ENVY 17 Manuel

Winbook

Winbook LM Manuel utilisateur

Dell

Dell Inspiron 1464 Manuel utilisateur

Dell

Dell Inspiron 15R 5537 Manuel utilisateur

HP PROBOOK 4520S Manuel

Dell

Dell Latitude ATG D620 Manuel utilisateur

Sony

Sony VAIO PCG-FX270 Manuel utilisateur

Dell

Dell Latitude 7310 Manuel utilisateur

Dell

Dell Precision GU806 Manuel utilisateur

Sony

Sony VAIO PCG-R505JLK Manuel utilisateur

Lenovo

Lenovo THINKPAD X32 Manuel utilisateur

HP Compaq tc4200 Guide de démarrage rapide

Toshiba

Toshiba mini NB300 Manuel utilisateur

Lenovo

Lenovo ThinkPad X201 Tablet Manuel
