INSTALLATION INSTRUCTION: Fanout Fixation Kit
FAC T FRAME
Contents
Installation Instructions
FACT FRAME FANOUT FIXATION KIT
TC-40152-IP-EN
Rev B, May 2019
www.commscope.com
Page 2 of 8
© 2019 CommScope, Inc. All Rights Reserved
860648300
Rev. B
1. General product information
The FACT fanout plate (FOPL) is designed to xate up to thirty two incoming fanout cables in the cable side duct.
The kit includes one fanout xation plate with fasteners and xation components for eight fanout xations.
2. Warnings and caution
• Fiber optic cables may be damaged if bent or curved to a radius that is less than the recommended minimum
bend radius. Always observe the recommended bend radius limit when installing ber optic cables and patch
cords.
• Exposure to laser radiation can seriously damage the retina of the eye. Do not look into the ends of any optical
ber. Do not assume the laser power is turned off or that the ber is disconnected at the other end.
1. General product information ................................................ 2
2. Warnings and caution ............................................................ 2
3. Kit Content...............................................................................3
4. Mounting Fanout Fixation Plate........................................... 4
5. Fanout Retainer ...................................................................... 5
6. Routing Fanouts...................................................................... 7
7. Trade-marks ............................................................................ 8
8. Contact Information................................................................8
Page 3 of 8
© 2019 CommScope, Inc. All Rights Reserved
M6 Bolt+Washer
Fanout Fixation Plate
Cable Tie
3. Kit Content
Fanout Retainer
1x
16x
8x
2x
Page 4 of 8
© 2019 CommScope, Inc. All Rights Reserved
4. Mounting Fanout Fixation Plate - Step 1
Step 1: Mount the fanout plate on the predetermined position on
the “xed side” of the FACT Frame (indicated with an arrow). Two
fanout plates can be mounted per frame. Use two M6 screws +
washers / plate.
M6 Bolt + Washer
2x
Page 5 of 8
© 2019 CommScope, Inc. All Rights Reserved
5. Fanout Retainer - Step 2
Step 2: Take the fanout retainer and the fanout. Position the
fanout on the retainer as illustrated. Apply two cable ties to secure
the fanout on the bracket.
123
Page 6 of 8
© 2019 CommScope, Inc. All Rights Reserved
5. Fanout Retainer - Step 3
Step 3:Position the assembled retainer in the opening of the fa-
nout plate. Slide it down until you hear a “click”. Start in the back.
There can be up to 32 assembled brackets / plate.
2
1
Page 7 of 8
© 2019 CommScope, Inc. All Rights Reserved
6. Routing Fanouts - Step 4
Step 4: Route the cables as illustrated.
The fanouts that are terminated on the top
fanout plate should be routed to the top 28
Fact elements.
The fanouts that are terminated on the bottom
fanout plate should be routed to the bottom
28 Fact elements.
Repeat the process for all the fanouts that
have to be installed.
Page 8 of 8
© 2019 CommScope, Inc. All Rights Reserved
© 2019 Commscope,
Inc. All Rights Reserved
7. Trade-marks:
All trademarks identied by ® or ™ are registered trademarks or trademarks, respectively, of CommScope,
Inc. This document is for planning purposes only and is not intended to modify or supplement any specications
or warranties relating to CommScope products or services. CommScope is committed to the highest standards
of business integrity and environmental sustainability, with a number of CommScope’s facilities across the globe
certied in accordance with international standards, including ISO9001, TL 9000, and ISO 14001. Further informa-
tion regarding CommScope’s commitment can be found at:
www.commscope.com/About-Us/Corporate-Responsibilityand-Sustainability.
8. Contact Information:
Visit our website or contact your local CommScope representative for more information.
For technical assistance, customer service, or to report any missing/damaged parts, visit us at:
http://www.commscope.com/SupportCenter
This product is covered by one or more U.S. patents or their foreign equivalents. For patents, see
www.commscope.com/ProductPatent/ProductPatent.aspx
