CommScope PFU-P-E-O-060-01 Manuel utilisateur
860659348 Rev A
1-Port 5Gb PoE Extender
Manual
860659348 Rev A
October 2020
1-Port 5Gb PoE Extender Manual
This product is copyright © 2020 CommScope, LLC. All Rights Reserved.
Table of Contents
1 Notices ................................................................................................... 1
Electrical Safety .............................................................................................................. 1
General................................................................................................................... 1
CE NOTICE .................................................................................................................... 3
FCC NOTICE .................................................................................................................. 3
Return Product Procedure .............................................................................................. 3
WEEE ............................................................................................................................. 3
2 Introduction ........................................................................................... 5
Extender Surge Protection.............................................................................................. 6
3 Package Contents................................................................................. 7
1-Port 5Gb PoE Extender, PFU-P-E-O-060-01...................................................... 7
4 Installation ............................................................................................. 9
Step 1: Remove Solar Shield.......................................................................................... 9
Step 3: Remove the Enclosure Lid ............................................................................... 11
Step 4: Powered Fiber Cable Installation...................................................................... 11
Step 4A: Splitting the Cable ................................................................................. 11
Step 4B: Installing the Cable Gland ..................................................................... 12
Step 4C: Connecting the Power Strands.............................................................. 13
Step 4D: Connecting the fiber .............................................................................. 13
Step 6: Sealing the Unit ................................................................................................ 16
Step 7: Mounting the Unit ............................................................................................. 17
Wall Mount ........................................................................................................... 17
Pole Mount ........................................................................................................... 18
Step 8: Grounding......................................................................................................... 19
Step 9: Install the Solar Shield...................................................................................... 19
5 Detailed Specifications....................................................................... 21
Copyright, Trademarks and Commercial Disclaimer .................................................... 23
1-Port 5Gb PoE Extender Manual
This product is copyright © 2020 CommScope, LLC. All Rights Reserved.
1-Port 5Gb PoE Extender Manual
Rev A 1
1. Notices
In support of Low Voltage Directive 2014/35/EU this notice contains safety information important
for the correct installation and operation of this equipment.
Note, the term SELV (Safety Extra Low Voltage) used in this addendum is defined strictly in
accordance with IEC 62368-1.
Electrical Safety
1. This equipment is intended for installation by trained service personnel only.
2. The safety requirements for Information Technology equipment is only valid if the building
installation is in compliance with relevant national or international safety standards and in
accordance with good engineering practice.
3. Remove the DC supply from the supply cable at source before changing supply
connections to this product.
4. Unless otherwise specifically stated in the equipment installation manual, all data and
control ports are connected to ES1/SELV/NEC Class 2 conformant circuits inside the
enclosure. To maintain all the ports on the equipment at SELV/NEC Class 2, it is essential
that if any connection is made to any of these ports by other equipment, the other
equipment must maintain its relevant port at ES1/SELV/NEC Class 2.
General
1. Unless otherwise stated in the equipment manual, there are no user serviceable parts
inside this equipment.
2. Ultimate disposal of this equipment must be carried out according to relevant national
laws.
3. The equipment should be installed by suitably trained personnel, and installation should
follow good working practice.
4. The product Earth point serves as a discharge path for power surges or lightning events
on the supply or Ethernet cables, and must be bonded to Earth ground.
5. Note: All wiring that connects to the equipment must meet applicable local and national
building codes and network wiring standards for communication cable.
1-Port 5Gb PoE Extender Manual
2
1-Port 5Gb PoE Extender Manual
3
CE NOTICE
This is a Class A product intended for use in industrial environments only. It is not intended for
residential use.
FCC NOTICE
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
Modifications not expressly approved by the manufacturer could void the user's authority to
operate the equipment under FCC rules.
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numerique de la class A est conforme a la norme ICES-003 du Canada
Return Product Procedure
If the unit is found to be defective, please contact Technical Support via
http://www.commscope.com/SupportCenter
WEEE
Recycling information can be obtained from the Product Compliance Support Center at
www.commscope.com.
1-Port 5Gb PoE Extender Manual
4
1-Port 5Gb PoE Extender Manual
5
2. Introduction
The 60W 5Gb 1-port PoE Extender is a component of CommScope's® powered fiber cable
system, a hybrid optical fiber/copper cable system for remote powering of network access
devices. It is designed to simply and easily function with the powered fiber cable system to extend
the distance of PoE (Power over Ethernet) enabled devices. The extender encompasses four primary
elements:
1. Environmentally sealed enclosure
2. Electrical power management
3. Circuit protection electronics
4. Optical to electrical Media Conversion
When coupled with any standard NEC Class 2 48V DC power supply, CommScope's Powered
Fiber Cable system can power and communicate with PoE standard devices at far greater
distances than "category style" copper cabling systems (typically limited to 90 meters) while still
meeting NEC Class 2 and SELV standards, eliminating the need for qualified electricians during
installation.
The extender contains circuit protection and DC/DC conversion electronics which automatically
condition electrical voltage to the correct level needed for PoE powered end devices such as small
cells, high definition security cameras, Wi-Fi hot spots, etc...
1-Port 5Gb PoE Extender Manual
6
Extender Surge Protection
Long length DC low voltage electrical systems are at increased risk of:
•Noise from high voltage cables
•Higher current in the event of a short circuit
•Strong electrical surges due to lightning strikes or other EM events in close vicinity
The PoE Extender provides multiple levels of electrical protection:
•Primary Protection:
•2.5kA Metal oxide varistors - operate for slower surges as well as fast surges
•Protects both differential and common mode
•Secondary Protection:
•MOV and Inductors - reduce surge voltage down to ~100-150
•Tertiary Protection:
•Transient voltage suppressors - work at relatively low/slow surges, adds an extra
layer of protection against voltage spikes
•Protects differential mode only
•Clamps voltage spikes to 80-100V
Additional protection elements include:
•Cross-polarity protection to simplify installation - the circuit will work regardless of the
input polarity
•AC cross protection:
•4A non replaceable fuses
•No exposed high voltage pads
•High power inductors used as coordinating elements to maximize energy efficiency
•Sealed enclosure for environmental protection
