Code Alarm PC 4300 Manuel utilisateur

Owner's Manual

Remote Vehicle Control System

IMPORTANT NOTE:The operation of the PowerCode as described in this

manual is applicable to most vehicles. However, due to the engine type

and configuration of some vehicles (i.e. diesel engines), some functions

AND/OR SAFETY PRECAUTIONS may not apply.Please see your

installing dealer for more information.

PC 4300

Security and

Convenience System

101510-6

Table of Contents

Features and Benefits of the PowerCode PC 4300TM ..................... 3

Using Your Remote Transmitter .............................................. 4

Arming the Security System

Pre-arm Mode

Disarming the Security System

Attempted Intrusion Identification

Disabling the IT-sTM InteriorTheft Sensor ............................... 5

Two-Stage Door Unlock

Activating the Trunk Release Feature

Turning on the Vehicle Headlights

AUX 3

Using the Car Finder Feature

Personal Protection Alarm (Panic)

Using Valet Mode

WhenYour Security System isTriggered ............................... 7

Automatic Convenience Options ............................................ 7

The Interior Status Indicator .................................................... 7

System Maintenance ................................................................ 8

Changing the Remote Control Battery

Adding Remote Controls to Your System

Deleting Lost or Stolen Remote Controls from Your System

BasicTroubleshooting .............................................................. 9

Emergency Disarm Procedure .......................................... 10

Emergency Disarm Button Location

Installer Programmed Options

Your Code-Alarm, Inc. Limited LifetimeWarranty ............... 11

Code AlarmTheft Protection Plan ............................................12

Features and Benefits of the Power Code PC 4300

Two Easy-to-Use Weather-Resistant Remote Controls

The remote controls included with the PowerCode PC 4300TM utilize

durable, moisture resistant cases and sealed rubber buttons for

reliability and long life. Rolling code technology prevents the

transmitter signals from being duplicated. The button functions are

clearly labeled to make the Power Code PC 4300TM simple to operate.

All Entrances Protected

Opening any door or entrance protected by the security system

triggers the alarm’s 125db siren (or vehicle horn) and flashes the

vehicle parking lights.

Starter Disable

The PowerCode PC 4300TM protects your vehicle from theft by

disabling the starter when the system is armed.

IT-s

InteriorTheft Sensor

This patented sensor uses infra-red technology to reliably detect

vehicle impact associated with attempted intrusion.The IT-sTM

sensor guards against vehicle body damage, and theft of vehicle’s

equipment (such as airbags) and personal belongings.

Remote Keyless Entry

The PowerCode PC 4300TM conveniently locks and unlocks vehicle

doors and opens the trunk or hatch by remote control.*

Personal Protection Features

Remote Panic Alarm, Headlight Control, Illuminated Entry,

and Car Finder are among an array of features that enhance

personal safety.**

Interior Status Indicator

The bright-red warning light is an effective visual deterrent to a

would-be thief.

PowerRange

Antenna

This long-range antenna allows you to operate the PowerCode PC

4300TM from distances of up to 1/8 mile. Remote-start your vehicle

from the safety of your home, apartment or office building.

E-Code Coded Override System

If this feature is enabled, it will allow you to enter a personal 4-digit

code that only you will know. This will be used for overriding the

system in the case of an emergency or a lost transmitter.

* If vehicle is equipped with power door locks and they are connected to the alarm system by your installer.

** May requireadditionalconnections, components,and/orcharges. Seeyourinstaller fordetails.

** ’Siren’ also refers to the vehicle horn if it is used as the alarm sounding device.*

†If you have chosen the Silent Arming Option, the siren will not sound when arming or disarming until the

appropriatebuttonis pressedasecond time.

Press for Car Finder

Press and Hold for

Panic Alarm

Arming the Security System

To arm the system, exit the vehicle, close all doors, then press* the

ARM button. The siren** will “chirp” twice†and the parking lights will

flash twice, indicating the system is armed. The doors will also lock at

this time (if equipped and connected). The status indicator (red

warning light on the dash) will blink steadily, once per second.

Pre-arm Mode

If the siren chirps and the parking lights flash only once, this indicates

that the vehicle courtesy light is on, or that an entrance is not closed

securely. Check to see that doors, hood, and trunk are properly

closed. Once all entrances are secured (and the courtesy light is off),

the system will chirp / flash again.The system is now fully armed.

(If the entrance is not secured within 4 minutes, the system will arm

and ignore the unsecured entrance until it is closed.)

Disarming the Security System

To disarm the system, press the DISARM button.The siren will chirp

and the parking lights will flash once, and the doors will unlock. The

courtesy light will turn onand the LED will flash GRN for 1 minute, or

until the vehicle is started.

Attempted Intrusion Identification

If the siren chirps four times when disarming, this indicates that the

system was triggered in your absence. The status indicator will also

flash rapidly. Perform the following operation to determine the protected

zone that triggered the system:

After disarming, press the

emergency override button.

The siren will chirp to indicate

the cause of the alarm trigger:

1 chirp IT-s Interior Theft Sensor

2 chirps Door

3 chirps Hood

4 chirps Trunk/Optional Sensors

5 chirps Ignition was turned on

Using Your Remote Transmitter

Press for two-car

operation (SHIFT)

Press* to ARM the

Security System and

Lock the Doors

Press to DISARM Security

System and Unlock Doors

Press TWICE for Two-Stage

Door Unlock*

Press to activate

auxiliary function

Press and Hold* to turn

on headlights

Press and Hold* to

Open Trunk

UsingYour Remote Transmitter

(cont.)

Disabling the IT-s

InteriorTheft Sensor

It may be necessary at times to disable the IT-sTM Interior Theft Sensor,

especially when parking in areas (like parking garages) where

extreme vibration may cause false alarms. Press the ARM button and

then press the FIND/PANIC button within two seconds of pressing

ARM to disable the interior theft sensor.The siren will chirp three times

to indicate that the sensor is disabled.The sensor will become

enabled again the next time the system is armed normally.

Two-Stage Door Unlock

If this feature is enabled on your system, pressing DISARM one time

will unlock only the driver’s door. Press DISARM again within 1 minute

to unlock all doors.

Activating theTrunk Release Feature

Press and hold TRUNK to open the vehicle trunk or hatch (if equipped

and connected). If this button is used to operate another accessory,

the accessory will stay active for as long as the button is held.

Turning on theVehicle Headlights

Press and hold the LIGHTS button to turn on the vehicle headlights.

(The alarm system will attempt to arm if not already armed, unless it is

in Valet mode.) The lights will stay on for 20 seconds, or until LIGHTS

is pressed again.

Using AUX 3

If this feature is enabled on your system, pressing AUX for 1 second

will activate the auxiliary function (if enabled).

Using the Progressive Car Finder Feature

Press FIND on the remote control to locate your vehicle.The siren will

emit five short chirps at low volume, increasing in volume each time

the button is pressed.

Personal Protection Alarm (Panic)

Press and hold the PANIC button to activate the vehicle siren and

parking lights for 30 seconds. (If the vehicle horn is connected, the

horn will “pulse” for 30 seconds.) Press any remote control button to

turn off the Panic alarm.

Using Second Car Mode

If this feature is enabled, one transmitter will control two vehicles

equipped with a PowerCode PC 4300TM system. To operate the

second vehicle, press the shift button, then within two seconds, press

the desired function button.

UsingValet Mode

If the Passive Arming feature is enabled on your system, Valet mode

temporarily prevents the alarm system from arming automatically.

This is useful when fueling or servicing your vehicle.

To enterValet Mode:

With the vehicle ignition on, press the ARM button. The red dashboard

warning light (status indicator) will turn on for one second, then turn off.

This indicates that the system is in Valet mode. Once the ignition is

turned off, the status indicator will emit a quick double-flash pattern.

Note: In Valet mode, all keyless entry, convenience and remote start

features operate normally.

To exitValet Mode:

With the vehicle ignition on, press the DISARM button.The red

dashboard warning light (status indicator) will turn on for one second,

then turn off.This indicates that the system has exited Valet mode.

Hint: To prevent your security system from automatically arming while

unloading or refueling your vehicle, without placing the system in

Valet mode, simply press the disarm button on your remote control

transmitter after turning the ignition key off. Doing so places your

system into a temporary or onetime Valet mode. Next time you exit

your vehicle the system will arm in the normal manner.

UsingYour Remote Transmitter (cont.)

Automatic Convenience Options

The PowerCode PC 4300TM performs a variety of automatic functions to

enhance security and comfort. Some of these features are programmable

at the time of installation. Please see your installer for further details.

Illuminated Entry

When the alarm system is disarmed, the vehicle courtesy lights will turn

on for 1 minute, or until the vehicle is started or the system is re-armed.

Illuminated Exit

When removing the key from the ignition, the vehicle courtesy lights

will turn on for 1 minute, or until the PowerCodeTM is armed.

Automatic Arming

The PowerCode PC 4300TM will arm automatically 1 minute after the

key is removed from the ignition. This feature can be temporarily

disabled by placing the system into Valet mode.

Ignition Lock

If all doors are closed and the vehicle is started with the key, the doors

will automatically lock.

Ignition Unlock

When removing the key from the ignition, the doors will automatically unlock.

WhenYour Security System is Triggered

The Power Code PC 4300TM will trigger if one of the following events

occurs while the system is armed:

• Any protected entrance is opened

• The vehicle ignition is turned on

• The vehicle is jolted hard enough to signal the impact detector

Once the alarm is triggered, the siren (or horn) sounds and the vehicle

parking lights flash for 30 seconds.The system will then re-arm, awaiting

the next intrusion attempt.To stop the siren while keeping the alarm armed

and doors locked, press the ARM button while the system is triggered.

The Interior Status Indicator

The Status Indicator is a high-intensity red light mounted in a visible

location on the vehicle dashboard. This red light gives a visual

indication of the alarm system’s state of operation. Note the chart

below:

If the Status Indicator is... ....then the Security System

Flashing Green is disarmed

Flashing Slowly is armed

Flashing Very Quickly was triggered in your absence

(see Attempted Intrusion ID - page 4)

Flashing Intermittently is in Valet mode (LED is Green)

(2 flashes, off, 2 flashes)

On (not flashing) is in Pre-arm mode

System Maintenance

Changing the Remote Control Battery

The two 3-v lithium batteries (CR2016) supplied in your remote

control should last approximately one year, depending on usage.

When the battery begins to weaken, you will notice a decrease in

range, or the distance from your vehicle that your remote transmitter

will operate. Follow the instructions below to change the remote

transmitter battery.

1. Insert the edge of a coin into the slot at the top of the remote

control.Twist the coin to pry the remote control halves apart.

2. Remove the old batteries and replace with new ones.

Be sure to observe the (+) and (-) signs in the battery

compartment.

3. Carefully snap the case halves back together, then test the

remote control.

Adding Remote Controls toYour System

The PowerCode has the ability to operate from up to six (6) remote

controls. Follow these instructions to add a remote control to your system.

1. Make sure the security system is disarmed and the ignition is off.

2. Open the driver’s door.

3. Turn vehicle ignition on.

4. Press and hold emergency override button.

After 15 seconds, the siren or horn will sound three (3) times.

This indicates that the unit has entered the remote control

programming mode.

5. Release the button.

6. Press the ARM button (button 1) on the remote control to be

programmed.

The siren or horn will sound once, indicating that the system

has “learned” that remote control.

7. Repeat step 6 for any additional remote controls.

8. Turn the vehicle ignition off to exit the programming mode.

Test all remote controls to ensure that they work properly.

Basic Troubleshooting

This section outlines some of the basic issues you may experience

while becoming used to the Power Code PC 4300TM. If you have a

problem that is not covered by this section, please consult your installer.

motpmySmotpmySmotpmySmotpmySmotpmyS melborPmelborPmelborPmelborPmelborP noituloSnoituloSnoituloSnoituloSnoituloS

seodlortnocetomeRkrowton

yrettabdaedrokaeW

tonlortnocetomeR demmargorp

yrettabegnahC

etomermargorP )8egap(lortnoc

mratonlliwmetsyS

rehtororooD neposiecnartne

nosithgilysetruoC

telaVnisimetsyS

edom

ecnartneesolC

ffothgilysetruocnruT

edomtelaVffonruT)6egap(

Deleting Lost or Stolen Remote Controls fromYour System

If one of your remote controls is lost or stolen, follow these instructions

IMMEDIATELY to remove the control code from your system.

1. All remaining remote controls must be available.

2. Enter the control programming mode by following steps 1 - 5

Adding Remote Controls toYour System

(page 8).

3a. If you have only one remaining remote control, press the

ARM button on that remote control six (6) times, pausing at

least 1 second in between each press. Make sure that the

siren chirps each time you press the ARM button.

3b. If you have two remaining remote controls, press the ARM

button on each remote control three (3) times, pausing at

least 1 second in between each press. Make sure that the

siren chirps each time you press the ARM button.

3c. If you have three remaining remote controls, press the

ARM button on the three remote controls twice. Pause at

least 1 seconds in between each press. Make sure that the

siren chirps each time you press the ARM button.

4. Turn the vehicle ignition off to exit the programming mode.

When you are finished, the lost or stolen remote control will

no longer operate your system.

System Maintenance

,cont’d

Emergency Disarm Procedure

If your remote control is lost or fails to function, use this procedure to

disarm the PowerCode PC 4300TM and start your vehicle.

1.Use the keys to enter the vehicle.

The alarm will sound once the door is opened.

2.Insert the key into the ignition and turn to the ON position.

3.Locate and press the emergency override button.

The alarm will turn off and then you will be able to

start your vehicle.

Your Emergency Disarm Button is located:

Installer Programmed Options

Ignition On Door Lock ON OFF

Ignition Off Door Unlock ON OFF

Illuminated Entry/Exit ON OFF

Siren/Horn Chirps ON OFF

Passive Arming ON OFF

Pasive Door Locks ON OFF

Table des matières

Autres manuels Code Alarm Démarreur à distance

Code Alarm

Code Alarm ca6554 Manuel utilisateur

Code Alarm

Code Alarm CA611 Manuel utilisateur

Code Alarm

Code Alarm F40 Manuel utilisateur

Code Alarm

Code Alarm Professional Series CA 5050 Manuel utilisateur

Code Alarm

Code Alarm ca5354 Manuel utilisateur

Code Alarm

Code Alarm PROFESSIONAL CASECRS Manuel utilisateur

Code Alarm

Code Alarm ca5154 professional Series Manuel utilisateur

Code Alarm

Code Alarm ca5554 Professional series Manuel utilisateur

Code Alarm

Code Alarm CA 5051MT Manuel utilisateur

Code Alarm

Code Alarm ca6554 Manuel utilisateur

Code Alarm

Code Alarm ca5153 Manuel utilisateur

Code Alarm

Code Alarm CA 421 Manuel utilisateur

Code Alarm

Code Alarm ca 4552 Manuel utilisateur

Code Alarm

Code Alarm Professional ca5054 Manuel utilisateur

Code Alarm

Code Alarm CA2LCD5 Manuel utilisateur

Code Alarm

Code Alarm CA1BTW5 Manuel utilisateur

Code Alarm

Code Alarm Professional Series CA 4050 Manuel utilisateur

Code Alarm

Code Alarm SRT 9000 Manuel utilisateur

Code Alarm

Code Alarm CA 4055 Manuel utilisateur

Code Alarm

Code Alarm PC 7400 Manuel utilisateur

Code Alarm

Code Alarm CA 5051 Manuel utilisateur

Code Alarm

Code Alarm CA 440SS Manuel utilisateur

Code Alarm

Code Alarm ca 5152 Manuel utilisateur

Code Alarm

Code Alarm CA 410A Manuel utilisateur

Manuels Démarreur à distance populaires d'autres marques

AstroStart

AstroStart 803U Manuel utilisateur

Durite

Durite 0-649-20 Manuel

EINHELL

EINHELL BT-PS 1000 Manuel

Linear

Linear ACCESS AK-21 Caractéristiques techniques

Soundstream

Soundstream TARANTULA RS.2 Manuel utilisateur

Jaycar Electronics

Jaycar Electronics MB3752 Manuel utilisateur

Ultra Start

Ultra Start 72 Series Manuel utilisateur

ADS

ADS FLASHLOGIC FLRSVW1 Manuel utilisateur

Selecta

Selecta JS012 Manuel utilisateur

Black Widow Security

Black Widow Security BW RAS 400 Manuel utilisateur

Vector

Vector Power City DK080706 Supplément

Ozito

Ozito OJS-800 Manuel utilisateur

Profi-Partner

Profi-Partner 46387 Manuel utilisateur

EZ STARTER

EZ STARTER EZ-45 Manuel utilisateur

Viper

Viper 4204 Manuel utilisateur

Essex Electronics

Essex Electronics KE-1701 Manuel utilisateur

EINHELL

EINHELL EGS 3600 Manuel

Rooboost

Rooboost RB-1750WP Manuel utilisateur
