Coban GPS103-A Manuel utilisateur
1
GSM/GPRS/GPS Vehicle Tracker
GPS103-A/GPS103-B User Manual
Preface
Thank you for purchasing the tracker. This manual shows how to operate the
device smoothly and correctly. Make sure to read this manual carefully before
using this product. Please note that specification and information are subject to
changes without prior notice in this manual.
Any change will be integrated in the latest release. The manufacturer assumes
no responsibility for any errors or omissions in this document.
2
Contents
1. Function Introduction........................................................................................4
2. Applications ......................................................................................................4
3. Hardware Description .......................................................................................4
4. Accessories Name.............................................................................................6
5．Specifications..................................................................................................7
6. Operating Instructions.......................................................................................8
6.1 Terminal Installation.......................................................................................8
6.4 GSM/GPS LED Indicator .............................................................................10
6.5 Initialization ..................................................................................................10
6.6 Change Password ..........................................................................................10
6.7 Authorization.................................................................................................11
6.8 Single Locating .............................................................................................12
6.9 Successive Locating Automatically..............................................................12
6.10 Get location in real street/address name .....................................................13
6.11 Monitor........................................................................................................13
6.12 Modes switch between “track” & “monitor”..............................................13
6.13. Alarms........................................................................................................14
6.13.1 Low battery alarm....................................................................................14
6.13.2 Power off alarm........................................................................................14
6.13.3 SOS...........................................................................................................14
6.13.5 Movement alarm ......................................................................................15
6.13.6 Overspeed alarm.......................................................................................15
6.14 Cut off the Oil and Power System ..............................................................16
6.15 Resume the Oil and Power System.............................................................16
6.16 Arm..............................................................................................................16
6.17 Disarm.........................................................................................................17
6.18 Function of Remote Control (Option, for model B ONLY).......................18
6.19. Alarms under Arm State ............................................................................18
6.19.1 door alarm ................................................................................................18
6.19.2 Sensor alarm.............................................................................................18
6.19.3 ACC alarm ............................................................................................19
6.20. Silent Mode................................................................................................19
6.21. No GSM Network Alarm...........................................................................20
6.22 Check the Vehicle State..............................................................................20
6.23 Tracker’s Hardware Resetting ....................................................................21
6.24 IMEI Checking............................................................................................21
6.25 Time Setting................................................................................................21
6.26 GPRS Setting ..............................................................................................21
6.27 Setting up APN ...........................................................................................22
6.28 GPRS User Name and password Setup ......................................................22
6.29 IP and Port Setup.........................................................................................23
3
6.30. Modes Switch between “SMS” and “GPRS” ............................................23
6.31 User manual of web based and PC installation monitor software..............23
7．Cautions.......................................................................................................23
8．Faults & the Solutions.................................................................................24
4
1. Function Introduction
1.1 This tracker is a new product based on the GSM / GPRS network and GPS
satellite positioning system, which set multiple functions of security, positioning,
monitoring surveillance, emergency alarms and tracking in its entirety. It can
track and monitor remote target by SMS or internet.
1.2 Features
1.2.1 Support both GPS / GSM station positioning ways.
1.2.2 Support SMS/GPRS/Internet Network data transmission
(GPRS/Internet instructions in CD enclosed）
1.2.3 Support GPRS on-line and GPRS re-connected automatically if
GPRS drops
1.2.4 Support SMS / GPRS dual-mode switching
1.2.5 Support configuration by remote terminal.
1.2.6 Support for point-to-point, point to group, group-to-group
monitoring.
1.2.7 Set multiple functions of security, positioning, monitoring surveillance,
emergency alarms and tracking in its entirety.
2. Applications
Used widely for vehicle and other moving objects tracking.
3. Hardware Description
5
①. GSM Antenna jack ⑥. Sensor jack
②.SIMcardslot ⑦. External Connection jack
③. SIM card slot Pop-up switch ⑧. Power/GSM/GPS LED indicator
④.Monitorjack ⑨. Backup battery switch
⑤. GPS Antenna jack ⑩. Remote control receiver antenna
（Option, For model B only）
6
4. Accessories Name
NO. PHOTOES
NAME NOTE
1
GPS Antenna 3 meters
2
GSM Antenna 3 meters
3
Microphone 1.5 meters
4
Harness 10PIN
5
Relay
12V/40A to 24V/40A
according to vehicle
model
6
Shake sensor Option for both model A
and B
7
Siren Option for model B
ONLY
8
Remote control Option for model B
ONLY
7
5．Specifications
Content specifications
DIM. 83*54*26mm
Weight 120g
Network GSM/GPRS
Band 850/900/1800/1900Mhz or 900/1800/1900Mhz
GSM/GPRS
Module Simcom900B
GPS Module SIRF3 chip
GPS Sensitivity -159dBm
GPS Accuracy 5m
GPS Start time
Cold status 45s
Warm status 35s
Hot status 1s
Voltage of car
power system
12 V -24V
Backup battery Chargeable changeable 3.7V 800mAh Li-ion battery
Storage Temp. -40°C to +85°C
Operation Temp. -20°C to +65°C
Humidity 5%--95% non-condensing
8
6. Operating Instructions
6.1 TERMINAL INSTALLATION
6.1.1 Please ask the qualified engineers to install it.
6.1.2 Do not install it in a environment which is more than GSM performance,
And please pay attention to fix the antennas in a exactly position with good
signals.
6.1.3 Pay attention to make installation location preventing water and dust.
6.1.4 Find the 10 PIN harness and insert it into the corresponding holes of the
products, and connect the wires with the original car circuit showing below:
Wiring diagram
6.1.5 Note: The orange wire can be connected to the original car alarm horn; it
can also be connected to the siren you buy with the tracker. (Siren is
Option)
9
6.1.6 Knowing about the type of the door trigger is positive or negative trigger.
Please connect the green wire to the door control circuit if it is positive, and
connect blue wire if it is negative.
6.1.7 Please install the Reset button and SOS button on the place driver can
touch.
6.1.8 Insert the shake sensor plug into the sensor jack. (Shake sensor is Option)
6.1.9 Insert the external monitor Microphone into the monitor jack.
6.1.10 Connected the GPS and GSM antenna to the right jack, and find a
appropriate place and fix the antennas to make sure it receive signals very
well.
6.2 SIM CARD INSTALLATIONS
6.2.1 Use a tweezers or a sharp thing to touch the SIM CARD popup switch, the
SIM CARD slot will pop up, take out the SIM card slot and put SIM card
in it. And then put the SIM card slot back to its original position after
confirm the SIM card in the right place.
6.2.2 Please make sure that the SIM card is able to execute the function of
incoming calls display, no calls can be diverted and the PIN code is
locked. The SMS format must be TXT format, and can’t recognize the
PDU format.
6.3 Turn on the Tracker Device.
6.3.1 Connect the positive and negative wire, red and black ones, with 12V or
24V car power system, wait for 1 minute after connecting power to wait
tracker works normal, and then turn on the backup battery switch.
10
6.4 GSM/GPS LED Indicator
6.4.1 Red LED indicator on: No GSM network signals.
6.4.2 Red LED indicator flash fast (one time each second): GSM Network
signal is normally, and tracker works under GSM mode.
6.4.3 Red LED indicator flashes slowly (one time each three second): Tracker
works under GPRS mode.
6.4.4 Green LED indicator on: GPS signal is normal.
6.4.5 Green LED indicator off: No GPS signals.
6.5 Initialization
Send SMS “begin+password” to the unit, it will reply “begin OK” and initialize
all the settings to default factory settings.（default password: 123456）
For example: send SMS “begin123456”, it will reply “begin ok”. (No
quotation marks” ” when sending all the SMS)
6.6 Change Password
6.6.1 Send SMS “ password+old password+space+new password” to the unit to
change the password.
For example: send SMS “password123456 888888” to the unit. If succeeded,
“password OK” will reply to your cell phone from the device tracker.
6.6.2 Be sure to keep the new password in mind, you have to upload the
